beating dynamics in uniaxial single-spin magnets

Takuya Hatomura, Bernard Barbara, Seiji Miyashita

To cite this version:

Takuya Hatomura, Bernard Barbara, Seiji Miyashita. Distribution of eigenstate populations and

dissipative beating dynamics in uniaxial single-spin magnets. Physical Review B, American Physical

Society, 2017, 96 (13), pp.134309. �10.1103/PhysRevB.96.134309�. �hal-01655467�

arXiv:1704.06466v1 [cond-mat.mes-hall] 21 Apr 2017

Distribution of eigenstate populations and dissipative beating dynamics in uniaxial single-spin magnets

Takuya Hatomura, ^{1, ∗} Bernard Barbara, ² and Seiji Miyashita ^{1, 3}

1

Department of Physics, Graduate School of Science, The University of Tokyo, 7-3-1 Hongo, Bunkyo, Tokyo, Japan

2

Institut N´ eel, CNRS and Universit´ e Grenoble-Alpes, B.P. 166 38042, Cedex 166, Grenoble, France

3

CREST, JST, 4-1-8 Honcho Kawaguchi, Saitama, Japan (Dated: April 24, 2017)

Numerical simulations of magnetization reversal of a quantum uniaxial magnet under a swept magnetic field [Hatomura, et al., Quantum Stoner-Wohlfarth Model, Phys. Rev. Lett. 116, 037203 (2016)] are extended. In particular, how the “wave packet” describing the time-evolution of the system is scattered in the successive avoided level crossings is investigated from the viewpoint of the distribution of the eigenstate populations. It is found that the peak of the distribution as a function of the magnetic field does not depend on spin-size S, which indicates that the delay of magnetization reversal due to the finite sweeping rate is the same in both the quantum and classical cases. The peculiar synchronized oscillations of all the spin components result in the beating of the spin-length. Here, dissipative effects on this beating are studied by making use of the generalized Lindblad-type master equation. The corresponding experimental situations are also discussed in order to find conditions for experimental observations.

PACS numbers: 75.40.Mg, 75.50.Xx, 75.75.Jn, 75.78.-n

I. INTRODUCTION

Quantum spin systems are usually realized in experi- ments by diluted ensembles of single-domain ferromag- netic nano-particles ^1,2 , single-molecule magnets ^3,4 , or single-spins magnets ^5,6 . These systems are generally with relatively large spins S (collective spins of nano-particles and single-molecule magnets, or large rare-earth angu- lar momentum of single-spins magnets). Except for the nano-particles case, this ensures the total absence of size- and therefore spin-distribution, and as well, slow enough quantum dynamics to be measurable. Due to small inter- actions, they can be regarded as almost isolated, even at low temperatures. This is particularly true with single- spin magnets which can be diluted at will. Various quan- tum effects have been reported in both single-molecule and single-spin magnets. One of the significant quan- tum effects is the stepwise magnetization process in hys- teresis of blocked magnetization at low temperatures, in which quantum tunneling between the states with magnetizations in opposite directions plays an important role ^7,8 . This phenomenon is understood as a quantum hybridization of discrete opposite magnetization energy levels forming an avoided level crossing. The scattering rate at the avoided crossing point is characterized by the Landau-Zener formula ^9–12 , which has been theoretically applied to quantum nano-magnets ^13–15 and confirmed in experiments ^16,17 . Quantum effects at each avoided cross- ing point have been intensively studied both theoretically and experimentally during the last decades ¹⁸ .

Uniform magnetization reversal in a single ferromag- netic domain associated with the classical metastable state collapse was studied by Stoner and Wohlfarth ¹⁹ . Because of the uniaxial anisotropy, the magnetization op- posite to the direction of the magnetic field is metastable

until the magnetic field reaches a certain value. At the end of metastability, which is called the Stoner-Wohlfarth point, magnetization exhibits a jump to the stable di- rection. This point draws an astroid known as the Stoner-Wohlfarth astroid in the longitudinal and trans- verse fields’ plane.

In the previous study ²⁰ , we considered this metastable- to-stable transition in the quantum case, where quan- tum tunneling at each anti-level crossing plays an im- portant role. Besides the well-known stepwise hysteresis mentioned above, we discovered the spinodal-like criti- cal behavior of the energy gaps in the successive avoided crossing points. This result was obtained by a study of the magnetization reversal resulting from the succes- sive Landau-Zener scatterings at avoided crossing points.

These scatterings take place along the continuation of the ground state energy level for H z > 0 to the H z < 0 until the Stoner-Wohlfarth point, which we called the metastable branch. The spinodal criticality appears along this metastable branch, or more precisely around the Stoner-Wohlfarth point, at which the metastable state in the corresponding classical model collapses into the stable state. Furthermore, a characteristic recursive beating of the magnetization takes place during its pre- cession beyond the Stoner-Wohlfarth point. This beat- ing results from the synchronized oscillations of all the components of magnetization and leads to the recursive oscillation of the spin-length, s f ≡ hs x i ² + hs y i ² + hs z i ² , which we called the spin-fidelity.

In the present paper, we study the nature of the tran-

sition from the quantum mechanical behavior to the clas-

sical one. In particular, we investigate how the distribu-

tion of the eigenstate populations for a given magnetic

field H z changes as a function of S and discuss the cor-

responding classical deterministic state. It is found that

the distributions of the scattered populations beyond the Stoner-Wohlfarth point follow a universal scaling law in- dependent of S. This indicates that the same distribution holds even in the classical case. As to the beating of mag- netization, we study the dissipative effects by making use of the generalized Lindblad-type equation ^21–24 . The re- sults enable us to provide the conditions to observe the beating phenomenon in experiments.

This paper is constructed as follows. In Sec. II, the model is explained. In particular, the notations of the quantum Stoner-Wohlfarth model and the conventional spin Hamiltonian are explained in detail. The distribu- tion of the eigenstate populations beyond the Stoner- Wohlfarth point and its classical limit are studied in Sec. III. Section IV is devoted to the dissipative dynam- ics of the quantum Stoner-Wohlfarth model. We give summary and discussions in Sec. V.

II. QUANTUM STONER-WOHLFARTH MODEL A. Uniaxial single-spin magnets

The spin Hamiltonian, which is used for the study of uniaxial quantum magnets, such as the molecular magnet Mn 12 , is generally written as

H ˜ = − DS ˜ _z ² − H ˜ x S x − H ˜ z S z , (1) which contains an anisotropy constant ˜ D and a mag- netic field ˜ H = ( ˜ H x , 0, H ˜ z ). Through this paper, we set gµ B = 1. Owing to the uniaxial anisotropy, the system exhibits magnetic hysteresis. For systems with finite S, i.e. with the discrete energy levels, magnetic hysteresis is also discrete and is associated with dynamical jumps.

The classical correspondence of the Hamiltonian (1) is nothing but the energy expression of the Stoner- Wohlfarth model ¹⁹

E = −Dm ² _z − H x m x − H z m z , (2) where m = (m x , m y , m z ) is a classical spin described by a unit vector, | m | = 1. In the past, this model was de- voted to the study of the magnetization reversal of single- domain ferromagnetic nano-particles under a tilted mag- netic field. The important relation between the quanti- ties ˜ D and D will be given in the next subsection.

If the magnetic field is applied along a direction in the hemisphere opposite to spontaneous magnetization, the latter classical model (2) can be in metastable equilib- rium. When the magnetic field becomes large so that the energy barrier vanishes, the system changes from metastable to unstable. Such a point associated with a metastable-to-stable transition is generally called the spinodal point. In the present model, it is called the Stoner-Wohlfarth point and given by

(2D) ^2/3 = (H x ) ^2/3 + (H z ) ^2/3 . (3)

(a)

(b)

−1

−0.5 0 0.5

1−1

−0.5 0

0.5 1

−1

−0.5 0 0.5 1

m_z

m_x

my m_z

(c)

−1

−0.5 0

0.5 1−1

−0.5 0

0.5 1

−1

−0.5 0 0.5 1

mz

mx

m_y mz

−1

−0.5 0

0.5 1−1

−0.5 0

0.5 1

−1

−0.5 0 0.5 1

m_z

m_x

my m_z

FIG. 1. Typical trajectories for the cases (a) with the degener- ated ground states, (2D)

> (H

)

+ (H

)

, H

= 0, (b) at the Stoner-Wohlfarth point, (2D)

= (H

)

+ (H

)

, H

= H

, and (c) without the metastable state, (2D)

<

(H

)

+ (H

)

, H

= −4. Here, D = 1 and H

= 1.

This equation represents the famous Stoner-Wolhfart as- troid which was actually observed in experiment ²⁵ .

In Fig. 1, we show the three main types of trajec- tories (a) with the metastable state, inside the Stoner- Wohlfarth astroid (2D) ^2/3 > (H x ) ^2/3 + (H z ) ^2/3 , (b) at the Stoner-Wohlfarth point, on the astroid (2D) ^2/3 = (H x ) ^2/3 + (H z ) ^2/3 , and (c) without the metastable state, outside the astroid (2D) ^2/3 < (H x ) ^2/3 + (H z ) ^2/3 .

B. Quantum Stoner-Wohlfarth model

When we study the quantum effects of the Stoner-

Wohlfarth model, it is convenient to adopt the quantum

Stoner-Wohlfarth model rather than the spin Hamilto-

nian (1). In the quantum Stoner-Wohlfarth model, we

replaced the classical spin in Eq. (2) by the normalized

3 quantum spin operator

s = S /S, (4) which satisfies the following commutation relation

[s i , s j ] = i

S ǫ ijk s k . (5) Here and hereafter, we take ¯ h = 1 and obtain the quan- tum Stoner-Wohlfath Hamiltonian

H(t) = −Ds ² _z − H x s x − H z (t)s z , (6) where the explicit time-dependence of the longitudinal field H z (t), which is taken in our analyses, is given by

H z (t) = H z (0) − ct, (7) where c is a given sweeping rate.

In order to make clear the relation between the spin Hamiltonian (1) and the quantum Stoner-Wohlfarth model (6), we rewrite Eq. (1) as

H ˜ = S(− DSs ˜ ² _z − H ˜ x s x − H ˜ z s z ). (8) Comparing with Eq. (6), we find the ralations D = ˜ DS, H = ˜ H , and H = ˜ H/S. The overall factor S causes the following time rescaling

τ = t

S , (9)

which gives

H z (t) = H z (0) − ct = H z (0) − vτ, v = cS, (10) where v is the sweeping rate in the spin Hamiltonian (1).

In the rest of the present paper, we shall consider the Hamiltonian (6), which is the same as in our previous paper ²⁰ . Note that the corresponding anisotropy con- stant is D = ˜ DS, where ˜ D is the usual one in the spin Hamiltonian (1).

C. Population dynamics

Let {|ψ k (t)i} be the instantaneous eigenstates of the Hamiltonian (6),

H(t)|ψ k (t)i = E k (H z (t))|ψ k (t)i. (11) Under the swept field (10), the time-evolution is given by the time-dependent Schr¨odinger equation

i ∂

∂t |ψ(t)i = H(t)|ψ(t)i, (12)

|ψ(t)i = X

k

c k (t)|ψ k (t)i, (13) where c k (t) is the time-dependent coefficient. Now, we introduce the population of the eigenstate

P k (t) = |c k (t)| ² . (14) (a)

(b)

− 5

− 4

− 3

− 2

− 1 0 1 2

− 4 − 3 − 2 − 1 0 1 2

H

0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 P

k

FIG. 2. (a) Energy spectrum of the quantum Stoner- Wohlfarth model for spin-size S = 10, the anisotropic con- stant D = 1, and the transverse field H

= 1. The horizontal axis is the longitudinal field H

. The purple curves represent the eigenenergies. Population dynamics under the swept field with the velocity v = 0.05 is represented by the green circles.

The black line denotes the Stoner-Wohlfarth point. (b) The distribution of the populations at H

(t) = −4. The horizon- tal axis represents the number of the state k and the vertical axis represents the populations P

.

A typical energy spectrum given by the ensemble {E k (H z (t))} k=1,··· ,2S+1 is depicted in Fig. 2 (a) for S = 10, where the (2S +1 = 21) eigenenergies are plotted as a function of H z (t). In this figure, the population dynam- ics is simulated for the initial condition H z (0) = 2 with the sweeping rate v = 0.05, starting from the ground state. The size of circles denotes the population of the eigenstates P k (t). The distribution of the eigenstate pop- ulations at H z (t) = −4 is depicted in Fig. 2 (b).

The scattering process is understood as follows. When

the longitudinal field H z (t) is swept from positive to

negative, the fully occupied initial state is scattered

at the successive anti-crossing points with the states

corresponding to the magnetization M z = −S, −S +

1, · · · , +S − 1 along the diadiabatic continuations of the

initial state (metastable branch). The population P k (t)

at a certain negative magnetic field H z (t) can be in-

0 0.2 0.4 0.6 0.8 1

−0.6 −0.5 −0.4 −0.3 −0.2 −0.1 0 S ∆ E

H

S = 20 S = 40 S = 80 S = 160 S = 320

−| H

|

FIG. 3. Critical behavior of gaps at avoided crossings on the metastable branch, which and its finite-size scaling are found by Hatomura et al. [Phys. Rev. Lett. 116, 037203 (2016)]. Gaps are plotted from spin-size S = 20 to S = 320.

The anisotropic constant is D = 1 and the transverse field is H

= 1. The vertical axis is the scaled gaps S∆E

and the horizontal axis is the corresponding longitudinal magnetic fields H

. The Stoner-Wohlfarth point H

is represented by the black line.

terpreted as the amount of the scattering at the kth avoided-crossing point. Here, the kth avoided-crossing point is the anti-crossing point of the states correspond- ing to M z = +S and the state corresponding to M z =

−S + k − 1. The energy gap of the kth avoided-crossing point is denoted by ∆E k , and the corresponding field is defined as H k , which gives the minimum energy gap at the anti-crossing level. The amount of the scattering is, of course, related to the size of the energy gap. In the classical limit S → ∞, the scaled gap S∆E k depicted in Fig. 3 is responsible to the scattering phenomenon. For

|H z | < |H SW |, the state remains in the metastable state, which indicates S∆E k vanishes while it has a finite value for |H z | > |H SW |. This situation is responsible for the critical behavior at the Stoner-Wohlfarth point, which is characterized by the scaling law of the renormalized gaps S∆E k versus the longitudinal field H k observed in the previous paper ²⁰

(S∆E k ) ² = S ^−1/3 g((H k − H SW )S ^2/3 ), (15)

where g(·) is the scaling function. This scaling function turned out to be identical to one of the spinodal critical scaling ²⁶ .

In the present paper, we study the distribution of the populations P k (t) at the field H z (t) = −4, P k ≡ P k (t)| H

(t)=−4 , after the scattering region, i.e. far be- yond the Stoner-Wohlfarth point (Fig. 2 (a)).

(a)

(b)

0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5

0 20 40 60 80 100 120 140

P

k

S = 10 S = 20 S = 40 S = 80 S = 160

0 0 . 05 0 . 1 0 . 15 0 . 2 0 . 25 0 . 3 0 . 35 0 . 4 0 . 45 0 . 5

0 0 . 2 0 . 4 0 . 6 0 . 8 1

P

k/S

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 4. (a) The distributions of populations for S = 10, 20, 40, 80, and 160. (b) The data are plotted as a func- tion of the scaled parameter k/S.

III. DISTRIBUTION OF POPULATIONS A. Distribution and its scaling behavior First, we study S dependence of the eigenstate popu- lations {P k }. The distributions are plotted versus k in Fig. 4 (a) for spin S = 10 to 160. They are given again in Fig. 4 (b) versus k/S. This leads to a concentration of the curves at a certain position. In Fig. 5, we show the accumulated population

Q k ≡

k

X

k

=1

P k

(16)

as a function of k/S. Here, we find that the accumulated

populations reach almost 1 around k/S ≈ 0.7, and thus

the scattering processes almost finish around there. In-

deed, the populations are almost zero for large k, which

do not contribute to the scattering processes. Therefore,

hereafter, we will not care about large k regions. In ad-

dition, we find that all the curves with different S cross

at almost the same point. We denote this crossing point

as k ^cl _peak /S.

5

0 0 . 2 0 . 4 0 . 6 0 . 8 1

0 0 . 2 0 . 4 0 . 6 0 . 8 1

Q

k/S

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 5. The accumulated populations for S = 10, 20, 40, 80, and 160. The horizontal axis is the scaled parameter k/S and the vertical axis is the accumulated populations Q

.

−0 . 5

−0 . 4

−0 . 3

−0 . 2

−0 . 1 0 0 . 1 0 . 2 0 . 3 0 . 4 0 . 5

0 0 . 2 0 . 4 0 . 6 0 . 8 1

H

− H

( k

− 1) S

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 6. Relations between H

and k. From the first avoided crossing to the Stoner-Wohlfarth point, H

< H

< 0, S de- pendence of the field corresponding to the kth gap is given by H

∝ kS

. The horizontal black line represents the Stoner- Wohlfarth point and the vertical black line is depicted to es- timate corresponding k.

When we consider the distributions, the field H k is more meaningful than the label k, and so we plot the difference of the fields H k −H SW as a function of (k−1)/S in Fig. 6. Here, we estimate the Stoner-Wohlfarth point in terms of k for later analysis, and it is given by k SW ≃ 1+0.45S. We find this is actually a good scaling until the Stoner-Wohlfarth point. However, this scaling is broken beyond the Stoner-Wohlfarth point. This point will be discussed in more details later.

Now, we study the population ˜ P H

, which is a func- tion of H k , measuring the scattering rate at the field H k

during the sweeping process. The relation between the populations P k and ˜ P H

is given by

P k ∆k = ˜ P H

∆H k → P ˜ H

= P k

∆H k

∆k −1

, (17)

0 5 10 15 20 25 30

− 0.8 − 0.7 − 0.6 − 0.5 − 0.4 − 0.3 − 0.2 − 0.1 0

˜ P

H

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 7. The distributions ˜ P

as a function of H

for S = 10, 20, 40, 80 and 160. The horizontal axis is the fields H

and the vertical axis is the populations ˜ P

.

0 0 . 2 0 . 4 0 . 6 0 . 8 1 1 . 2

−2 −1 . 5 −1 −0 . 5 0 0 . 5 1 1 . 5 2

˜ P

S

( H

− H

) S

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 8. The possible scaling plot for ˜ P

. The horizontal axis is scaled as (H

− H

)S

and the vertical axis is scaled as ˜ P

S

.

where ∆k = k − (k − 1) = 1 and ∆H k = H k − H k−1 . By using this relation, we obtain the distributions of the populations ˜ P H

as depicted in Fig. 7. In this expression, the areas of the distributions are conserved and equal to unity. Furthermore, the peak positions are almost S independent for large S and nearly given by

H peak ≃ 0.52, (18)

suggesting the existence of a scaling plot. In order to keep the conservation law for the areas of the distributions, the scaling plot must take the form, ( ˜ P H

S ^−α , (H k − H peak )S ^α ), where α is a real number. Taking α = 2/3, we obtain the scaled distributions as shown in Fig. 8.

This is actually the scaling law of the distributions of the populations for large S.

In the above calculations, we adopted finite differ-

ences for the transformation from k to H k . This causes

non-negligible errors, especially for small S. Indeed,

the results are quantitatively different when we adopt

−0 . 4

−0 . 3

−0 . 2

−0 . 1 0 0 . 1 0 . 2 0 . 3 0 . 4

−0 . 2 −0 . 15 −0 . 1 −0 . 05 0 0 . 05 0 . 1 0 . 15 0 . 2 H

− H

( k

− k

) S

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 9. Relation between H

and k above the Stoner- Wohlfarth point, H

< H

< 0. The horizontal axis is (k − k

)S

and the vertical axis is H

− H

.

0 0 . 2 0 . 4 0 . 6 0 . 8 1 1 . 2 1 . 4 1 . 6 1 . 8 2

− 2 − 1 . 5 − 1 − 0 . 5 0 0 . 5 1 1 . 5 2 P

× S

( H

k

− H

) × S

S = 10 S = 20 S = 40 S = 80 S = 160

FIG. 10. The possible scaling for distributions. The horizon- tal axis is plotted as (H

− H

)S

and the vertical axis is P

S

.

∆H k = H k+1 − H k instead of H k − H k−1 . Therefore, we consider the continuous limit S → ∞ in Eq. 17,

P ˜ H

= P k

∆H k

∆k −1

→ P(H ˜ k ) = P (k)

dH (k) dk

−1

, (19) where ˜ P (H k ) and P (k) are the continuous limit of ˜ P H

and P k , and H (k) is the continuous limit of H k . From Fig. 6, the derivative dH(k)/dk is proportional to S ⁻¹ for 0 < |H(k)| < |H SW |. Now, we consider the scal- ing for |H (k)| > |H SW |. The possible scaling is plotted in Fig. 9. From this scaling, the derivative dH (k)/dk is proportional to S ^−7/6 for |H (k)| > |H SW |. Therefore, the scaling property of the vertical axis is ˜ P(H k )S ^−2/3 ∝ P (k)S ^1/2 above the Stoner-Wohlfarth point, and thus we obtain the scaled distributions as shown in Fig. 10.

We remark that the heights of the distributions are dif- ferent from Fig. 8 because we neglect the coefficient of dH(k)/dk ∝ S ^−7/6 .

0 0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16

0 0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16

| H

− H

|

v

FIG. 11. Sweeping-rate dependence of the peaks of the dis- tributions. Spin-size is S = 160, the anisotropic constant is D = 1, and the transverse field is H

= 1. The horizontal axis represents the sweeping rate v and the vertical axis represents the difference of the peak field and the Stoner-Wohlfarth point

|H

−H

|. The purple curve is |H

−H

| = 0.52v

.

B. Velocity dependence of the peak fields In the above subsection, we studied the S dependence of the distribution for the particular sweeping rate v = 0.05. In this subsection, we investigate the sweeping rate dependence of the shift ∆H peak = |H peak − H SW | for the particular spin S = 160. The result of the calculations is given in Fig. 11. Here, we find that the shift ∆H peak is proportional to v ^2/3 for small velocities v < ∼ 0.08. This dependence can be understood from the scaled energy gaps depicted in Fig. 3 and the scaling property (15).

Indeed, from the scaling form (15) and Fig. 3, we find asymptotically

(S∆E k ) ² ∝ |H k − H SW | ^1/2 , (20) beyond the Stoner-Wohlfarth point |H k | > |H SW | for spin S → ∞. The amount of the scattered populations in a given small interval is approximately proportional to the adiabaticity parameter δ ≡ P

k (∆E k ) ² /c when the avoided-crossing gaps ∆E k are small and well-separated.

Here, summation is taken over a given interval of H z and c is the sweeping rate. Thus, the amount of the scattered populations in the interval [H peak , H SW ] is proportional to

k

X

k=k

(∆E k ) ²

c =

k

X

k=k

1 S

(S∆E k ) ² v

∝

k

X

k=k

1 S

|H k − H SW | ^1/2

v , (21)

for large S. Although S dependence of dH (k)/dk is com-

plicated and k SW /S is also S dependent, we regard the

7 summation as the following integral

k

X

k=k

1 S

|H k − H SW | ^1/2

v ≃

Z H

H

|H − H SW | ^1/2

v dH

∝ |H peak − H SW | ^3/2

v , (22)

for large S and just above the Stoner-Wohlfarth point.

As the scattered populations should be invariant for var- ious velocities v, the v dependence of the peak H peak is given by

|H peak − H SW | ∝ v ^2/3 . (23) It is obvious that this behavior (23) does not work for large velocities v because the above assumptions will not hold for large fields |H − H SW |.

IV. EFFECTS OF THE ENVIRONMENT ON THE BEATING DYNAMICS

A. Beating phenomenon

The beating phenomenon of the spin-length has been found in the magnetization dynamics after the Stoner- Wohlfarth point ²⁰ . This recursive oscillation is regarded as the beating of the resonant oscillations between the adjacent energy levels. The period of this beating oscil- lation is given by

T τ = 2πS

D , T ˜ τ = 2π

D ˜ , (24)

in the τ unit. We remark that this beating is not only the oscillation of the z component of magnetization ²⁷ , but also of all the components of spin, and as the result, of the spin length

s f = hs x i ² + hs y i ² + hs z i ² , (25) which we call the spin-fidelity ²⁰ (Fig. 12).

Surprisingly, it was also found that the period of the recursive oscillation does not depend on the strength of the magnetic field H z . In this sense, the beating is ro- bust. However, in order to observe the beating in ex- periments at finite temperatures, we must study their stability against relaxation and decoherence.

B. Effects of relaxation and decoherence In order to take dissipative effects in account, we use the generalized Lindblad-type equation ²⁴ . Although the general treatment for the time-dependent fields is diffi- cult ²⁸ , the generalized Lindblad equation works in the cases, where the change of parameters is much slower than the relaxation time of the thermal bath ^24,28–31 .

In this scheme, we consider the quantum Stoner- Wohlfarth model coupled with a thermal reservoir. We assume that the interaction Hamiltonian and the bath Hamiltonian are given by

H I = λs x (B + B ^† ), B = X

k

g k b k , (26) H B = X

k

ω k b ^† _k b k , (27) where λ is the coupling constant, b k is the bosonic oper- ator associated with the thermal barth, and ω k and g k

are the characteristic parameters of the thermal reser- voir. With such an interaction Hamiltonian, both spin dephasing and relaxation are taken in account.

In the weak coupling limit λ ≪ 1, the dissipative dy- namics is given by the generalized Lindblad equation ^24,31

∂

∂t ρ(t) = −i[H(t), ρ(t)]−λ ² π{[s x , R(t)ρ(t)]+h.c.}, (28) with

R(t) = X

k,l

Ψ(E k (t) − E l (t))

×hψ k (t)|s x |ψ l (t)i|ψ k (t)ihψ l (t)|, (29) where ρ(t) is the reduced density operator for the system, E k (t) is the instantaneous eigenenergy of the quantum Stoner-Wohlfarth model

H(t)|ψ k (t)i = E k (t)|ψ k (t)i, (30) and Ψ(·) is the bath spectral function

Ψ(ω) = J(ω) − J (−ω)

e ^βω − 1 , J (ω) = ASω ^l Θ(ω). (31) Here, β is the inverse temperature, J (ω) is the spectral density, and Θ(ω) is the step function. Spin-size S ap- pears in the spectral density J (ω) due to the normal- ization of the system Hamiltonian H(t). The thermal reservoir is called Ohmic for l = 1, sub-Ohmic for l < 1, and super-Ohmic for l > 1. In the following, we cal- culate the beating dynamics in the Ohmic case l = 1 for different values of the (inverse) temperature β, the coupling-constant γ = λ ² πAS, and the sweeping-rate v (Fig. 13).

The oscillations of magnetizations with beatings, ob-

served in the previous paper ²⁰ , exhibit two time scales

as seen in Fig. 12. The faster one is the simple spin-

precession with the time-dependent frequency ˜ ω p ∼

2 ˜ DhS z i + ˜ H z and the slower one is the beating with the

time and field-strength independent frequency ˜ ω b ∼ D. ˜

Detection of both frequencies, i.e. of the full spin motion,

should be possible in the absence of damping if the mea-

surement frequency ω m is faster than both frequencies,

ω m ≫ ω p > ω b . However, this is difficult to realize in real

systems. Furthermore, the spin dynamics is generally

damped by the environments. This results in finite spin-

lattice (dissipation) and spin-spin (decoherence) times T 1

− 1

− 0.5 0 0.5 1

0 50 100 150 200

h s

i

τ

0 0.2 0.4 0.6 0.8 1

0 50 100 150 200

s

τ

− 1

− 0.5 0 0.5 1

0 50 100 150 200

h s

i

τ

− 1

− 0.5 0 0.5 1

0 50 100 150 200

h s

i

τ

FIG. 12. Beatings of the spin-components and the spin-fidelity. The horizontal axis is time τ and the vertical axes are (top left) hs

i, (top right) s

, (bottom left) hs

i, and (bottom right) hs

i. Spin-size is S = 10, the anisotropic constant is D = 1, and the transverse field is H

= 1. The longitudinal field is swept from H

(0) = 1 with the sweeping rate v = 0.05.

and T 2 , respectively. In the Ohmic generalized Lindblad- type equation, the parameter is γ ∝ 1/T 1 . In Fig. 13, we show the effects of the inverse temperature β and the coupling constant γ. On the experimental side, measure- ments may require ensembles of identical single-domain ferromagnetic nano-particles, single-molecular magnets, or atomic magnets. Of course, single-objects measure- ments are also possible.

Taking the example of the single-molecular magnet Mn 12 , the experiment ⁷ shows that the anisotropic con- stant ˜ D = 0.61K giving the ratio ˜ D/gµ B = 0.44T. For an infinitesimal transverse field H x , the Stoner-Wohlfarth point for Mn 12 is given by H SW ≃ 8.8T. The frequency of the beating is given by ω b ≃ 1.3 × 10GHz. In spite of the fact that such a value is rather large, we believe that these beatings could be observed in a particular setup which will be described later. Furthermore, other systems such as single-spin magnets should show significantly smaller beating frequencies.

V. SUMMARY AND DISCUSSIONS In the present paper, we extended our previous work on the quantum Stoner-Wohlfarth model ²⁰ (6) to the stud- ies of (i) the distributions of the eigenstate populations and their associated scaling properties (Sec. III) and (ii) the beating dynamics of magnetization in the dissipative (thermal) environment (Sec. IV).

(i) At a given swept field, the distribution of the eigen-

state populations beyond the Stoner-Wohlfarth point is

given by the amount of the scattered populations at the

successive avoided level crossings along the metastable

branch, which is the diabatic continuation of the state

corresponding to M z = +S to the negative field re-

gion until the Stoner-Wohlfarth point. The calculations

show that the distribution of eigenstate populations {P k }

has a peak at the field H peak , which is not located at

the Stoner-Wohlfarth point H SW but is shifted a certain

amount ∆H peak = |H peak − H SW |, which depends on the

sweeping rate v. It should be noted that the shift does

not depend on S, and thus it is the same in the classi-

cal limit S → ∞. We investigated the S dependence of

the distribution of the eigenstate populations {P k }, and

found a possible scaling form. The dependence of the

9

− 1

− 0.5 0 0.5 1

0 50 100 150 200

h s

i

τ

γ = 0.01, β = 10, v = 0.05

− 1

− 0.5 0 0.5 1

0 50 100 150 200

h s

i

τ

γ = 0.01, β = 1, v = 0.05

− 1

− 0 . 5 0 0 . 5 1

0 50 100 150 200

h s

i

τ

γ = 0 . 05 , β = 10 , v = 0 . 05

− 1

− 0 . 5 0 0 . 5 1

0 50 100 150 200 250 300 350 400

h s

i

τ

γ = 0 . 01 , β = 10 , v = 0 . 01

FIG. 13. Beatings in dissipative environments. Spin-size is S = 10, the anisotropic constant is D = 1, and the transverse field is H

= 1. The longitudinal field is swept from H

(0) = 1. The horizontal axis is the classical time τ and the vertical axis is the expectation value of the normalized spin operator hs

i. The cases of (top left) the coupling constant γ = 0.01, the inverse temperature β = 10, and the sweeping rate v = 0.05, (top right) γ = 0.01, β = 1, and v = 0.05, (bottom left) γ = 0.05, β = 10, v = 0.05, and (bottom right) γ = 0.01, β = 10, and v = 0.01 are plotted.

shift on v was estimated to be proportional to v ^2/3 for small v, which was discussed from the viewpoint of the scattering at each avoided crossing and the associated criticality around the Stoner-Wohlfarth point.

(ii) Finally, we studied how the beatings found out- side of the Stoner-Wohlfarth point H z < H SW < 0 are modified by dissipative effects due to the contact with a thermal reservoir. Adopting the generalized Lindblad- type equation ²⁴ , we showed how the beatings could be preserved while magnetization relaxes to the ground state, and clarified how a fast enough measurement and sweeping time-scales could allow their observation at low

enough temperatures.

ACKNOWLEDGMENTS

This work is supported by Grants-in-Aid for Scientific Research C (Grant No. 25400391) from MEXT of Japan and the Elements Strategy Initiative Center for Magnetic Materials under the outsourcing project of MEXT. The numerical calculations were supported by the supercom- puter center of ISSP of the University of Tokyo. T. H. is supported by the Program for Leading Graduate Schools:

Material Education program for the future leaders in Re- search, Industry, and Technology (MERIT) from JSPS.

∗

[email protected]

1

L. N´eel, Compl. Rend. Acad. Sci. 224, 1488 (1947).

2

W. Wernsdorfer, E. Bonet Orozco, K. Hasselbach, A. Benoit, D. Mailly, O. Kubo, H. Nakano, and B. Bar- bara, Phys. Rev. Lett. 79, 4014 (1997).

3

R. Sessoli, D. Gatteschi, A. Caneschi, and M. A. Novak, Nature 365, 141 (1993).

4

D. Gatteschi, R. Sessoli, and J. Villain, Molecular Nano- magnets (Oxford University Press, 2006).

5

R. Giraud, W. Wernsdorfer, A. M. Tkachuk, D. Mailly,

and B. Barbara, Phys. Rev. Lett. 87, 057203 (2001).

6

R. Giraud, A. M. Tkachuk, and B. Barbara, Phys. Rev. Lett. 91, 257204 (2003).

7

L. Thomas, F. Lionti, R. Ballou, D. Gatteschi, R. Sessoli, and B. Barbara, Nature 383, 145 (1996).

8

B. Barbara, Phil. Trans. R. Soc. A 370, 4487 (2012).

9

L. D. Landau, Phys. Z. Sowjetunion 2, 46 (1932).

10

C. Zener, Proc. R. Soc. London Ser. A 137, 696 (1932).

11

E. Majonara, Nuovo Cimento 9, 43 (1932).

12

E. C. G. St¨ uckelberg, Helv. Phys. Acta 5, 369 (1932).

13

S. Miyashita, J. Phys. Soc. Jpn. 64, 3207 (1995).

14

S. Miyashita, J. Phys. Soc. Jpn. 65, 2734 (1996).

15

H. De Raedt, S. Miyashita, K. Saito, D. Garc´ıa-Pablos, and N. Garc´ıa, Phys. Rev. B 56, 11761 (1997).

16

W. Wernsdorfer and R. Sessoli, Science 284, 133 (1999).

17

M. Ueda, S. Maegawa, and S. Kitagawa, Phys. Rev. B 66, 073309 (2002).

18

S. A. Owerre and M. B. Paranjape, Phys. Rep. 546, 1 (2015).

19

E. C. Stoner and E. P. Wohlfarth, Phil. Trans. R. Soc. A 240, 599 (1948).

20

T. Hatomura, B. Barbara, and S. Miyashita, Phys. Rev.

Lett. 116, 037203 (2016).

21

M. A. Nielsen and I. L. Chuang, Quantum Computation

and Quantum Information (Cambridge University Press, 2000).

22

H. P. Breuer and F. Petruccione, The Theory of Open Quantum Systems (Oxford University Press, 2002).

23

U. Weiss, Quantum Dissipative Systems, 4th ed. (World Scientific, 2012).

24

K. Saito, S. Takesue, and S. Miyashtia, Phys. Rev. E 61, 2397 (2000).

25

W. Wernsdorfer, E. B. Orozco, B. Barbara, K. Hasselbach, A. Benoit, D. Mailly, B. Doudin, J. Meier, J. E. Wegrowe, J.-P. Ansermet, N. Demoncy, H. Pascard, N. Demoncy, A. Loiseau, L. Francois, N. Duxin, and M. P. Pileni, J. Appl. Phys. 81, 5543 (1997).

26

T. Mori, S. Miyashita, and P. A. Rikvold, Phys. Rev. E 81, 011135 (2010).

27

D. A. Garanin and R. Schilling, Phys. Rev. B 69, 104412 (2004).

28

T. Shirai, T. Mori, and S. Miyashita, J. Phys. B: At. Mol.

Opt. Phys. 47, 025501 (2014).

29

W. Weidlich and F. Haake, Z. Phys. 185, 30 (1965).

30

R. Kubo, M. Toda, and N. Hashitsume, Statical Physics II (Springer-Verlag Berlin Heidelberg, 1991).

31

T. Mori and S. Miyashita, J. Phys. Soc. Jpn. 77, 124005

(2008).
