New techniques and results in the measurement of magnetostriction

HAL Id: jpa-00234406

https://hal.archives-ouvertes.fr/jpa-00234406

Submitted on 1 Jan 1951

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

New techniques and results in the measurement of

magnetostriction

J.E. Goldman

To cite this version:

NEW

TECHNIQUES

AND RESULTS IN THE MEASUREMENT OF MAGNETOSTRICTION

By

J. E. GOLDMAN,

Westinghouse

Research Laboratories and

_Carnegie

Institute of

_Technology.

Sommaire. - L’auteur décrit la nouvelle

technique qu’il a élaborée pour la mesure des magnéto-strictions linéaires et _cubiques et _qui est _applicable aussi bien aux cristaux _{uniques qu’aux} matériaux

polycristallins. Il donne les résultats des mesures des constantes de _{magnétostriction} pour les alliages

fer-silicium et pour un très petit cristal _unique d’un _{alliage fer-cobalt,} ainsi _{que pour différentes} substances polycristallines. Les données relatives au cristal fer-cobalt ont conduit à _une nouvelle théorie de l’origine de _{l’anisotropie magnétique} de l’alnico V, qui est brièvement discutée. Enfin,

l’auteur _{indique rapidement} une relation entre la _{magnétostriction} eL la transformation ordre-désordre.

JOURNAL

19;)J,

Introduction. --

In 1947

[11,

the writer

_proposed

the use of electrical resistance strain _gauges for the measurement of

_{magnetostriction.}

This method off ers certain notable

_advantages

which will 1Je ennumerated below. Since that

time,

the

tech-nique

of measurement has been

refined,

the accuracy and _range

_improved;

this has made

_possible

measu-rements on materials and

_sample

_geometries

not

previously

amenable to accurate measurement. This paper will be devoted to a

_description

of the

method of measurement and a _{survey of} some

of the more recent results obtained as

_part

of a

program for the

_study

of

_{magnetostrictive}

pheno-mena initiated in the writer’s

_laboratory

and more

recently

continued in a _program under the writer’s direction at

_Carnegie

Institut of

_Technology

_[2].

The measurements on

single crystals

of iron-silicon

are

_part

of an

_unpublished

dissertation

_by

W. J.

Carr,

Jr. at the latter institution with the

_cooperation

of Prof. Smoluchowski.

Experimental Technique.

-- Electrical

resis-tance _{strain gauges}

_operate

on the

_principle

that

if a thin wire is stretched its resistance will

_undergo

a

_change

_proportional

to the

_degree

of strain. The constant of

_{proportionality}

is termed the _gauge

factor,

i.e.

and _{may vary} from i to i

depending

_upon the

material, the

_magnitude

of the stress and other

factors. In our

_experiments

we have used

commer-cial

_Type

A _gauges manufactured in the United States

_by

the Baldwin Locomotive Works. These gauges are of advance

₍₆₀

cu,

fio

ni)

wire and at

the

_magnitude

of

_magnetic

fields

used,

the

magneto-resistive effect in this material is either

_negligible

or small

_enough

so that it can be

_compensated

for without

_unduly

_impairing

_{the accuracy. In}

practice

the gauge is bonded to the

_sample

with

a cellulose-acetate cement. Commercial _gauges as

small as I.5 mm in

_length

are available

_permitting

the measurement of

_{magnetostriction}

on

_single

crystals

or other

_samples

as small as 3 mm in

diameter.

Measurements of the

_change

of resistance of the active _gauge are made with a conventional DC

Wheatstone

_bridge

in which all the arms of the

bridge

are made up of

_equivalent

_gauges that are

bonded to

_non-magnetic

material but with a

coeffi-cient of thermal

_{expansion closely matching}

that of the material under test thus

_eliminating

errors

due to ambient

_temperature

variations. The detector is a sensitive DC

_amplifier

which has

_{a y5}

c

_chopper

in the

_input,

_{a 75}

c narrow-band

_amplifier

and a

synchronous

commutator at the

_output.

The

_output

signal

is recorded on a o-5 mA recorder. Full scale deflection on the recorder can be obtained with an

_{input signal}

of jo-7 V. A schematic circuit

diagram

is shown in

_{figure i.}

The

_constancy

of the _gauge factor and the behavior of the bond at _{very low}

_positive

and

_negative

strains

_(expansion

and

_contraction)

were checked

by measuring

the known elastic moduli of metal

samples

using

this method. The

_system

is

_readly

calibrated in terms of strain

_by

_introducing

a

known

_change

in resistance in the active arm of the

_bridge

and

_noting

the deflection of the

_recording

milliammeter. With this

_arrangement

and with drift as well as

_pick-up

reduced to a minimum a

strain

_sensitivity

of the order of 2 x I o- 8 : mm scale

deflection can be obtained.

472

This method of measurement has the

_following,

noteworthy

advantages :

1. It can be

_applied

to the measurement of

magnetostriction

on

_samples

of a

_variety

of

_shapes

and

_geometries

_{including extremely}

small

_single

crystals

that do not

_permit

of

_ready

measurement

by

other methods.

2. In the case of thin laminated

_samples,

errors

due to

_bending

can be eliminated

_{by applying}

gauges on both sides of

_sample

and

_connecting

them in series.

3.

_Regions

over .which strain measurements are made are small so that variables such as end effects,

shearing

stresses and

_{non-uniformity}

are eliminated.

Fig. I. - Circuit

diagram of the magnetostriction measuring apparatus.

-4. The effects of

_temperature

variations and other ambient variables are eliminated.

_Adequate

sensitivity

and

_stability

are available so that mea-surements can be made when the

_sample

has attained thermal

_equilibrium

thus

_minimizing

errors

_resulting

from

_temperature

effects in the

_sample

due to

magnetocaloric

effect and other

_{magnetothermal}

eff ects.

5. A closed

_{magnetic path}

may be

used,

thus

assuring

a

_greater

_uniformity

of flux distribution

and

_eliminating

_possible

erros due to form effect. 6.

_Finally,

and

_perhaps

most

_significant,

measu-rements are _very

_readily

made in two

_{perpendicular}

directions thus

_eliminating

to a

_great

extent the

uncertainty

in the

_knowledge

of the

_demagnetized

state and errors in the

_{interpretation}

of results due to the

_possible

non-randomness in

_crystal

orientation

or in the initial distribution of domain directions. In the case of the

_{single crystal}

measurements the

sample

is

_always

saturated and

_only

the direction of

M3

is varied with

_respect

to the direction of strain measurement.

Moreover,

by measuring

the strain

_{simultaneously}

_parallel

and transverse to the direction of

_{magnetization,}

the _volume

magne-tostriction _{is very}

_easily

_separated

from the

longi-tudinal

_{magnetostriction,}

if one assumes that no

first order volume

_change

_accompanies

the latter. In this connection it _{may be}

_pointed

out that we

have

_recently

_adopted

this

_technique

for the measu-rement of volume

_{magnetostriction.}

Measurements on

_Single

_Crystals.

--

Quan-titative data on the behavior of the

_{magnetostriction}

constants of

_alloys

as a function of

_composition

are available

_only

in the case of the iron-nickel

alloys

[3]

and a few isolated cases

_[4]

where

_large

single crystals

have been made. In such cases as

the iron-cobalt

_alloys,

it is

_quite

difficult to obtain sizeable

_{single crystals}

and hence the

_significant

single crystal

magnetostriction

data is not avai-lable.

_Using

the above described

_technique

we have made measurements on a

_{single crystal}

of a 3o _per 100 cobalt-iron

_alloy

in the from of an

oblate

_spheroid

3.5 mm in diameter and o.3 mm in

thickness

_[5].

The

_plane

of the

_crystal

was

ascer-tained

_{by taking}

a back-reflection

_X-ray

_picture

and

found to be

_{approximately}

_(411).

_{A very fine} strain _gauge with active dimensions

approxi-mately

I.~ mm2 was bonded onto the

crystal

in such a _way that the direction-cosines of the _gauge axis

relative to the cubic axes are

_{(0.93 I,}

_{o .21).}

The

_crystal

was

_placed

in a

_magnetic

field

of lj

ooo Oe

and the

_change

in strain in the above fixed direction was measured as a function of the

_angle

made

_by

this direction

with

the direction of the field. The results

are

_plotted

in

_figure

2.

Using

the relation

given by

Al

Fig. 2. -

in

direction of gauge VS angle

between M~ and gauge.

Becker

_[6]

for the

_{magnetostriction}

of a cubic

_single

crystal

as a function of the direction-cosines of the direction of strain measurement and the direc-tion of

_{magnetization,}

we have obtained for the

_single

crystal

constants

and domain

_orientation)

in excellent

_agreement

with values obtained on a

sample

of this

_composition

measured in our

labo-ratory

in such a _way as to eliminate the

_uncertainty

in

_knowledge

of the initial domain distribution and in

_agreement

with the value

_{given by}

Snoek

_[7].

c _Kaya and Takaki

x _Webster

A Honda and _Mosiya,7a

Fig. 3. - Single crystal magnetostriction constants

of Fe-Si alloys (after Carr); and

.H, = z ~,~Iu

The

_availability

of such data has

_{become, indeed}

helpful

in

_interpreting

the mechanism of some

reactions

_{taking place}

in

_{magnetic alloys.}

The writer in collaboration with Smoluchowski in some

as

_yet

_unpublished

work has endeavored to

_explain

the mechanism of nucleation in Alnico V on this basis. It is

_proposed

that the

_precipitate

in this

alloy

is a

_phase

rich in iron and cobalt of the

approxi-mate

_composition

3o _per i oo Co. This is

compatible

with the

_hypothesis

of

_Bradley

and

_Taylor

_[8]

and with the observations of Geisler

_[9]

and fits the known

_optimum

_composition

of Alnico V if one

assumes that cobalt when added to the FeNiAl

system

simply

behaves like iron. The measured low

_{niagnetostriction}

of such a

_phase

in the

_[100]

suggests

that nuclei whose

_[100]

axes make a small

angle

with the _{matrix grow}

_{preferentially}

and the

magnetic

anisotropy

of the

_alloy

results from the

crystalline anisotropy

of the

_precipitate.

This data is also of further interest in

_{making possible}

a

quantitative

interpretation

of the effect of a

_magnetic,

field

_{applied during recrystallization}

_{upon the}

recrystallized

texture

_{reported by}

Smoluchowski and Turner

_[10].

Recently,

Carr

_[11]

has made measurements of the

_{single crystal magnetostriction}

constants of iron-silicon

_alloys

as a function of silicon content. His results are shown in

_figure

.3. These results

are also of

_great

theoretical

_{interest, for,}

_comparison

of the data with other

_systems

such as Fe-Al

_bring

out _{the very}

_significant

difference in the behavior of the

_magnetic

shells

_{during alloying}

and is the

subject

of a

_separate

treatment.

Moreover,

as

will be shown

below,

this data makes

_possible

a more

_quantitative

evaluation of the distribution

of domain directions in

_{polycrystalline}

media. Measurements on

_{Polycrystalline}

Materials.

- 1. A1 aterials with

Preleri

ed

Crystal

Orientation.

-Information on the distribution of domain directions

in a

_{polycrystalline}

material can be obtained

by

means of

_{magnetostriction}

measurements. A

_good

example

is afforded

_by

the data on

polycrystalline

materials

_having

a

_preferred

_grain

orientation. The

magnetostriction

vs. B curve for oriented 3.25 per I o0

silicon steel

_(Hipersil)

is shown in

_figure

l.

From

Fig. ~. - Magnetostriction in Hipersil in rolling direction.

Carr’s data shown in

_figure

3 we know the actual value of the

_{single crystal}

constants for this compo-sition. A check on the

_{compatibility}

of the measu-rements is afforded

_by

_noting

the measurement of the

_{magnetostriction}

as measured with the

_sample

magnetized

transverse to the direction of

_rolling

as shown in

_figure

5. The orientation of the crys-tallites in the material is as shown

_{schematically}

in

_figure

6. Thus one would

_expect

that when

magnetized

transverse to the

_rolling

direction the

magnetostriction

would be

_positive

until all the domains are

_magnetized

at 45°

to the direction of

B,

b

measurement, i.e.

_14.000

_gauss as observed.

V2

At this

_juncture

the material should behave

substan-tially

as a

single crystal

so that the

_{magnetostriction}

resulting

from

_turning

the direction of

magnetiza-tion from the

_[100]

to the direction of the field i.e.

_[110],

is

_{[6] :}

_~20134.0

x 10-0 in

_good

agreement

with

(Al l)

/50.000

-

474

the

_anisotropy

in the distribution of _{domains among} the six

_possible

_{easy initial directions.}

Fig. 5. -

Magnetostriction in _Hipersil transverse to _rolling direction.

The

_{negative magnetostriction}

at low inductions is associated with the laminar character of the

sample

and is

_interpreted

as

being

due to the extra

magnetostatic

energy if there is a

_component

of

magnetization

normal to the

_plane

of the sheet.

Fig. 6. - Orientation of crystals in Hipersil.

Thus if the

_crystal

makes a small

_angle

with the

_plane

of the

sheet,

then

_during

the

_steep

_portion

of the

magnetization

curve when

_{magnetization proceeds}

almost

_{exclusively by}

means of i 8oo

_boundary

displacements

there would result a

_component

of

magnetization

normal to the

sheet;

accordingly,

there are some " reverse " _goo

displacements

in

which domains

_{initially magnetized}

_antiparallel

to the field

_change

their

directions

by

goo

to neutralize the normal

_component.

This is

_analogous

to Stewart’s

_{interpretation}

of the

_negative

effect of tensile stress on

_{magnetization}

i n the same

_alloy

_[12].

A similar effect is observed in a _{5o per} 100 Fe-Co

alloy

with

_preferred

_grain

orientation as shown in

figure

7. The

negative

strain at low inductions does not _appear when the

_preferred

_grain

orientation is not

_pronounced.

2.

_{Magnetostriction}

and Order-Disorder. -

Gold-man and Smoluchowski

[13]

first discovered a

relationship

between

_{magnetostriction}

and the state of order of an

_alloy.

The

original

measurements were made on an

_alloy

of Fe-Co

_by

the

technique

Fig. 7.-

_{l- VS.B}

from demagnetized state for 50 % Fe-Co

alloy vith some preferred orientation.

described above. A theoretical

_{interpretation}

was

given

for the effect in terms of the

_{dipole-dipole}

interaction treatment of Becker. This

_required

certain

_assumptions

as to the character of the atomic moment in an

_alloy.

Our

original

ideas

Fig. 8. -

Magnetostriction of _{polycristalline} Iron-aluminium alloys.

have since been

_amplified

_by

Smoluchowski and form the basis for some of the ideas

presented

in

his paper elsewhere in this

meeting.

The writer has also extended the measurements of

magneto-striction as a function of order to

_Ni3Fe

(per-malloy)

[14]

where an increase

_by

a factor of two is observed in the

_{magnetostriction}

on

ordering;

and in the Fe-Al

_system

_{[ 1 ~~.}

The data on Fe-Al

are shown in

_figure

8. The

_single

_crystal

constants of Carr have also been found to be sensitive to thermal

_{treatment-probably}

due to a variation

pro-perties

of these three

_systems

to thermal treatment is due

_primarily

to _{the very}

_{large changes}

in

magneto-striction that are

_produced..

Remarque

de Street. - I should like to ask

Dr Goldman for further information on two

_points

of

_experimental

_{technique. Firstly,}

is there _any

disadvantage

in

_using

A. C.

_bridge

methods

_compared

with the method described i.e.

_using

a D. C.

_supply

and a "

chopped "

D. C.

_{amplifier ? Secondly,}

in his measurements has it been found _necessary to calibrate the resistance strain _gauges in situ or is it found sufficient to

_accept

_{the gauge factor} in accurate measurements ? I should like also to know if Dr Goldman has been able to make _any measurements on reversible

_{magnetostriction,}

i . e. the

_alternating

strain

_{produced by}

an

_alternating

field

_applied

at different

_points

on the

_hysteresis

cycle.

It would _{appear that his form of}

_apparatus

would be

_extremely

useful for such measurements.

Réponse

de M. Goldman. - We feel _{we can} obtain

lower noise level with D. C. than with A. C. As to the

calibration,

in the initial

_stages

of

_development

of this method we checked the _gauge factor

_given

hy

the manufacturer

_{by measuring}

the modulus of

_elasticity

in standard

_samples.

In

_general,

we have found the manufacturer’s data to be

_quite

accurate

_making

a

_regular

check of the _gauge factor unnecessary.

Remarque

de M. Weil. - Nous _avons utilis6

des 11 strain _gauges "

pour des mesures de

magneto-striction, A

diff6rentes

_temperatures

et dans des

champs

6lev6s

₍₁₅

ooo

_Oe),

notamment dans 1’etude

du ferrite de cobalt

_(~’.

R. A cad.

_{Sc., 1950,}

231,

224).

Remarque

de AI. Hoselitz. - We have also been

using

strain gauges for

_{magnetostriction}

measure-ments and the _{results obtained with strain gauges} have been the same as those obtained with our

opticai

lever method. In our

experiments

we were

able to use an

optical

lever in fields up to 5 ooo Oe.

REFERENCES.

[1] GOLDMAN J. E. - Phys. Rev., 1947, 72, 529.

[2] Supported by ONR.

[3] LICHTENBERGER F.2014 Ann. Physik, 1932, 15, 45. [4] SHTURKIN D. A. - C. R. Acad.

Sc., U. R. S. S., 1947, 58, No. 4, 581.

[5] The Fe-Co crystal was very kindly loaned to us _by Prof. L. W. Mc Keehan of Yale University and is

part of the set used _by J. W. Shih for the measurement of crystal anisotropy. Phys. Rev., 1934, 46, 139.

[6] BECKER-DORING. 2014 Ferromagnetismus, Berlin, Julius Springer, 1939, p. 275.

[7] SNOEK J. L. - New Developments in Ferromagnetic

Materials, Elsevier, 1947, p. 15.

[8] BRADLEY A. J. and TAYLOR. 2014 Nature, 1937, 140, 1012.

[9] GEISLER A. H., to be published. We are indebted to

Dr Geisler for _making available to us a _manuscript of _{his paper} in advance of _publication.

[10] SMOLUCHOWSKI R. and TURNER R. W. 2014 J. Appl. Phys., 1949, 20, 745.

[11] CARR W. J. Jr. 2014

Dissertation, Carnegie Institute of

Technology, 1950. [12] STEWART K. H. 2014

Physica, 1949, 15, 235.

[13] GOLDMAN J. E. and SMOLUCHOWSKI R. 2014

Phys. Rev., 1949, 75, 140.

[14] GOLDMAN J. E. - Phys. Rev., 1949, 76, 470; J. Appl.

Phys., 1949, 20, 1131.

[15] GOLDMAN J. E., STANLEY J. K. and HASSEL W., to be
