Unsupervised Multi-Source Domain Adaptation for
Regression
Guillaume Richard, Antoine de Mathelin, Georges Hébrail, Mathilde
Mougeot, Nicolas Vayatis
To cite this version:
Guillaume Richard, Antoine de Mathelin, Georges Hébrail, Mathilde Mougeot, Nicolas Vayatis. Unsu-
pervised Multi-Source Domain Adaptation for Regression. European Conference on Machine Learning
and Principles and Practice of Knowledge Discovery in Databases, Sep 2020, Ghent, Belgium. pp.395-
411, �10.1007/978-3-030-67658-2_23�. �hal-02543790�
Unsupervised Multi-Source Domain Adaptation
for Regression
Guillaume Richard
1,2, Antoine de Mathelin
1, Georges H´ ebrail
2,
Mathilde Mougeot
1,3, and Nicolas Vayatis
11
Centre Borelli, ENS Paris-Saclay, Saclay, FRANCE
2
EDF R&D, Palaiseau, FRANCE
3
ENSIIE, Evry, FRANCE
January 2020
Abstract
We consider the problem of unsupervised domain adaptation from mul- tiple sources in a regression setting. We propose in this work an original method to take benefit of different sources using a weighted combination of the sources. For this purpose, we define a new measure of similarity between probabilities for domain adaptation which we call hypothesis- discrepancy. We then prove a new bound for unsupervised domain adap- tation combining multiple sources. We derive from this bound a novel adversarial domain adaptation algorithm adjusting weights given to each source, ensuring that sources related to the target receive higher weights.
We finally evaluate our method on different public datasets and compare it to other domain adaptation baselines to demonstrate the improvement for regression tasks.
1 Introduction
In classical machine learning, one assumes that the source data used to train an algorithm comes from the same distribution as the target data it is applied to. This assumption is not true for many applications: for instance, a human activity recognition model trained on young people may not perform well when applied to older ones. Moreover, for many applications, different sources have different relations to the target domain. Including sources that are not related to the target may lead to negative transfer ie reduce the performance of adap- tation on the target domain. Hence we consider in this paper the problem of unsupervised domain adaptation from multiple sources tackling the issue of adapting from a labelled source domain to a target domain with no labeled data.
An abundant literature exists for unsupervised domain adaptation with a single source for classification: [3] introduced a single source adaptation bound for classification. It was later used in several works, notably adversarial methods of [10] and [19]. While those methods can be applied to regression, it is not theoretically founded and often fails in practice. [14] proposed a novel theoretical
bound for regression using the notion of discrepancy between predictors. It is not easy to estimate in the general case but has led to several works using linear regression [1] to train GANs or kernels [8] for domain adaptation.
The main risk of adapting from multiple sources comes from one or several sources being detrimental to adaptation. It is particularly true with adversarial methods trying to match source and target domains. Then one wants to find a way to give high weights to sources the most related to the target. In [15] a weighting scheme is proposed assuming that the target distribution is a convex combination of the sources. A boosting method is used in [21] to derive weights.
Recently, [22] extended previous bounds with a maximum over multiple sources leading to an algorithm giving high weights to sources far from the target. In [13] inter-relationships between sources are used to compute the weights.
There are two main contributions in this work: firstly, we prove new a bound for multi-source domain adaptation that is tighter than existing bounds in a regression task. It is based on a new measure of similarity between distribu- tions which we call hypothesis-discrepancy. For a given predictor, it measures how another predictor can give different results on one of the domains while staying close on the other and can be computed with adversarial learning. The second main contribution is a new algorithm optimizing both representations and weights of each source for multi-source domain adaptation. To the best of the authors’ knowledge, this is the first adversarial unsupervised domain adaptation tailored for regression. We conduct experiments on both synthetic and real-world datasets and improve on state of the art results for multi-source adversarial domain adaptation for regression.
2 Unsupervised Multiple Source Domain Adap-
tation with Hypothesis-Discrepancy
Setting. We first define the problem of Multi-Source Domain Adaptation (MSDA). We define K independent source domains Dk such that Dk= {Xk, fk} where Xk is the input data with associated marginal distribution Xk ∼ pk and fkthe true labelling function of the domain. Similarly, we define a target domain Dt= {Xt, ft} with Xt∼ pt. We assume that every input is in the same space X ie Xk ∈ X and Xt∈ X which is the case of homogeneous transfer. The predic- tion task is the same for both domains ie fk : X → Y and ft: X → Y (fk and ftare supposed to be close to each other). For instance, Y ⊂ R for regression or Y = {0, 1} for binary classification. We also consider a loss L : Y × Y → R+ and a hypothesis class H of hypotheses h : X → Y. We also assume that the loss L is bounded over Sk by M = supksupx∈Sk,h∈HL(h(x), fk(x)).
For two hypotheses h and h0, we define k(h, h0) = Ex∼pk[L(h(x), h0(x))] the average loss of two hypotheses over a the source domain Dk and t(h, h0) = Ex∼pt[L(h(x), h0(x))] over the target domain. We also consider a labelled source sample Sk of size m with an associated empirical probability ˆpk. Similarly, we consider a unlabelled target sample St of size n with an associated empirical probability of ˆpt.
Objective. The goal of Domain Adaptation is to minimize the target risk
t(h, ft) = Ex∼pt[L(h(x), ft(x))]. In unsupervised domain adaptation, no label
is available in the target task and we cannot directly estimate ft. Consequently we want to leverage the information about the labels in the source domains fk to adapt to the target domain. After defining the hypothesis-discrepancy we propose a new bound relating the target risk with a weighted combination of the source risks k(h, fk).
2.1 Hypothesis-discrepancy
We introduce the concept of hypothesis-discrepancy:
Definition 1. For two distributions P , Q over a set X and for a hypothesis class H over X , for any h ∈ H, the hypothesis-discrepancy (or HDisc) associated with h is defined as:
HDiscH,L(P, Q; h) = max
h0∈H|Ex∼P[L(h(x), h0(x)] − Ex∼Q[L(h(x), h0(x)]| (1) For any given h ∈ H hypothesis-discrepancy measures a similarity between two distributions. It is directly dependent on the hypothesis class H and the loss L and can be estimated with finite samples. In the definition, h0 can be seen as a predictor that would be very close to h on the source domain but far on the target domain (or vice-versa). Using HDisc, we are able to show the following proposition for unsupervised single source domain adaptation:
Proposition 1. If L is symmetric and follows the triangle inequality, then the following bound holds for any k ∈ {1, ..., K},
t(h, ft) ≤ k(h, fk) + ηH(fk, ft) + HDiscH,L(pt, pk; h) (2) where
ηH(fk, ft) = min
h0∈H[t(h0, ft) + k(h0, fk)]
Proof. See Appendix A
This bound gives a good intuition about the conditions under which domain adaptation can work. Indeed, the first term k(h, fk) corresponds to the error made by h on the source data. The third term is our hypothesis-discrepancy and characterizes the similarity between marginal probabilities over the input data. The second term ηH is the sum of the error made by the ideal hypothesis on both domains: it is small when the two labelling functions are close which is the general assumption of unsupervised domain adaptation [4]. As it involves ft it cannot be controlled in unsupervised domain adaptation without access to labels in the target domain. It follows that, under the assumption that the two labelling functions are close, if the two other terms of the bound can be minimized, the target risk will also be minimized. Another strength of HDisc is that it is directly dependent on H and L: it can be used for any task including regression.
2.2 Multi-Source Domain Adaptation bound
When multiple sources are available, a straightforward idea would be to merge all the source domains into one and transform the problem to single-source domain adaptation where Proposition 1 applies. This solution is clearly not
optimal as different source domains may have different relationships to the target one.
We propose to attribute weights to each source: we introduce the α-weighted source domain Dα = {pα, fα} such that for α ∈ ∆ = {α ∈ RK; αk ≥ 0, PK
k=1αk = 1}, fα : x → (PK
k=1αkpk(x)fk(x))/(PK
j=1αjpj(x)) and pα = PK
k=1αkpk.
The α-weighted sample is Sα =
K
S
k=1
Sk with probabilities ˆpα(x(k)i ) = αk/m.
Similarly, we consider an unlabeled target sample St = {(x(t)1 , ..., x(t)n )} where x(t)i i.i.d∼ pt. We define the sets Hk = {g : x → L(h(x), fk(x)); h ∈ H}. Moreover, the Rademacher complexity of a set Hk is defined as
Rm(Hk) = ESk[Eσ[supg∈Hk
m
X
i=1
σig(x(k)i )]]
where the expectations is taken over any sample Sk = {x(1)k , ..., x(m)k } ∼ ˆpk(m) and σi are iid variables uniformly distributed over {−1, 1} independent from X1, ..., XK.
Theorem 1. Assuming that the loss L is symmetric and follows the triangle inequality, then for any hypothesis h ∈ H, with probability 1 − δ the following bound holds:
t(h, ft) ≤
K
X
k=1
αkˆk(h, fk) + HDiscH,L(pt, pα) + ηH,α
+ 2
K
X
k=1
αkRm(Hk) + kαk2M
rln(1/δ) 2m
(3)
where
• ηH,α= min
h0∈H[α(h0, fα) + t(h0, ft)]
• Rm(Hk) is the Rademacher complexity of Hk= {h : x → L(h(x), fk(x)); h ∈ H}
Proof. We give a sketch of the proof. The full details can be found in Ap- pendix B. Using Proposition 1 with pα, we get:
t(h, ft) ≤ α(h, fα) + ηH(ft, fα) + HDiscH,L(pα, pk; h) (4) We then define φ = α(h, fα) − ˆα(h, fα). Using McDiarmid’s inequality [17] for φ, we obtain that with probability 1 − δ,
α(h, fα) ≤ ˆα(h, fα) + Epˆα[φ] + kαk2M
rlog 1/δ 2m
Then one can show using the usual ghost sample argument of Rademacher complexity that:
Epˆα[φ] ≤ 2
K
X
k=1
αkRm(Hk)
Noting that ˆα(h, fα) =PK
k=1αkˆk(h, fk) concludes the proof.
Theorem 1 gives a theoretical analysis in the multi-source domain adaptation framework. The first term corresponds to the α-weighted source risks and can be controlled by learning h close to fk. The second term connects the target distribution with the α-weighted source distribution. The third term is related to how different the labelling functions on the target and the source are and is expected to be small in unsupervised domain adaptation. The last two terms show the convergence rate of this bound and it was proven in [6] that Rm(Hk) = O(1/√
m) for some functions such as neural networks.
Then in order to adapt from sources S1, ..., Sk to the target, we need to mini- mize the hypothesis-discrepancy between the α-weighted domain and the target domain. We propose in Section 3 an algorithm to find ideal representations of the sources and weights to select the best sources for adaptation.
3 Adversarial algorithm for Multi-Source Do-
main Adaptation
3.1 Optimization objectiv: a min-max problem
We now present the practical solution derived from Theorem 1. We introduce a feature extractor parametrized by θ φθ: X → Z and a class of predictor HZ : Z → Y. Given unlabeled target sample Xt = {(x(t)1 , ..., x(t)n } ∈ Rn×d and K labeled sources Xk = {(x(k)1 , ..., x(k)m } ∈ Rm×d with labels Yk= {y(k)1 , ..., y(k)m } ∈ Rm, we want to minimize the combination of the source risk and the hypothesis- discrepancy between the marginal weighted source distribution and target dis- tribution as in Theorem 1.
Using the definition of HDisc, we formulate the following objective for our Adversarial Hypothesis-Discrepancy Multi-Source Domain Adaptation (AHD- MSDA):
min
φθ,h∈H kαk1=1
max
h0∈H
"K X
k=1
αkk(h ◦ φθ, yk) + λkαk2
+|t(h ◦ φθ, h0◦ φθ) −
K
X
k=1
αkk(h ◦ φθ, h0◦ φθ)|
# (5)
where λ is a hyperparameter. It was shown in [1] that if HZ is a subsect of µh- Lipschitz functions and φθ is continuous in θ then the discrepancy is continuous in θ and it also stands for hypothesis-discrepancy.
The first term of the objective forces h to be a good predictor on the source task.
For any given h and h0the discrepancy term constrains both representations φθ
Figure 1: MSDA: The adversarial scheme is similar to single-source with weights α. At each iteration, the weights α are udpated.
and weights α to align domains. The term ηH is ignored in our objective and assumed to be small.
This objective involves a min-max formulation that is similar to the ones used in adversarial domain adaptation [10]. While computing the true solution of this min-max problem is still impossible in practice, we derive an alternate optimization algorithm in the next section.
3.2 Adversarial Domain Adaptation
We display the general structure of our algorithm in Figure 1. Similarly to most other adversarial methods, we sequentially optimize differents parameters of our networks according to different objectives. At a given iteration, four losses are minimized sequentially:
1. Lh= αkk updates h to minimize the source loss 2. Lh0 = −HDisc updates h0 to maximize discrepancy 3. Lθ= HDisc +PK
k=1αkk updates φθto minimize discrepancy and source loss
4. Lα = HDisc + λ||α||2 updates α to minimize the discrepancy between α-weighted domain and target domain
The predictor h0can be seen as a discriminator in traditional adversarial domain adaptation methods. It is trained to give predictions close to h on one domain and far on another. The representations φθ are gradually updated against the discriminator. We include a source loss in its update as otherwise extracted features would be meaningless for the final task. The loss Lh ensures that h is performing well on the source domains.
In the loss Lα, we only included the discrepancy term. Indeed, our goal is to select the domains closer to the source in terms of discrepancy. Including the source loss in Lαmay give too high weights to sources that are ”easy” to predict.
It is possible to keep the term with a µ parameter to control its influence but in our experiments, it did not bring any improvement. It would also be possible
Algorithm 1 Pseudo-algorithm for AHD-MSDA
Initialize αk= K1, h, h0 and θ randomly, choose learning rates ηh, ηθ and ηα
for e = 1...epochs do Forward propagation
k= m1 Pm
i=1L(h(e)(φθ(e)(x(k)i ), y(k)i )) HDisc =
t(h(e)◦ φθ(e), h0(e)◦ φθ(e)) −
K
P
k=1
αkk(h(e)◦ φθ(e), h0(e)◦ φθ(e)) Backward propagation
h(e+1)← h(e)− ηh
PK
k=1α(e)k ∆hk(h(e))
. (∗) h0(e+1)← h0(e)+ ηh
PK
k=1α(e)k ∆h0HDisc(h0(e)) θ(e+1)← θ(e)− ηθ
PK
k=1αk(e)∆θk(θ(e)) + ∆θHDisc(θ(e)) α(e+1)k ← α(e)k − ηα
∆αkHDisc(α(e)k ) + 2λα(e)k Clip weights of φ(e+1)θ , h(e+1) and h0(e+1) α(e+1)= α(e+1)/kα(e+1)k1
end for
(∗) For a parameter p and a loss L, we note ∆pL(p0) the gradient of L with respect to p computed at p0
to completely update α at each epoch but we found it sub-performing. Our method allows the weights to smoothly adapt to the representations learnt by φθ.
We present a pseudo-algorithm in Algorithm 1. The order of the steps did not matter in our experiments. It is possible to include a short pre-training phase where hypothesis-discrepancy is not minimized as in the beginning of the training, representations and h may be meaningless and weights may be updated for unrelated sources. Our algorithm can also be applied in the single-source scenario by setting K = 1 and α = 1.
4 Related works
Relation with other measures. The hypothesis-discrepancy has several ad- vantages. Firstly, it can be estimated with finite samples (see Appendix C).
Moreover, it is dependent on the hypothesis class H and loss L so it is pos- sible to use in both classification and regression settings. The hypothesis- discrepancy is based on the discrepancy introduced in [14]: the original dis- crepancy is more conservative than our hypothesis-discrepancy as it is defined by Disc(P, Q) = suph∈HHDisc(P, Q; h). Our bound is tighter than the one of [14] or [8] as it involves only one supremum over H. The idea of discrepancy with only one supremum is also used in [12] with the source-discrepancy which is a specific case of our hypothesis-discrepancy with h = h∗s. While the bound is tighter than the original [14] it does not lead to efficient practical solutions.
The popular dH introduced in [3] for classification also involves only one supre- mum but often fails in practice for regression problems. Indeed, minimizing it aligns domains in a sense of classification and one can see on Figure 2 how in a simple linear regression problem dHwould fail. Our algorithm presented in the
next section is general to classification and regression.
Discrepancy minimization. While our method minimizes the new hypothesis- discrepancy, several methods worked on discrepancy minimization: in the orig- inal work [14], authors derive a quadratic formulation for `2-loss in regression where the goal is to re-weight each sample in the source domain and was later extended with kernels in [7]. Recently, discrepancy with linear regressors was used as a measure of distance between probabilities to train GANs [1]. Most works focusing on discrepancy have used specific values of the loss L and hy- pothesis class H to compute it: for instance, the `2-norm with linear regression was presented in the original work of [14], later extended to kernels [8] or even used to train GANs [1]. For classification, previous works used dH as it is a special case of discrepancy for binary classification.
Adversarial Domain Adaptation. The first work using adversarial learning for Domain Adaptation was introduced in [10] with the gradient reversal layer.
Using the bound of Ben-David [2], authors find a new representation that is discriminative for the task but where domains are confounded. [19] follows a similar idea. The main benefit of our method is that the adversarial structure is directly dependent on the task at hand. Maximum Classifier Discrepancy [18] is the closest idea to our practical solution even though they use a specific instance of discrepancy. Our HDisc-based algorithm is more general as it works for both regression and classification. To the best of authors’ knowledge, this is the first work proposing an adversarial domain adaptation tailored for regression.
Multi-Source Domain Adaptation. Other authors also proposed methods to compute weights for different sources. For instance, in [15], authors assume that the target distribution is a convex combination of the source distributions and derive optimal weights. [16] and [11], authors use the R´enyi divergence to derive ideal weights for each of the sources.
Other authors tried to attribute weights to different sources with an adversarial objective. Recently, [22] and [13] extended the adversarial framework of [10] to multi-source domain adaptation. Namely, they both prove extended previous bounds from single source DA based on dHand Wasserstein distance. [22] gives a bound for regression based on dH, but is based on the generalized VC-dimension for regression which is hard to use in practice. Moreover the adopted weighted scheme in their algorithm sequentially adapts the worst source to the target
Figure 2: Basic linear regression problem: source domain is in red and target in blue. Here using linear regressors and `2-loss, for any h, HDisc(Xs, Xt; h) = 0 but using linear classifiers dH(Xs, Xt) = 1 as domains are perfectly separable
which we assume to be suboptimal. [13] uses relationships between sources to get weights to adapt to the target using Wasserstein distance, which is not tailored for regression applications. A very recent pre-print [20] proposes a weighting scheme for multi-source DA using the original discrepancy of [14] in the linear regression case, similar to [1].
5 Experiments
In this section, we evaluate our method both in the multi-source (AHD-MSDA) and single-source scenario (AHDA) on several datasets. It should be noted that unsupervised Domain Adaptation is hard to evaluate as having no labeled sam- ples limits usage of classical comparison tools (cross-validation, hyperparameter tuning, ...). Hence we firstly use a synthetic dataset to test how our algorithm behaves. Secondly, we improve on previous state of the art results on an ex- tended version of the Multi-Domain Amazon Review dataset orginally used in [5]. We also applied our algorithm to a digit classification task for which we get comparable results with methods tailored for classification.
5.1 Synthetic Dataset (Friedman)
To generate synthetic data, we use a modified version of the Friedman regres- sion problem [9]. The Friedman dataset uses inputs x of dimension 5 and the prediction function is
y(x) = 10sin(πx1x2) + 20(x3− 0.5)2+ 10x4+ 5x5+ where ∼ N (0, σy).
To highlight the two contributions of this work, our goal is two-fold: we firstly want to demonstrate the effectiveness of HDisc in the single-source DA scenario (K=1 and α = 1). Then we run different experiments to show when multi- source DA is expected to bring an improvement.
We generate source data as follows: we define three clusters of sources {S1, S2, S3}, {S4, S5, S6} and {S7, S8, S9}. For each cluster, and for each feature (1...5), a mean of −1 or 1 is selected at random. Then each mean of each source of a given cluster is shifted by a random shift ie for a source k associated to a clus- ter c µ(f )k ∼ N (µc, σc). Finally, each source sample is randomly chosen with a normal distribution pk = N (µ(f )k , σk). In Figure 3, we display each feature of the generated data.
In order to separate the effects of our two contributions, we split the experi- ments in two parts: in the first experiment, demonstrate the effectiveness of our hypothesis-discrepancy minimization in the single source scenario (ie when αk= K1) and why the classical dH fails in this regression scenario. In a second scenario, we show how our weighting scheme helps adaptation in multi-source, especially to select sources that are related to the target.
Hypothesis-Discrepancy. For single-source, we merge all 9 source domains together to create one. The target sample is generated choosing uniformly one of the source domains for each element and adding a noise of the form N (µshif t, σshif t). This experiment helps to understand the purpose of unsupervised do- main adaptation. Indeed, as the underlying condition for unsupervised DA to
Figure 3: Data for the single-source Friedman experiment over the 5 features with σk = 0.2, σc = 0.2, µshif t= 0.5, σshif t= 0.5. From right to left: (x0, x1)
; (x2, x3); (x4; x0). Each color corresponds to a source, the target is in black.
(a) Validation loss on source data (b) Target loss
Figure 4: Training curves for Single Source DA: without adaptation, the target loss increases as the validation loss keeps decreasing. DANN exposes the same behaviour as the target loss of AHDA decreases.
work is that the labelling function is similar in every domain (ηH small in our experiments), unsupervised DA is closely related to the issue of generalization.
As a consequence, if the algorithm learnt on the source data is able to general- ize, domain adaptation will not bring any improvement. As such, one can see unsupervised DA as a data-driven regularization to improve the target risk.
For this experiment, we use a shallow network with 2 layers with 5 neurons and LeakyRelu activation for the feature extractor and 1 layer for the final predic- tor as detailed in Appendix D. We keep this architecture for three methods:
Multi-Layer Perceptron (MLP) without adaptation, Domain-Adversarial Neu- ral Network (DANN) minimizing the dHbetween domains and our Adversarial Hypothesis-Discrepancy Adaptation (AHDA) our method in the case of single source (no weights α). To get the results for DANN, we tuned then hyper- parameter µ balancing the regression and domain losses: without this tuning, DANN always fails to converge because its adversarial scheme is related to classification.
We conducted the experiments with various amount of shift. In Figure 4, we report the validation loss (computed validation set different from the training set) and target loss for each method for σx= 0.2, µshif t= 0.5 and σshif t = 0.5, which is the case of target data related but not too close to the source domain plottend on Figure 6. While MLP and DANN overfit on the source data, our method is able to decrease the target loss. Hence, our adversarial scheme helps the algorithm to better learn for the target data. We report in Table 1 the average MSE scores over ten runs for the three methods and various shifts. One can notice that the further µshif t is, the more useful the adaptation is. We also
(a) One cluster with uniform weights (b) Two clusters with uniform weights
Figure 5: Friedman Multiple Source experiment: α found by AHD-MSDA (blue) vs True α (orange)
report in Appendix D a visualization of the extracted features from AHDA and DANN which shows that DANN tries to align domains only to be able not to separate them while AHDA is constrained by the final regression task.
µshif t 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
MLP 0.221 0.214 0.260 0.360 0.510 0.695 0.909 1.132 1.322 1.484 1.632 DANN 0.223 0.235 0.296 0.412 0.581 0.784 1.017 1.258 1.462 1.629 1.772 AHDA 0.222 0.214 0.255 0.350 0.490 0.670 0.881 1.044 1.197 1.392 1.446
Table 1: Single source domain adaptation: MSE for different amounts of shift.
Multi-Source DA. We also tried our multi-source algorithm on the previous target domain. As we expected, multi-source domain adaptation did not bring any improvement in the previous scenario as the target was sharing the same relations with every source. But MSDA is particularly interesting in the case where some of the sources are not useful for adaptation. We demonstrate it in an experiment where we control the weights α given to each source in the creation of the target domain.
In a first experiment, we give equal weights α1,2,3= 1/3 to every source in one cluster and α4:9 = 0 for every other cluster. In a second experiment, we gave equal weights to two clusters α1:6 = 1/6 and α7:9 = 0 In both experiments, and on different runs, the algorithm was able to retrieve weights close to the real ones. It was translated by a decrease of the target loss. When putting weights to only one source in a cluster, our algorithm struggled to identify a specific source but still gave high weight to sources in the same cluster. In some experiments where sources were very different from each other (no cluster), we noticed a tendency for α to give 1 for one source and 0 for all the others. It can be meaningful as the target may be close to only one source in that case or be balanced using the λ parameter of the `2 regularization.
Discussion. Based on this toy experiment, we can conclude that our AHD- MSDA and AHDA perform well for regression under the condition that the labelling functions are the same. The proposed weighting scheme is performing well when sources have really different relations to the output. The main lim- itation we found to HDisc is that since it is dependent on h, its estimation is hard, especially in regression where values are not constrained. As we have seen the weighting scheme mainly helps when the target data is close to only few of
Dataset apparel auto baby beauty books camera cellphones computer dvd
MLP 0.897 0.902 0.841 0.880 1.024 0.923 0.871 0.842 0.912
DANN 0.929 1.017 0.893 0.878 1.141 0.944 1.051 1.135 1.052
AHDA 0.837 0.887 0.840 0.860 0.945 0.893 0.859 0.849 0.882
MDAN 0.980 0.797 0.908 0.973 1.234 0.921 0.954 1.749 1.322
AHD-MSDA 0.859 0.767 0.794 0.790 0.969 0.876 0.825 0.770 0.868
Dataset electronics food grocery health jewelry kitchen magazines music musical
MLP 0.833 0.882 0.774 0.869 0.759 0.851 0.960 0.976 0.778
DANN 1.064 1.036 0.793 0.955 0.783 0.856 0.985 1.293 0.727
AHDA 0.844 0.866 0.796 0.851 0.815 0.849 0.909 0.955 0.895
MDAN 1.041 0.820 0.789 0.987 0.755 0.850 1.295 1.330 1.117
AHD-MSDA 0.815 0.849 0.716 0.840 0.715 0.848 0.911 0.991 0.723
Dataset office outdoor software sports tools toys video Average Avg rank
MLP 0.969 0.831 0.924 0.844 0.823 0.873 0.866 0.892 3.12
DANN 0.854 0.803 1.090 0.850 0.888 0.861 1.00 0.955 3.92
AHDA 0.956 0.851 0.880 0.839 0.813 0.864 0.878 0.868 2.52
MDAN 1.041 0.789 0.964 0.910 1.656 0.843 1.467 1.060 3.96
AHD-MSDA 0.882 0.755 0.858 0.814 0.741 0.873 0.883 0.838 1.48
Table 2: Average MAE over 5 runs for each method and domain of the Amazon Multi-Domain Dataset
the sources. In the next experiment, we show how our algorithm performs on a real world dataset.
5.2 Multi-Domain Amazon Dataset
We use the extended version of the Multi-Domain Sentiment Dataset1 with 25 categories (books, dvd, ...). The dataset is made of textual reviews from Amazon and associated ratings. We treat it as a regression problem where the goal is to predict the rating based on the review. As in previous papers [22]
[10], we transform the data using tf-idf transform and filtering only the 1, 000 words with highest coefficients.
Similarly to the reduced dataset for classification [5], we kept 2, 000 samples for each category (or less when there was not 2, 000 available). We alternate on each category as a target and use every other category as a source.
In order to study the performance of our method AHD-MSDA, we compare it to several other baselines on different datasets:
• MLP corresponds to merging all sources and applying to the target dataset without adaptation.
• DANN corresponds to merging all sources into one and applying the DANN from [10].
• AHDA corresponds to merging all sources into one and applying our adversarial scheme using discrepancy specific to the task.
• MDAN is a multi-source domain adaptation based on the dH distance proposed in [22]. It gives high weights to sources far from the target (we used the soft version).
• AHD-MSDA is our method described in Algorithm 1.
We also experimented the Multi-Domain Matching Network (MDMN) that uses Wasserstein distance between sources and the target to give weights but it did not perform well at all for regression as the adversarial structure is not well conditioned for regression. For DANN and MDAN the predictors have been specified to regression by changing the last layer by a regression layer and loss with mean squared error. The implementation of MDAN is inspired from the original implementation from the authors. 2. We tried some methods to
1https://www.cs.jhu.edu/~mdredze/datasets/sentiment/
2https://github.com/KeiraZhao/MDAN
pre-compute weights for our multi-source algorithm based on different distances between domains but at best it led to similar results to AHDA so we do not report it here.
For fair comparison, the basic architecture is kept the same for every method (see Appendix E). We tried different architectures and came to the same con- clusion. For every method, we use Adam optimizer. Hyperparameter selection in unsupervised domain adaptation is a hard task as no labeled target data is available. For DANN and MDAN, we tried different sets of values and only report the ones giving the best results on test data which is very advan- tageous and normally not possible for unsupervised DA (λ = 0.01 for DANN, γ = 10, µ = 0.1 for MDAN which are the hyperparameters they used in the classification setting). For our algorithm, the only hyperparameter is λ for `2- regularization of α for which we tried several values and we report results for λ = 1 here as we did not notice significant differences for values betwenn 10−3 and 10.
We ran the experiment 5 times and report the average MAE for each method in Table 2. The standard deviations are around 0.01 for AHD-MSDA and AHDA (see Appendix E) and for most domains, improvements are statistically significants using a Wilcoxon rank test. While the gains over the MLP with no adaptation may seem small, we emphasize that obtaining an improvement is already challenging as the MLP can already learn general features with the variety of data it is feeded. For most domains, AHD-MSDA obtains the best result with multi-source bringing an improvement over AHDA for many domains. One can notice the instability of DANN and MDAN for a few number of domains where the error becomes very large.
Overall, the AHDA achieves the best score and shows its efficiency for ad- versarial regression domain adaptation. The weights obtained by our method were meaningful for some domains (giving high weight for software to transfer to computer for instance) but not for all. We assume that the efficiency of the method is very dependent on the nature of the dataset as even in this case, for some domains, every adaptation method we tried fails.
5.3 Digit classification
Finally, we experiment our method on a digit classification task using 5 different domains: MNIST, MNIST-M, Synth, SVHN and USPS. SVHN and USPS are known to be the hardest datasets to classify as they are much more diverse. In each experiment, we use one domain as the target and the 4 others as the sources.
We resize all domains to images made of 28 × 28 pixels. For fair comparison we use the same architecture for every network, using a simple convolutional neural network (CNN see Appendix F for details). For this experiment, we use a reduced version of the datasets with 10, 000 samples in each domain.
Since we are in a classification setting, the loss used to train AHDA and AHD- MSDA cannot be the Mean Squared Error. We found that the cross-entropy loss was performing better than the `1-loss, so we use it to compute HDisc (even though it does not follow triangle inequality). Our adversarial structure becomes very close to the MCD introduced in [18] and our weighting scheme extends this structure to a multi-source setting.
We report the accuracy for each dataset and each method in Table 3. One can see that for a classification task, our HDisc still gives state of the art results
Dataset MNIST MNIST-M SVHN Synth USPS
CNN 0.916 0.450 0.489 0.562 0.624
DANN 0.918 0.530 0.546 0.710 0.659
AHDA 0.912 0.512 0.510 0.769 0.667
MDAN 0.923 0.460 0.488 0.671 0.574
AHD-MSDA 0.923 0.518 0.501 0.793 0.657
Table 3: Accuracy for the visual adaptations on digit datasets
compared to other methods tailored for classification. For MNIST, even without adaptation, the CNN can learn general features from other datasets. MDAN fails as it gives high weights to datasets that are not similar (such as USPS for SVHN) while our AHD-MSDA does not suffer from this drawback.
6 Conclusion
In this work we proposed a new general domain adaptation bound based on a new hypothesis-discrepancy compatible with classification and regression. We proposed an adversarial domain adaptation algorithm tailored for the task at hand, which is novel for regression. We extended these results to multiple sources to find ideal convex combinations of the sources. We demonstrated the efficiency of our method for a regression task for which we improved on previous state of the art results. For a classification task, AHD-MSDA obtains comparable results to other state of the art results. We emphasize that in the multi-source setting, our weighting scheme limits the risk of negative transfer.
As we saw in our experiments, we mainly expect improvements of the multi- source method when some domains are really closer to other forming clusters.
The main limitation of our work comes from the assumption of unsupervised domain adaptation that the labelling functions are the same in every domain.
In our future work, we intend to investigate the semi-supervised and few-shot learning settings, where a few labeled target data is available.
References
[1] Adlam, B., Cortes, C., Mohri, M., Zhang, N.: Learning gans and ensembles using discrepancy. In: Advances in Neural Information Processing Systems.
pp. 5788–5799 (2019)
[2] Ben-David, S., Blitzer, J., Crammer, K., Kulesza, A., Pereira, F., Vaughan, J.W.: A theory of learning from different domains. Machine learning 79(1- 2), 151–175 (2010)
[3] Ben-David, S., Blitzer, J., Crammer, K., Pereira, F.: Analysis of represen- tations for domain adaptation. In: Advances in neural information process- ing systems. pp. 137–144 (2007)
[4] Ben-David, S., Lu, T., Luu, T., P´al, D.: Impossibility theorems for do- main adaptation. In: International Conference on Artificial Intelligence and Statistics. pp. 129–136 (2010)
[5] Blitzer, J., Dredze, M., Pereira, F.: Biographies, bollywood, boom-boxes and blenders: Domain adaptation for sentiment classification. In: Pro- ceedings of the 45th annual meeting of the association of computational linguistics. pp. 440–447 (2007)
[6] Cortes, C., Gonzalvo, X., Kuznetsov, V., Mohri, M., Yang, S.: Adanet:
Adaptive structural learning of artificial neural networks. In: Proceedings of the 34th International Conference on Machine Learning-Volume 70. pp.
874–883. JMLR. org (2017)
[7] Cortes, C., Mohri, M.: Domain adaptation and sample bias correction theory and algorithm for regression. Theoretical Computer Science 519, 103–126 (2014)
[8] Cortes, C., Mohri, M., Medina, A.M.: Adaptation based on generalized discrepancy. The Journal of Machine Learning Research 20(1), 1–30 (2019) [9] Friedman, J.H.: Multivariate adaptive regression splines. The annals of
statistics pp. 1–67 (1991)
[10] Ganin, Y., Ustinova, E., Ajakan, H., Germain, P., Larochelle, H., Lavi- olette, F., Marchand, M., Lempitsky, V.: Domain-adversarial training of neural networks. The Journal of Machine Learning Research 17(1), 2096–
2030 (2016)
[11] Hoffman, J., Mohri, M., Zhang, N.: Algorithms and theory for multiple- source adaptation. In: Advances in Neural Information Processing Systems.
pp. 8246–8256 (2018)
[12] Kuroki, S., Charoenphakdee, N., Bao, H., Honda, J., Sato, I., Sugiyama, M.: Unsupervised domain adaptation based on source-guided discrepancy.
In: Proceedings of the AAAI Conference on Artificial Intelligence. vol. 33, pp. 4122–4129 (2019)
[13] Li, Y., Carlson, D.E., et al.: Extracting relationships by multi-domain matching. In: Advances in Neural Information Processing Systems. pp.
6798–6809 (2018)
[14] Mansour, Y., Mohri, M., Rostamizadeh, A.: Domain adaptation: Learning bounds and algorithms. COLT 2009 - The 22nd Conference on Learning Theory (02 2009)
[15] Mansour, Y., Mohri, M., Rostamizadeh, A.: Domain adaptation with mul- tiple sources. In: Advances in neural information processing systems. pp.
1041–1048 (2009)
[16] Mansour, Y., Mohri, M., Rostamizadeh, A.: Multiple source adaptation and the r´enyi divergence. arXiv preprint arXiv:1205.2628 (2012)
[17] McDiarmid, C.: Concentration. In: Probabilistic methods for algorithmic discrete mathematics, pp. 195–248. Springer (1998)
[18] Saito, K., Watanabe, K., Ushiku, Y., Harada, T.: Maximum classifier dis- crepancy for unsupervised domain adaptation. In: Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition. pp. 3723–3732 (2018)
[19] Tzeng, E., Hoffman, J., Saenko, K., Darrell, T.: Adversarial discriminative domain adaptation. In: Proceedings of the IEEE Conference on Computer Vision and Pattern Recognition. pp. 7167–7176 (2017)
[20] Wen, J., Greiner, R., Schuurmans, D.: Domain aggregation networks for multi-source domain adaptation. arXiv preprint arXiv:1909.05352 (2019) [21] Xu, Z., Sun, S.: Multi-source transfer learning with multi-view adaboost.
In: International conference on neural information processing. pp. 332–339.
Springer (2012)
[22] Zhao, H., Zhang, S., Wu, G., Moura, J.M., Costeira, J.P., Gordon, G.J.:
Adversarial multiple source domain adaptation. In: Advances in neural information processing systems. pp. 8559–8570 (2018)
A Proof of Proposition 1
Proof. For any h ∈ H, and any k ∈ {1, ..., K}
t(h, ft) ≤ k(h, fk) + |t(h, ft) − k(h, fk)|
≤ k(h, fk) + |t(h, h0) − t(h, ft)| + |k(h, h0) − k(h, fk)| + |t(h, h0) − k(h, h0)|
≤ k(h, fk) + HDiscH,L(pk, pt; h) + Ex∼pt[|L(h(x), h0(x)) − L(h(x), ft(x))|]
+ Ex∼pk[|L(h(x), h0(x)) − L(h(x), ft(x))|]]
≤ k(h, fk) + HDiscH,L(pk, pt; h) + Ex∼pt[|L(h0(x), ft(x))|] + Ex∼pk[|L(h0(x), fk(x))|]
≤ k(h, fk) + k(h0, fk) + t(h0, ft) + HDiscH,L(pk, pt; h)
where the first inequality comes from the triangle inequality, the second holds for any h0 ∈ H. The third comes from the definition of HDisc(pk, pt) and the fourth follows from triangle inequality on L. Finally, the result follows taking the minimum over all h0.
B Proof of Theorem 1
Proof. Using Proposition 1 with pα, we get:
t(h, ft) ≤ α(h, fα) + ηH(ft, fα) + HDiscH,L(pα, pt; h) (6) Let us consider K empirical distributions ˆpk corresponding to a sample Sk = {x(k)1 , ..., x(k)m of size m and a hypothesis h ∈ H. Then the α-weighted sample Sα
is of size Km and empirical distribution ˆpαdefined as ˆpα(x(k))i = αmk. We define φ = α(h, fα) − ˆα(h, fα). Changing an element x(k)i modifies φ by a maximum of αmk. We can deduce from the McDiarmid’s inequality that:
P(φ − E(φ) ≤ t) ≤ exp
−2mt2 PK
k=1α2k
Hence with probability 1 − δ,
α(h, fα) ≤ ˆα(h, fα) + Epˆα[φ] + kαk2M
rlog 1/δ
2m (7)
We are able to compute Epˆαusing the classical tool of ghost sample in Rademacher complexity analysis as in the proof of Theorem 2 in [14]. In the following we will use a random variable σ taking its values uniformly over {−1, 1}. We will write {x(k)i ; 1 ≤ k ≤ K, 1 ≤ i ≤ m} the sample associated to ˆpα ∼ pα and {z(k)i ; 1 ≤ k ≤ K, 1 ≤ i ≤ m} ˆqα∼ pα.
Epˆα∼pα[φ] = Epˆα[α(h, fα) − ˆα(h, fα)]
≤ Epˆα∼pα[ sup
h∈H
α(h, fα) − ˆα(h, fα)]
≤ Epˆα∼pα[ sup
h∈HEqˆα∼pα[Ex∼ ˆqα[L(h(x), fα(x))]] − Ex∼ ˆpα[L(h(x), fα(x))]
≤ Epˆα, ˆqα∼pα[ sup
h∈HEx∼ ˆqα[L(h(x), fα(x)] − Ex∼ ˆpα[L(h(x), fα(x)]
≤ Epˆα, ˆqα∼pα[ sup
h∈H K
X
k=1
αk(Ex∼ ˆqk[L(h(x), fk(x)) − Ex∼ ˆpk[L(h(x), fk(x)))]
≤ Epˆα, ˆqα∼pα[ sup
h∈H K
X
k=1
αk
m
m
X
i=1
(L(h(x(k)i ), fk(x(k)i )) − L(h(z(k)i ), fk(z(k)i )))]
≤ Epˆα, ˆqα∼pα
σi∼σ
[ sup
h∈H K
X
k=1
αk m
m
X
i=1
σi(L(h(x(k)i ), fk(xi(k))) − L(h(z(k)i ), fk(z(k)i )))]
≤ Epˆα∼pα
σi∼σ[ sup
h∈H K
X
k=1
αk
m
m
X
i=1
σiL(h(x(k)i ), fk(x(k)i ))]
+ Eqˆα∼pα
σi∼σ [ sup
h∈H
−
K
X
k=1
αk
m
m
X
i=1
σiL(h(zi(k)), fk(zi(k)))]
≤ 2Epˆα∼pα σi∼σ [ sup
h∈H K
X
k=1
αk
m
m
X
i=1
σiL(h(x(k)i ), fk(x(k)i ))]
≤ 2
K
X
k=1
αkRm(Hk)
(8) Finally, noting that with empirical distributions ˆα(h, fα) =PK
k=1αkˆk(h, fk), we have the final result with probability 1 − δ over the sample of S1, ..., SK:
t(h, ft) ≤
K
X
k=1
αkˆk(h, fk) + HDiscH,L(pt, pα) + ηH,α
+ 2
K
X
k=1
αkRm(Hk) + kαk2M
rln(1/δ) 2m
(9)
C Empirical bound for the hypothesis-discrepancy
Like the original discrepancy, for any h ∈ H, HDisc(., .; h) is symmetric and can be estimated with finite samples. In Theorem 2, we give a bound for em- pirical distributions. With Hs = {h : x → L(h(x), fs(x)} and Ht = {h : x → L(h(x), ft(x)}, and the empirical source risk ˆs(h, fs) =Pm
i=1 1
mL(h(x(s)i ), fs(x(s)i )).
Theorem 2. We assume that the loss L is symmetric, follows the triangle inequality and verifies L(h(x), y) ≤ M for all h ∈ H and (x, y) ∈ X × Y. Then for any hypothesis h ∈ H, with probability 1 − δ over the samples of Ssof size m according to ps and Stof size n according to pt the following bound holds:
t(h, ft) ≤ˆs(h, fs) + ηH(fs, ft) + HDiscH,L( ˆpt, ˆps; h) + 4Rm(Hs) + 2Rn(Ht) + 2M
rlog 2/δ 2m + M
rlog 2/δ 2n
(10)
where Rm(Hs) and Rn(Ht) are the Rademacher complexities of Hs and Ht defined in Appendix ??.
Proof. The proof is similar to the ones of [14]. Let us consider the empirical distribution ˆpscorresponding to a sample Ssof size m and a hypothesis h ∈ H.
We first define φ(h) = s(h, fs) + HDisc(ps, pt; h) − ˆs(h, fs) + HDisc( ˆps, pt; h).
Then as the loss L is bounded by M, changing one element of Ss will changes φ(h) by a maximum of 2Mm. McDiarmid’s inequality states that with probability 1 − δ2,
s(h, fs)+HDisc(ps, pt; h) ≤ ˆs(h, fs)+HDisc( ˆps, pt; h)+Epˆs[φ(h)]+2M
rlog(2/δ) 2m Moreover, from Theorem 2 and Proposition 2 from [14], we know that
• Epˆs[s(h, fs) − ˆs(h, fs)] ≤ 2Rm(Hs)
• Epˆs[HDisc( ˆps, pt; h) − HDisc( ˆps, pt; h)] ≤ 2Rm(Hs) where Hs= {x → L(h(x), fs(x)); ∀h ∈ H}
As a consequence, with probability 1 −δ2 over the sampling of Ss:
s(h, fs)+HDisc(ps, pt; h) ≤ ˆs(h, fs)+HDisc( ˆps, pt; h)+4Rm(Hs)+2M
rlog(2/δ) 2m Using Proposition 2 from [14] we obtain that with probability 1 − δ2 over the sampling of St :
HDisc( ˆps, pt; h) ≤ HDisc( ˆps, ˆpt; h) + 2Rm(Hs) + M
rlog(2/δ) 2n
Hence using an union bound, we have the final result with probability 1 − δ:
t(h, ft) ≤ˆs(h, fs) + ηH(fs, ft) + HDiscH,L( ˆpt, ˆps; h) + 4Rm(Hs) + 2Rn(Ht) + 2M
rlog 2/δ 2m + M
rlog 2/δ 2n
(11)
Figure 6: Data for the multiple source domain adaptation with α = {1/6, 1/6, 1/6, 1/6, 1/6, 1/6, 0, 0, 0} (2 clusters with uniform weights)
D Details for the Friedman experiment
We display the obtained data in Figure 6 where only two clusters are selected to generate the target data. Every implementation has been made in Python and the method has been implemented using the Pytorch library.
The network architecture is kept the same for every method as follows:
• Feature extractor:
– Linear (5, 10, ELU ), – Dropout (0.2) – Linear (10, 5), – Dropout (0.2)
• Predictor/Discriminator:
– Linear (5, 1)
We use SGD optimizer with lr = 0.001 and momentum 0.9. The batch size is set to 32 in every experiment.
In Figure 7, we report one of the features extracted by AHDA and DANN against y. As the final layer is linear, we expect a linear relationship, which is done by AHDA while DANN tries to align domains in the sense of classifica- tion.
E Details about Sentiment analysis Experiments
The architecture is kept the same for each method:
• Feature extractor:
– Linear (1000, 500, LeakyRELU ), – Dropout (0.1)
– Linear (500, 20, LeakyRELU ), – Dropout (0.1)
• Predictor/Discriminator:
– Linear (20, 1)
Figure 7: X-axis: Extracted features (before the final predictor) using AHDA (left) and DANN (right) ; Y-axis: labels to predict (y)
We tried different architectures and the conclusions were the same: adversarial hypothesis discrepancy performs the best out of other compared methods. For every method, we use Adam optimizer with learning rate lr = 0.001 and a batch size equal to 128. We give equal amount of data from each domain in each batch.
Every time, we take one product as the target and every other as the source.
Each network is trained for 100 epochs. In
Dataset apparel automotive baby beauty books camera cellphones computer dvd
MLP 0.011 0.007 0.004 0.011 0.016 0.01 0.004 0.008 0.009
DANN 0.037 0.15 0.039 0.04 0.112 0.06 0.08 0.167 0.137
AHDA 0.007 0.016 0.012 0.009 0.008 0.008 0.015 0.012 0.018
MDAN 0.025 0.048 0.051 0.051 0.32 0.051 0.042 0.274 0.162
AHD-MSDA 0.007 0.04 0.002 0.015 0.017 0.009 0.015 0.016 0.014
Dataset electronics food grocery health jewelry kitchen magazines music
MLP 0.009 0.011 0.004 0.005 0.008 0.005 0.008 0.009
DANN 0.079 0.166 0.017 0.059 0.019 0.027 0.106 0.236
AHDA 0.011 0.012 0.011 0.011 0.018 0.006 0.009 0.023
MDAN 0.049 0.055 0.02 0.057 0.029 0.01 0.438 0.285
AHD-MSDA 0.01 0.01 0.008 0.006 0.036 0.014 0.014 0.018
Dataset musical office outdoor software sports tools toys video
MLP 0.012 0.035 0.007 0.007 0.006 0.028 0.006 0.01
DANN 0.052 0.118 0.013 0.147 0.034 0.264 0.044 0.101
AHDA 0.018 0.014 0.009 0.012 0.009 0.031 0.012 0.014
MDAN 0.082 0.09 0.005 0.049 0.045 0.315 0.024 0.09
AHD-MSDA 0.035 0.053 0.01 0.013 0.017 0.072 0.009 0.017
Table 4: Standard deviation of the MAE for each method and each dataset over 5 runs
F Details about Visual adaptation Experiments
Each dataset is formed with 20, 000 samples and resized to 28 × 28 pixels. The architecture is kept the same for every method:
• Feature extractor:
– Conv2d (1, 64, 3, padding = 1) with LeakyReLU – MaxPool2d (2)
– Conv2d (64, 128, 3, padding = 1) with LeakyReLU – M axP ool2d(2)
