Patella tuberculosis: A case report

(1)

Orthopaedics & Traumatology: Surgery & Research (2009)95, 649—651

CLINICAL REPORT

Patella tuberculosis: A case report

S. Fnini

^∗

, J. Hassoun , A. Garches , A. Largab

Orthopedic and Traumatological Surgery Department, Ibn Rochd Teaching Hospital, Casablanca, Morocco Accepted: 15 October 2009

KEYWORDS Patella;

Tuberculosis;

Infection;

Knee

Summary A rare case of patella tuberculosis is reported. Clinical signs comprised chronic inﬂammatory pain, knee swelling and joint stiffness, with two years’ evolution. Standard X-ray showed focal osteolysis with intact joint line. Diagnosis was based on surgical biopsy during arthrotomy. Treatment comprised nine months’ antibiotherapy and bone curettage to pre- vent intra-articular extension. At 42 months’ follow-up, functional results were good, without recurrence of infection.

Introduction

Worldwide, osteoarticular tuberculosis accounts for 3 to 5%

of cases of tuberculosis and 15% of extrapulmonary forms. In Morocco, osteoarticular tuberculosis is in third place after pulmonary and ganglion tuberculosis in terms of frequency.

The most frequent osteoarticular locus is the spine, then the hip and then the knee[1,2,3].

In the knee, involvement is mainly synovial, with local extension eroding the bone. Pure tuberculous osteitis is rare, with a few occasional reports. Patella tuberculosis is extremely rare, at less than 0.1% of cases of osteoarticular tuberculosis in the French-language literature[4,5]. We here report one case.

Observation

This case is of an 18-year-old, educated woman with no particular history, who had had all the vaccinations and

DOI of original article:10.1016/j.rcot.2009.10.006.

∗Corresponding author. Tel.: +00 212 61210388.

E-mail address:sfnini@hotmail.com(S. Fnini).

boosters (including BCG) scheduled under the Moroccan public health system. She came from a low-level socioeconomic background, but there was no suspicion of any tuberculosis contagium in the family.

Her clinical history, going back two years prior to admis- sion, consisted in inﬂammatory pain, right knee swelling and limping, accompanied by knee stiffness and ﬂexion contrac- ture. There was no clear feverish syndrome or night sweats, but she did suffer a 2 kg weight-loss.

Clinical examination was relatively unrevealing, with tenderness on palpation of the medial joint surface of the patella, patellar crepitation, and slight effusion. Mobil- ity was −5^◦/0/120^◦. There was no knee laxity, inguinal adenopathy or other (notably, respiratory) associated signs.

On standard X-ray, the lateral view (Fig. 1) showed a circumferential rosette form with a light peripheral halo.

CT scans (Fig. 2) showed a circular image of varying den- sity and well distinguished from the healthy bone, taking up almost all of the medial half of the patellar thickness.

Arthroscan, to check patellar joint cartilage integrity, was not performed. There was a lateral shift in the patella, with slight joint effusion. Chest X-ray was normal. Biological analysis found moderate anemia and an inﬂammatory syndrome:

doi:10.1016/j.otsr.2009.10.004

(2)

650 S. Fnini et al.

Figure 1 Lateral X-ray view of right knee: circumscribed central patellar lesion surrounded by light halo.

SR = 36—105 and CRP = 32 mg/l. Suggested diagnoses were osteoid osteoma, benign cartilage tumor or Brodie’s abscess.

The patient underwent open surgery with a medial para- patellar approach and arthrotomy. Joint ﬂuid was sampled.

Direct exploration of the medial side of the patella found soft but continuous cartilage on palpation. Inﬂammatory synovitis in the sub-quadricipital recess was sampled for biopsy. Opening the cartilage revealed crumbly grayish-

Figure 2 Transverse CT section: heterogeneous central image of medial face of patella, clearly distinguished.

Figure 3 Knee X-ray at three years’ follow-up: medial femoropatellar conﬂict.

white tissue, which was entirely removed by curettage, leaving an unﬁlled bone space over which the joint cartilage was simply laid without suture.

Intra-osseous tissue histology confirmed the diagnosis of bone tuberculosis, revealing caseous necrosis surrounded by epithelioid and giant-cell follicles. Synovial biopsy diagnosed non-specific chronic synovitis. The joint fluid con- tained no BK bacilli; the curettage tissue was not explored for BK.

Chest X-ray was normal; three BK cultures proved negative. Tuberculin skin test was positive at 12 mm.

Antibiotherapy was administered for nine months, following the ofﬁcial Moroccan protocol: two months rifampicin (10 mg/kg/d), isoniazid (5 mg/kg/d) and pyraz- inamide (25 mg/kg/d), followed by seven months rifampicin and isoniazid. Plaster cast immobilization was maintained for four weeks.

Familial contagion survey proved negative.

Short-term evolution was good, with improved knee func- tion and normalized SR and CRP levels. Knee X-ray showed gradual ﬁlling of the curettage bone space.

The patient was re-operated on three years later for medial femoropatellar conflict associated with an osteophyte on the medial edge of the patella where curettage had been performed (Fig. 3). The conflict area was trimmed and the medial osteophyte was dissected. There were no macroscopic signs of recurrence of infection. The final six- months’ result was good, pain-free and with complete knee mobility (0/0/135^◦). Knee X-ray showed no femorotibial or femoropatellar joint narrowing or alterations to the tibia or femur.

Discussion

The incidence of patella tuberculosis in the international literature ranges from 0.09 to 0.15% [6]. Tuli reported one patella tuberculosis in a series of 1,074 lesions in 980 patients[7]. The knee is the third most frequent skeletal location for tuberculosis. Galois et al., in their 2003 literature review, found 10 cases of patella tuberculosis[5]. The largest recent series was that of Ravi Mittal et al., with ﬁve cases[6].

(3)

Patella tuberculosis: A case report 651 Tuberculosis is coming back into the spotlight due to

AIDS, and is a public health issue in pandemic areas such as Morocco. Osteoarticular involvement is probably hemato- genic, of pulmonary origin [6]. Clinicians should therefore look for entry points and possible secondary loci.

Patella tuberculosis is hard to diagnose, especially at early stages, which accounts for the generally late diagnosis. It mainly affects adolescent and young adult males, even without risk factor. The clinical aspect is initially non- specific. The appearance of a fistulized prepatellar cold abscess argues for a diagnosis of tuberculosis[5]. Reactive joint effusion is frequently observed, but BK culture in joint fluid often proves negative.

A considerable inﬂammatory syndrome is often found on biological analysis, and provides a means of monitoring treatment efﬁcacy.

On X-ray, the aspect is of central osteolysis with, at ﬁrst, continuous patella joint cartilage, but evolving towards an opening through the cartilage within the knee joint, trans- forming a pure bone mass into a potentially more serious osteoarticular form. Hartoﬁlakidis-Garofalidis [8]reported three cases of patella tuberculosis, all involving open osteolysis in the knee joint and probably representing very evolved forms.

The most suggestive aspect, however, is osteolysis con- taining a central bone sequestration, bordered by peripheral sclerosis [6,9,10—17], reminiscent of the X-ray aspect of chronic osteomyelitis.

Bone scan and MRI can locate the lesion and its joint extension, but it is the arthroscan that explores patella joint cartilage integrity in the pure osseous form.

Diagnosis is confirmed by histology and bacteriology. With the benefit of hindsight, we consider that biopsy could be performed percutaneously under X-ray or CT guidance, given the superficial location of the patella. This would avoid seed- ing the knee joint. Knee arthroscopy is another less invasive solution that could be applied at any point during care, first for biopsy of open evolved forms in the joint space, and then for complete curettage of the lesion.

Osteoarticular tuberculosis treatment is based on mul- tiple antibiotherapy. Treatment duration varies, but often exceeds one year. In recent publications, surgery has been limited to biopsy. The presence of an abscess, however, or persistent resistant bone lesion may require surgical cavity curettage[14,18].

Evolution of strictly osseous forms tends to be favor- able. Knee joint extension, with generalized osteoarthritis, on the other hand, is always of poor functional prognosis [1,6,15,18].

Conclusion

Bone tuberculosis remains difﬁcult to diagnose. Certain locations should always be borne in mind, however rare,

in case of pandemic or immunodeﬁciency. In case of osteolysis, associated with abscess or not, infectious etiology is to be considered and appropriate samples should be taken.

Diagnosis is conﬁrmed by histology and bacteriology. The slow evolution of bone tuberculosis requires local treatment of lesions and abscesses. Antibiotherapy regularly ensures recovery.

Conﬂict of interest

None.

References

[1] Tazi Moukha K, Lezrek M, Rachid K, Choho A, Aouam H, Moulay I. Tuberculose de la rotule : une localisation inhabituelle : à propos de 2 cas. J Chir 1995;132:201—5.

[2] Rachid K, Chkoura M, Moudene A. Localisations rares de la tuberculose osseuse. Orthop Traumatol Surg Res 2001;87:176—9.

[3] Moujtahid M, Essadki B, Lamine A, Bennouna D, Zryouil B. La tuberculose osseuse multifocale : à propos d’un cas. Orthop Traumatol Surg Res 1995;81:553—6.

[4] De Mourgues G, Schnepp J, Bonnier P. À propos d’une tuberculose primaire de la rotule. Lyon Chir 1960;56:931—3.

[5] Galois L, Chary-Valckenaere I, Mainard D, Pourel J, Delagoutte JP. Tuberculosis of the patella. Arch Orthop Trauma Surg 2003;123:192—4.

[6] Mittal R, Trikha V, Rastogi S. Tuberculosis of patella. Knee 2006;13:54—6.

[7] Tuli SM. Tuberculosis of the skeletal system (bones, joints, spine and bursal sheaths). New Delhi: Jaypee Brothers; 2004.

[8] Hartoﬁlakidis-Garofalidis G. Cystic tuberculosis of patella. J Bone Joint Surg Am 1969;51:582—5.

[9] Dhillon MS, Rajasekhar C. Tuberculosis of the patella: report of a case and review of the literature. Knee 1995;2:56.

[10] Dhillon MS, Rao SS, Sandhu MS, Vasisht RK, Nagi ON. Tubercu- losis of the patella. Skeletal Radiol 1998;27:40—2.

[11] Bonnet C, DeBandt M, Palazzo E, Malaizier D. Tuberculosis involving the patella. Am J Rad 1992;159:677.

[12] Shah P, Ramakantan R. Tuberculosis of the patella. Br J Radiol 1990;63:363—4.

[13] Hernández Gimenez M, Tovar Beltran JV, Frieyro Segui MI, Pascual Gómez E. Tuberculosis of the patella. Pediatr Radiol 1987;17:328—9.

[14] Aabye R. Tuberculous osteomyelitis of the patella; report of three cases treated with antibiotics and surgical measures.

Acta Chir Scand 1956;12(111):409—16.

[15] Dhillon MS, Rajasekhar C, Nagi ON. Tuberculosis of the patella: report of a case and review of the literature. Knee 1995;2:53—6.

[16] Khan AA, Khan AA, Iraqi AA. Cystic tuberculosis of patella.

Indian J Med Sci 1976;30:192—4.

[17] Scudese V. Primary tuberculosis of patella. Am J Surg 1954;87:639—40.

[18] Roy DR. Osteomyelitis of the patella. Clin Orthop 2001;389:30—4.
