Prototyping and Evaluating Sensory Substitution Devices by Spatial Immersion in Virtual Environments

Aziliz Guezou-Philippe, Sylvain Huet, Denis Pellerin, Christian Graff

To cite this version:

Aziliz Guezou-Philippe, Sylvain Huet, Denis Pellerin, Christian Graff. Prototyping and Evaluating

Sensory Substitution Devices by Spatial Immersion in Virtual Environments. VISIGRAPP 2018 -
