INTERNAL FRICTION ASSOCIATED WITH THE RE-SOLUTION AND PRECIPITATION OF THE θ - PHASE ALONG THE GRAIN BOUNDARIES AND IN THE MATRIX OF ALUMINIUM-COPPER ALLOYS

(1)

HAL Id: jpa-00227167

https://hal.archives-ouvertes.fr/jpa-00227167

Submitted on 1 Jan 1987

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

INTERNAL FRICTION ASSOCIATED WITH THE RE-SOLUTION AND PRECIPITATION OF THE θ - PHASE ALONG THE GRAIN BOUNDARIES AND IN

THE MATRIX OF ALUMINIUM-COPPER ALLOYS

P. Cui, T. Kê

To cite this version:

P. Cui, T. Kê. INTERNAL FRICTION ASSOCIATED WITH THE RE-SOLUTION AND PRECIP- ITATION OF THE θ - PHASE ALONG THE GRAIN BOUNDARIES AND IN THE MATRIX OF ALUMINIUM-COPPER ALLOYS. Journal de Physique Colloques, 1987, 48 (C8), pp.C8-417-C8-422.

�10.1051/jphyscol:1987863�. �jpa-00227167�

(2)

JOURNAL DE

PHYSIQUE

Colloque C8, supplbment au n012, Tome 48, dbcembre 1987

INTERNAL FRICTION ASSOCIATED WITH THE RE-SOLUTION AND PRECIPITATION OF THE

8

- PHASE ALONG THE GRAIN BOUNDARIES

AND

I N THE MATRIX OF ALUMINIUM-COPPER ALLOYS

A

P.

C U I

and T. S. KE

Institute of Solid State Physics, Academia Sinica, Hefei, China

A b s c r a c c Low f r e q u e n c y i n ; e r n a l frLc::on a n d e 1 a s : i c m o d u l u s measure men;^

w e r c made wi:h a l u m i n i u m c o n : a i n i n g 0 . 0 1 5 L O 1 . 2 w: % Cu. ( 1 ) Wnen Cu con:enn i s l o w e r :;Ian 0 . 5 wt %, a n i n z e r n a l f r i c ~ i o n p e a k P l a p p e a r s a i a l o w e r L e m p e r a t u i e ::Ian t h a t o f :he g i - a l n b o u n d a r y p e a k o b s e r v e d i n p u r e a l u m i n i u m . ( 2 ) When c o p p e r conZen: r e a c h e s 0.5 wc "L, P l a p p e a r s i n m e a s u r e m e n t s wi:n d e s c e n d i n g ;empera:ures.

However, t n i s p e a k i s l o w e r e d c o n s i d e r a b l y when m e a s u r e d w::h a s c e n d i n g cempera:ures a n d a n o c h e r p e a k P 2 a p p e a r s a r o u n d 3 6 0 % a n d i s i n d e p e n d e n : o t f r e q u e n c y b u ~ v a r i e s w i t h c o p p e r c o n p e n t , t h e way o f c h a n g i n g c e n p e r a t u r e s , a n d a g e i n g L e m 2 e r a t u r e a n d c i m e . Tne e l a s c i c m o d u l u s d r o p s a b r u p t l y c o r r e s p o n d i n g wi:h :he a p p e a r a n c e o f

%.

^{( 3 )}

When c o p p e r c o n t e n : r e a c h e s 1 . 2 wt %, a p e a k P 3 a p p e a r s a r o u n d 2 9 0 ' ~ when m e a s u r e d w l t n d e s c e n d i n g :empcra:ures. The b e h a v l o r o f P3 i s s i m i l a r t o t n a : o f

9,

e x c e p t t h e e l a s t i c m o d u l u s r i s e s instead of d r o p p i n g c o r r e s p o n d : n g w i t h t h e a p p e a r a n c e of P 3 '

Expe.riments wi:h s p e c i m e n s c o n : a i n i n g o n l y a few bamboo b o u n d a r i e s a n d X-ray a n a l y s i s show :ha: t h e a p p e a r a n c e o f P, a n d P 2 L s o r i g i n a c e d respectively f r o m t h e r e - _L s o l u t i o n a n d ;he p r e c i p I : a t i o n of 0 - p h a s e a r o n g t h e g r a i n b o u n d a r i e s .

E x p e r i m e n c s wi:h A1-4 wt % show t h a : P' ( 4 3 0 ' ~ ) a n d P ' ( 4 1 0 ' ~ ) p e a k s a s s o c i a t e d

2 .

w i t h t h e r e - s o l u t i o n a n d p r e c i p i ~ a t i o n o f O-pilase i n s i d e

2,e

g r a i n s p r o p e r a p p e a r L o g e t h e r w i t n p e a k s P a n d P

2 3 '

I. I n t r o d u c t i o n

S i n c e t h e d i s c o v e r y of t h e g r a i n b o u n d a r y i n t e r n a l f r i c t i o n p e a k o f 9 9 . 9 9 a l u - minium by KG I n 1947 [ I ] , n u m e r o u s r e s e a r c h w o r k s h a v e b e e n d o n e on t n e e f f e c : of a l l o y i n g e l e m e n t s on : i ~ L s ; n : e r n a l f r i c t i o n p e a k [ 2 ] . T h i s p e a k was f o u n d 2 0 s n i f : i o l o w e r c e n p e r a t u r e s t o r l e s s p u r e 9 9 . 6 % alum:n<um [ 3 ] . However, r e c e n : r e s u l t s show ;ha: :he op:imum :enpera:ures f o r :he g r a i n b o u n d a r y p e a k o b s e r v e d I n 9 9 . 9 9 , 9 9 . 9 9 9 a n d 9 9 . 9 9 9 9 h i g h - p u r i : y a l u m i n i u m a r e r e s p e c : i v e l y 2 9 0 , 270 a n d 210UC r e f e r r i n g

;o f r e q u e n c y = 1 Hz [ 4 ] . T h i s i n d i c a : e s :hat :he pea^ s ; ~ i f t s t o n i g n e r L e m p e r a i u r e s f o r l e s s p u r e s p e c i m e n s . Sucn a contradiction o f r e s u l t s may r e f l e c t t h e f a c : :na:

:he s:a:e of t h e a l l o y i n g e l e n e n t s a: :ne q r a l n b o u n d a r i e s , i n s o l i d so1u:Ion o r i n p r e c i p i t a ~ i o n s t a t e , may be c r u c i a l i n a f f e c t i n g :lie g r a i n b o u n d a r y : e l a x a t i o n p r o - c e s s g i v i n g r i s e i o :he i n t e r n a l f r i c c l o n p e a k . A f o r w a r d s ~ e p was made by Q u a d e r [ 5 ] ;n 11;s i n ~ e r n a l f r i c i i o n s:udy on a l u n l n L u m a l l o y s wi::~ 2 a n d 2 . 9 5 w: % Cu. Two t r a n s i c n : I n c e r n a l f r i c t i o n p e a k s w e r e o b s e r v e d : o n e p e a k i s c o n n e c c c d wi:n p r o c e s s of p r e c i p i t a t i o n from s o l i d so1u:ion a n d :he o t h e r Ls c o n n e c z e d wi:n i h e p r o c e s s of r e - s o l u t i o n of :he p r e c l p i : a t l o n s : a i e . I n :he p r e s c n : r e s e a r c h , a s y s t c n a ; i c s t u d y a l o n g : h i s l ; n e was made w i c k l o w e r ( 0 . 0 1 5 :o 1 . 2 wi %! a n d h i g n e r ( 4 w: %) c o p p e r con:cn;s i n a l u m i n i u n wi:n :he p u r p o s e o f c 1 a r ; f y i n g :he c o n t r a d i c t o r y r e s u l ~ s r e - p o r t e d I n :he l i c e r a t u r e . X-ray s ~ u d i e s w e r e made I n c o r r e 1 a : i o n w i t h i n t e r n a l f r : c - t i o n a n d e l a s ~ i c m e d u l u s m e a s u r e m e n t s .

TI. The S p e c i m e n s

The s p e c i m e n s u s e d w e r e s u p p l i e d by Fusnun Aluminium P l a n : o f C h i n a wiLk compo- s;:ion shown i n T a b l e 1 . The 3-mn r o d s r e c e i v e d w e r c a n n e a l e d a t 550°C f o r 8 5 ,

T a b l e 1 . C o m p o s i t i o n o f t h e A1-Cu a l l o y s

S p e c i m e n s No. 1 2 3 4 5 6 7 8

Cu con:en:(wt%! 0 . 0 1 5 0 . 0 4 5 0 . 1 3 0 . 2 9 0 . 5 1 0 . 8 0 1 . 2 4 . 0 w a t e r q u e n c h e d a n d t h e n c o l d - d r a w n t o 1 mm wLre a: room t e m p e r a c u r e . 'The 1eng:h of

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1987863

(3)

JOURNAL

DE

PHYSIQUE

:he specimens used in lnternal fric:lon and elastic modulus measurements is 100 mm.

Measurements were made in an inver:cd cors:on pendulum. X-ray stud:cs were madc witn Acomat<.c Power 1700 Diffrac:ometer made in Philips, Holland.

111. E x ~ e r i m e n t i a l results

1. t1easuremen;s on specimens witn low Cu conten:

In Fig. 1 are shown the variation of internal friction and elastic modulus with temperature for specimens with copper contents o f 0.015, 0.045, 0.13 and 0.29 w: % (corresponding :o curve 1 to 4). The specimens were annealed in-s;:u in the torsion apparatus at 450°C for 2 h. An in:ernal fric:ion pea^ P appears for all specimens whether :ne measurements were taken witn descending or ascending tempera;ures. Tne 1 elasYcmodulus drops considerably wi:h the temperature range of ;ne internal frictior.

pea^. The ac'ivation energy a s s o c i a ~ e d with this pea^ a s determined by changing the frequency of measurement is 3 2 kcal/mol, which is stmilar to tha: for 99.99 aluminium. Tne height of the peak is somewflat lower(0.07 vs 0.09) and does no: change by age:ng. The optimum temperazure of :he peak which is abouc 275'C with

E

= 2 Hz seems no: to change with the copper content, nu; i: is d e f i n i ~ e l y lower than that of 99.99 aluminium. This agrees with the resul: by Kg [3] for 99.6 % aluminium. The apparen:

independency of the optimum temperature with Cu concent may be due to the superposi-

- :

L ~ o n of two different effects: ( I ) For lower Cu contents which can only form solid solucion at the grain boundaries, :he peak will shift to higher temperatures wi;n an increase of Cu conten:. (2) For higlier Cu contents which may cause precipitation at the grain boundaries, the peak will shift :o lower temperatures with an increase of the Cu content. The Cu content ranging from 0.015 to 0.51 wt % may well be ihe demr- cation of :he lower and :he higher Cu contents giving opposite effects.

T('C)

450 350 250 I 50

Fig. 1. Internal friction and elastic modulus curves of specimens wi:h various C u contents. Curve 1 to 4: 0.015, 0.045, 0.13 and 0.29 w: %. f = 2 H z .

Fig. 2. Effec: of various kinds of heat Zreatments on the internal fric::on a n d elastic modulus of the specimen con:a:ning 0.8 w: % of Cu annealed at 450°C f o r 2 h. Curve 1: Measured wi:n descending :empera:ures. Curve 2: Measured witn ascendLng temperatures and ageing at 270'~. Curve 2': Measured w;:n ascending :em- peratures after an ageing at 270% for 3 h. Curvc 1 , 2, 2': WL:b f = 2 Hz. Curve 3 and 3': Heat :reatmenis :he same as :ha: for curve 2 and 2 ' , ou: measuredwithE=O.Sllz.

2. Eeasuremen:~ on specimens wl:k medlum Cu conZen:

Tnc internal friction and modulus curves for :he specimen con:a;ning 0.80 wt % of C u a r e shown in Fig. 2. Af:c; :he specimen was annealed a: 450°C for 2 ;i and aea-

(4)

surements taken wi:h descending :cmpera:ures, only peak Pl appears a s shown by curve 1 (f = 2 8 2 ) . The height of :he peak is only a 1i:tle h i : lower than that shownin Fig.l, Indicating :hat prec5pI:acion has no; taken place very much when the specimeniscoolec' down from 4 5 0 ' ~ co P l p c a k temperature. Af:er :he spectmen w a s cooled down :o room :empers:ure and measurrnentc:akenwith ascending tcmpcraEurss, rhe heigh: of P peak is considerably reduced a s shown b y curve 2 . This is evidently due to che progress of 1 precipi:a:ion at grain boundarieswhen the specimen w a s cooled down to room :em~era- :!!re and heated to peak :empera:ure. The con:inuous lowerlng of P I d u r i n g an ageIng at 2 7 0 ' ~ is also shown b y curve 2 . This indicates :ha: 0.8 w: % Cu is much higher :ban ihe solubili2y of Cu in A1 at 2 7 0 ~ ~ . A saturacion value of the heigh: of is reached after an ageing at 2 7 0 ' ~ for 3 h. When meas:uemen;s are :aken again f r o m r o o m cemperacure, curve 2 ' shows tha: :hc hcign: of Pl is reduced very much and L:s 1oca.-

<:on sn;f:s to a lower :empe:a<urc, and a peak P, appeals around 390°c.. The modulus drops abruptly corresponding wi:h the appearance of L Q

.

When measured wi:h a frequency of 0 . 4 H z , :he locarion of P2does no: cnange nu: :hat of P.shif:s to a lower temperature. Thts i n d i c a ~ e s :ha: P2is no: a zhermal-ac:iva:ed relaxation process bu:

P,is. Similar behavior of PI is shown by comparing curve 3 w;:n curve 2 which are caken rcspec::vely wirh f = 0 . 4 and 2 Hz. I: is seen that :he op:imum t e m p e r a ~ u r e of PI shown by curve 3 ' Is abou; 227 OC which is ',den",cal wich :ha: previously observed w i ~ h 9 9 . 2 :o 99.6 % aluminium[3]. The response of peak

q,

to :he described heat treat- men: indicates :hat 1: is :he s:ablc grain boundary precipitation peak, of whlch :he

lower :he helgh: is, the more the amount of precipi:ation at :he grain boundaries.

The P l a n d

q

peaks also appear in the specimen con:ainLng 0.51 w: % C u , and :heir behavior is slmilar :o that in :ne specimen concalning 0 . 8 w: % Cu. The reduction of

;he heigh: of P l a n d &?if; of ;:s 1oca:ion to lower cempera:ure is less. And

5

^appears

around 360°c which is lower than :he 3 9 0 ' ~ for che 0 . 8 w: % Cu specimen.

3. measure men:^ o n specimen con:a:nlng 1.2 w: %

For :11e A1 - 1 . 2 w: % C u specimen annealed a: 450°C for 2 h and measurements taken wi:h descending :empera:ures(f = 2 H z ) , a peak

8

appears a t abouc 290°C in add- tion to peak P,(curve I of Pig. 3 ! . During :he ageing at ::?e o p ~ i m u m temperature of $, the Internal friction decreases and modulus increases gradually a s shown by curve 2.

The increase of modulus during ageing indica:es that a hardening process cakes place dur;ng agelng. This is evidenzly a process of precipitat:on hardening. Afzer an ageing of 2 h and xeasurements :aken with ascending temperazures,

%

peak disappears and P,, P2pcaks appear a s shown by curve 3. When measured wlth a frequency of 0 . 4 i l z , :he 1oca:lon of P2and

9

does no: change bu: :hat of PI shif:s :3a lower :emperaturc a s

(5)

C8-420 JOURNAL

DE

PHYSIQUE

Pig. 3. Effect of various kinds of heat treatments on the internal friction and elastlc modulus oL :he specimen containing 1.2 wt % Cu annealed a: 450'~ for 2 h. Curve 1: Measured with descending temperatures. Curve 2: Specimen aged again at 4 5 0 ' ~ for 0.5 h and measured with descending temperaiures and ageing at 3 0 0 ' ~ for 2 h.Curve 3: Specimen furnace-cooled from 450'~. measured with ascendicg zernpera- tures. Curve 1-3: With f = 2 Hz. Curve 4, 5: Heat treatment :he same as that for curve 1 , 3, but measured with f = 0.4 Hz.

Fig. 4. Internal friction and elastic modulus curves of "single crystal" Al- 1.2 wt % Cu specimen. Curve l: Annealed at 4 5 0 % for 2 h and measurements taken with descending temperatures. Curve 2: Measured wieh ascending cempera:ures,f = 2Hz.

shown by curve 4 and 5. This indicates cha: both peak P2and

8

are no: relaxation peaks.

Auxiliary expertments show tna: before the grain boundary precipi2atlon reaches its saturated state, Pland P2are complementary in that one raises while o:her drops by differen: age;ngs.So P2is connected w::h :he process of re-solution of :he gra;n bouw- dary precipitates. On ihe contrary, Pjis connected wi:h the process of precipi:a:;on to the grain boundaries and the height of PI is reduced accompanying wiih the appearance of PS

"Single crystals" of s p e c i m ~ n s containing 0.8 and 1.2 wt % Cu were prepared by static and dynamic strain-annealing me:hod. The "single crys:all' grown contains only 4 bamboo boundar;es in a l e n g ~ h of 100 mm. Measurements were caken under idencralcon- d;tions as ihosc for t h e fine grain-sized specimens. No internal friction peaks(q,P2, P3) were observed for such specimens. The internal friciion and e l a s ~ i c modulus curve of A1-1.2 wt % Cu specimen are shown in Fig. 4. These resulcs demonsirate conclusively tnat peaks P,, P,and P,are all connected with the grain boundaries in the sDecimens.

a L

-

4. Measurements on specimens wtth 4 wc % Cu conten;

For an A1-4 w: % Cu specimen annealed a? 550'~ for 2 h. onlv ~ e a k _,

.

P-aooeared J

..

when measured with descending temperatures (curve 1 of Fig. 5), and P;,P2 appear when

Pig. 5. Internal friction ^{T ('C}⁾

5% 4% 350 2 5 0 150

and elascic modulus curves of I I

polycryscalline and "single crystal" A1-4 wc % Cu specimens.

Curve 1, 2: Polycrystalline specimen annealed ai 550'~ for 2 h and measurements :aken respect:vely with decend:ng and with ascending

:empera:ures. Curve 3, 4: Same as curve 1 , 2 , but for "single crys - tal" specimen. f = 2 Hz.

5 measured with ascending tempera- -

tures again (curve 21. For "single '4 crystal" specimen wich a few bamboo boundaries, a new peak Pf 3 appears when measured wl:n dcscen- ding temperatu,:es (curve 3:, and 2 another peau Pd appears whenmea- sured with ascend;ng temperacures I (curve 4:.

It is to be noced :ha:: (1) _I2

Correspondfng to :he appearance lA ¹⁶ ^I&_IO?T(%)^2.0 ^2.2 ^2.4 of P2(:he re-solu~ion peak asso-

ciated with the re-solution process caking place at grain boundaries!, che elastic modulus decreases as shown in Fig. 2, 3, and 5. The elasclc modulus decreases cori-es- ponding to the beginning of the emergence of Pi foi :'single crystal:' spectmen when measurements are taken in ascending cemperacures (curve 4 of Fig. 5). Consequently, we believe tnat Pi is associated w i t i t che re-solution process taking place in ihe

interior of :he grains. 1: is seen chac both T a n d Pi appear in :he case of polycrys- tals and Pi appears at a lower temperature :han thai o f

9.

This i n d i c a ~ e s that the re-soluiion process scarts earlier at a lower :emperature. (2) Corresponding to the appearance of Pj(the preclpitacion peak associated wizn :he precipi:ation process

(6)

Faking place at grain boundarles),:he elas:ic modulus increases corresponding :o the appearance of Pj for "single crystal" specimen whcn measuremen:s are taken in descending tcmpera~ures (curve 3 of Fig. 5). Consequenrly, we believe that

3'

^{is asso-}

ciated with the precipitation process taking place in the inzerior of the grains. It is seen tha: P appears ac somewna: higi1e.r ,:ern?erarure than tha: of P;'. This indi.ca:es that the precigi:ation 3 process starts earlier at the grain boundaries at a higher rempera:ure.

5 . Results of X-ray diffraction analysis

The A1-1.2 w: % specimen was annealed at 450°C for 2 h, furnace-cooled down to room cemperacurc and heated up :o 290°C, and then aged a: 290°C for 7 h. This :emperature corresponds to :he peak remperature of P3 (:he precipi;a:ion peak) as shown by curve (a) of F<g. 3. X-ray diffraction analysis of this specimen at 200C shows

Fig. 6, X-ray dlffrac:ion graph of A 1 - 1.2 wt '% Cu specimtn.(a) Specimen a g e d at 290°C for 7 h and analysis made a c 20 OC. (b! Specimen heated in-situ :o 300% from 20°C. ( c ) Specimen heated in- sicu to 4 0 0 % from 300°C. The six srrong- es: diffrac:;on peaks of 0-phase are mark- ed wi:h 1-6. The two strong peaks are K, peaks of aluminium.

Fig. 7. Variat<on of che 0 diffrac- :ion peak (d-4.30298,(110! ) of A1-1.2 w:

X C u specimen w;:h ageing a: dlfferenr temperacures for various rimes. (a):Grow- :h of :he Q peak during ageing a: 3 0 0 ' ~ (20 -c 300°c?. (b)Disappearance of the 8 peak during ageing at 400'C(300 4 400'~).

(c) Grow:h of chc 0 peak during ageing a: 300°C (400 -+ 300°C).

i:~ac ;he six strongest diffraciion peaks of the 0 pnase (CuA12\ all appear. After rhe speccaen was h e a ~ e d in-si:u of the X-ray diffrac:oae:er to 300°c, :he dlffrac- Lion peaks o f 8 phase do no: cnange. However, w;?en :he specimen was heated from300°C

L O 4009: which corresponds L O :he peak Cemperacure of

9

( z i ~ e re-soluiion peak) as shown (c) of Flg. 6, all :he d i f f r a c ~ i o n peaks of 0 phase alsappear.

In-si:u observation was made on one strong diffracrion pea^ of :he 0 pnase (d = 4.3029

1 ,

(110)) during ageing a: differen: temperatures for various :imes. I: is shown in Fig. 7(a) tnat tor a solut:on-:reared Al-1.2 w; % Cu specimen water - quenched :o room zemperacure and :hen hea:ed ;n-sicu :o 3 0 0 ' ~ (which rakes abou: 1 nin), the 0 peak appears af:er an agefng o f 9 min. The specimen was kept In 3 0 0 ' ~ for 2 i7 and :hen hearcd LO 4 0 0 ~ ~ (in 1 min), :he 0 peak drops rapidly and disappears afzer an ageing of 6 m;n as shown by Fig. 7 ( b ) . When the specimen was cooled down from 400 to 300°C (in I min) and aged :here for 12 min, :he 0 peak appears gradually and raises 20 its naximus neigh: afzer 2 h as shown by Fig. 7(c).

The resu1:s of X-ray analysis si~ow tna:: (1) The condltion for he appearance of Ppis tha: t;le 0 phase has exis:cd already in chc specimen. The 0 phase disappears gradually accompanying thc appearance of P 2 . A s such, P2Ls connected wicn che re-solution of :hc 0 phase. ( 2 : The condition tor the appearance of P3 is :ha: :nc specimen was solu::on - created ( without 0 phase ) . And 0 phase forms gradually accompanying :he appearance of P3. S o P J i s ;he reverse process of P, _L

.

^{I i}^is

conneczcd w i ~ h :he precip;;a:ion of 0 pnase

.

(7)

JOURNAL

DE

PHYSIQUE

VI. Concluding Remarks

I n con:rast wi:h the conventional grain boundary internal friction peak ( KG pcak 1, f;ve internal friction peaks were observed in A1 - Cu alloys under different conditions. Arranged in ascending order of :heir optimum tempera:ures, :ney are: PI, P;, pi, P3and P2.

( 1 ! P1 is the grain boundary peak ( a relaxation peak ) wi:h prec;pi:ates ac the grain boundaries.

( 2 ) Pi is :he re-su1u:ion peak associated w;th the re-so1u::on process :aking place in :he interior of the grains.

( 3 )

Pj

is the precipita:ion 2eak associa:ed :he precipitation process LakLng place in the interior o f the grains,

( 4 ) P3 is the precipi:ac;on peak associated wich the precipitation process taking place a: the grain boundaries.

( 5 ) PZ is :he re-solui.ion pcak associated w;ch the re-solucion process taklng place at the grain boundaries.

I n addition, there should be a grain boundary 'nrernal f-:c:'o,i pea4

;

a relaxation peak ) with solute atoms existing in the solid solution state at 'the grain boundaries. Such a peak ( the solu:c 2ra:n boundary inrernal fr;.c:-on peak ) should ap7ear in aluminium spec:mens with Cu content less :han that studied in :he present research (0.015 W L "L C < I > .

Acknowledgement

Thanks are due to B. P. Cheng, Y. M. Gao tor help in X-ray experiments, and to Q. Huang and other members of Internal Friction Laboratory of the Lns:itu:e for help in experimental work and discussions.

References

[I]

T. S. KC, Phys. Rev. 71. 533(1949).

[2] Cf. for example: H. Gleiier and Chalmers, High-Angle Grain Boundaries, Progress in MacerLals Science, Vol. 16(Pergamon Process, 0xford.New.Yor~.

Toronto. Sydney. Braunschweig, 1972!, Chap. 8, pp.219-254.

[3] T. S. K C , J. appl. Phys. 20 274(1949).

[4] T. S. KC, P. Cui, S. C. Yan, and Q. Huang, phys. stat. sol. (a) 86, 593(1984).

[ 5 ! M. A . Quader, J. appl. Pnys. 33, 1922(1962).
