Channel engineering of SOI MOSFETs for RF applications

(1)

Channel engineering of SOI MOSFETs for RF applications

The MIT Faculty has made this article openly available.

Please share

how this access benefits you. Your story matters.

Citation

Chen, C.L. et al. “Channel engineering of SOI MOSFETs for RF

applications.” SOI Conference, 2009 IEEE International. 2009. 1-2. ©

2009 IEEE

As Published

http://dx.doi.org/10.1109/SOI.2009.5318756

Publisher

Institute of Electrical and Electronics Engineers

Version

Final published version

Citable link

http://hdl.handle.net/1721.1/53745

Terms of Use

Article is made available in accordance with the publisher's

policy and may be subject to US copyright law. Please refer to the

publisher's site for terms of use.

(2)

This work was supported by the Defense Advanced Research Projects Agency under Air Force Contract FA8721-05-C-0002. Opinions, interpretations, conclusions, and recommendations are those of the authors, and are not necessarily endorsed by the United States Government.

1 Channel Engineering of SOI MOSFETs for RF Applications

C. L. Chen, J. M. Knecht, J. Kedzierski, C. K. Chen, P. M. Gouker, D-R. Yost,

P. Healey, P. W. Wyatt, and C. L. Keast

Lincoln Laboratory, Massachusetts Institute of Technology, Lexington, MA 02420-9108

Email: CLCHEN@LL.MIT.EDU, Tel: (781) 981-4507 Abstract-Channel engineering of SOI MOSFETs is

explored by altering ion implantation without adding any new fabrication steps to the standard CMOS process. The effects of implantation on characteristics important for RF applications, such as transconductance, output resistance, breakdown voltage, are compared. Data show that the best overall RF MOSFET has no body and drain-extension implants.

Introduction

Silicon MOSFETs have been used for RF circuits for their high performance and relatively low power consumption. Most RF circuits are integrated with logic CMOS to provide mixed-signal functions or to realize a compact system on a chip (SOC). High speed and low leakage current are the most critical requirement for logic circuits and they are achieved usually by deep scaling while maintaining a high threshold voltage VT. However, for most RF circuits, in addition to a low gate resistance, a high output resistance, high drive current with high breakdown, and high linearity are desirable.

The requirements for logic and RF MOSFETs are not always the same and in some cases they are even opposite to each other. Although different devices tailored for logic and RF can be optimized separately, added processes may not be compatible and they definitely increase the cost. In this work, we showed that desired RF properties can be obtained by simply modifying channel implants of standard SOI logic MOSFETs without additional masks or process steps.

Processing and implant engineering

The n-MOSFETs were fabricated using 150-nm fully depleted (FD) SOI CMOS process with added metal T-gate [1] for RF applications. Poly-Si T-gate with 2.5-nm gate oxide was used. Standard- and high-VT FETs were implemented using different body implant doses. The source/drain (S/D) extension and halo were implanted before depositing an 85-nm-wide spacer, which was followed by heavy S/D contact implants. Standard Co salicide was used for contacts. The thicknesses for SOI and BOX are 42 and 400 nm, respectively. Body doping of the standard device is around 5×1017_cm-3_{while the} unimplanted device is around 1×1017_cm-3_p-type.

The FETs compared in this work have either one of the two body implants or no body implant at all. Deviating from conventional devices, some FETs did not have extension implants for drain, source, or both. Because the same mask was used, no extension implant

also means no halo implant. All FETs use the standard S/D contact implant.

Test results

The effects of body implant on 150-nm FETs are shown in Fig. 1(a). As expected, the FET without body implant (NoB) has lower VT, therefore, higher drain current, and is still on at 0-V gate bias, Vg. It also shows higher output resistance (Rout) in the saturation region and higher breakdown voltage. Without the body implant, the inversion charge is controlled dominantly by the gate bias and less affected by the drain bias, resulting in a smaller short channel effect (SCE). The peak transconductance (gm) increases from 506 for the standard FET to 563 μS/μm without the body implant.

For high-VT FETs with higher body doping, as shown in Fig. 1(b), the Rout also increases and this is the conventional approach for SCE reduction. The apparent kink in the I-V plot suggests that the FET is no longer fully depleted and a higher body doping also lowers the drain current Id at the same Vg, limiting power handling capability for RF applications. Note that the drain is biased beyond the designed 1.5 V to reveal breakdown characteristics. Even biased below 1.5 V, it is not uncommon to drive the FET into this regime when a large signal is applied, and any sharp decrease in Rout will degrade the linearity of RF circuits. Therefore, a high breakdown voltage is highly desirable.

Obviously, a longer effective gate can reduce the SCE and our data show that this can be achieved by eliminating the drain extension implant (NoD) without significant performance degradation. As shown in Fig. 2(a), the Rout and breakdown voltage (VBD) increase by eliminating the drain extension implant. However, the series resistance and the knee voltage also increase because of higher drain resistance. Similar improvements on Rout and breakdown, but without the negative effects, were observed for the FET-NoB-NoD, as shown in Fig. 2(b). Although the SCE can be further reduced by eliminating both source and drain extension implant (NoSD), the device performance is severely degraded. At absence of source to gate overlap, the gm is lowered by more than 50% (not shown).

Figure 3 compares the gm and the subthreshold plots of the standard FET with and without both body and drain extension implants. Compared to the standard FET, the FET-NoB-NoD shows more than 12% increase in gm which peaks at lower Vg, characteristics favored for RF.

(3)

Lack of body implant results in a higher subthreshold swing (SS), 99.5 vs. 70.7 mV/dec for the standard FET at Vd = 1.5V, and higher leakage current at 0 V. However, unlike for logic circuits, these parameters are often not as important for RF devices. Table I summarizes the effects of various channel implants on the DC device parameters. The results suggest that the FET-NoB-NoD has the most desirable properties as an RF device.

On-wafer scattering (S) parameters were measured and Fig. 4 compares the effects of channel engineering on the fT and fmax. MOSFETs with 180-nm gate are compared because of completeness of the implant splits and similar trend is observed for 150-nm devices. In this measurement, Vd is kept at 1.5 V while varying Vg and the highest fT and fmax are shown. The fT increases with gm and it peaks at the Vg coinciding with that for maximum gm. The data show that the FET-NoB has the highest fT because of the highest gm. However, the fmax actually suffers slightly from a lower Rout. Despite a lower fT, absence of the drain extension implant increases Rout and decreases overlapping capacitance, resulting in a large increase in fmax. Figure 5 shows similar improvement for 150-nm gate FETs which has a higher fT than those with 180 nm gate. The highest fmax measured is 119 GHz, a 20% increase compared to a standard FET. A combination of no body and drain extension implant provides the best overall RF performance. Although not shown here, in this work, we also found that the FET always degrades with increasing total gate width. Therefore, for the same drive current and power of RF circuits, smaller total gate width is desirable which also favors the FETs without body implant.

Summary

Our results demonstrate that by simply changing the implants in the channel of a FDSOI MOSFET, both DC and RF performance can be improved and such optimization can be easily integrated into the standard logic CMOS. The best fT can be achieved by eliminating the body implant while the highest fmax is obtained by also eliminating the drain, but not source, extension and halo implants.

References

1. C. L. Chen, et al., IEEE Electron Device Lett., vol. 23, no. 1, 2002, pp. 52-54.

Fig. 1 Id-Vd of n-MOSFETs with 150-nm gate length and 10-μm-wide T-gate. (a) Standard and no body implant. (b) Standard and high VT.

0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id (μA/ μm) Standard No body/drain implant Vg = 0 to 1.25 V Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 (b) 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id (μA/ μm) Standard No body/drain implant Vg = 0 to 1.25 V Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 (b) 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id ( μA/ μm) Standard No drain-extension implant Vg = 0 to 1.25 V Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 (a) 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id ( μA/ μm) Standard No drain-extension implant Vg = 0 to 1.25 V Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id ( μA/ μm) Standard No drain-extension implant Vg = 0 to 1.25 V Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 (a)

Fig. 2 Id-Vd of n-MOSFETs with 150-nm gate length and

10-μm-wide T-gate. (a) Standard and no drain-extension implant. (b) Standard and no body/drain-extension implant.

0 100 200 300 400 500 600 700 -0.4 -0.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) gm ( μS/ μm) 0.5 V 1.5 V Vd = 1.5 V 0.5 V No body/drain-extension implant Standard _(b) -0.4 -0.2 0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) 100 200 300 400 500 600 700 0 gm (μ S/ μm) 0 100 200 300 400 500 600 700 -0.4 -0.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) gm ( μS/ μm) 0.5 V 1.5 V Vd = 1.5 V 0.5 V No body/drain-extension implant Standard _(b) -0.4 -0.2 0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) 100 200 300 400 500 600 700 0 gm (μ S/ μm) 1.5 V 1.E-12 1.E-11 1.E-10 1.E-09 1.E-08 1.E-07 1.E-06 1.E-05 1.E-04 1.E-03 1.E-02 -0.4 -0.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) Id ( A /μ m) Vd = 0.5 V Standard No body/drain-extension implant 10-2 10-4 10-6 10-8 10-10 10-12 (a) Id ( A /μ m) -0.4 -0.2 0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) 1.5 V 1.E-12 1.E-11 1.E-10 1.E-09 1.E-08 1.E-07 1.E-06 1.E-05 1.E-04 1.E-03 1.E-02 -0.4 -0.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V) Id ( A /μ m) Vd = 0.5 V Standard No body/drain-extension implant 10-2 10-4 10-6 10-8 10-10 10-12 (a) Id ( A /μ m) -0.4 -0.2 0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 Vg (V)

Fig. 3 Comparison of standard FET and FET-NoB-NoD with 150-nm gate length and 10-μm-wide T-gate. (a) Subthreshold plot. (b) gm plot.

Fig. 4 Measured fT and fmax of 180-nm-gate MOSFETs all with 10-μm-side T-gate. The Vd is fixed at 1.5 V and Vg varies for maximum fmax. 30 40 50 60 70 80 90 100 110 120

2x10T-180 2x10T-180-B2 2x10T-180-NoB 2x10T-180-NoD 1x10T-180-NoD-NoB

FET fT , fma x (G H z) fT fmax

Standard High VT No body No drain No body/drain

180 nm metal-T gate length

fT , fma x (GH z) 30 40 50 60 70 80 90 100 110 120 30 40 50 60 70 80 90 100 110 120

2x10T-180 2x10T-180-B2 2x10T-180-NoB 2x10T-180-NoD 1x10T-180-NoD-NoB

FET fT , fma x (G H z) fT fmax

Standard High VT No body No drain No body/drain

180 nm metal-T gate length

fT , fma x (GH z) 30 40 50 60 70 80 90 100 110 120

Fig. 5 Comparison of fT and fmax of FETs with different channel implant and gate length. All FETs have one 10-μm wide T-gate finger except for 150-nm standard FET, which has two 5-μm wide gate fingers. Because of narrower gate, this FET inherently has slightly higher fT and fmax than the others. The bias condition is the same as in Fig. 4.

30 40 50 60 70 80 90 100 110 120 130 2x5T-150 1x10T-150-NoD 1x10T-150-NoD-NoB 1x10T-180 1x10T-180-NoD 1x10T-180-NoD-NoB FET fT , fmax (G Hz) fT fmax 150 nm 180 nm fT , fma x (G Hz ) 30 40 50 60 70 80 90 100 110 120 130 No drain/body No drain/body

Standard No drain Standard No drain

30 40 50 60 70 80 90 100 110 120 130 2x5T-150 1x10T-150-NoD 1x10T-150-NoD-NoB 1x10T-180 1x10T-180-NoD 1x10T-180-NoD-NoB FET fT , fmax (G Hz) fT fmax 150 nm 180 nm fT , fma x (G Hz ) 30 40 50 60 70 80 90 100 110 120 130 No drain/body No drain/body

Standard No drain Standard No drain

0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id ( μA/ μm) Standard No body implant Vg = 0 to 1.25 V (a) Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id ( μA/ μm) Standard No body implant Vg = 0 to 1.25 V (a) Vd (V) Id ( μA/ μm) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id (μA/ μm) Vg = 0 to 1.25 V Standard

High body doping

(b) Vd (V) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 Id ( μA/ μm) 0 100 200 300 400 500 600 700 800 0.0 0.5 1.0 1.5 2.0 2.5 3.0 Vd (V) Id (μA/ μm) Vg = 0 to 1.25 V Standard

High body doping

(b) Vd (V) 100 200 300 400 500 600 700 800 0 0.5 1.0 1.5 2.0 2.5 3.0 0 Id ( μA/ μm) No body/drain No source/drain No drain No body High threshold Standard I_off SS V_BD R_out g_m I_d FETS No body/drain No source/drain No drain No body High threshold Standard I_off SS V_BD R_out g_m I_d FETS

Table I. Effects of implant on DC characteristics
