Intrusion-tolerant fine-grained authorization for Internet applications
V. Nicomette a,b, * , D. Powell a,b , Y. Deswarte a,b , N. Abghour c , C. Zanon a,b
a
CNRS, LAAS, 7 Avenue du Colonel Roche, F-31077 Toulouse, France
b
Université de Toulouse; UPS, INSA, INP, ISAE; LAAS; F-31077 Toulouse, France
c
Université Hassan II Faculté des Sciences An Chock, Département de Mathématiques et Informatique, BP 5366 Maarif Casablanca 20100, Morocco
a r t i c l e i n f o
Article history:
Received 15 October 2009
Received in revised form 2 April 2010 Accepted 5 May 2010
Available online 13 May 2010
Keywords:
Authorization scheme Fined-grained Delegation Intrusion-tolerance
a b s t r a c t
This paper presents the architecture of an authorization service proposed for composite operations involving many Internet partners. The main contributions of this paper are: (1) a scheme for access con- trol systematically applied at the fine-grained level of each elementary operation, (2) a novel proof of authorization concept and flexible authorization delegation technique, and (3) the design and proof- of-concept implementation of an intrusion-tolerant prototype of the authorization architecture. The architecture is based on two component types: an authorization server and a set of reference monitors.
The authorization server is in charge of distributing proofs of authorization for composite operations in the system. On each site involved in the execution of the composite operation, a local reference monitor is in charge of checking the validity of the proofs of authorization used for each elementary operation. The paper presents the overall design of the authorization service. It also includes a brief description of the prototype that was developed as well as performance measures.
Ó 2010 Elsevier B.V. All rights reserved.
1. Introduction
Authentication and authorization are key issues in computer security. The authentication process provides a way for a user to prove his identity (typically by presenting a valid username and password) while the authorization process consists in determining whether a user has permission to execute given operations in the system. This paper deals with authorization. While it is not a sim- ple issue in standalone systems, it really becomes intricate when one considers distributed applications and particularly applica- tions distributed over the Internet.
Most protection models are based on the notion of a reference monitor [1] that controls all interactions in the system to check whether each access is authorized or denied, using an access matrix that stores all the access rights of the system. If we consider applications distributed across the Internet, we can imagine a di- rect application of the standalone system paradigm by using a cen- tral reference monitor located on one host of the distributed system. This reference monitor would check all interactions in the whole distributed system. An implementation of this paradigm has been proposed in [2]. A major drawback of this approach is
obviously the fact that security of the entire system relies on just one machine, which is thus a single point of failure. Even if the cen- tral reference monitor were to be implemented as a fault- and intrusion-tolerant server running on several separately adminis- tered machines, it would still be a major bottleneck regarding system performance. Another possible solution can be found in the Red Book [3]. In this approach, a local reference monitor in each site of the distributed system checks all the accesses from remote entities to local entities. The local reference monitor is part of the site’s Trusted Computing Base (TCB) and each TCB trusts all the other TCBs of the whole system: when an access from a remote entity is made to a local entity, the local TCB trusts the remote TCB to correctly supply the remote entity’s identity, which is used for the verification of the access rights. Thus, in this approach, if any of the TCBs is corrupted, the security of the whole system is compromised.
Our first objective was thus to design an authorization scheme that is a trade-off between totally centralized and totally distrib- uted systems and that has none of their drawbacks.
Today, most Internet applications are based on the client–server model. This model is not rich enough to cope with composite oper- ations involving more than two participants. For example, an elec- tronic commerce transaction typically requires the cooperation of a customer, a merchant, a credit card company, a bank, a delivery company, etc. Each of these participants has different interests, and may thus distrust the other participants. Moreover, in this model, typically, the server distrusts clients, and grants each client access 1383-7621/$ - see front matter Ó 2010 Elsevier B.V. All rights reserved.
doi:10.1016/j.sysarc.2010.05.005
* Corresponding author at: CNRS, LAAS, 7 Avenue du Colonel Roche, F-31077 Toulouse, France.
E-mail addresses: nicomett@laas.fr (V. Nicomette), dpowell@laas.fr (D. Powell), deswarte@laas.fr (Y. Deswarte), nabghour@fsac.ac.ma (N. Abghour), czanon@laas.fr (C. Zanon).
Contents lists available at ScienceDirect
Journal of Systems Architecture
j o u r n a l h o m e p a g e : w w w . e l s e v i e r . c o m / l o c a t e / s y s a r c
rights according to the client’s identity. This enables the server to record a lot of personal information about clients: identity, usual IP address, postal address, credit card number, shopping habits, etc. Such a model is thus necessarily privacy intrusive.
Our second objective was thus to design an authorization scheme that is able to distribute proofs of authorization to the par- ticipants of a composite operation whilst enforcing the ‘‘least priv- ilege principle”: each participant should be granted the minimum set of proofs of authorization necessary to execute the composite operation. For that purpose, our authorization scheme defines a new proof of authorization concept and an authorization delega- tion scheme that is more flexible that the usual ‘‘proxy scheme”.
The paper is organised as follows. Section 2 presents the design of the authorization scheme and the security properties of the main entities. In Section 3, we give the definitions of the different proofs of authorization that are used in our scheme and discuss our delegation scheme. Sections 4 and 5 give a detailed presentation of the two main entities of our scheme: the authorization server and the local reference monitor. Section 6 gives an overview of a proto- type implementation of the authorization service. Some perfor- mance measures are also provided. Finally, Section 7 presents related work and Section 8 draws conclusions and proposes future work.
2. Design of the authorization service
This section gives a global presentation of our authorization scheme and the security properties required by the different enti- ties that compose the authorization service.
2.1. Architecture
The authorization scheme aims to ensure that each participant is granted the rights it needs to execute its task, while only distrib- uting the information that is strictly necessary, i.e., a proof that the task is authorized and the parameters authorized for this execu- tion, without unnecessary information such as the identities of other participants. The scheme is based on two levels of protection:
An authorization server, which is in charge of granting or deny- ing rights for composite operations involving several partici- pants in a given realm; if a composite operation is authorized, the authorization server distributes proofs of authorization (see Section 3) for all the elementary operations that are needed to carry it out. This authorization server must be built in such a way that it is not a single point of failure.
A local reference monitor on each participating host, which is responsible for fine-grained authorization of atomic operations accessing local resources and objects, according to the proofs of authorization that accompany each request. The authorization to execute an atomic operation is represented by a capability issued by the authorization server and checked by a local refer- ence monitor. To enforce hack-proofing of such reference mon- itors on off-the-shelf computers connected to the Internet, critical parts of the reference monitor must be implemented in tamperproof hardware (see Section 6 for an example with JavaCards).
This two-level architecture (see Fig. 1) provides:
simplicity of administration, since only the rights for composite operations need to be assigned by the security administrators of the realm;
fine grain protection, since authorization is checked at each exe- cution of an atomic operation.
It should also be noted that this approach is more capable of preserving privacy than the usual client–server approach: in the client–server model, the server grants or denies a client’s access according to the identity of the client, which has to be recorded to- gether with other information to be used as evidence in case of dis- pute. Much more personal information is thus recorded than really needed. With the more flexible authorization scheme we propose, a composite operation is authorized if the corresponding permission is presented, which, by itself, discloses no personal information. Only the personal information really necessary for execution of the composite operation needs to be disclosed (appli- cation of the ‘‘need-to-know” principle to privacy).
method invocation authorization request
p4 ps1
f3 fs2
... ...
u
Site Site
Security Security
Site Security
Reference Monitor
Authorization Server
Monitor Reference Monitor
tamperproof hardware Reference
Fig. 1. Authorization architecture.
2.2. Security properties
The security of the overall system is ensured by the collabora- tion between the authorization server and the local reference mon- itors. We present in this section the security properties required for each of these two entities.
2.2.1. Security properties of the authorization server
The authorization server is in charge of creating all the proofs of authorization that allow objects in the system to execute opera- tions. As a consequence, the failure of the authorization server would compromise the security of the entire system (i.e., the security of all the applications of the system). Thus, the following security properties need to be enforced with respect to the autho- rization server:
AS1 : The authorization server generates only valid proofs of authorization (safety).
AS2 : The authorization server eventually generates proofs of authorization (liveness).
2.2.2. Security properties of the reference monitor
Our authorization scheme is intended for Internet applications, i.e., applications that require the cooperation of objects residing on geographically distributed hosts. Hosts may fail accidentally or may be maliciously compromised. In particular, we consider that each host is locally administered by a person who has complete control over that host but who is not necessarily trustworthy. An administrator does not necessarily trust the administrators of the other participating hosts, so there is no mutual trust between hosts supporting the objects involved in a distributed application. We re- fer to failing or compromised hosts as faulty hosts.
However, even if some hosts may be faulty, we want the follow- ing properties to be enforced:
RM1 : Only authorized operations will be executed on a non- faulty host (safety).
RM2 : If an authorized operation invocation is received by a non- faulty host, the invocation will be acknowledged and the operation will eventually be executed (liveness).
RM3 : A faulty host cannot generate a valid acknowledgment for an operation authorized for a different host (safety).
We show in Sections 4 and 5 how we design the authorization server and the reference monitor in such a way that these security properties are enforced.
3. Authorization proofs
3.1. Concepts and definitions
We build on the generic authorization scheme for distributed object systems that we proposed in [4]. In that scheme, an applica- tion is considered to be composed of objects that interact through method invocations. Execution can be viewed at two levels of abstraction: atomic operations and composite operations. An atomic operation is simply the execution of one method of one ob- ject. A composite operation corresponds to the coordinated execu- tion of several atomic operations towards a common goal. For instance, printing file F3 on printer P4 is a composite operation involving the execution of a particular method of the spooler object attached to P4, which itself has to request the execution of a par- ticular method of the file server object managing F3, etc.
Details on how the authorization server checks if a composite operation request is to be granted or denied are given in [5] and [6]. We give a brief description here and an example.
3.1.1. Symbolic rights
A request from object O to run a composite operation is autho- rized or denied by the authorization server according to symbolic rights rules applied to symbolic rights stored in an access control matrix. A symbolic right is a high-level right that is used in order to authorize the execution of a composite operation in the system (e.g., the right to print file f on any printer of the system is a sym- bolic right). In general, several symbolic rights are needed to authorize the realization of a single composite operation. In order to authorize a composite operation, the authorization server eval- uates symbolic rights rules. A symbolic rights rule describes the set of all symbolic rights that must be found in the access matrix in or- der to authorize the realization of a composite operation.
For example, in the access matrix described by Table 1, the first row represents symbolic rights that are granted to subject S. The symbolic right PF(this,PRINTER) in column f
3means that S is authorized to print file f
3on any printer of the system (any in- stance of class PRINTER). In the same way, PF(FILE,this) in col- umn p
4means that S is authorized to print any file of the system on printer p
4.
The last rows of the access matrix represent method rights that print server ps
1and file server fs
2respectively have on printer p
4and file f
3: ps
1is authorized to access method print of p
4and fs
2is authorized to access methods read and write of f
3.
The following symbolic right rule:
PF e;f ðf; pÞ; PF e;p ðf; pÞ CopðprintfileÞðe; f; pÞ
means that in order to authorize an entity e to execute the compos- ite operation ‘‘printing file f on printer p”, it must be checked, via the access matrix, that the entity holds the following symbolic rights:
PF for file f on a set of printers that includes p.
PF on printer p for a set of files that includes f.
3.1.2. Permissions
If the request is authorized, proofs of authorization are created by the authorization server for all the operations composing the composite operation. These proofs of authorization are delivered in the form of a list of permissions for O to perform operations
op
1, . . ., op
n, and the list is signed by the authorization server
(AS) to prevent forgery:
ðfPermðO; op 1 Þ ; . . . ; PermðO; op n ÞgÞ SK
asð1Þ The notion of a composite operation is recursive: the execution of a composite operation corresponds to the execution of a set of operations, each of them being either an atomic operation or a (nested) composite operation.
Atomic operations: The permission for an atomic operation (i.e., a method execution) contains the identification of the object O authorized to invoke the method, the identification of the
Table 1
Example of access matrix.
ps1 fs2 f3 p4
S PF(this,PRINTER) PF(FILE,this)
ps1 print
fs2 read, write
authorized method O
0:m, some constraints parC on the invocation parameters, a capability for O to invoke O
0:m with these constraints, and optionally a voucher (defined below):
PermðO; O 0 :mÞ ¼ O; O 0 :mðparCÞ; CapðO; O 0 :mðparCÞÞ½; VouchðO 0 :mÞ ð2Þ The capability CapðO; O
0:mðparCÞÞ is a proof that object O is authorized to invoke method m of object O
0with some constraints parC on the invocation parameters. These constraints can be simply the values of the authorized invocation parameters, or relations on the values of the parameters, such as a maximum authorized value.
When O invokes O
0:m, the invocation must be accompanied by the capability, which will be checked by the local reference monitor lo- cated on the host of O
0.
If, during its execution, O
0:m needs to invoke other operations (atomic or composite), it will need proofs of authorization for these invocations. In that case, PermðO; O
0:mÞ contains a voucher, which is a sealed list of permissions for O
0to invoke op
1; . . . ; op
n: VouchðO 0 :mÞ ¼ ðfPermðO 0 ; op 1 Þ ; . . . ; PermðO 0 ; op n ÞgÞ SK
asð3Þ
VouchðO
0:mÞ will be transmitted by O to O
0when O invokes
O
0:m, in the same way as the list of permissions was transmitted
by the authorization server to O as a reply to the request by O for a composite operation. The voucher is created by the authoriza- tion server during the process of permission generation, and is signed by the authorization server to prevent forgery. Note that the proofs of authorization represented by the voucher cannot be used directly by O. They can only be delegated by O to O
0in order to execute m on behalf of O.
Composite operations: The permission for a (nested) composite operation contains the identification of the object O authorized to invoke the composite operation, the identification of the com- posite operation cop, some constraints parC on the invocation parameters, and a token for O to invoke cop with these constraints:
PermðO; copÞ ¼ fO; copðparCÞ; TokenðO; copðparCÞÞg ð4Þ TokenðO; copðparCÞÞ is a proof that object O is authorized to car- ry out the composite operation cop with constraints parC on the invocation parameters. With this token, object O can request from the authorization server all the proofs of authorization needed to perform cop.
3.2. Discussion 3.2.1. On tokens
Tokens are not strictly necessary. Since a token is a proof of authorization to be presented to the authorization server to gener- ate permissions, it would have been possible for the authorization server to generate these permissions in the first place and distrib- ute them instead of the token. But tokens are useful for flexibility and efficiency:
Flexibility: without tokens, when the authorization server receives a request for a composite operation, it would have to evaluate the complete invocation tree for all possible execu- tions of the composite operation, and to generate all the capa- bilities for all possible atomic operations. In this case, cycles must be prevented in the invocation sequences. On the con- trary, tokens enable dynamic evaluation of authorization during execution.
Efficiency: without tokens, the authorization server would have to generate all capabilities for all possible atomic operations in all possible executions of the composite operation. Many of these capabilities might not be used in the real composite oper- ation execution, so the authorization server would have wasted
its time in generating them. Moreover, this means that the objects would receive more capabilities than needed, in contra- diction with the least privilege principle. On the contrary, the authorization server will have only to evaluate at run time the tokens corresponding to composite operations that are really executed.
3.2.2. On delegation
The voucher-based delegation scheme presented above is more flexible than the usual ‘‘proxy” scheme [7–10], by which an object transmits to another object some of its access rights for this dele- gated object to execute operations on behalf of the delegating ob- ject. Our scheme also adheres more closely to the least privilege principle, since it helps to reduce the privilege needed to perform delegated operations. For instance, if an object O is authorized to print a file, it has to delegate a read-right to the spooler object for the latter to be able to read the file to be printed. To delegate this read-right, with the proxy scheme, O must possess this read- right; and thus O could misuse this right by making copies of the file and distributing them. Clearly, the read-right is a privilege much higher than a simple print-right. In our scheme, if O is autho- rized to print a file, O will receive a capability to call the spooler and a voucher for the spooler to read the file. The voucher, by itself, cannot be used by O. With the provided capability, O can only in- voke the spooler and transmit the voucher to the spooler. The spooler can then use the capability contained within the voucher to read the file. Thus O can have the right to print a file without being authorized to read it.
Let us also note that all the required permissions do not neces- sarily have to be transmitted in a voucher (or even in a reply to a request for composite operation authorization). The invoked object can have its own rights, stored as symbolic rights in the authoriza- tion server access control matrix. Thus, a composite operation cop can be launched by O
0on behalf of O (i.e., by running a method O
0:m invoked by O) without O delivering a voucher for cop, if O
0is autho- rized to perform cop by itself.
3.2.3. On transient objects
Only persistent objects are known by the authorization server AS. Transient objects, such as buffers or temporary files, created for the execution of a single composite operation are not known by AS, and thus AS cannot generate capabilities for such objects.
The capabilities for transient objects are completely managed by the reference monitor associated with that host (a transient object capability can be ciphered by a persistent symmetric key of the lo- cal reference monitor; this symmetric key is never transmitted outside the reference monitor). A transient object can be created dynamically by another object, which then receives from the refer- ence monitor all capabilities for this object and it can transmit these capabilities to other local objects at method invocation. Tran- sient object capabilities cannot be transmitted to remote objects.
4. Authorization server
Since only composite operations are managed by the authoriza- tion server, system security is relatively easy to manage: the appli- cation security administrators of the realm have just to assign the rights to execute composite operations, they do not have to con- sider all the elementary rights to invoke object methods. Moreover, since only one request has to be checked by the authorization ser- ver for each composite operation, the communication overhead scales well.
The authorization server is a trusted third party (TTP), which
could be a single point of failure, both in case of accidental fail-
ure, or in case of successful intrusion (including by a malicious
administrator). To prevent this, the authorization server can be made tolerant to accidental faults and intrusions [6]. A fault and intrusion-tolerant authorization server is made of diverse security sites, administered by independent persons, so that acci- dental faults and malicious intrusions can be tolerated without degrading the service, as long as only a minority of security sites are affected.
To tolerate the failure of one or a small number of the sites composing the authorization server, several protocols specified in [11–14], are used (cf. Fig. 2):
Atomic multicast: the request sent by an object to the authoriza- tion server is distributed to all the sites composing the authori- zation server. The multicast communication is reliable in the sense that all requests (sent by a non-faulty site) are received correctly by all non-faulty receiving sites and atomic in the sense that non-faulty receiving sites receive identical message sets in the same order. This condition is useful for achieving mutual agreement.
Mutual agreement: all non-faulty sites agree on the decision to grant or deny the authorization corresponding to a given request. This guarantees a correct decision as long as there are at most f faulty sites, where the number f depends on the failure mode assumptions. If we assume that the faulty sites are fail- silent (e.g., thanks to dedicated hardware as presented in [15]), then f must be such that ðn > 2f Þ where n is the total number of sites. If we do not make any assumption on the fail- ure mode of the sites (e.g., by admitting that a security site might have a corrupt administrator), then Byzantine behavior needs to be taken into account and, under these hypotheses, we have the relationship ðn > 3fÞ. We use the ABBA protocol [11], which is a randomized Byzantine agreement protocol that terminates in a constant expected number of asynchronous rounds, except with negligibly small probability.
Threshold signature: the capabilities, tokens and vouchers are globally signed by the authorization server, using a threshold signature scheme. For that, each of the sites composing the authorization server generates a signature share (based on its own private key share) so that if at least t valid signature shares are available (t being the threshold), it is possible to combine these shares to generate a unique signature that can be verified with a global public key. This guarantees that if a capability (or a token, or a voucher) has a correct signature, the corresponding operation is indeed authorized (the signed capability cannot be
forged, even by conspiracy between f faulty sites, as long as f is strictly less than the threshold t).
This set of protocols allows the safety property AS1 (cf. Section 2.2.1) to be enforced. Indeed, thanks to the protocols presented above, we can tolerate a number f of faulty sites: f depends on the assumption regarding the failure mode of the faulty sites as ex- plained above (n > 2f or n > 3f) and, furthermore, f must be less than t. Under the assumption that no more than f sites are faulty, the authorization server cannot generate false authorization proofs (property AS1), because the mutual agreement protocol guarantees a correct decision and because the threshold signature scheme guarantees a correct signature of the proofs of authorization.
Regarding the liveness property AS2, fault prevention and toler- ance mechanisms must be used so that no network denial of ser- vice attack can succeed and no network failure can occur. These mechanisms are out of the scope of this paper. However, some hints on how this might be done are as follows. Network failure can be prevented by using network redundancy and reconfigura- tion, in such a way that the network stays operational even during successful sub-network attacks. Regarding denial of service at- tacks, some research work has been done to identify malicious net- work flows and propose mechanisms and methods to tolerate them [34]. Even in the absence of network attacks, the authoriza- tion server must be dimensioned so that it can answer authoriza- tion requests in an efficient way for a particular realm. As a consequence, a precise evaluation of the necessary processing and networking resources must be done so that the authorization server does not suffer from unavailability. As presented in Section 6.3.1, the performance measures that we obtained for one proto- type implementation lead us to believe that this is quite realistic.
The dialogue between an object initiating a composite opera- tion and the authorization server is typically as follows. Object O asks the authorization server for the authorization to carry out the composite operation. If the authorization is granted by a major- ity of the sites composing the authorization server, each non-faulty site of the authorization server returns to O the same list of permis- sions for atomic operations, signed by its signature share. If Oreceives at least t copies of the list, Ocan rebuild the global autho- rization server signature for the list:
ðfPermðO; O 1 :m 1 Þ; . . . ; PermðO; O n :m n ÞgÞ SK
asð5Þ Each of these permissions contains a capability CapðO; O
i:m
iðparCÞÞ or a token.
Security Security Authorization Server
Site
...
Site Security
hardware tamperproof Monitor
Reference threshold signature
mutual agreement atomic multicast transmission Site
Fig. 2. Protocols of the authorization server.
To prevent capability forgery or abuse, each one is ciphered
1with the public key PK
hðOiÞof the host where O
iis located, and signed by the global private key SK
asof the authorization server AS:
CapðO; O i :m i ðparCÞÞ ¼ ððO; O i :m i ; parC; nonceÞ PK
hðOiÞ
Þ SK
asð6Þ
The nonce is used to prove the freshness of the capability and pre- vent replay.
If the capability is accompanied by a voucher, this voucher con- tains a set of permissions needed by O
ito execute m
ion behalf of O.
The voucher itself is signed by the global private key SK
asof the authorization server:
VouchðO i :m i Þ ¼ ðfPermðO 0 ; op 1 Þ; . . . ; PermðO 0 ; p n ÞgÞ SK
asð7Þ
5. Reference monitor
There is a local reference monitor on each participating host.
The reference monitor is responsible for granting or denying atom- ic operations (i.e., local object method invocations), according to capabilities generated by the authorization server (or by the refer- ence monitor itself, for transient local objects). In the context of wide-area networks (such as the Internet), the implementation of such a reference monitor is quite complex since, due to the heter- ogeneity of connected hosts, it would be necessary to develop one version of the reference monitor for each kind of host. Moreover, since the hosts are not under the control of a global authority, there is no way to ensure that each host is running a genuine reference monitor, or the same version thereof.
The reference monitor host is thus composed into two parts: a tamperproof hardware-resident part and a host-resident part (called dispatcher). The dispatcher is a local object, run by each host, that is in charge of controlling all invocations by/to local ob- jects. To improve application transparency, the dispatcher also stores and manages the permissions that have been granted to all objects located on the host. For instance, when an object in- vokes another object, the dispatcher checks the permissions belonging to the invoking object to verify it has indeed a capability to carry out this invocation. It inserts the capability and (option- ally) the voucher into the invocation message, and sends the whole message to the destination dispatcher, which will then check the capability and store the permissions included in the voucher for the invoked object.
The dispatcher has the responsibility of deciding whether or not to authorize the invocation of particular methods on particular ob- jects on the local host by asking the tamperproof hardware part of the reference monitor to check that the corresponding capabilities are present and valid (through signature verification routines).
These checks represent the central part of the authorization scheme, and thus have to be protected as strongly as possible, which is why they must be implemented on tamperproof hard- ware. Note that, any software, even that within an operating sys- tem, can be copied and modified by a malicious user who possesses all privileges on a local host. In particular, on the Inter- net, any hacker can easily have these privileges on his own com- puter! With capability checks run on truly tamperproof hardware, we can be confident that any remote request is genuine (if the capability is correct), and that a genuine request can only be executed on the host for which the capability is valid. The hacker’s
privilege on his host gives him no privilege outside that host as long as he cannot hack the tamperproof hardware.
A private/public key pair associated to each host is generated and stored on its tamperproof hardware. The public key of the authorization server is also stored on this tamperproof hardware.
The public keys are stored on tamperproof hardware for integrity reasons, to prevent attacks that would modify these keys. The host’s private key is generated and stored on tamperproof hard- ware for confidentiality reasons: this private key never leaves the tamperproof hardware, it cannot neither be read nor modified.
Each capability generated by the authorization server is ciphered with the public key of the host where the invoked object resides and then signed with the private key of the authorization server.
These techniques allow the property RM1 (cf. Section 2.2.2) to be implemented: on a non-faulty host, if the capability is not cor- rectly ciphered and signed, the corresponding operation will not be executed. We trust the reference monitor to correctly check the capabilities. We think it is reasonable to trust the reference moni- tor because we trust the code and data that are embedded in the tamperproof hardware. Furthermore, a faulty host cannot generate false permissions for other hosts because these permissions must be signed by the private key of the authorization server.
An acknowledgement mechanism is used to prevent a faulty host from impersonating a non-faulty host without being detected:
each time a proof of authorization is received by a host, the latter returns an acknowledgement signed with its private key to the re- quester. This acknowledgment is accompanied by a certificate gen- erated by the authorization server. If the acknowledgment is received from a non-faulty host, the requester can verify its valid- ity (property RM2). If a faulty host tries to impersonate a non- faulty host by intercepting all the messages for this non-faulty host, it cannot send this acknowledgement because it cannot ci- pher it with the private key of the non-faulty host (this key is never transmitted outside of the tamperproof hardware). As a conse- quence, even if this faulty host intercepts messages for the non- faulty host in such a way that the non-faulty host no longer receives them (denial of service attack), the attack will be detected because the requester will not receive correct acknowledgements.
This protection mechanism ensures property RM3 (cf. Section 2.2.2) and is also useful against network denial of service attacks or net- work failures. We can rely on this acknowledgment mechanism because we trust tamperproof hardware not to reveal the crypto- graphic keys. We trust it not to reveal the keys because we con- sider that accessing data stored on this tamperproof hardware is sufficiently difficult.
Let us emphasize the following point: the mechanisms pre- sented are not sufficient to guarantee the correct behaviour of a complete application. If a host is corrupted, the local processes can do anything locally, and thus can totally change their behav- iour with respect to the whole application. They can decide to in- voke operations on local objects that do not form part of the composite operation, or to invoke constantly the same method of the same local object, or not to invoke necessary operations on ob- jects located on other hosts. The mechanisms we implement aim to enforce the security policy of the system and cannot guarantee that the behaviour of each process is correct as regards the application it is part of. Other mechanisms such as object replication are needed to deal with these problems. The only information that is managed by our authorization scheme (authorization server and reference monitors) is authorization information and our mecha- nisms only deal with this information. In summary, the authoriza- tion mechanisms guarantee that only authorized operations will be executed on a non-faulty host and guarantee that a faulty host cannot prevent other non-faulty hosts from operating correctly.
Furthermore, the tamperproof hardware used to carry out crypto- graphic verification allows Sybil attacks to be prevented.
1
A capability is the only proof of authorization that needs to be ciphered and
signed; tokens are only signed, because the knowledge of their contents cannot give
any authorization privilege. Nevertheless, it would also be useful to cipher (with the
reference monitor’s public key) the lists of permissions and the vouchers, if the
knowledge of their contents is considered a breach of privacy.
6. Prototype: an implementation example
In this prototype, we chose to implement all the objects of a complete distributed application in Java. Invocation between ob- jects are carried out through Java RMIs (Remote Method Invoca- tions). The tamperproof hardware-resident part of the reference monitor is a JavaCard.
26.1. Cryptographic keys
Several cryptographic keys are stored in the JavaCard:
The realm public key, that we note PK
r. This key is associated with the realm private key SK
r, which is not stored in the Java- Card. SK
ris used to sign realm-compliant code.
A private/public key pair specific to JavaCard j, that we note SK
j, PK
j.
The authorization server public key, PK
as(this key is associated with the private key shares of the authorization sites, using a threshold signature algorithm, see Section 4).
The secret symmetric key K
iused to cipher the capabilities for local transient objects.
6.2. Capability verification
A distributed application in the context of a realm is executed by means of method invocations between realm objects located on realm-compliant hosts. The realm object codes are signed off- line by the global realm private key SK
r, and this signature is checked by the local JVM of the realm host by using the corre- sponding public key PK
r, which can be read on the JavaCard by the JVM. The invocation parameters and returned values are thus exchanged between objects by passing messages through these Java RMIs.
Each capability is ciphered by the public key PK
jof the JavaCard of the host where the invoked object is located and signed by the private key SK
asof the authorization server. Capability verification is thus done in three steps: (1) the JavaCard checks the signature of the capability by using the authorization server public key PK
as; (2) the JavaCard deciphers the capability with its own private key SK
j; (3) the JavaCard verifies that the invocation is compatible with the capability contents (identity of the invoker, identity of the invoked method including the invoked object identity, compatibility of the invocation parameters with the parameter constraints included in the capability).
As explained in Section 3, a capability is generally accompanied by a voucher, which contains the permissions needed for the in- voked method to be authorized to invoke other operations.
A permission can be a capability to invoke an object method or a token to initiate a composite operation. If the permission is a capa- bility, this capability is ciphered by the public key of the JavaCard associated with the host on which the invoked object resides and will be checked by the corresponding JavaCard (step 3 of Fig. 3).
If the permission is an authorization to carry out a composite oper- ation, the token is presented to the authorization server as a proof that the object is authorized to carry out that operation (step 3 of Fig. 4). The authorization server simply checks the validity of the token and then delivers the corresponding permissions to the object.
6.3. Proof-of-concept implementation
We implemented an experimental prototype of our approach and carried some performance measurements with the aim of identifying potential bottlenecks in the security mechanisms.
The authorization server of our prototype is composed of four security sites, configured to tolerate a single Byzantine fault (i.e., n = 4, f = 1). The equipment we had available to implement the ser- ver consisted of two Dell desktops (with Intel Xeon and Core2 Duo processors, and 2 and 6 Gb of RAM respectively), and two MacBook laptops (both with Intel Core2 Duo processors and 2 Gb of RAM).
These four machines communicate through a 100 Mbps network.
O’
. This capability is verified by the reference monitor of the host O’
2. The corresponding method of is invoked once the capability O
O message
1
2
3
3. The voucher contains the capability for to invoke a method of 1. An invocation message carrying a capability and a voucher
PKm, PKas SKj,PKj, Ki
is received by the local reference monitor
authorizing this access has been certified by the Java Card O
O’
Java Card
of when invokes the corresponding method of O O’
Reference Monitor
Java Card Reference
Monitor
Fig. 3. Example of a voucher containing a capability on a remote object.
2
