SEGOMOE: Super Efficient Global Optimization with Mixture of Experts
Rémy Priem – Nathalie Bartoli (ONERA) – Youssef Diouane (ISAE-Supaero) – Thierry Lefebvre (ONERA) – Sylvain Dubreuil (ONERA) – Michel Salaün (ISAE-Supaero) – Joseph Morlier (ISAE-Supaero)
Contact : Rémy Priem – remy.priem@isae-supaero.fr / remy.priem@onera.fr
Bibliography
[1] D. R. Jones, et al., ‘Efficient global optimization of expensive black- box functions’, Journal of Global optimization, vol. 13, no. 4, pp. 455–
492, 1998.
[2] M. A. Bouhlel, et al., ‘Efficient global optimization for high- dimensional constrained problems by using the Kriging models combined with the partial least squares method’, Engineering Optimization, pp. 1–16, 2018.
[3] N. Bartoli et al., ‘An adaptive optimization strategy based on mixture of experts for wing aerodynamic design optimization’, in 18th AIAA/ISSMO Multidisciplinary Analysis and Optimization Conference, 2017, p. 4433.
Context
New Aircraftconcepts No semi-empiric
models
Multidisciplinary Optimization
Expensive to evaluate black
box models
Surrogate Models
Surrogate model
Constraint criteria Success SEGO-M [6] 3/10 SEGO-U (𝜏 = 3) 10/10 SEGO-U (𝜏 log behavior) 10/10
Constraint Handling max 𝐼𝐶 𝑥
𝑥∈ℝ𝑑
𝑠. 𝑡.
𝑐 𝑥 ≥ 0
Add the uncertainty information on the constraints surrogate
models
𝑼 𝑥 = 𝑐 𝑥 + 𝜏𝜎 (𝑥),
𝐸𝐹 𝑥 = 𝑐 𝑥 Φ 𝜎 𝑥𝑐 𝑥 + 𝜎 𝑥 ϕ 𝜎𝑐 𝑥 𝑥 − 𝜏, 𝐴𝐸𝐹 𝑥 = 𝛽𝑐 𝑥 + 1 − 𝛽 𝐸𝐹 𝑥 − 𝜏,
New constraints handling criteria 𝐶𝐻𝐶
New optimization sub-problem
Find most probable areas and search in
uncertain areas
𝛽 ∈ 0,1 ϕ = pdf of 𝑁(0,1)
Φ = cdf of 𝑁(0,1)
𝑴 𝑥 = 𝑐 𝑥
max 𝐼𝐶 𝑥
𝑥∈ℝ𝑑
𝑠. 𝑡.
𝐶𝐻𝐶 𝑥 ≥ 0
𝜏 ∈ 0,3
Super Efficient Global Optimization with Mixture of Experts
Compute the Observation
Train the GP based models
max 𝐼𝐶 𝑥
𝑥∈ℝ𝑑
𝑠. 𝑡.
𝑐 𝑥 ≥ 0 Evaluate the
points Optimization
problem
𝑥∈ℝmin𝑑𝑓 𝑥 𝑠. 𝑡.
𝑐 𝑥 ≥ 0
IDEA: Use the surrogate models to perform the optimization
→ Identify the best points for the
optimization and learning of the model via an iterative enrichment process GP based models
prediction and error
SEGOMOE [3]
One enrichment step
Infill criteria 𝐼𝐶 that allows to choose the new point to
evaluate (EI, etc.) [1]
Take the constraints into account
Mixture of Experts
• Gaussian mixture model clustering
• Each point 𝑥 of the domain belong to each cluster 𝑘 with a probability 𝛼𝑘 𝑥
• One Gaussian Process (GP) model 𝑦 𝑘 𝑥 , 𝑠 𝑘 𝑥 trained by cluster
• KPLS & KPLS+K: GP mixed with PLS for large scale model [2]
• 𝑦 𝑥 = 𝛼𝑘 𝑘 𝑥 𝑦 𝑘 𝑥 Prediction of y
• 𝑠 2 𝑥 = 𝑘𝛼𝑘2 𝑥 𝑠 𝑘2 𝑥 Error estimation
Observations Clusters probabilities Cluster borders
Recombination
Training Clustering
Find and train expert models on changing behavior areas [3]
Optimizer Success SNOPT 5/15 (33%)
SEGO-M 18/18 (100%)
Results
Modified Branin function (2 DV, 1 C)
𝑓∗ = 12,005 Results on engineering test cases ADODG6 (17DV, 1C [3])
Aerodynamic wing shape constrained optimization
1 Global & 5 Local minima
local
Global
