Density distribution of polymer chain segments near a nonadsorbing wall
D.A. Svetogorsky
To cite this version:
D.A. Svetogorsky. Density distribution of polymer chain segments near a nonadsorbing wall. Journal de Physique, 1987, 48 (4), pp.689-692. �10.1051/jphys:01987004804068900�. �jpa-00210486�
Density distribution of polymer chain segments near a nonadsorbing wall
D. A. Svetogorsky
Laboratory of Theoretical Physics, Joint Institute for Nuclear Research, Dubna, P.O. Box 79, Moscow, U.S.S.R.
(Requ le 1er juillet 1986, revise le 2 décembre, accepte le 8 d6cembre 1986)
Résumé. 2014 On calcule le profil de densité des segments d’un polymère près d’une paroi non adsorbante. Le résultat peut être appliqué au cas de chaînes courtes. La distribution théorique obtenue est en bon accord avec
les données expérimentales de D. Ausserré, H. Hervet et F. Rondelez (Phys. Rev. Lett. 54 (1985) 148).
Abstract. 2014 The density distribution of polymer chain segments near a non-adsorbing wall has been
obtained. It can be applied to short chains. The theoretical distribution is in good agreement with the experimental data by D. Ausserré, H. Hervet and F. Rondelez (Phys. Rev. Lett. 54 (1985) 148).
Classification
Physics Abstracts
36.20E - 68.45
1. Introduction.
A polymer molecule becomes a statistical coil in a
dilute solution. This coil keeps its shape near a non-
adsorbing wall, it only touches the wall by its
surface. This is due to the fact that the state of the coil flattened over the wall is of a small statistical
weight and will be realized in very rare cases. The
density of chain segments near the wall will conse- quently have the same distribution as the distribution of chain segment density with respect to the centre of the macromolecule mass. This concept may
already be considered classical [1-4].
Recently, D. Ausserré, H. Hervet and F. Ron- delez [5] have measured the density of segment distribution near a wall by the evanescent wave
induced fluorescence method [6]. Experimental re-
sults showed that the density at a distance of the
order of the chain radius of gyration is in good
agreement with theory, but near the wall it does not
tend to zero as theory predicts. In reference [7] D.
Ausserr6, H. Hervet and F. Rondelez obtained the
density distribution, based on model physical con- siderations, which agrees with the experimental
data.
In this paper a practically accurate density distri-
bution of chain segments has been obtained within the framework of the existing theory owing to improving the calculation method. This distribution is valid for chains with a small number (N ) of Kuhn
segments. Near the wall the segment density is proportional to 1/N. In references [1-4] terms of the
order of 1/N were omitted since N is usually very
large. In reference [5] N = 18, so theory must be
more accurate to interpret experiments with such
short chains.
2. The distribution of segment density of an ideal
chain.
As is known, any ideal chain can be compared with
an equivalent freely jointed chain of the same length
and with the same radius of gyration. This deter-
mines the magnitude of the Kuhn segment (a) in the freely jointed chain and the number (N) of Kuhn
segments in the chain. The number N depends only
on the chain length, and the magnitude of the Kuhn segment (a) can be regarded as a degree of flexibility
of a real chain, A partition function of the freely jointed chain in the volume V can be written in the form
where xi is the radius vector of the end of the i-th segment of the chain, and
Since only the size of the Kuhn segment enters into the final expressions, other expressions for g are also possible. We will assume that
Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:01987004804068900
690
The i-th segment density distribution will be
where
and the density distribution is
As is well known (e.g. see Ref. [14]) for the i - j I iterated kernel we have :
where A k and 4’k are eigenvalues and eigenfunctions
of the integral equation
If ci slightly varies at distance of an order of the Kuhn segment a, solutions of integral equation (7)
are close to the solution of the differential
equation [9] :
Moreover, a21 åI/J I I/J s a2 k2 1 where k is con-
stant, and consequently, A = 1 + E where [ E [ = a2 k2.
In case the walls are non-adsorbing, the function
must obey the boundary condition on the wall [9-12]
However, this boundary condition is inaccurate and it should be replaced by
where qi’(xs) is the derivative normal to the surface ;
6 is of an order of the Kuhn segment a. One can see
this if one tries to approximately satisfy integral equation (7) at a surface point. For this aim we expand t/J (y) in (7) in a series and keep first- and second-order terms, then we have
where
For Q to satisfy equation (11) up to the first order of ak it is necessary that
The given « derivation » of relation (10) is aimed
at showing the necessity of a boundary condition (10). Equation (10) is a boundary condition of the
third kind for the second-order equation (8). A boundary condition of this kind has been used by de
Gennes in papers [10], and also by Grossberg in
paper [15] for investigating the pressure distribution
over a nonspherical globule. The value of b slightly depends on a specifics of kernel g. Since our
consideration is related not to the actual chain but to the equivalent freely jointed one, a theoretical calculation of b for kernel (2) makes no sense.
Indeed, actual chains with the same Kuhn segment but with different flexibility mechanisms (persistent
or rotationally isomeric one) behave differently near
the wall. Therefore, it is reasonable to introduce a
parameter B via the relation
This parameter will be defined by experiment. For a freely jointed chain x = 0.5 a, one may assume that
B must always be close to 0.5.
Since, near a flat wall, the density distribution
depends only on the normal coordinate, we shall
further consider the one-dimensional equation (8) only. The normal coordinate is denoted by x.
Eigenfunctions and eigenvalues of equation (8)
are known :
The boundary condition on the wall (x = 0) can
be written as
From (6) and (13) we have :
if m is large. For large m an essential contribution to
(15) comes from small k (ak -- 1/ /m). Since
b ~ a, the r.h.s. of (14) is small and a good approximation is given by
In this approximation
where
The density distribution is expressed through quantities of the type
Integrating (17) over y, we obtain
where
is a normalized density distribution of the final segment in the chain of m Kuhn segments. Using (19), one can write the density distribution as
where no is the density far from the wall.
One can also calculate nem (x ), accurately taking
account of boundary condition (14). With this boundary condition in (15) we get
The integrals in (21) can be expressed by
(see e.g. [16]). Upon calculating Gm(x, y) and integrating over y (see (18)), we have
The resulting expression is slightly more complicated
than (19). The expression for density (20) with nem (x ) from (23) is also valid for chains of a small number of Kuhn segments. It was obtained with the
following approximations : eigenvalues for the Gaus-
sian kernel g, used in calculating (6), and eigenfunc-
tions slightly inaccurate at a distance of the order of the Kuhn segment from the wall.
3. Comparison of the theory with experimental data
from reference [5].
The density distribution of xanthan segments was measured in the diluted solution (96 ppm). The
xanthan chain has persistent flexibility under exper- imental conditions. The chain length is 1.8 um ; the
Kuhn segment is 0.1 um long. D. Ausserr6, H.
Hervet and F. Rondelez found, as mentioned in the Introduction, that the density distribution
where Rg = 0.18 um, a = 0.1 iLm is in good agree-
ment with the experimental data. Therefore, density
distribution (20) obtained in this paper should be
compared with distribution (24).
Figure 1 shows curves of n (x ) and ne18 (x ) for B = 0.44 and Q = 0.86 (the latter is too large to be possible).
Fig. 1. - Normalized density distributions of chain segments and the density distribution of end segments
near the wall x = 0. The chain consists of 18 Kuhn segments (a denotes the Kuhn segment). The distribution n from reference [7] is shown by a solid hold-face line. A
light-face solid line and line (-.-.) show n(x) for B = 0.44 and (3 = 0.86, respectively. There is also
ne18 (x ) for these values : crosses denote ne18 (x ) for B = 0.44, the dashed line is for B = 0.86.
According to references [8, 13] the xanthan sample
under investigation had the polydispersity index Mwl Mn = 1.35. To compare theory with experiment,
the chain length averaging was performed. Since
there were no data on the molecular weight dis- tribution, it was assumed that it has a normal form
where N was taken to be 18, k = 1.35.
692
In figure 2 one can see curves of n(x) for B=0.5 with averaging (k = 1.35) and without
averaging (k = 1). In the experimentally accessible region (x/a > 0.7) n (x ) differs from np (x) by not
more than 3 %. The maximum difference is on the
Fig. 2. - Normalized segment density distributions as a
function of the distance from the wall. A solid bold-face line represents net> (x). For f3 = 0.5 shown are the density
distribution for a chain of 18 Kuhn segments (-.-.) and
the density distribution for chains distributed by a normal
law with the average 18 and polydispersity index Mw/MN = 1.35 (---).
wall where no = 0.14 and n (0 ) = 0.085. Therefore,
a direct measurement of the xanthan concentration
on the wall, as proposed in reference [7], is of
current importance..
4. Conclusion.
The density distribution of polymer segments near the wall has been obtained in this paper for short chains. This distribution is in good agreement with the experimental data measured by D. Ausserrd, H.
Hervet and J. Rondelez [5] and with the density distribution, proposed by them [7]. The density
distribution is proportional to a
2
on the wall
Rg
and it should be used when quantities of that order
can be measured. The theoretical density distribution
near the wall in the semi-dilute regime should also be corrected. In this case concentration near the wall will be proportional to (a/§f where 6 is the
correlation length (see Ref. [9]).
Finally, the author expresses his gratitude to
V. K. Fedyanin, V. B. Priezzhev and A. Yu. Gross-
berg for discussions of the task and results.
References
[1] HOLINGSWORTH, C. A., J. Chem. Phys. 16 (1948)
544 and 17 (1949) 971.
[2] WEIDMANN, J. J., KUHN, H. and KUHN, W., J.
Chem. Phys. 50 (1953) 266.
[3] DIMARIZIO, E. A., J. Chem. Phys. 42 (1965) 2101.
[4] CASSASA, E. F., J. Polym. Sci. B 5 (1967) 773.
CASSASA, E. F., Macromolecules 17 (1984) 601.
[5] AUSSERRE, D., HERVET, H. and RONDELEZ, F., Phys. Rev. Lett. 54 (1985) 1948.
[6] ALLAIN, C., AUSSERRÉ, D. and RONDELEZ, F., Phys. Rev. Lett. 49 (1982) 1694.
[7] AUSSERRÉ, D., HERVET, H. and RONDELEZ, F., J.
Physique Lett. 46 (1985) L-929.
[8] MULLER, G., LECOURTIER, J., CHAUVETEAU, G.
and ALLAIN, C., Macromol. Chem. Rapid. Com-
mun. 5 (1984) 203.
[9] DE GENNES, P. G., Scaling Concepts in Polymer Physics (Cornell University Press, Ithaca and
London), 1979, chapter 9 and comments after [11].
[10] DE GENNES, P. G., Rpts. Progr. Phys. 32 (1969) 14.
DE GENNES, P. G., Macromolecules 14 (1981) 1637.
[11] POLAN, A. K., EDWARDS, S. F., Proc. Roy. Soc.
London 337 (1974) 509.
[12] LIFSHITZ, I. M., Zh. Eksp. Teor. Fiz. 55 (1968) 2408.
Sov. Phys.-JETP 28 (1969) 1280.
[13] AUSSERRÉ, H., HERVET, H. and RONDELEZ, F., Macromolecules 19 (1986) 85.
[14] MORSE, P. M., FESHBACH, H., Methods of Theoreti-
cal Physics (McGraw-Hill Book Company,
New York, Toronto, London), 1953, chapter 8.
[15] GROSBERG, A. Yu., Vestn. Mosk. Univ. Ser. Fiz. 1
(1972) 14.
[16] OBERTHETTINGER, F., Fourier transforms of distribu- tions and their inverses (Academic Press) 1973,
table I, formula (78).
