Extracting Policies from Replays to Improve MCTS in Real Time Strategy Games

Zuozhi Yang and Santiago Onta ˜n´on

^∗

Drexel University, Philadelphia, Pennsylvania 19104 {zy337, so367}@drexel.edu

Abstract

In this paper we study the topic of integrating supervised learning models into Monte Carlo Tree Search (MCTS) in the context of RTS games. Specifically, we focus on learning a tree policy for MCTS using existing supervised learning algorithms. We evaluate and compare two families of models: Bayesian classifiers and decision trees classifiers. Our results show that in experiments under same iteration budget for MCTS, the models with higher classification performance also have better gameplay strength when used within MCTS. However, when we constrain computation budget by time, faster models tend to outperform slower, more accurate, models. Surprisingly, the classic C4.5 algorithm stands out in our experiments as the best model since it has good classification performance and fast classification speed.

Introduction

Board and computer games have always been popular in the AI research community since they offer a challenging and rich testbed for both machine learning and search techniques. A prominent example is AlphaGo (Silver et al.

2016), which demonstrated that it is possible to deal with large search spaces by integrating machine learning and search. Real-time strategy (RTS) games have become a more active research area as it offers a greater challenge because of their enormous state space and branching factor, real-time nature, and partial observability. In this paper we study the topic of integrating supervised learning models into Monte Carlo Tree Search (MCTS) in the context of RTS games.

Specifically, we focus on learning tree policy for MCTS using existing supervised learning algorithms. Due to the large state space and branching factor, it is hard to obtain good policy real-time from MCTS. Thus, learning a reliable policy offline and bias the tree search towards a more promising search space can significantly improve the performance of MCTS.

In this paper we build upon previous work on Informed MCTS, where Bayesian models were trained from data to inform the tree policy (Onta˜n´on 2016). Moreover, given that RTS games have much more limited decision budget between each two game decisions compared to other games, like board games, the model we build must make fast pre-

∗Currently at Google

diction at testing time, apart from the requirement of accuracy. In consideration of the time constraint, we evaluate and compare two family of models: Bayesian classifiers and decision trees classifiers. Our results show that in experiments under same iteration budget for MCTS, the models with higher classification performance also have better gameplay strength when used within MCTS. However, when we constrain computation budget by time, faster models tend to outperform slower, more accurate, models. Specifically, the C4.5 model stands out in our experiments as the best model since it has good classification performance and fast classification speed.

The rest of this paper is structure as follows: (1) In the background section we introduce RTS games research, the research platform we employ, and work on applying MCTS to RTS games. (2) Then we describe and compare the two algorithm families that we study. (3) After that, we specify the details of our experiments on comparing the models in classification performance and gameplay strength as tree policy for MCTS. (4) Finally, we discuss the empirical results and layout the possible lines of future work.

Background

Real-time strategy (RTS) games have been receiving an in- creased amount of attention as they are even more challenging than games like Go or Chess in at least three different ways: (1) the combinatorial growth of the branching factor (Onta˜n´on 2017), (2) limited computation budget between actions due to the real-time nature, and (3) lack of forward model in most of research environments like Starcraft. Many research environments and tools, such as TorchCraft (Synnaeve et al. 2016), SCIILE (Vinyals et al.

2017),µRTS (Onta˜n´on 2013), ELF (Tian et al. 2017), and Deep RTS (Andersen, Goodwin, and Granmo 2018) have been developed to promote research in the area. Specifically, in this paper, to stay focused on the problem of interest of this paper, we choseµRTS as our experimental domain, as it offers a forward model for game tree search approaches such as minimax or Monte Carlo Tree Search.

Real-Time Strategy Games

RTS is a sub-genre of strategy games where players aim- ing to defeat their opponents (destroying their army and

(2)

base) by strategically building an economy (gathering resources and building a base), military power (training units and researching technologies), and controlling those units.

The main differences between RTS games and traditional board games are: they are simultaneous move games (more than one player can issue actions at the same time), they have durative actions (actions are not instantaneous), they are real-time (each player has a very small amount of time to decide the next move), they are partially observable (players can only see the part of the map that has been explored, although in this paper we assume full observability) and they might be non-deterministic.

Furthermore, comparing to traditional board games, RTS games have a very large state space and action space at each decision cycle. For example, the branching factor in Star- Craft can reach numbers between30⁵⁰and30²⁰⁰(Onta˜n´on et al. 2013).

µRTS

µRTS¹is a simple RTS game designed for testing AI techniques.µRTS provides the essential features that make RTS games challenging from an AI point of view: simultaneous and durative actions, combinatorial branching factors and real-time decision making. The game can be configured to be partially observably and non-deterministic, but those set- tings are turned off for all the experiments presented in this paper. We chose µRTS, since in addition to featuring the above properties, it does so in a very minimalistic way, by defining only four unit types and two building types, all of them occupying one tile, and there is only one resource type.

Additionally, as required by our experiments,µRTS allows maps of arbitrary sizes and initial configurations.

There is one type of environment unit (minerals) and six types of units controlled by players, which are:

• Base: can train Workers and accumulate resources

• Barracks: can train attack units

• Worker: collects resources and construct buildings

• Light: low power but fast melee unit

• Heavy: high power but slow melee unit

• Ranged: long range attack unit

Additionally, the environment can have walls to block the movement of units. A example screenshot of game is shown in Figure 1. The squared units in green are Minerals with numbers on them indicating the remaining resources. The units with blue outline belong to player 1 (which we will call max) and those with red outline belong to player 2 (which we will call min). The light grey squared units are Bases with numbers indicating the amount of resources owned by the player, while the darker grey squared units are the Bar- racks. Movable units have round shapes with grey units being Workers, orange units being Lights, yellow being Heavy units (now shown in the figure) and blue units being Ranged.

1https://github.com/santiontanon/microrts

"max"

player units

"min"

player units

Figure 1: A Screenshot ofµRTS.

Monte Carlo Tree Search in RTS Games

Monte Carlo Tree Search (Browne et al. 2012) (Coulom 2006) is a method for sequential decision making for do- mains that can be represented by search trees. It has been a successful approach to tackle complex games like Go as it takes random samples in the search space to estimate state value. However, most of the successful variants of MCTS, e.g. UCT (Kocsis and Szepesvári 2006), do not scale up well to RTS games due to the combinatorial growth of branching factor with respect to the number of units. Sampling techniques for combinatorial branching factors such as Na¨ıve Sampling (Ontañón 2013) or LSI (Shleyfman, Komenda, and Domshlak 2014) were proposed to improve the exploration of MCTS exploiting combinatorial multi-armed bandits. Inspired by AlphaGo, another approach to address this problem is the use of Na¨ıve Bayes models to learn a action probability distribution as a tree policy prior to guide the search (Ontañón 2016). Other work to deal with this problem involves limiting the search space by introducing action abstractions. For example, instead of searching directly in the raw unit action space, Portfolio greedy search (Churchill and Buro 2013) and Stratified Alpha-Beta Search (Moraes and Lelis 2017) search in the abstracted action spaces generated by hard-coded scripts.

In this paper, we extend the work of policy distribution learning (Onta˜n´on 2016) by comparing existing machine learning models and applying the trained model to tree policy of MCTS.

Na¨ıve Monte Carlo Tree Search. Na¨ıve Monte Carlo Tree Search (Na¨ıveMCTS) (Onta˜n´on 2013) is a variant of MCTS specifically designed to handle RTS games. For that purpose, Na¨ıveMCTS can also handle durative and simultaneous actions. Most importantly, the key feature of

(3)

Na¨ıveMCTS is that rather than using standard-greedy or UCB1, it uses a sampling policy for Combinatorial Mul- tiarmed Bandits (CMABs) called Na¨ıve Samplingin order to scale up to the combinatorial branching factors of RTS games.

Specifically, in our experiments, we use the implementation of Informed Na¨ıveMCTS built in intoµRTS, which can be used to incorporate machine learning models into the tree policy, as described below.

Informed Tree Policy. MCTS algorithms can be broken down into the following four stages (Browne et al. 2012):

1. Selection: Starting at root node, recursively select child nodes according to a pre-definedtree policy until a leaf nodeLis reached.

2. Expansion: If the selected nodeLis a not a terminal node then add a child nodeC ofLto the tree (also using the tree policy).

3. Simulation: Run a simulation fromCaccording to aplay- out policyuntil a terminal state is reached.

4. Backpropagation: Update the statistics of the current move sequence with the simulation result.

The tree policy serves as the criteria of child node selection within the search tree and balances exploration and exploitation. It can also be informed by a given prior distribution and then bias the search towards the desired action space. For example, the PUCB algorithm (Predic- tor+UCB) (Rosin 2011) extends the standard UCB1 strategy commonly used as the tree policy with an existing distribution. A variation of PUCB was used in AlphaGo, where Silver et al. (Silver, Sutton, and M¨uller 2012) used temporal difference method to learn a value function and to inform the tree policy. This prior distribution can be trained offline, e.g.

from existing game replays. AlphaGo, for example, trained a neural network using the human expert plays as supervision, and then refined it using reinforcement learning. Unlike the game of Go, however, the RTS games are real-time, which means the computational budget per action is much smaller than in Go. Therefore, large neural network models become impractical since they are currently too slow for the available computational budget. Thus, in this paper, we select a collection of statistical learning algorithms which are poten- tially fast at classification time as our subjects of study.

Methods for Tree Policy Learning

We use supervised learning to model and predict the move probability of script bots and bias the tree search to mimic and hopefully improve upon script bots with the help of tree search. A supervised learning modelpu(ai|s)takes a feature vectorsas the representation of the game state from the point of view of a unituand output the probability distribution over allnpossible actions(a₁, a₂, a₃,· · ·, a_n)the unit can perform. The model is trained beforehand and prediction is made each time the tree policy needs to be used. Thus our learning algorithm for modeling the problem must be fast at classification time. Also, in order to increase the sampling quality, the classifier should also provide good class

probability estimations. Therefore, we selected a relatively small set of categorical features (eight features) to represent the game states. Moreover, two types of classification algorithms what are previously known to be suitable to categorical data and fast at classification time are studied in this paper: (semi) Na¨ıve Bayes and (ensembles of) decision trees.

Na¨ıve Bayes and Semi Na¨ıve Bayes

The Na¨ıve Bayes classifier is a simple probabilistic classifier that makes a strong assumption that all the features are independent. This allows us to write the joint density as the product of all the component densities:

p(x|y=c,θ) =

D

Y

i=1

p(xi|y=c,θic)

Na¨ıve Bayes classifiers are highly scalable and can be trained and tested both in linear time. However, the assumption of independent features can be to violated for most of the situations. Thus, the research community has developed many semi-Na¨ıve Bayes algorithms that have a weakened independence assumption.

The semi-Na¨ıve Bayes algorithms tested in our paper is called averaged one-dependence estimators (A1DE) (Webb, Boughton, and Wang 2005). Sahami introduces n- dependence estimators, where the probability of each feature is conditioned by the class and nother features. (Sa- hami 1996) The averaged one-dependence estimators work like this: for each feature x, a classifier that assumes the other features are independent given the label and featurex.

The model makes predictions by averaging the outcome of all classifiers. Therefore, A1DE can be also viewed as a ensemble methods for Na¨ıve Bayes classifiers. We also test a more relaxed variation of A1DE called A2DE, which build estimators conditioned by each pair of features.

Decision Trees and Ensembles

The C4.5 classifier (Quinlan 2014) iteratively builds a decision tree by splitting the instances by the feature with the most information gain (reduction of entropy) at each internal node. Then it assigns class predictions at leaf nodes. Then the algorithm prunes the tree by a threshold confidence in- terval of 25%. We can estimate the class probability natu- rally from the label frequency of the leaves. Moreover, this estimation can be skewed towards 0 or 1 since the leaves are mostly dominated by one class. In our experiments, Laplace smoothing is applied in order to produce more accurate class probability estimation.

Bootstrapped aggregating (bagging) (Breiman 1996) is an ensemble method that helps to improve accuracy and stabil- ity by combining results from multiple training sets resam- pled with replacement. In our experiments, we apply 10 iterations of bagging to C4.5.

Random forest (Liaw, Wiener, and others 2002) is a meta classifier that fits a collection of random tree classifiers on resamples of the dataset and thus improve the predictive accuracy and control overfitting by averaging. The internal random trees select a subset of features to build the model.

In our case, each random tree selects a subset oflog(n) + 1

(4)

Table 1: Model Comparison on Classification Accuracy in the 12 Datasets

Na¨ıve Bayes A1DE A2DE J48 Bagging Random Forest

Accuracy Exp. l.l. Accuracy Exp. l.l. Accuracy Exp.l.l Accuracy Exp. l.l. Accuracy Exp. l.l. Accuracy Exp. l.l.

WR 0.6119 -1.0749 0.6609 -0.8921 0.6698 -0.8527 0.6821 -0.8574 0.6828 -0.9074 0.6882 -0.9810 LR 0.7955 -0.6048 0.8210 -0.5059 0.8276 -0.4876 0.8188 -0.4972 0.8248 -0.5598 0.8263 -0.6504 HR 0.8490 -0.4765 0.8671 -0.3950 0.8732 -0.3825 0.8666 -0.3995 0.8703 -0.4379 0.8716 -0.4855 RR 0.8411 -0.5223 0.8585 -0.4110 0.8602 -0.3954 0.8593 -0.4070 0.8606 -0.4389 0.8648 -0.4450 LSI500 0.3637 -1.4711 0.3713 -1.4048 0.3715 -1.3902 0.3637 -1.3488 0.3618 -1.5125 0.3595 -1.9905 LSI1000 0.3743 -1.4626 0.3795 -1.3904 0.3776 -1.3721 0.3628 -1.3392 0.3619 -1.5155 0.3606 -1.9683 LSI2000 0.3832 -1.4621 0.3920 -1.3877 0.3915 -1.3708 0.3749 -1.3314 0.3764 -1.5202 0.3741 -1.9860 LSI5000 0.3977 -1.4382 0.4062 -1.3578 0.4051 -1.3400 0.3866 -1.3119 0.3903 -1.4692 0.3878 -1.9382 Na¨ıveMCTS500 0.3747 -1.4711 0.3832 -1.4017 0.3811 -1.3861 0.3677 -1.3385 0.3672 -1.5314 0.3635 -1.9821 Na¨ıveMCTS1000 0.3839 -1.4544 0.3926 -1.3809 0.3893 -1.3641 0.3740 -1.3312 0.3747 -1.4991 0.3709 -1.9431 Na¨ıveMCTS2000 0.3916 -1.4527 0.3995 -1.3831 0.3985 -1.3665 0.3798 -1.3296 0.3827 -1.5034 0.3802 -1.9374 Na¨ıveMCTS5000 0.4005 -1.4422 0.4123 -1.3652 0.4126 -1.3451 0.3969 -1.3100 0.3974 -1.4677 0.3963 -1.9043

Table 2: Comparison of Model Classification Speed Model Instances/ms. Complexity

Na¨ıve Bayes 303.58 O(kn)

A1DE 174.46 O(kn²)

A2DE 43.07 O(kn³)

J48 298.05 O(log(n))

Bagging+J48 64.37 O(m·log(n)) Random Forest 30.97 O(m·log(n))

wherenis the number of features. In our experiments 100 random trees are built by the random forest algorithm. The class probability estimation is generated from the proportion of votes of the trees in the ensemble.

In practice, we observed that learning a different model for each different unit type in the game (workers, bases, barracks, etc. inµRTS), resulted in better estimation of the probabilities. So, for the experiments reported in the remain- der of this paper, we generated the probability models in the following way: (1) For each unit type we train a model using the subset of the training data corresponding to the unit type. (2) If this subset is empty, then just train with the whole training set (i.e., if we have no training data to model the way a specific unit is controlled, we just train a model with the whole training set for such unit, hoping it will reflect what the script we are collecting data from would have done).

Experiments and Results

Bots for Data Collection

We generated training data in the following way. We collected data from a round-robin tournament consists of six bots in 8 different maps, four of which are 8 ×8 maps and the other four are12×12. Four of the bots are built- in hard-coded bots: WorkerRush, LightRush, HeavyRush, and RangedRush. The other two were Monte-Carlo search bots: LSI and Na¨ıveMCTS, whose computational budgets are configurable. We run the experiments for LSI and Na¨ıveMCTS bots for four times with computation budgets of 500, 1000, 2000, and 5000 playouts per game frame respectively. The description of each bot is as below:

• Rush bots:hardcoded deterministic bots that implement a rush strategy that constantly produces one type of unit

and sends them to attack the opponent’s base. Specifi- cally, we used theWorkerRush,LightRush,RangedRush andHeavyRush bots ofµRTS, which implement rushes with worker, light, ranged, and heavy units respectively.

• LSI: Monte Carlo search with Linear Side Informa- tion (Shleyfman, Komenda, and Domshlak 2014)

• Na¨ıveMCTS:MCTS algorithm with a tree policy specifically designed for games with combinatorial branching factors. The tree policy exploits Combinatorial Multi- Armed Bandits (Onta˜n´on 2017) to handle the combinatorial explosion of possible moves.

The feature vectorx(u, s) used to represent each game state contains only eight features: the number of resources available to the player, the cardinal direction (north, east,south, west) toward where most friendly units are, the cardinal direction toward where most enemy units are, whether we have a barracks or not, and four features indicating the type of the unit in the cell two positions north, east, south or west (or whether these cells are empty or are a wall). Adding more features could certainly improve performance, which will be part of our future work. We employed these 8 features, as used in previous work (Onta˜n´on 2016), for comparison purposes.

The 12 datasets collected are described below:

• I_WR: consisting of all the unit-actions of WorkerRush (32679 instances)

• I_LR: consisting of all the unit-actions of LightRush (30139 instances)

• I_HR: consisting of all the unit-actions of HeavyRush (24385 instances)

• I_RR: consisting of all the unit-actions of RangedRush (31279 instances)

• I_LSI⁵⁰⁰,I_LSI¹⁰⁰⁰,I_LSI²⁰⁰⁰,I_LSI⁵⁰⁰⁰: consisting of all the unit-actions of LSI under computing budget of 500, 1000, 2000, and 5000 respectively (85918, 88816, 85611, and 68236 instances respectively)

• I_NMCTS⁵⁰⁰ ,I_NMCTS¹⁰⁰⁰ ,I_NMCTS²⁰⁰⁰ ,I_NMCTS⁵⁰⁰⁰ : consisting of all the unit- actions of Na¨ıveMCTS under computing budget of 500, 1000, 2000, and 5000 respectively (73249, 83925, 78896, and 68158 instances respectively)

(5)

Table 3: Win rates against the baselines of the models trained byI_WR

Tree Policy NB A1DE A2DE J48 Bagging RF Random 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 0.987 1.000 1.000 0.993 0.993 0.993 WorkerR 0.668 0.650 0.662 0.637 0.675 0.668 LightR 0.843 0.875 0.806 0.900 0.868 0.850 HeavyR 1.000 1.000 1.000 1.000 1.000 1.000 RangedR 1.000 1.000 1.000 1.000 1.000 1.000 LSI 0.656 0.662 0.637 0.612 0.662 0.706 NMCTS 0.475 0.531 0.506 0.637 0.587 0.687 Average 0.829 0.840 0.827 0.848 0.848 0.863 Table 4: Win rates against the baselines of the models trained byI_LR

Tree Policy NB A1DE A2DE J48 Bagging RF Random 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 0.993 1.000 1.000 1.000 0.987 0.993 WorkerR 0.662 0.581 0.625 0.6 0.687 0.681 LightR 0.862 0.862 0.787 0.781 0.862 0.831 HeavyR 1.000 1.000 1.000 1.000 1.000 1.000 RangedR 1.000 0.993 1.000 1.000 1.000 1.000 LSI 0.618 0.656 0.618 0.650 0.650 0.687 NMCTS 0.456 0.525 0.500 0.643 0.593 0.606 Average 0.824 0.827 0.816 0.834 0.848 0.850 Table 5: Win rates against the baselines of the models trained byIHR

Tree Policy NB A1DE A2DE J48 Bagging RF Random 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 1.000 0.994 1.000 1.000 1.000 1.000 WorkerR 0.631 0.625 0.637 0.713 0.688 0.744 LightR 0.844 0.869 0.856 0.881 0.869 0.919 HeavyR 1.000 1.000 1.000 1.000 1.000 1.000 RangedR 1.000 0.993 1.000 1.000 1.000 1.000 LSI 0.544 0.569 0.650 0.738 0.725 0.637 NMCTS 0.512 0.487 0.550 0.575 0.606 0.675 Average 0.816 0.818 0.837 0.863 0.861 0.872

Empirical Comparison of Models

For all six models, we used the Weka implementation². In this section we compare the six machine learning models described before from the following aspects:

• action prediction (accuracy and probability estimation)

• classification speed

• gameplay strength as tree policy under iteration budget

• gameplay strength as tree policy under time budget Unit Action Classification First we evaluate the models on the classification and class probability estimation performance. Table 1 shows the predictive accuracy and expected log-likelihood of the six models in each of the 12 datasets using a 10-fold cross validation. There is a total of 69 different actions a unit can perform inµRTS, but each individual can perform only between 5 and 33 unit-actions. We can see that the models predict the behavior of the four hard-coded

2The open sourced implementation of C4.5 in Weka is J48.

Table 6: Win rates against the baselines of the models trained byI_RR

Tree Policy NB A1DE A2DE J48 Bagging RF Random 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 0.994 1.000 0.994 0.994 1.000 0.994 WorkerR 0.675 0.600 0.637 0.681 0.694 0.713 LightR 0.800 0.825 0.875 0.812 0.906 0.838 HeavyR 1.000 1.000 1.000 1.000 1.000 1.000 RangedR 1.000 1.000 1.000 1.000 1.000 1.000 LSI 0.588 0.637 0.725 0.700 0.706 0.738 NMCTS 0.619 0.494 0.644 0.588 0.619 0.600 Average 0.834 0.820 0.859 0.847 0.866 0.860 Table 7: Win rates against the baselines of the models trained byI_LSI5000

Tree Policy NB A1DE A2DE J48 Bagging RF Rndom 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 1.000 1.000 1.000 1.000 0.994 1.000 WorkerR 0.650 0.675 0.700 0.706 0.675 0.725 LightR 0.856 0.944 0.894 0.931 0.894 0.844 HeavyR 1.000 1.000 1.000 1.000 1.000 1.000 RangedR 1.000 1.000 1.000 1.000 1.000 1.000 LSI 0.850 0.825 0.688 0.688 0.688 0.744 NMCTS 0.675 0.688 0.662 0.562 0.725 0.625 Average 0.879 0.891 0.868 0.861 0.872 0.867 Table 8: Win rates against the baselines of the models trained byINMCTS5000

Tree Policy NB A1DE A2DE J48 Bagging RF Random 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 1.000 1.000 1.000 0.994 0.994 0.994 WorkerR 0.731 0.700 0.738 0.600 0.688 0.688 LightR 0.875 0.831 0.881 0.887 0.887 0.875 HeavyR 1.000 1.000 1.000 1.000 1.000 1.000 RangedR 1.000 1.000 1.000 1.000 1.000 1.000 LSI 0.800 0.762 0.769 0.700 0.775 0.794 NMCTS 0.650 0.725 0.756 0.688 0.688 0.669 Average 0.882 0.877 0.893 0.859 0.879 0.877

bots better than the Monte Carlo search bots. But as the computing budget increases, the prediction performance also im- proves for the Monte Carlo search bots. This indicates that the Monte Carlo search bots converge to more stable strate- gies as the computing budget increases.

We also report the expected log-likelihood of the actions in the dataset given the model. This is a better metric to consider than classification accuracy given that we want to estimate the probability distribution of the actions, and not just predicting the most likely action. The best possible log- likelihood would be 0. We can observe that for Bayesian models, the more we relax the independence assumption, the better the accuracy and the log-likelihood. However, for decision trees, bagging and random forest outperformed J48 in accuracy but not in the log-likelihood.

Table 2 report the speed in classification time, wherekis the number of classes,nis the number of features, andmis the number of iterations and trees built for bagging and random forest respectively. The fastest models are Na¨ıve Bayes and J48. The classification speed is very important in time- constrained MCTS experiments as we will show later.

(6)

WorkerRush LightRush HeavyRush RangedRush LSI5000 NMCTS5000 Datasets

0.700 0.725 0.750 0.775 0.800 0.825 0.850 0.875 0.900

Win rates

Naive Bayes A1DEA2DE J48Bagging RandomForest

Figure 2: Win Rates by Dataset and Model under iteration budget.

Win rates under Iteration Budget We now evaluate our models as the prior distribution for the tree policy. We use the trained models in the tree policy as the sampling prior for the Na¨ıve Sampling process and we used RndBiased bot as the default policy. In this experiment, the Na¨ıveMCTS bots coupled with models trained from different datasets are tested against the eight baseline bots that were used for training trace generation. The individual results for each dataset are reported in Tables 3-8. Figure 2 shows an aggregated bar chart view of the average win rates grouped by training set and model. The overall average performance of every model is reported in Table 9.

The best model overall is random forest with 0.865 win rate against the baselines, and being the best performing model in three out of six experiments trained separately for each dataset. A general observation is that decision tree models especially the tree ensembles have better gameplay performance than Bayesian models when the training dataset is one of the rush bots. Meanwhile the Bayesian models outperformed the decision tree models in the more complex datasets, I_LSI⁵⁰⁰⁰ andI_NMCTS⁵⁰⁰⁰ . This seems to be because decision trees are better at predicting the deterministic behavior of the rush bots, but struggle to estimate the probability distribution of moves of the more stochastic search bots.

Win rates under Time Budget Due to the nature of RTS games, the computational budget is normally constrained by time. In that sense, complex models that are working well under iteration budget might lose their edges because they run less iterations than simpler but faster models. Thus, we run the gameplay strength experiments against seven³of the baseline bots again with computational budget being 50 mil- liseconds per cycle. The results are reported in Table 10.

We can observe that the model performance is significantly affected by the time budget. Although the more so- phisticated models like A1DE, bagging, and random forest have a better performance in experiments with iteration bud-

3The current version of LSI does not support time budgets.

Table 9: Overall Win rates per Model under Iteration Budget Tree Policy NB A1DE A2DE J48 Bagging RF

Overall 0.844 0.846 0.850 0.852 0.862 0.865

Table 10: Overall Win rates per Model under Time Budget Tree Policy NB A1DE A2DE J48 Bagging RF

Random 1.000 1.000 1.000 1.000 1.000 1.000 RndBiased 0.992 0.987 0.982 0.991 0.991 0.980 WorkerR 0.522 0.514 0.512 0.551 0.514 0.495 LightR 0.634 0.648 0.608 0.703 0.665 0.624 HeavyR 0.991 0.993 0.995 0.997 0.996 0.987 RangedR 0.993 0.997 0.992 0.996 0.992 0.988 NMCTS 0.708 0.688 0.634 0.736 0.594 0.579 Average 0.834 0.833 0.818 0.853 0.822 0.808

get, they do not have the same performance in experiments with time budget. The reason is that those models are significantly slower than Na¨ıve Bayes and C4.5, according to Table 2. The C4.5 model stands out as the best performing model (0.853 overall win rate) under experiments with time constraints due to its speed and better class probability estimation performance comparing to Na¨ıve Bayes model.

Conclusions and Future Work

The long term goal of this paper is to study the dynamics of the integration of machine learning models and MCTS methods and factors that affect the performance of their in- teraction in the context of RTS games. Specifically, this paper presents a comparison study on two types of machine learning models, Bayesian models and decision tree models, integrated in MCTS as part of the tree policy. We compare the models in terms of classification performance, classification speed, and gameplay strength as part of the tree policy under iteration and time budget.

Our empirical results showed that both classification accuracy and speed play a significant role when integrating

(7)

machine learning models into MCTS. Specifically, a random forest model has the best classification performance and best gameplay performance as tree policy when we models are compared under iteration constraints. However, in experiments under time constraint, random forest model has much worse performance compared to faster models. Instead, the C4.5 model, which has logarithmic complexity in classification time, has the best performance.

There are a number of future work directions we intend to pursue. For example, the models in this paper ignore the interdependence of actions (when selecting an action for a unit, knowing which action was selected for another unit on the same game state might be relevant). Training a model that takes action interdependence into account should po- tentially result in better performing agents. Another possible improvement can come from models learned online using techniques like contextual bandit algorithms (Chu et al.

2011; Mandai and Kaneko 2016).
