Numerical investigation of Taylor bubble and development of phase change model

(1)

HAL Id: tel-03177304

https://tel.archives-ouvertes.fr/tel-03177304

Submitted on 23 Mar 2021

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of sci-entific research documents, whether they are pub-lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

development of phase change model

Longkai Guo

To cite this version:

Longkai Guo. Numerical investigation of Taylor bubble and development of phase change model. Fluids mechanics [physics.class-ph]. Université de Lyon, 2020. English. �NNT : 2020LYSEI095�. �tel-03177304�

(2)

N°d’ordre NNT : 2020LYSEI095

THESE de DOCTORAT DE L’UNIVERSITE DE LYON

opérée au sein de

l’INSA LYON

Ecole Doctorale

N° EDA162

Mécanique, Energétique, Génie Civil, Acoustique

Spécialité/ discipline de doctorat : Mécanique des Fluides

Soutenue publiquement/à huis clos le 28/10/2020, par :

Longkai GUO

Numerical investigation of Taylor bubble and

development of a phase change model

Devant le jury composé de :
