A Restful Interface for RDF Stream Processors

(1)

A Restful Interface for RDF Stream Processors

Marco Balduini¹and Emanuele Della Valle¹ DEIB – Politecnico di Milano, Italy

marco.balduini@polimi.it, emanuele.dellavalle@polimi.it

Abstract. This poster proposes a minimal, backward compatible and combinable restful interface for RDF Stream Engine.

1 Introduction

A number of RDF Stream Processors exists (e.g., CQELS [1], SPARQLstream[2], ETALIS/EP-SPARQL [3], Sparkwave [4], INSTANS [5] and C-SPARQL En- gine [6]), butthey do not talk each other.

This hampers comparative evaluations: existing benchmark proposals [7, 8]

had to create software adapters to test the various processors. In this condition, it is difficult to assess how much the benchmark results depend on the performances of the processors and how much on those of the adapters.

Moreover, the lack of a shared protocol to transmit RDF streams hinders the combined usage of those processors. For instance, a user may want:a) to deploy SPARQLstream to natively process data streams¹;b) to semantically enrich the resulting RDF streams using Sparkwave (or INSTANS); c) to aggregate the enriched streams in events using the C-SPARQL Engine (or CQELS); and d), finally, to detect complex events with ETALIS/EP-SPARQL.

This poster proposes a restful interface for RDF Stream Processors that is:

1. minimal– more sophisticated interface can be envisioned, but in this at- tempt we would like to create a broad consensus, thus we avoid proposing controversial solutions.

2. backward compatible – we are reusing RDF and SPARQL standards wherever we can so to guarantee that adaptation of non-streaming clients for RDF and SPARQL is straight forward.

3. combinable– the proposed interface enforces that the output of a processor can serve as input to a processor (including the one that generates it).

The remainder of the paper is organised as follows. Section 2 briefly presents the background required to understand the proposed interface. Section 3 proposes the interface. Section 4 shortly discusses two requirements that are not considered for this minimal proposal and how the interface can be extended to cover them. A proof of concept implementation of the proposed interfaces for the C-SPARQL engine is available for download at http://streamreasoning.org/

download.

1 SPARQLstream rewrites continuous SPARQL queries issued against virtual RDF streams on continuous SQL-like queries on data streams.

(2)

2 Background

From a conceptual point of view, existing RDF Stream Processors are homoge- nous. They define the notion ofRDF Stream– an unbound list of tuples< t, τ >

wheretis an RDF triple andτ is a non-decreasing timestamp –, andcontinuous SPARQL query– a SPARQL query extended so that it can process RDF streams using continuous operators (e.g., windows to logically convert a portion of the infinite RDF stream in an RDF graph) and time-aware operators (e.g., sequence to ask that a graph pattern is detected before another one).

To the best of our knowledge, limited efforts was spent in defining a protocol for: a) transmitting RDF stream across RDF Stream Processor on separated machines, b) registering a continuous query in a processor, and c) observing the continuously evolving results. The only existing solution are proprietary.

For instance, the C-SPARQL Engine is typically used within the Streaming Linked Data framework [9]. Similarly, CQELS is paired with the Super Stream Collider [10].

3 Services

A community effort is needed to propose a continuous SPARQL extension that can span across the existing proposals, but we believe this is the right time to propose a restful interfaces that processors can easily implement.

The following proposal specifies how to manage RDF streams, continuous SPARQL queries, and observers of continuous results (see Table 1 for details).

Complying to restful principles, users can register a new RDF streamσin the processor using the PUTmethod on the resource /streams/. As a result the RDF stream /streams/σ becomes available in the processor. At this point, they can stream information on the RDF stream POSTing an RDF graph to /streams/σ) and they can unregister it using the DELETE method. The list of all registered stream is returned whenGETting the resource/streams/.

It is worth to note that, learning from flexible time management in data stream processors [11], we propose to avoid annotating the streamed RDF graphs with a timestamp. This complies to the expected input of best effort data stream processors (e.g. esper). We leave the annotation of the streamed RDF graphs with application timestamp to a future extension of thisminimalprotocol. Moreover, this design decision allows the proposal to be backward compatible. Any Semantic Web application can send information to an RDF Stream Processor simply posting an RDF graph.

User can register a new continuous SPARQL queryγin the processor using the PUT method on the resource /queries/. The proposed interface is agnostic w.r.t. the language used to declare the query and leaves to the processor to parse the query in the body of the request. Nonetheless, it requires the query to refer only to RDF streams already registered in the processor. If the user tries to register a query on streams that have not been registered, yet, the service must refuse to register the query. If the registration is successful, the processor starts the continuous execution of the query and the query/queries/γappears in

(3)

Table 1: The herein proposed restful interfaces for RDF Stream Processors. Along with restful principles,GETing a resource returns what wasPUTed.

RDF Streams

Method Address Body Description

PUT /streams/<id> Register new stream

DELETE /streams/<id> Delete specified stream

POST /streams/<id> RDF model Stream new information

GET /streams Get the list of streams

Continuous SPARQL queries

PUT /queries/<id> query Register new query

DELETE /queries/<id> Delete specified query

POST /queries/<id> callback URL Adds an observer POST /queries/<id> Action [pause, restart] Change query status

GET /queries Get the list of queries

Observers

DELETE /queries/<id>/observers/<id> Delete specified observer GET /queries/<id>/observers Get observers list

the list of queries that can be retrievedGETting the resource/queries/. As for the RDF streams, the query/queries/γcan be unregistered using theDELETEmethod.

The methodPOSTon the resource/queries/γis used to start observing the query results, to pause the query and to restart it.

Access to query results follows an observable-observer design pattern. In order to start observing the results of a query γ, a user has to POST a callback URL to/queries/γ. The created observerω is identified by an URL of the form

/queries/γ/observers/ω. The user can stop observing the query byDELETing this resource. Multiple observers per query are possible. Whenever γcomputes new results, the processor notifies all the observers by invoking the provided callback URLs.

If the query is of the formsSELECTorASK, results must be formatted according to SPARQL 1.1 query results², thus allowing forbackward compatibilitywith existing SPARQL resultset parsers.

If the query is of the formsCONSTRUCTor DESCRIBE, the processor mustPOSTan RDF graph containing the result. As a result our proposal is not onlybackward compatibility – it is conform to SPARQL 1.1 result formats –, but it is also combinable – the results of a query can bePOSTed to another registered RDF stream. The callback URL passed as parameter in starting an observer simply has to be the URL of an existing RDF stream³.

4 Conclusions

The proposal, being minimal, ignored important requirements w.r.t. time mod- elling, access control, and transmission overhead.

2 Our implementation supportshttp://www.w3.org/TR/2013/REC-sparql11-results-json/

3 In order to avoid the overhead to stream on HTTP an RDF stream that is consumed by the same processor, when a queryγof the formsCONSTRUCTorDESCRIBEis registered, an RDF stream, whose identifier is/streams/γ, is automatically registered. The result of the queryγ is internally streamed on it.

(4)

Adding the application time to the protocol is only a matter toPOSTa timestamp together with the RDF graph. However, as explained in [11], in the case of multiple distributed sources POSTing to the same RDF stream, out-of-orders can appear due to lack of clock synchronisation and different network delays. In our future work, we will propose this extension and, at the same time, we will release an open-source package that includes the management out-of-orders.

The proposed interface lacks access control, but it is ready for HTTP-based access control. An HTTP server, between the user and the Restful service con- tainer, can handle access to /streams and/queries. Moreover, only the owner of a query γ can start observing the results of γ or is allowed to list all the observers (i.e., GETting/queries/γ/obsevers/). However, investigating OAuth-based access-control is on our research agenda.

Last, but not least, we recognise that the transmission overhead of the proposed solution can reduce the processor throughput if the user frequently POSTs RDF graphs containing only few triples. In our future work, we intent to explore the streaming of RDF triples in N-quads format on a Web-socket.

References

1. Le-Phuoc, D., Dao-Tran, M., Xavier Parreira, J., Hauswirth, M.: A native and adaptive approach for unified processing of linked streams and linked data. In:

ISWC. (2011) 370–388

2. Calbimonte, J.P., Corcho, O., Gray, A.J.G.: Enabling ontology-based access to streaming data sources. In: ISWC. (2010) 96–111

3. Anicic, D., Fodor, P., Rudolph, S., Stojanovic, N.: EP-SPARQL: a unified language for event processing and stream reasoning. In: WWW. (2011) 635–644

4. Komazec, S., Cerri, D., Fensel, D.: Sparkwave: continuous schema-enhanced pattern matching over RDF data streams. In: DEBS. (2012) 58–68

5. Rinne, M., Nuutila, E., Törmä, S.: Instans: High-performance event processing with standard rdf and sparql. In: ISWC (Posters & Demos). (2012)

6. Barbieri, D.F., Braga, D., Ceri, S., Della Valle, E., Grossniklaus, M.: Querying rdf streams with c-sparql. SIGMOD Record39(1) (2010) 20–26

7. Zhang, Y., Duc, P., Corcho, O., Calbimonte, J.P.: SRBench: A Streaming RDF/S- PARQL Benchmark. In: ISWC. (2012) 641–657

8. Le-Phuoc, D., Dao-Tran, M., Pham, M.D., Boncz, P., Eiter, T., Fink, M.: Linked stream data processing engines: Facts and figures. In: ISWC. (2012) 300–312 9. Balduini, M., Celino, I., Dell’Aglio, D., Valle, E.D., Huang, Y., il Lee, T.K., Kim,

S.H., Tresp, V.: Bottari: An augmented reality mobile application to deliver per- sonalized and location-based recommendations by continuous analysis of social media streams. J. Web Sem.16(2012) 33–41

10. Quoc, H.N.M., Serrano, M., Le-Phuoc, D., Hauswirth, M.: Super stream collider–

linked stream mashups for everyone. In: Proceedings of the Semantic Web Chal- lenge co-located with ISWC2012, Boston, MA, US (2012)

11. Srivastava, U., Widom, J.: Flexible time management in data stream systems. In:

PODS, New York, New York, USA (2004) 263
