Strongly reducing (Diarylamino)benzene-based covalent organic framework for metal-free visible light photocatalytic H2O2 generation

Strongly Reducing (Diarylamino)benzene-Based Covalent Organic Framework for Metal-Free Visible Light Photocatalytic H

O

Generation

Chidharth Krishnaraj, Himanshu Sekhar Jena, Laurens Bourda, Andreas Laemont, Pradip Pachfule, Jérôme Roeser, C. Vinod Chandran, Sander Borgmans, Sven M. J. Rogge, Karen Leus,

Christian V. Stevens, Johan A. Martens, Veronique Van Speybroeck, Eric Breynaert, Arne Thomas,*

and Pascal Van Der Voort*

Cite This:https://dx.doi.org/10.1021/jacs.0c09684 Read Online

ACCESS

*

ABSTRACT: Photocatalytic reduction of molecular oxygen is a promising route toward sustainable production of hydrogen peroxide (H₂O₂). This challenging process requires photoactive semiconductors enabling solar energy driven generation and separation of electrons and holes with high charge transfer kinetics. Covalent organic frameworks (COFs) are an emerging class of photoactive semiconductors, tunable at a molecular level for high charge carrier generation and transfer. Herein, we report two newly designed two-dimensional COFs based on a (diarylamino)benzene linker that form a Kagome (kgm) lattice and show strong visible light absorption. Their high crystallinity and large surface areas (up to 1165 m²·g⁻¹) allow efficient charge transfer and diffusion. The diarylamine (donor) unit promotes strong reduction properties, enabling these COFs to efficiently reduce oxygen to form H₂O₂. Overall, the use of a metal-free, recyclable photocatalytic system allows efficient photocatalytic solar transformations.

■

Covalent organic frameworks (COFs) are an emerging class of crystalline porous organic materials, built up from covalently linked organic molecules.¹ Tuning the reticular chemistry leading to these structures enables synthesis of crystalline, photoactive, porous, and highly stable materials, providing an optimal platform for photocatalysis.²The main factors required for an efficient photocatalyst are (i) suitable band gaps, (ii) proper band position alignments, (iii) strong light absorption, (iv) efficient charge carrier generation, (v) high charge transfer kinetics, (vi) low recombination, and (vii) efficient diffusion and active sites.³⁻⁵By modifying the starting linker, COFs can be functionalized at a molecular level to optimize these properties. Functionalities such as triazine, porphyrin, and benzothiadiazole have been incorporated into COFs to improve charge transfer kinetics and charge carrier separa- tion.^2,6 By incorporating alternating donor−acceptor moieties into an extended framework, several COFs have been rendered suitable for photocatalysis.^7,8 There remains, however, extensive potential to design COFs optimized for photo- catalysis by tweaking their structures at a molecular level.

In photocatalysis, COFs have been mainly limited to hydrogen evolution reaction through water splitting,⁹ CO₂ reduction,¹⁰ degradation of organic pollutants,¹¹ oxidative

hydroxylation of arylboronic acids to form phenols,¹²oxidation of anisoles to sulfoxides,¹³ reductive dehalogenation of phenacyl bromide,¹⁴oxidative coupling of amines to imines,¹⁵ etc. To the best of our knowledge, COFs enabling photo- catalytic reduction of molecular oxygen to produce H₂O₂have not yet been reported.

Hydrogen peroxide (H₂O₂) is a widely used chemical with applications as an antiseptic, a disinfectant, and a bleaching agent, and as an oxidizer in synthetic pathways. It is produced on a large scale through multistep hydrogenation of anthraquinone moiety using H₂, followed by oxidation using O₂.¹⁶ Direct production of H₂O₂ with Au−Pd bimetallic catalysts using H₂and O₂gas mixtures was also investigated.¹⁷ Alternative approaches involving electrochemical, photocata- lytic, and photoelectrochemical processes were also studied for this purpose.^18,19 Recently, Yamashita and co-workers have developed a two-phase system for the photocatalytic H₂O₂

Received: September 9, 2020

Article pubs.acs.org/JACS

© XXXX American Chemical Society A

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX copying and redistribution of the article or any adaptations for non-commercial purposes.

Downloaded via 94.226.14.68 on November 13, 2020 at 16:01:01 (UTC). See https://pubs.acs.org/sharingguidelines for options on how to legitimately share published articles.

production. The photocatalyst is dispersed in one phase (benzyl alcohol) where oxidation reaction takes place, whereas in the other phase (water) reduction of O₂ to form H₂O₂ occurs.^20,21 This promoted separation and avoided catalytic decomposition of H₂O₂. Photocatalytic pathways provide a sustainable route for H₂O₂synthesis as they involve (i) a one- step reaction, (ii) utilization of green reagents, and (iii) light as the source of energy. Especially, the use of only visible light for the production of H₂O₂ is considered to be particularly sustainable.²² Photocatalytic H₂O₂synthesis is performed by irradiating water saturated with oxygen in the presence of a semiconductor, using alcohols as the electron and proton donors. Excitation of the semiconductor produces electron (e⁻) and hole (h⁺) pairs. The holes oxidize the alcohol and produce aldehyde and protons (eq 1). Simultaneously, the electrons promote a two-electron reduction of oxygen to give H₂O₂(eq 2).²²A side reaction, detrimental to the desired two- electron reduction of oxygen, involves one-electron reduction to produce a superoxide anion. Hence an efficient system to selectively perform the two-electron reduction is required.

− + ⁺→ − + ⁺

R CH OH₂ 2h R CHO 2H (1)

+ ⁺+ ⁻→

O₂ 2H 2e H O_{2 2} (0.68 V vs NHE) (2) Wurster-type systems are classic examples of phenylenedi- amine units displaying redox activity (Figure 1a).^23,25Phenyl-

enediamine units are found in several dyes and are relevant in several biological processes. In erythrocytes, they can react with molecular O₂ to form superoxide radicals and Wurster salts, which can further react to generate hydrogen peroxide (Figure 1b).²⁵ For example, N,N,N′,N′-tetramethyl-p-phenyl- enediamine (TMPD) undergoes autoxidation to generate

“active oxygen” species which could be responsible for toxic changes in the erythrocytes. In a similar molecular system, Ito et al. reported one-electron oxidation of 9,10-bis(di(p-anisyl)- amino)anthracene inducing formation of a mixed-valence species, i.e., a delocalized cationic radical species, [D−π−

D]^•+.²⁴Recently, diarylamine scaffolds (derivatives of phenyl- enediamine) have been used for metal-free molecular photo- catalytic fluoroalkylation.²⁶ The diarylamine (donor) moiety acts as a strong reducing agent and promotes reduction. These studies encouraged us to design COFs based on diarylamine/

diaminobenzene units for exploiting their strong reduction properties in photocatalysis.

Herein, we report the synthesis of two highly crystalline COFs: TAPD-(Me)₂ and TAPD-(OMe)₂. Both COFs are highly stable (chemically and thermally) and form a Kagome lattice as a result of the C4 + C2 linkage. There are only a limited number of COFs with Kagome lattices,²⁷⁻²⁹and the N,N,N′,N′-tetrakis(4-aminophenyl)-1,4-phenylenediamine

(TAPD) linker expands the inventory of C4 linkers which can be used to form Kagome lattices. Considering the high charge transfer transitions in COFs, for the first time, TAPD-(Me)₂ and TAPD-(OMe)₂ COFs have been applied for photo- catalytic production of H₂O₂through oxygen reduction. This photocatalytic system is completely metal-free and green solvents are used for the reaction, thus paving way for a sustainable pathway.

■

TAPD-(Me)₂and TAPD-(OMe)₂COFs are synthesized in the presence of 6 M acetic acid (0.1 mL) by reactingN,N,N′,N′- tetrakis(4-aminophenyl)-1,4-phenylenediamine (TAPD, 23.6 mg. 0.5 mmol) with 2,5-dimethylbenzene-1,4-dicarboxalde- hyde ((Me)₂, 16.2 mg, 1 mmol) or 2,5-dimethoxybenzene-1,4- dicarboxaldehyde ((OMe)₂, 19.4 mg, 1 mmol), in the presence of 1:1 o-dichlorobenzene/butanol (0.6 mL) or 1:1 dioxane/

mesitylene (0.6 mL) respectively (Figure 2, section S2 in the Supporting Information). For the synthesis of the COFs, the TAPD linker was deliberately utilized because of the possibility of internal charge transfer transitions leading to strong absorption bands in the visible light region. In similar molecular systems (diarylamino(anthracene)), Konishi et al.

showed that distorted donor planes induce interchromophoric conjugation rather than conjugation within the local structure which promotes charge transfer between the diarylamine and anthracene moieties.³⁰ Contrary to the general expectation, Brédas et al. have shown that the strength of electronic interaction is higher in benzene than in anthracene for such diarylamino systems due to the dependence on steric interactions.³¹ This led us to use diarylamino(benzene) as the COF linker to promote strong electronic interactions.

The imine (CN) bond formation was confirmed through Fourier transform infrared (FT-IR) spectroscopy. Stretching vibrations at 1616 and 1612 cm⁻¹correspond to imine linkages in TAPD-(Me)₂ and TAPD-(OMe)₂ COFs, respectively (Figures S4 and S5). ¹H direct excitation MAS NMR (35 kHz MAS; 800 MHz) confirmed the presence of phenyl, N CHPh, and methyl and methoxy protons for TAPD-(Me)₂ and TAPD-(OMe)₂ COFs, respectively. ¹³C{¹H} CPMAS (Figure 3g−j) revealed nine different carbon signals for TAPD- (Me)₂COF and TAPD-(OMe)₂COF. All carbon resonances can be assigned to the local chemical structure forming the Kagome sheets. Note that both ¹H MAS NMR and ¹³C{¹H}

CPMAS NMR reveal the presence of methoxy and methyl substitutions in the structure. Combining¹H double quantum (DQ)−single quantum (SQ) and¹³C{¹H} CP heterogeneous correlation (HETCOR) spectra allows confirmation of the local chemical environments occurring in the COF structures (Figure 3c−f). While ¹³C{¹H} CP HETCOR reveals the substitution of the C_A and C_B of the phenyl moiety with methyl and methoxy groups, respectively, ¹H DQ−SQ MAS NMR reveals a strong correlation between the respective methyl/methoxy protons and the HCα of the phenyl group (Figures S6−S9). Elemental analyses were performed to reveal the elemental composition of the COFs. The obtained C/N and C/H ratios were 7.23/13.49 for TAPD-(Me)₂COF and 7.42/13.90 for TAPD-(OMe)₂ COF, respectively. These values matched well with the theoretically calculated values (Table S2).

Powder X-ray diffraction (PXRD) analyses were performed to determine the structural features of the synthesized COFs.

Both TAPD-(Me)₂ and TAPD-(OMe)₂ COFs exhibited Figure 1. (a)N,N,N′,N′-Tetramethyl-p-phenylenediamine (TMPD)

as a two-stage Wurster-type redox system. (b) Generation of hydrogen peroxide in erythrocytes in the presence of TMPD.²³

Journal of the American Chemical Society pubs.acs.org/JACS Article

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX B

intense reflections in the low-angle region at 2.3 and 2.4°2θ(d spacing ∼3.8 and 3.7 nm), respectively. An additional set of lower symmetry reflections that could not be assigned to the starting monomers are also obtained in the low-angle region, indicating the formation of crystalline frameworks (Figure 4, Figures S21 and S24). Indexing of the PXRD patterns in primitive hexagonal lattices and the presence of broad diffraction peaks at∼20.4 and 18.6°2θsuggest the formation of a 2D layered material stacking in the c direction through π−πinteractions. According to the symmetry of the linkers, the structural models for TAPD-(Me)₂and TAPD-(OMe)₂COFs were constructed by generating the expected 2D layers with kgmtopology and modeling stacking sequences with eclipsed (AA) and staggered (AB) arrangement (Figure 4c−f, section S4 in the Supporting Information, Figures S21−S26). The models were geometrically optimized, and their corresponding theoretical PXRD patterns were compared to the experimen- tally measured patterns. Pawleyfitting over the full profile was carried out to refine thefinal unit cell parameters (for TAPD- (Me)₂,a=b= 43.26 Å,c= 4.35 Å,R_wp = 3.28%; for TAPD- (OMe)₂,a=b= 41.50 Å,c= 4.76 Å,R_wp= 3.17%), resulting in low residual values and acceptable profile differences (Figure 4a,b).

To further elucidate the atomic structure of the synthesized COFs, molecular dynamics (MD) simulations were performed at 300 K and 1 bar to include peak broadening effects. These MD results are obtained withoutfitting or refining any model parameter, using ab initio derived force fields for the TAPD- (Me)₂and TAPD-(OMe)₂COFs with QuickFF protocol^32,33 (section S5 in theSupporting Information). Furthermore, the dynamic simulations intrinsically take into account the movement of adjacent layers. Hence, no separate AA and AB models need to be considered. However, given that the

functional groups in adjacent layers can be in either a parallel or an inverted conformation, both possibilities were explicitly modeled (Figure S28). As illustrated in Figure 5 and Figure S30, the MD simulations provide similar unit cell parameters for both COFs in line with the expectations for the almost identical building units used in both materials and indicate that the COFs display only limited deviations from a perfect AA stacking, showcasing the strong interlayer interactions.

Furthermore, the MD simulations indicate that the most likely ordering of the functional groups is inverted for both COFs and allow the indexing of the experimentally observed PXRD peaks, as shown inFigure 5.

The permanent porosity of TAPD-(Me)₂COF and that of TAPD-(OMe)₂ COF were assessed by argon sorption measurements at 87 K and N₂sorption measurements at 77 K (Figure 6,Figures S32 and S33). Both COFs display a steep uptake in the low-pressure region (P/P₀< 0.01), correspond- ing to permanent microporosity. In addition, a step is observed in the isotherm aroundP/P₀= 0.22. This feature represents the filling of the second type of bigger pores. The overall isotherm is a combination of type I and type IV isotherms, indicating both microporous and mesoporous characteristics as expected in the Kagome type structures. With the use of Ar sorption, Brunauer−Emmett−Teller (BET) surface area values of 1105 and 1165 m²·g⁻¹were observed for TAPD-(Me)₂and TAPD- (OMe)₂COFs, respectively. With the use of N₂sorption, the BET surface area values were calculated to be 1083 and 1153 m²·g⁻¹ for TAPD-(Me)₂ and TAPD-(OMe)₂ COFs, respec- tively. Pore size analysis, using an argon sorption-based quenched solid density functional theory (QSDFT) carbon kernel for cylindrical-type pores, shows two different pore sizes as expected from the Kagome type COF structures. The experimental and theoretical average pore sizes for TAPD- Figure 2.Synthesis of TAPD-(Me)2and TAPD-(OMe)2COFs forming a dual pore Kagome lattice.

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX C

(Me)₂and TAPD-(OMe)₂COFs were 1.7/2.7 nm (theoretical 1.5/2.5 nm) and 1.3/2.5 nm (theoretical 1.4/2.4 nm), respectively (Figure 6, inset), thus confirming the formation of 2D layers with kgm topology stacking in an eclipsed AA stacking mode. These characterizations prove the successful formation of the expected structures of TAPD-(Me)₂ and TAPD-(OMe)₂COFs.

Transmission electron microscopy (TEM) images of both COFs revealed crystalline features with domain sizes in the range of >50 nm (Figure 7a,c,Figures S14 and S16). Scanning electron microscopy (SEM) analyses show rough spherical morphologies of both COFs (Figure 7b,d, Figures S15 and S17). To analyze the structural integrity, the chemical and thermal stabilities of the COFs were tested. Both COFs (20 mg each) were immersed in 1 M HCl (acidic) and 1 M NaOH

(basic) solutions for 72 h and were washed with water and acetone before further analysis. PXRD patterns collected after these treatments show that the COFs retain their crystallinities and remain stable (Figures S18 and S19). The yields of the COFs after treatment with acid and base were >90%.

Additionally, both COFs remain insoluble in common organic solvents such as acetone, methanol, ethanol, hexane, tetrahydrofuran, diethyl ether, and dichloromethane. Further- more, after the COFs were soaked in dimethylformamide for 8 days, the crystallinity was retained (Figures S18 and S19). In addition to the chemical stability, no significant loss in mass of COFs was observed when they were heated to 450 °C as shown through thermogravimetric analyses (Figure S20).

By integrating functionalized units or groups such as triazine,² diacetylene,⁹ sulfone,³⁴ etc., in the COF backbone, Figure 3.Solid-state NMR spectra of TAPD-(Me)₂(left column) and TAPD-(OMe)₂(right column). Panels a and b show¹H MAS (35 kHz) NMR spectra and decompositions which yielded the chemical shifts and fractions. Panels c and d show¹H DQ-SQ 2D correlations indicating the proximity of one of the phenyl protons to the methyl and methoxy protons. Panels e and f show¹H−¹³C CP HETCOR 2D correlations indicating the proximity of one type of carbon atoms at the phenyl rings to the attached methyl and methoxy protons. The¹³C{¹H} CPMAS spectrum (g) corresponds to the structure (h), and the spectrum (j) corresponds to the structure (i). All the experiments were carried out on a Bruker Neo 800 MHz spectrometer operating at 18.8 T magneticfield.

Journal of the American Chemical Society pubs.acs.org/JACS Article

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX D

several photocatalytic conversions have been achieved successfully. For efficient photocatalytic activity, the COF

needs to generate electron−hole pairs and avoid recombina- tion. The (diarylamino)benzene unit in the TAPD-(Me)₂and Figure 4.PXRD pattern and Pawley refinement of (a) TAPD-(Me)2 and (b) TAPD-(OMe)2COFs. Top views of (c) TAPD-(Me)2 and (d) TAPD-(OMe)2COFs showing the ideal eclipsed (AA) structures. Side views of (e) TAPD-(Me)2and (f) TAPD-(OMe)2COFs. H atoms are omitted for clarity.

Figure 5.Comparison between experimentally observed and MD calculated PXRD patterns for TAPD-(Me)₂and TAPD-(OMe)₂, averaged over the course of a 400 ps MD simulation at 300 K and 1 bar (Cu-kα,λ= 1.5406 Å) usingab initioderived system-specific forcefields. The resulting unit cell parameters and peak positions have been indicated.

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX E

TAPD-(OMe)₂ COFs is a strong donor and has strong reducing properties.²⁶Moreover, high crystallinity of the COFs can enhance the charge transfer kinetics.³⁴Diffuse reflectance ultraviolet−visible (UV−vis) spectroscopy was used to analyze the optical properties of the COFs, where it was observed that each COF exhibits a broad and strong absorbance peak in the visible region (Figure 8a). The optical band gaps calculated from Tauc plots are 2.61 and 2.63 eV, respectively, for TAPD- (Me)₂ and TAPD-(OMe)₂ COFs (Figure 8b). This makes them ideal materials for visible light activation and photo- catalytic H₂O₂generation.

The positions of the conduction bands (CBs) and valence bands (VBs) of both COFs were estimated on the basis of linear sweep voltammetry measurements under chopped illumination.^35,36 A photocatalyst-coated FTO substrate was used as the working electrode in a three-electrode setup, together with an Ag/AgCl (3 M NaCl) reference electrode and a Pt coil counter electrode. Under an applied bias of +0.4 V vs Ag/AgCl and chopped white light illumination, an anodic

photocurrent was measured. As the bias voltage was swept in the negative direction from +0.4 to−0.4 V at a scan rate of 4 mV/s, the photocurrent decreased in magnitude and then changed sign. The potential at which the sign change of the photocurrent occurred allows calculation of a good estimate of the conduction band minimum (Figures S35−S37). The CB band positions were determined in three different alkaline buffers, displaying a Nernstian dependence of the CB position with pH. From these values, the CB positions at pH 0 were extrapolated (Figure S38). In combination with the optical band gaps as derived from the Tauc plots, the band structures were derived for TAPD-(Me)₂ (CB =−0.97 eV, VB = 1.64 eV) and TAPD-(OMe)₂ (CB = −0.80 eV, VB = 1.83 eV) COFs as shown in Figure 8c. The band positions are very much under the requirements for oxygen reduction to hydrogen peroxide (0.68 V vs NHE); hence the COFs were utilized further for H₂O₂generation.

Photocatalytic H₂O₂ generation experiments were per- formed in sealed glass vials with water:ethanol (9:1), where ethanol acts as the electron and proton donor. Under visible light (420−700 nm) irradiation, long-term (16 h) reactions were carried out at room temperature (condenser) with 20 mg of COF used as the photocatalyst. H₂O₂ concentration was determined through iodometric titration.⁴⁴ After 16 h of reaction, the TAPD-(Me)₂ and TAPD-(OMe)₂ COFs produced 25.3 and 22.6 μmol of H₂O₂, respectively, when irradiated under 250 W (5.46 W m⁻²) light. This is quite comparable to pure carbon nitride, which produced 30μmol of H₂O₂but used a 2 kW (26.9 W m⁻²) light source and with 9 times higher ethanol content.²² Also, in the case of TAPD- (Me)₂COF when a higher amount of ethanol (water:ethanol 1:9) was used, 57.2 μmol of H₂O₂ was produced, which is almost twice more than pure carbon nitride.²² We acknowl- edge that it is difficult to compare the activities of different materials due to different reaction conditions (irradiation wavelength, light intensity, sacrificial agent, reaction time, etc.).

Besides, most of the catalysts used in the literature (Table 1) for H₂O₂ production involve the assistance of a metal (Au, TiO₂, etc.), whereas the COFs provide a completely metal-free platform. The H₂O₂production vs time profile was recorded for the photocatalytic reaction over 5 h (Figure 8d). The overall H₂O₂production rates of 97±10 and 91±10μmol h⁻¹g_cat⁻¹were obtained for TAPD-(Me)₂and TAPD-(OMe)₂ COFs, respectively.

The following reaction mechanism is proposed (Figure S39). The reaction proceeds with the formation of electron− hole carriers through visible light irradiation on the COF. The holes are utilized by ethanol to produce acetaldehyde and two protons along with it. Molecular oxygen utilizes the electrons from the COF and the protons from the alcohol trans- formation to produce H₂O₂. Electron and hole trapping experiments were performed using silver nitrate (AgNO₃) and triethylamine (TEA), respectively (Table S3). In the case of the electron trapping experiment there was a drastic decrease in the formation of H₂O₂, whereas in the case of the hole trapping experiment there was no formation of H₂O₂. This emphasizes the role of photocatalytic electron−hole carriers in the overall reaction. Further, benzoquinone was used as a radical scavenger in the reaction system to determine the role of radicals in the reaction (Table S3). However, the reaction proceeded without much hindrance which means the radicals formed are quickly utilized for the formation of H₂O₂. A similar fast step was also observed in the carbon nitride Figure 6.Ar sorption isotherms and pore size distributions (inset) of

TAPD-(Me)₂COF and TAPD-(OMe)₂COF.

Figure 7.TEM and SEM images of (a, b) TAPD-(Me)₂and (c, d) TAPD-(OMe)₂ COFs showing crystalline domains and the morphology of COF crystallites.

Journal of the American Chemical Society pubs.acs.org/JACS Article

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX F

photocatalyst,²² where the one-electron reduction of O₂ to release superoxide (^•OOH) is suppressed. To determine the H₂O₂selectivity, the reaction was tested with benzyl alcohol as the proton source instead of ethanol, as the quantification of benzaldehyde is more reliable than that of acetaldehyde using NMR analysis. The reaction was performed with water:benzyl alcohol (1:9) for 16 h at room temperature by using TAPD-

(Me)₂ COF. A 53.7 μmol amount of H₂O₂ was produced, which is comparable to the reaction with ethanol under the same conditions.¹H NMR analysis showed the production of benzaldehyde, and correspondingly H₂O₂ was produced with 96% selectivity (Figure S40). In addition, this also confirms the mechanism of the reaction. As expected, alcohol to aldehyde conversion occurs which provides protons for reducing oxygen Figure 8.(a) Solid state UV−vis spectra, (b) Tauc plot analyses for band gap calculations, (c) band potential alignments of the COF vs NHE (V) at pH 0, and (d) H₂O₂production per gram of catalyst over 5 h of reaction time of TAPD-(Me)₂and TAPD-(OMe)₂COFs.

Table 1. Photocatalytic Production of H₂O₂

entry material H₂O₂production rate irradiation conditions solvent system reference

1 g-C₃N₄ 63.00μmol h⁻¹g_cat⁻¹ λ= 420−500 nm H₂O:EtOH (1:9) 22

2 g-C₃N₄/PDI-BN0.2-rGO_0.05 30.80μmol h⁻¹g_cat⁻¹ λ> 420 nm H₂O 37

3 PEI/C₃N₄ 208.10μmol h⁻¹g_cat⁻¹ solar simulator

(AM = 1.5)

H₂O 38

4 Si/TiO₂-Au 14.80μmol h⁻¹ λ= 365 nm 0.01 M HCl, Y³⁺

cocatalyst

39

5 g-C₃N₄/AQ-COOH 361.00μmol h⁻¹g_cat⁻¹ λ> 400 nm propan-2-ol/H₂O (1:9) 40 6 g-C₃N₄/rGO (10 wt %) 74.30μmol h⁻¹g_cat⁻¹ λ> 400 nm propan-2-ol/H₂O (1:9) 40 7 boron nitride quantum

dots−carbon nitride (BNQD/UPCN)

72.30μmol h⁻¹g_cat⁻¹ λ> 420 nm propan-2-ol/H₂O (1:9) 41

8 C-N-g-C₃N₄ 0.98μmol h⁻¹g_cat⁻¹ 420 <λ< 700 nm H₂O 42

9 OPA/Zr_92.5Ti_7.5-MOF 9700.00μmol L⁻¹h⁻¹ λ> 420 nm benzyl

alcohol:H₂O (2.5:1) 20

10 resorcinol−formaldehyde resins ∼40.00^aμmol h⁻¹ λ> 420 nm H₂O 43

11 TAPD-(Me)₂COF 97.00μmol h⁻¹g_cat⁻¹ λ= 420−700 nm H₂O:EtOH (9:1) this work

12 TAPD-(OMe)₂COF 91.00μmol h⁻¹g_cat⁻¹ λ= 420−700 nm H₂O:EtOH (9:1) this work

13 TAPD-(Me)₂COF 234.52μmol h⁻¹g_cat⁻¹ λ= 420−700 nm H₂O:EtOH (1:9) this work

aExtrapolated from graph.

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX G

to H₂O₂. A control reaction was performed with all substrates excluding the COF yielding no significant amount of H₂O₂. Further, the reaction was also tested with all the substrates and the COF but in the absence of light. No H₂O₂was produced, thus confirming the requirement of light (Table S3). To check the reusability of the catalyst, the reaction was performed for five consecutive cycles with TAPD-(Me)₂ COF and no significant loss of activity was observed (Figure S41). The PXRD patterns of the COFs after 16 h of photocatalytic reactions show that they retain crystallinity, confirming that the structure is stable under the reaction conditions (Figures S42 and S43). SEM analyses before and after catalysis of TAPD- (Me)₂ and TAPD-(OMe)₂ COFs show no changes in the overall morphologies (Figures S44 and S45). Additionally, the reaction was performed for 96 h continuously and 142.3μmol of H₂O₂ was obtained. The production was still linear compared to the overall kinetics in the short-term reactions (Figure S46). The effect of different alcohol sources in the reaction was tested by performing the photocatalytic reactions using isopropanol and methanol in addition to ethanol and benzyl alcohol. The production of H₂O₂ was in the order isopropanol > ethanol > methanol > benzyl alcohol (Figure S47). These results imply that the COFs are active for metal- free visible light photocatalytic production of H₂O₂by oxygen reduction.

■

Inspired by Wurster-type systems, we have synthesized a new series of imine COFs consisting of (diarylamino)benzene units. These COFs are highly crystalline and arrange into a Kagome lattice. ¹³C−¹H and ¹H−¹H NMR experiments confirmed the local chemical environments of the COFs.

The COFs remained stable under various thermochemical conditions. Molecular dynamics simulations on the COF structures further confirmed the AA stacked crystalline nature.

Both COFs displayed high surface areas, strong absorption in the visible light region, and ideal band gaps for photocatalysis.

The absolute positions of the conduction and valence bands were determined by linear sweep voltammetry under chopped illumination. Photocatalytic reactions using oxygen-saturated water under visible light irradiation showed a high H₂O₂ production rate. The catalysts are stable and reusable for several runs of the reaction. This study is the first example of utilizing COFs for photocatalytic H₂O₂production and opens a new avenue toward solar driven metal-free photocatalysis.

■

*^sı Supporting Information

The Supporting Information is available free of charge at https://pubs.acs.org/doi/10.1021/jacs.0c09684.

Experimental details on organic synthesis, NMR, FT-IR, elemental analyses, TEM, SEM, structural modeling, ab initio PXRD modeling, photo(electro)chemical charac- terization, catalytic evaluations, and stability tests (PDF) Crystal structure data of TAPD-(Me)₂COF with Pawley refinement (CIF)

Crystal structure data of TAPD-(OMe)₂ COF with Pawley refinement (CIF)

Forcefields (ZIP)

■

Pascal Van Der Voort−COMOC−Center for Ordered Materials, Organometallics and Catalysis, Department of Chemistry, Ghent University, 9000 Ghent, Belgium;

orcid.org/0000-0002-4874-0943;

Email:pascal.vandervoort@ugent.be

Arne Thomas −Department of Chemistry/Functional Materials, Technische Universität Berlin, 10623 Berlin, Germany; orcid.org/0000-0002-2130-4930;

Email:arne.thomas@tu-berlin.be Authors

Chidharth Krishnaraj −COMOC− Center for Ordered Materials, Organometallics and Catalysis, Department of Chemistry, Ghent University, 9000 Ghent, Belgium;

Department of Chemistry/Functional Materials, Technische Universität Berlin, 10623 Berlin, Germany; orcid.org/

0000-0001-8625-7322

Himanshu Sekhar Jena−COMOC−Center for Ordered Materials, Organometallics and Catalysis, Department of Chemistry, Ghent University, 9000 Ghent, Belgium;

orcid.org/0000-0002-5869-5226

Laurens Bourda−COMOC−Center for Ordered Materials, Organometallics and Catalysis, Department of Chemistry and XStruct −Bio-Inorganic Chemistry, Department of

Chemistry, Ghent University, 9000 Ghent, Belgium Andreas Laemont−COMOC−Center for Ordered

Materials, Organometallics and Catalysis, Department of Chemistry, Ghent University, 9000 Ghent, Belgium Pradip Pachfule −Department of Chemistry/Functional

Materials, Technische Universität Berlin, 10623 Berlin, Germany

Jérôme Roeser−Department of Chemistry/Functional Materials, Technische Universität Berlin, 10623 Berlin, Germany

C. Vinod Chandran −NMRCoRe, 3001 Leuven, Belgium;

Center for Surface Chemistry and Catalysis− Characterisation and Application Team (COK-kat), Department of Microbial and Molecular Systems (M2S), KU Leuven, 3001 Leuven, Belgium

Sander Borgmans−Center for Molecular Modeling (CMM), Ghent University, B-9052 Zwijnaarde, Belgium

Sven M. J. Rogge−Center for Molecular Modeling (CMM), Ghent University, B-9052 Zwijnaarde, Belgium;

orcid.org/0000-0003-4493-5708

Karen Leus −COMOC− Center for Ordered Materials, Organometallics and Catalysis, Department of Chemistry, Ghent University, 9000 Ghent, Belgium

Christian V. Stevens−Synthesis, Bioresources and Bioorganic Chemistry Research Group (SynBioC), Department of Green Chemistry and Technology, Ghent University, 9000 Ghent, Belgium; orcid.org/0000-0003-4393-5327

Johan A. Martens −NMRCoRe, 3001 Leuven, Belgium;

Center for Surface Chemistry and Catalysis− Characterisation and Application Team (COK-kat), Department of Microbial and Molecular Systems (M2S), KU Leuven, 3001 Leuven, Belgium

Veronique Van Speybroeck−Center for Molecular Modeling (CMM), Ghent University, B-9052 Zwijnaarde, Belgium;

orcid.org/0000-0003-2206-178X

Eric Breynaert− NMRCoRe, 3001 Leuven, Belgium; Center for Surface Chemistry and Catalysis− Characterisation and Journal of the American Chemical Society pubs.acs.org/JACS Article

https://dx.doi.org/10.1021/jacs.0c09684 J. Am. Chem. Soc.XXXX, XXX, XXX−XXX H

Application Team (COK-kat), Department of Microbial and Molecular Systems (M2S), KU Leuven, 3001 Leuven, Belgium

Complete contact information is available at:

https://pubs.acs.org/10.1021/jacs.0c09684

Author Contributions

All authors have given approval to the final version of the manuscript.

Notes

The authors declare no competingfinancial interest.

■

The authors thank Katrien Haustraete for the TEM measure- ments. C.K., S.B., P.V.D.V., V.V.S., and C.V.S. thank the Research Board of Ghent University (GOA010-17, BOF GOA2017000303) for funding. C.K. acknowledges the support from the FWO travel abroad grant V427919N. H.S.J. thanks FWO [PEGASUS]²Marie Sklodowska-Curie grant agreement No. 665501 for Incoming postdoctoral fellowship. S.M.J.R.

wishes to thank the Fund for Scientific Research Flanders (FWO) for a postdoctoral fellowship (Grant No. 12T3519N).

This work was supported by the Hercules Foundation (AKUL/13/21) and by the Flemish Government, department EWI, via the Hermes Fund (AH.2016.134). J.A.M. and P.V.D.V. acknowledge VLAIO for Moonshot funding (ARCLATH, n° HBC.2019.0110). J.A.M. acknowledges the Flemish Government for long-term structural funding (Methusalem Beneficiary Johan A. Martens). J.A.M. and V.V.S. have received funding from the European Research Council (ERC) under the European Union’s Horizon 2020 research and innovation program under Grant Agreement Nos.

834134 and 647755 (DYNPOR), respectively. A.T., P.P., and J.R. acknowledge the funding by the Deutsche Forschungsge- meinschaft (DFG, German Research Foundation) under Germany’s Excellence StrategyEXC 2008-390540038 UniSysCat and the project TH 1463/15-1. The computational resources and services used in this work were provided by the VSC (Flemish Supercomputer Centre), funded by the Research Foundation Flanders (FWO) and the Flemish Government, department EWI.

■
