Dark-field Z-scan imaging technique

(1)

Invited Paper

Dark- ﬁ eld Z-scan imaging technique

Hongzhen Wang, Christophe Cassagne, Hervé Leblond, Georges Boudebs

ⁿ

LUNAM Université, Université d’Angers, LPhiA, Laboratoire de Photoniques d’Angers, EA 4464, 49045 Angers Cedex 01, France

a r t i c l e i n f o

Article history:

Received 9 October 2015 Received in revised form 14 December 2015 Accepted 15 December 2015

Keywords:

Z-scan

Dark-ﬁeld microscopy Third-order nonlinearity Phase object

a b s t r a c t

We report on Dark-Field Z-scan (DFZ-scan) as a new imaging technique combining Z-scan method with Dark-ﬁeld microscopy in order to measure optical refraction nonlinearity. Numerical and experimental results are provided to validate this concept. The image of the induced phase shift is spatially resolved without introducing a complex interferometric setup. Moreover, the experimental results show almost 3 times increase of the sensitivity when compared to the conventional Z-scan method. New perspective of microscope laser scanning is introduced.

1. Introduction

There are many nonlinear (NL) optical characterization techniques with proper advantages and inconveniences. Starting with the degenerated four-wave mixing [1] which only gives the modulus of the nonlinear susceptibilities, reaching gradually nonlinear imaging technique [2] combining simplicity and ele- gance with Z-scan method[3,4]. Z-scan is able to distinguish the real from the imaginary part of the nonlinear optical susceptibility.

It is found to be the most widely used technique in this field nowadays. Since its apparition so far it is being improved in a continuous way through Eclipsed Z-scan[5], Dual-arm Z-scan[6], and D4s-Z-scan [7]. Other efficient techniques have emerged, briefly we will only mention: the beam deflection measurement technique[8]and the Scattered Light Imaging Method (SLIM)[9]

showing that new methods to characterize NL response of the material are still relevant and subject to active research, in order to ﬁnd simple and sensitive ways to measure, especially, the induced nonlinear refraction at high intensity despite the presence of relatively high NL absorption. Other original characteristics include two stacked samples to be measured in a single run[10] where one material could be used as a reference.

The purpose of this paper is to demonstrate the feasibility of a new optical measurement technique based on darkfield microscope configuration combined with Z-scan method. The experimental acquisitions are performed and compared with related numerical simulations. The use of an annular illumination light and a magnified image of the focal plane, where the NL material is

moving, provides new characteristics in the measured signal. The darkﬁeld microscopy leads to a dark background image on which the observation of small structures stands out, clearly increasing the contrast in the NL diffracted energy. One can thus obtain images of the induced phase shift spatially resolved without re- quiring the introduction of a complex interferometric technique [11]. The gain in sensitivity and intrinsic advantageous using this method are speciﬁed.

2. Principle of the measurement and theory

The Dark-ﬁeld microscopy and Z-scan method are mature and popular techniques. The result of their combination will be labeled as DFZ-scan. The setup used to implement the DFZ-scan is pre- sented inFig. 1.

The system is composed of two subsystems: thefirst one with lens L1 (20 cm focusing length) is used to focus an annular illumination delivered by the object (O(x,y)) into the sample positioned at z in the focal region, the second subsystem is used to obtain a magnified image onto the CCD. This imaging subsystem is composed of lens L2 (10 cm focusing length) positioned in such a way as to obtain a 5x magnification by adjusting the distance d between the focal plane of L1 and lens L2 to be equal to 12 cm;

while the distance D between L2 and the CCD, has beenﬁxed to 60 cm (see Fig. 1). Fixed to L2 a circular aperture C is inserted where the radius is adjusted in such a way as to block the direct rays coming from the annular illumination (seeFig. 1). The sample (NLM) is mounted on a translation stage and moved along the beam direction (z axis) around the focal point. For each step of the motor (1 mm), one image is recorded by a CCD camera. A second arm is used to monitor the energyﬂuctuation of the incident laser Contents lists available atScienceDirect

journal homepage:www.elsevier.com/locate/optcom

Optics Communications

nCorresponding author.

E-mail address:[email protected](G. Boudebs).

(2)

pulses (via lens L3). While moving the sample, the self-diffraction on the induced NL phase-shift (and/or absorption) pattern origi- nates changes in the transmitted beam. A part of this beam (blue dashed line inFig.1) passes through the circular aperture C cen- tered on lens L2, which act as a spatialﬁlter blocking the direct light (red solid line inFig.1) and preventing direct optical rays from reaching the CCD, thus obtaining relatively dark image in the ab- sence of any nonlinearity. In our experiment, the material is moved along z (the optical axis) to vary the intensity inside the material. When the incident intensity is high enough, self-diffraction of the light on the induced phase spatial modulation in the nonlinear material is imaged through the lens L2. Then, measuring the change of the diffracted light in the image plane allows the detection of a characteristic signal related to nonlinearities.

Theoretically, the whole system is described with basis on Fourier optics[12]. The general scheme of beam propagation inside the system is similar to that described in[7], [13]and [14], where we must pay attention to the lens L2 which is not positioned in the same way as in the usual 4f system. To summarize the beam propagation and for self-consistency, let us consider E(x,y) as the amplitude ﬁeld at the entry of the setup,xand ybeing the spatial coordinates. At the output of the annular aperture, theﬁeld is described as O(x,y)¼E(x,y)t1 (x,y), where t1(x,y) is the transmittance of this aperture.

The spatial spectrum of the object is given by

∫ ∫

π

( ) = ˜ [ ( )] = ( ) [ − ( + )]

−∞

+∞

−∞

- +∞

S u v, O x y, O x y, exp j2 ux vy dxdy where-˜ denotes the Fourier transform operation, u and v are the normalized spatial frequencies. In general, the ﬁeld is propagated over a distancez′ by taking into account the transfer function of the wave propagation phenomenon

(

^π ^λ ^λ ^λ

)

( ′) = ′ − ( ) − ( )

H u v z, , exp 2j z 1 u² v²/ , where

λ

is the wave- length. Then theﬁeld amplitude atz′is obtained by computing the inverse Fourier transformE x y z′( , , ′) = ˜-⁻¹[ (S u v H u v z, ) ( , , ′)]. To calculate the output beam after passing through a lens with focal lengthf, we apply the phase transformation related to the thickness variation: t x yL( , ) =exp[−jπ(x2+y2)/λf]. The ﬁrst

propagation is performed on a distance z′ =f from the object plane to L1. Then we propagate the beam up to the sample located at z using z′ =f+z in the optical transfer function H.

Next, the NL response of the material is taken into account, before continuing the propagation with the same formalism up to the image plane of L2 considering z′ =d−zbefore this lens, and z′ =Dafter it.

We assume cubic nonlinearity and a thin NL medium of thickness L exhibiting (i) linear absorption defined byα(m¹), (ii) two-photon absorption defined by β(m/W) and (iii) NL refraction defined byn2(m²/W). In these conditions, the transmittance of the sample is described by

α ϕ

( ) = {[ + ( )] ( )}⁻ ⎡⎣ Δ ( )⎤⎦ ( )

T u v z, , 1 q u v z, , exp L ^1/2exp j NLeff u v z, , , 1

where q u v z( , , ) =βL I u v zeff ( , , ) with Leff= [1−exp(−αL)]/α, and

( )

I u v z, , , related to the input electricﬁeld S u v z( , , )², denotes the intensity of the laser beam within the sample. The NL phase shift is

ϕ π λ

Δ _NL^eff(u v z, , ) =2 n L2 eff effI (u v z, , )/ , where we deﬁne the effective intensity as Ieff(u v z, , ) = (I u v z, , )ln 1[ +q u v z( , , )]/q u v z( , , ). To characterize more simply the nonlinearities we use the on-axis at the focus NL absorption q0=βL Ieff 0 and the NL phase shift

φ ϕ

Δ ₀= Δ _NL^eff(0, 0, 0), whereI0is the focal on-axis intensity.

3. Experimental details and numerical simulation

Before starting the DFZ-scan experiments we used the 4f system [15] which was aligned carefully to obtain a magnification equal to 1, in such a way that it was possible to characterize accurately the profile of the annular beam at the entry in the linear regime (Fig. 2). The image of the annular home-made object is registered in the computer allowing to take into account the real profile of the object when necessary, and to measure the size of the object to adjust the radius of C. The dimensions of the annular object gave the following results: the mean value ofRi, the inner radius of the disc, was equal to 0.73 mm andRe, the outer radius, was 1.58 mm (Fig. 2). These values are used in the simulation defining the object as

( ) = +

− +

( )

⎛

⎝

⎜⎜

⎞

⎠

⎟⎟

⎛

⎝

⎜⎜

⎞

⎠

⎟⎟ O x y circ x y

R circ x y

, R ,

e i 2

2 2 2 2

BS

1

BS

2

M

2

M

1

C (x,y) O (x,y)

f f d D

L

1

O

L

2

NLM

CC D

C

z Z

L

3

Fig. 1.Darkﬁeld Z-scan imaging system. The sample (NLM) is scanned along the beam direction around the focal plane (z=0). The labels refer to: annular illumination (O), circular aperture (C), lenses (L1, L2 and L3), beam splitters (BS1 and BS2), CCD camera (CCD) and mirrors (M1 and M2). (For interpretation of the references to color in thisﬁgure text, the reader is referred to the web version of this article.)

0 200 400 600 800 1000

0 100 200 300 400 500 600 700 800 900 1000

x (pixels)

y (pixels)

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Ri=0.73 mm Re=1.58 mm

Fig. 2.Image of the real annular object used to illuminate the NL material [t1(x,y)].

This image is obtained using a 4f sytem[7]. Re and Ri are the mean values of the annular object radiuses.

(3)

the functioncirc r R(/ )is deﬁned equal to 1 if the radius r is less than or equal to R and 0 elsewhere.

Experiments were done with a block of 3.6 mm thick fused silica plate. Silica is a material known as relatively difﬁcult to measure because of its low n2value (10²⁰m²/W). Acquisitions were performed using an Nd: YAG laser emitting linearly polarized light at 532 nm (12 ps, FWHM pulse duration) at a repetition rate of 10 Hz. To reduce the thermally generated noise attributable to dark current, we used a CCD camera (14 bits) with a cooling system stabilizing the temperature sensor at 0°C, having 13801104 area of 9.08mm9.08mm square pixels. The circular aperture C situated just before the imaging lens L2 (Fig. 1) had a radius equal to 0.25 mm (imposed by the drilling) which was chosen smaller than the theoretical maximal value given by simple rays tracing:

= ≈

rC dR fi/ 0.44mm.

Fig. 3 shows the comparison between the simulated result (b) using the procedure detailed in section II and the experimental image (a) obtained under the same conditions (at z¼0). The qualitative agreement is very good, the images are almost iden- tical, presenting the same size.

For each experiment, two sets of acquisitions are performed.

Theﬁrst set is in the NL regime and the second by reducing the incident laser intensity in order to operate in the linear regime.

This is necessary to remove from the NL acquisitions the diffraction, diffusion and/or imperfection due to the sample in- homogeneities. We perform a Z-scan from 30 mm to þ30 mm

with a 1 mm step. So for each scan we register 61 images on the hard disk. After taking into account the reference beam to correct the energy ﬂuctuations, we integrate over all pixels of the diffracted image (as the one shown inFig. 3) to calculate the total transmitted energy.

Fig. 4 shows the signal of the diffracted energy (ﬁlled circle points) versusz, the position of the NLM together with the obtained numerical simulation (blue solid line). The normalization is done with respect to the diffraction in the linear regime, giving a signal equal to 1 when the NLM is far from the focus. It was considered the following experimental parameters:L¼3.60 mm, n2¼310²⁰m²/W, I0¼55 GW/cm² (giving

Δφ

0¼0.68 rad). I0

is measured after calibration considering the value of

= × ⁻

n2 3 1018m /W2 for CS2given in reference[4]. The numerical simulation obtained with these parameters is shown together with the experimental data. Note the very good agreement between the simulation and the experimental acquisition. A maximum is followed by a minimum for positive self-focusing in- dicating the ability to determine the positive sign of the nonlinearity. Of course a negativen₂will result in an opposite Z-scan trace characterized by a minimum followed by a maximum. In order to obtain simple relationship relating the NL phase shift with the signal, simulation has been performed (seeFig. 5), using the same parameters and only varying the induced NL phase shift to calculate the diffracted energy in the image plane versus z.

Also the energy diffracted in the NL regime is normalized to that obtained in the linear regime. Obviously, the signal increases with the incident intensity but more speciﬁcally, it is the difference

Δ

^Tpvbetween the maximum and the minimum which could be used for the measurement as for conventional Z-scan. The study of

Δ

^Tpvbased on the nonlinear phase shift at the focusΔϕ₀ shows a quadratic dependence (seeFig. 6). A quadraticﬁt of this dependence (blue dashed curve) gave us the following relation:

ϕ ϕ

ΔTpv= Δ 0× (0.64× Δ 0+0.61), which is valid between 0 and 1.5 rad.

This relationship allows us to accurately determine

Δφ

0 by measuring

Δ

^Tpv, in order to obtain the NL coefﬁcients. But a more simple linear relationship is preferable by performing a linearﬁt (solid red line) which allows to estimate this phase shift inside the useful interval where usually the measurements are done: for 0.2<∆φ₀<1.3 rad we obtain ΔTpv=1.3× Δϕ0−0.12. This relationship can be used to estimate the NL phase shift within 20%

accuracy. According to the deﬁnition of the sensitivity as the ratio

y (pixels)

560 680

0 2000 4000 6000 8000 10000 12000

x (pixels)

y (pixels)

650 750

500 620

0.02 0.04 0.06 0.08 0.1 0.12

Fig. 3.Image of the diffracted light in the NL regime at the output of the NLM situated atz¼0. (a) Experimental acquisition, (b) Numerical simulation. The col- orbars are given in two different arbitrary units.

-30 -20 -10 0 10 20

0.9 1 1.1 1.2 1.3 1.4 1.5 1.6 1.7

Diffracted energy

z (mm)

Fig. 4.The diffracted energy in the image plane versus the z position of the NLM obtained with 3.6 mm thick silica.

(4)

φ

∆ ∆

d Tpv/d 0[4], this new method is estimated to be 3.2 times more sensitive than that of the original Z-scan method where the equivalent relation is ΔTpv=0.41×Δϕ0 for the on-axis closed aperture trace. We performed also experimental comparison of this signal with that obtained by the conventional Z-scan, using the same sample under the same conditions (12 ps, 532 nm, and rectilinear polarization). Fig. 7 shows the usual closed aperture Z-scan signal obtained at 26 GW/cm²with a linear transmission of the closed aperture equal to 33%.

Comparing the signal obtained in Fig. 4 at 55 GW/cm² (ΔTpv=0.7) and the signal obtained here (Fig. 7, ΔTpv=0.14) at almost half of this intensity, it is found that the experimental gain in sensitivity is approximately equal to(26×0.7 / 55) ( ×0.14) ≈2.3.

This value is close to the theoretical value of 3.2 obtained with the on-axis Z-scan transmittance (linear transmittance of the closed aperture0) because more precisely we have to correct this obtained gain in sensitivity taking into account the linear transmittance of 33% considered in the experiment related toFig. 7. The gain that would be obtained with a completely closed ideal

aperture should be2.35/ 1( −0.33)^0.25=2.6when using the result of the numericalﬁtting obtained in[4]relating the signal∆Tpvto the NL phase shift. This validates our theoretical calculation on the sensitivity demonstrating a gain of a factor almost equal to 3. Of course, higher sensitivity could be obtained with other methods as in[5,8], but the beneﬁts and opportunities of this technique are numerous. The numerical simulations show that it is possible to obtain a signal whose response is mainly due to NL refraction whatever the NL absorption is (see Fig. 8). There is no need to divide the closed aperture Z-scan with the open one. Indeed, performing numerical simulation with the same parameters as those involved inFig. 4, but adding a relatively high NL absorption (q₀=1.9), we obtained approximately the same signal. Further application of this property is on the way to characterize high NL absorbing materials as those found in porphyrin compositions to improve the reliability of the NL refraction measurements [16].

Moreover, the image given on the CCD when the sample is in the focal plane is closely related to the spatial phase shift extension induced in the sample, which allows us to measure the size of the

Diffra cted Ene rgy

z (mm) In creasin g I

0

Δ T pv

→

Fig. 5.The diffracted energy as function of z with increasing intensity.ΔTpv(the vertical arrow) shows the difference between the maximum and the minimum for a given DFZ-scan simulation.

Δ T

pv

Δ ϕ

⁰

Fig. 6.Variation ofΔTpvas a function ofΔφ0. Quadratic (blue dashed) and linear (red solid)ﬁttings of the numerical simulation results. (For interpretation of the references to color in thisﬁgure legend, the reader is referred to the web version of this article.)

z (mm)

Normalized trans m ittance

Fig. 7. Z-scan proﬁle of the nonlinear refraction corresponding to 3.6 mm thick fused SiO2plate for an intensity of 26 GW/cm²with a linear transmission of the closed-aperture Z-scan equal to 33%.

-30 -20 -10 0 10 20 30

0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8

Diffracted en er g y

z (mm)

Fig. 8.Comparison of the diffracted energy in the image plane versus z. The solid line (in blue): no NL absorption (q₀=0) with Δφ₀=0.68(using the same parameters as in Fig. 4); the dashed line (in red): the NL absorption is deﬁned by q₀=1.9. Note that the signal is approximately the same in both cases.

(5)

output beam with an appropriate magnification, and to prevent the collapse of the beam when the operator notices a high variation of the size. Previously, this spatial resolution was obtained using interferometric techniques, as in[11]where the setup was difficult and complex to align and the processing was tedious to perform. When higher orders NL measurements are to be carried out[7,13], it will be more convenient to visualize directly the beam diameter at the output of the NL material than to deduce from the diffracted far field in the CCD plane a possible collapse of the beam, as it has been done up to now using the 4f system or Z-scan setups.

When compared to eclipsed Z-scan (EZ-scan) [5] which is known to be very sensitive, an advantage of this new method is that it does not require a perfectly Gaussian incident beam.

Moreover, the enhancement of the sensitivity in EZ-scan comes at the expense of a reduction in accuracy. Here also the size of the spatialﬁlter C and its inﬂuence on the sensitivity is not provided because the use of a reference material for calibration is highly recommended and the purpose of this paper remains principally restricted to demonstrate the feasibility of the method. In order to illustrate the behavior of a highly nonlinear material such as CS2

which is frequently used as a reference material to calibrate the setup we performed an experiment using 1 mm thick cell at I0

¼9 GW/cm² under the same experimental conditions. CS₂ is known to have a high nonlinear response when compared to silica.

Fig. 9shows this behavior, the data in blueﬁlled squares represent the signal obtained with CS2. The blue dash dot line is the simulation taking into account the experimental parameters (q0¼0, n2¼310¹⁸m²/W [3] and

λ

¼532 nm). In red points are the acquisitions shown in Fig. 4 (3.6 mm thick silica plate at 55 GW/cm²) reproduced here to facilitate the comparison. The red solid line is the corresponding simulation related to silica. Despite dividing the intensity by 6 and the thickness by almost 4 the signal of CS2 is still 10 times higher than that obtained with silica. Of course the linear relation relating∆Tpvto∆φ₀is no more valid here because of the high NL phase shift that occurs within the CS2cell.

Only the complete simulation described previously in section II could account for the exact NL phase shift. The simulation gives

φ

∆ ₀=3radwhich is only 13% larger than the value predicted by the

quadratic formula with∆Tpv=5.8.

Concerning the inconveniences of the method: (i) when combined with pulsed laser this technique remains sensitive to point- beam laser stability because of the hard apertures used in the experiment, (ii) the NL absorption is not directly measured, one should insert a beam splitter after the NLM (Fig. 1) and before C in order to deviate the light in another arm and to proceed with classical transmission measurements if necessary.

To summarize, the theoretical simulation are in very good agreement with the experimental data. The resulting feasibility is very encouraging as we successfully validate this technique with fused silica. Finally it is conceivable that this technique could be applied one day in a conventional darkfield microscope illumi- nated by an adapted laser beam to characterize thinfilms placed on a piezoelectric displacement plate. Further potential applications can be developed in thefield of laser scanning microscopy for optical NL thinfilm characterization and optical properties of NL nanoscale materials. More investigation could be done by adding another aperture in the image plane in order to obtain high-resolution optical images with depth selectivity as with confocal laser scanning microscopy.

4. Conclusion

In summary, the dark-field Z-scan method is based on the measurements of the non-direct diffracted light that passes through a circular aperture placed in the far-field region just before a lens magnifying the image of the output NL material. Z-scan is achieved using dark-field images with a relatively higher contrast. The experimental acquisition and the numerical simulation show very good agreement and demonstrate gain in sensitivity 3 times higher than conventional Z-scan. This imaging technique is also advantageous in presence of NL absorbing material where the signal is almost related to the induced NL refraction only. It allows to prevent collapse for high order NL coefficient estimation and to develop further potential applications in laser scanning microscopy.

References

[1]S.R. Friberg, P.W. Smith, Nonlinear optical glasses for ultrafast optical switches, IEEE J. Quantum Electron. 23 (1987) 2089–2094.

[2]G. Boudebs, S. Cherukulappurath, Nonlinear optical measurements using 4f coherent imaging system with phase objects, Phys. Rev. A 69 (2004) 053813.

[3]M. Sheik-Bahae, A.A. Said, E.W. Van Stryland, High-sensitivity, single-beam n2

measurements, Opt. Lett. 14 (1989) 955–957.

[4]M. Sheik-Bahae, A. Said, T.-H. Wei, D.J. Hagan, E.W. Van Stryland, Sensitive measurement of optical nonlinearities using a single beam, IEEE J. Quantum Electron. 26 (1990) 760–769.

[5]T. Xia, D.J. Hagan, M. Sheik-Bahae, E.W. Van Stryland, Eclipsing Z-scan measurement ofλ/10 4 wave-front distortion, Opt. Lett. 19 (1994) 317–319.

[6]M.R. Ferdinandus, M. Reichert, T.R. Ensley, H. Hu, D.A. Fishman, S. Webster, D.

J. Hagan, E.W. Van Stryland, Dual-arm Z-scan technique to extract dilute solute nonlinearities from solution measurements, Opt. Mater. Express 2 (2012) 1776–1790.

[7]G. Boudebs, V. Besse, C. Cassagne, H. Leblond, Cid B. de Araújo, Nonlinear characterization of materials using the D4smethod inside a Z-scan 4f-system, Opt. Lett. 38 (13) (2013) 2206–2208.

[8]M.R. Ferdinandus, H. Hu, M. Reichert, D.J. Hagan, E.W. Van Stryland, Beam deﬂection measurement of time and polarization resolved ultrafast nonlinear refraction, Opt. Lett. 38 (2013) 3518–3521.

[9]K.C. Jorge, H.A. García, A.M. Amaral, A.S. Reyna, L. de, S. Menezes, C.B. de Araújo, Measurements of the nonlinear refractive index in scattering media using the Scattered Light Imaging Method–SLIM, Opt. Express. 23 (2015) 19512–19521.

[10]M.L. Miguez, E.C. Barbano, J.A. Coura, S.C. Zílio, L. Misoguti, Nonlinear ellipse rotation measurements in optical thick samples, Appl. Phys. B 120 (2015) 653–658.

[11]G. Boudebs, M. Chis, X.N. Phu, Third-order susceptibility measurement by a new Mach–Zehnder interferometry technique, JOSA B 18 (2001) 623–627.

[12]J.W. Goodman, Introduction to Fourier optics, 2nd edition, Mc Graw Hill, United States, 1996.

-40 -30 -20 -10 0 10 20 30

0 1 2 3 4 5 6 7

Diffracted ener gy

z (mm)

Fig. 9.Comparison of the diffracted energy in the image plane versus z for high and low nonlinear material. Data in blueﬁlled squares represent the signal obtained with CS2(1 mm thick cell atI0¼9 GW/cm²). Red points are the acquisitions shown inFig. 4(3.6 mm thick silica plate at 55 GW/cm²). The blue dashdot line and the red solid line are the simulation taking into account the experimental parameters.

(6)

[13]Côme Schnebelin, Christophe Cassagne, Cid B. de Araújo, Georges Boudebs, Measurements of the third- andﬁfth-order optical nonlinearities of water at 532 nm and 1064 nm using the D4smethod, Opt. Lett. 39 (17) (2014) 5046–5049.

[14]K. Fedus, G. Boudebs, Experimental techniques using 4f coherent imaging system for measuring nonlinear refraction, Opt. Commun. 292 (2013) 140–148.

[15]G. Boudebs, K. Fedus, C. Cassagne, H. Leblond, Degenerate multi-wave mixing using Z-scan technique, Appl. Phys. Lett. 93 (2008) 021118.

[16] C. Cassagne, M. Chniti, C.B. de Araujo, H. Belmabrouk, G. Boudebs. Nonlinear optical characterization of tetraphenylporphyrin in the picosecond regime Transparent Opt. Netw. (ICTON) 2015. In: Proceedings of the 17th International Conference. IEEE, 2015, pp. 1–4.
