CVD OF TITANIUM CARBIDE AT MODERATE TEMPERATURE FROM TITANIUM SUBCHLORIDES

(1)

HAL Id: jpa-00229567

https://hal.archives-ouvertes.fr/jpa-00229567

Submitted on 1 Jan 1989

HAL

is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are published or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire

HAL, est

destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

CVD OF TITANIUM CARBIDE AT MODERATE TEMPERATURE FROM TITANIUM

SUBCHLORIDES

B. Drouin-Ladouce, J. Piton, L. Vandenbulcke

To cite this version:

B. Drouin-Ladouce, J. Piton, L. Vandenbulcke. CVD OF TITANIUM CARBIDE AT MODERATE

TEMPERATURE FROM TITANIUM SUBCHLORIDES. Journal de Physique Colloques, 1989, 50

(C5), pp.C5-367-C5-376. �10.1051/jphyscol:1989544�. �jpa-00229567�

(2)

JOURNAL DE PHYSIQUE

Colloque C5, supplement au n05, Tome 50, mai 1989

CVD OF TITANIUM CARBIDE AT MODERATE TEMPERATURE FROM TITANIUM SUBCHLORIDES

B. DROUIN-LADOUCE, J.P. PITON* and L. VANDENBULCKE

Centre de Recherches sur la Chimie de la Combustion et des Hautes Temperatures, CNRS, F-45071 Orleans Cedex 2 , France

" ~ n i v e r s i t 6 dlOrleans, U.F.R. Facult6 des Sciences, BP. 6759, F-45067 Orleans Cedex 2, France

Resume : La f o r m a t i o n i n - s i t u des sous-haloggnures de t i t a n e par r e d u c t i o n du tetrachforure de t i t a n e par l e t i tane metal lique e s t u t i 1 is & conjointement avec du butane pour deposer des couches de carbure de t i t a n e I temperature modgree, de 1 'ordre de 850°C.

La vitesse de depdt, l a composition en C/Ti e t en chlore des revetements ainsi que l e u r m i c r o d u r e t e s o n t e t u d i e e s en f o n c t i o n des parametres experimentaux, specialement l a composition i n i t i a l e de l a phase gazeuse

.

^Enl e s comparant aux r e s u l t a t s de calculs thermodynamiques, l e s variations de l a vitesse de depdt e t de 1 a composition du sol ide permettent de di scuter l ' i n f 1 uence de d i f f e r e n t e s 1 imi t a t i o n s cinetiques du processus qui interviennent en fonction des conditions de dCipdt

.

Dans t o u s l e s c a s un grand & a r t i l ' e q u i l i b r e e s t observe

.

^On

montre que ces conditions de temperature de depdt moderee e t de sursaturation elevee condui sent I une structure I grains tr6s fins.

La m i c r o d u r e t e des d e p - t s v a r i e dans un l a r g e domaine

.

Oes v a l e u r s a u s s i f a i b l e s que 1000 kg.mm-! s o n t obtenues quand 1 a q u a n t i t e de c h l o r e incorporge e s t @levee. Dans l e s m e i l l e u r e s c o n d i t i o n s de depdt, l e s couches s o n t bien c r i s t a l l i s 6 e s avec une concentration en chlore f a i b l e e t un rapport C/Ti proche de 1

.

Dans ce cas l a t a i l l e des grains e s t particulierement plus f a i b l e compa- ree 5 c e l l e observee sur l e s couches deposees de facon classique 1 temperature plus @lev@e, comprise e n t r e 1000 e t 1050°C, l a morphologie e s t tr6s dense e t l a microdurete a t t e i n t d e s v a l e u r s e n t r e 4000 e t 5000 kg.mm" sous une charge de 50g.

Abstract :The in-situ formation of the titanium subchlorides.by t h e reduction of titanium t e t r a c h l o r i d e by titanium metal i s used together with butane t o deposit titanium carbide layers a t moderate temperature, in t h e order of 850°C.

The deposition r a t e

,

t h e C/Ti composition of t h e coatings, the chlorine incorporation and the microhardness are studied as functions of t h e i n i t i a l gaseous composition. When compared w i t h t h e thermodynamical calculations, t h e variations of t h e deposition r a t e and the solid composition allow t o discuss the influence of d i f f e r e n t kinetic l i m i t a t i o n s of the process which a r i s e as a function of t h e deposition c o n d i t i o n s . In any c a s e a g r e a t d e p a r t u r e from t h e e q u i l i b r i u m i s observed. I t i s shown t h a t these conditions of moderate temperature and supersa- t u r a t i o n lead t o a very fine-grained structure.

The m i rohardness of the deposits varies in a large range. Values as tow as 1000 kr~.mm-~ can be observed when the chlorine content i s high. With t h e best deposition conditions, the deposits are we1 1-crystal 1 ized with a low chlorine content and a C/Ti r a t i o approaching 1. In t h a t c a s e i t i s shown t h a t t h e g r a i n s i z e i s p a r t i c u l a r l y lower than those observed in layers deposited a t c l a s s i c a l higher temperatures of 1000-1050°C, the morphology i s very dense and the microhardness i s in the range 4000-5000 kg.mm-2 under 509 load.

I Introduction :

In a previous s t u d y (1 ) a comparison between thermodynamic c a l c u l a t i o n s a p p l i e d t o s t o i - chiometric titanium carbide and some preliminary experiments f o r two systems TiC14

-

^C4H10

-

H p

-

Zn vapor and TiClx

-

C4H1

-

^Hz ⁽ ^{w i t h}^{x < 4} allowed t o reveal the conditions necessary t o overcome the k i n e t i c limrta%ions of t h e actual TiC14

-

^CH4

-

^Hz reactant gas mixture when Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1989544

(3)

employed a t moderate temperature. The role of Tic12 through i t s reduction or i t s disproportionation was especially emphasized and i t was shown t h a t a prereducing step of TiC14 t o i t s subchlorides by e l e m e n t a l t i t a n i u m coupled with t h e use of a l e s s s t a b 1 e hydrocarbon 1 ik e butane was an i n t e r e s t i n g way t o decrease t h e deposition temperature of titanium carbide.

Thermodynamic c a l c u l a t i o n s a r e extended here t o n o n - s t o i c h i o m e t r i c t i t a n i u m c a r b i d e and a more extensive experimental work i s reported with t h e TiCl.,

-

^C4H10

-

^H system a t 850°C. As a r e s u l t from a comparison, the deposition mechanism i s discussed and t%e deposition process optimized.

I1 Experimental techniques :

The deposition apparatus presents some d i s t i n c t i v e c h a r a c t e r i s t i c s necessary t o implement the process. I t i s composed of a hot-wall r e a c t o r ( of 53 m m ID ) surrounded by a two zones furnace. The f i r s t zone p e r m i t s reducing TiC14 by T i c u r l e d c h i p s a t a h i g h e r t e m p e r a t u r e than d e p o s i t i o n . Most of t h e hydrogen flow and t h e butane a r e introduced downstream i n a colder part of the reactor while the TiC14 i s passing through the titanium chips in order t o make up t h e whole m i x t u r e of hydrogen, butane and t i t a n i u m c h l o r i d e s which r e a c t s i n t h e deposition zone.

All t h e o t h e r p a r t s a r e c l a s s i c a l w i t h a c o n t r o l u n i t of g a s f l o w , Tic1 evaporation and regulation of pressure. A pumping system c a r r i e s t h e g a s e s through a f i j t e r and v a r i o u s traps.

The following deposition conditions were used : deposition temperature = 850+ 10°C, T i chips temperature evaporator = = 37OC, butane flow r a t e 1050°C, t o t a l p r e s s u r e = 5-50 cm /mn3 Tic14 flow r a t e = 40 t r r s (5.33 l o 3 Pa), temperatuF5 of t h e TiCll

S

= 5-50 cm / m n , hydrogen f l w r a t e through t h e Tic1 evaporator = 5-100 cm /mn, t o t a l hydrogen flow r a t e = 1000-4000 cm

9

/mn, deposition time

,(j

hours.

Most of t h e deposition experiments were carried out on s t e e l s samples, especially on XC 38 and 2220 CW 14, but cemented carbides were also t e s t e d as substrates. The growth r a t e s of t h e coating were deduced from the mass increase per unit surface, generally during two hours, and t h e coating thicknesses were a l s o measured on polished cross sections of t h e samples.

Fractured cross-sections were observed. by S.E.M. and the chemical composition of t h e deposits were measured by quantitative microprobe analysis. Vickers microhardnesses of s u f f i c i e n t l y thick coatings were measured under a 509 load.

I11 Thermodynamical study :

Generalities on the calculation procedure :

The chemical equilibrium calculations involve the minimization of the t o t a l Gi bbs f r e e energy taking i n t o account the conservation of the mass of each element, a constant temperature and a constant t o t a l pressure. A s l i g h t l y modified version of SOLGASMIX program elaborated by G.

ERIKSSON ( 2 ) has been employed t o perform t h e c a l c u l a t i o n s of t h i s paper. In t h i s program, non-stoichiometric s o l i d s can be considered.

As reported previously (1) these calculations are common f o r a l l a l i p h a t i c saturated hydro- carbons a s t h e C/H r a t i o i s c o n s t a n t whatever n i n t h e C n H 2 n + L

+

HL m i x t u r e f o r a c o n s t a n t t o t a l pressure, a given titanium chloride concentration and an i n i t i a l carbon concentration : n X°CnH2n+2.

The f o l l o w i n g s p e c i e s were considered : H , CH

,

TiC14, TiC13, Tic1 , TiC1, HC1, C12, C 2 H 2 and CC14 as constituants of t h e cJaseous mix?ure;?i,c and Ticx as solic?s ( pure Ti was considered a s t h e s o l u b i l i t y of C i n T i i s low ( 3 ) ) . Tic12 and Tic1 s o l i d s were not t a k e n i n t o account as stoichiometric thermodynamical calculations showed h a t they were never produced a t t h e c o n d i t i o n s s t u d i e d , e s p e c i a l l y when t h e p a r t i a l p r e s s u r e of t h e s e s p e c i e s were maximum, when aTi = 1.

All the thermodynamical properties of t h e gaseous species were taken in t h e JANAF tables. For non-stoichiometric sol i d s , . o t h e r d a t a sources must be used. Several s t u d i e s have r e p o r t e d thermodynamic properties of the Tic over i t s homogeneity range a t temperature between 850 and 1900 K (3-5). The p a r t i a l molar f r e e energies of titanium were calculated a t 1100 K from these r e s u l t s taking i n t o account the f r e e energy of stoichiometric Tic formation given by JANAF t a b l e s and the extent of t h e homogeneity range of t h e titanium carbide phase a t 1100 K.

(4)

The carbon p a r t i a l thermodynamic prgperties were deduced from t h e Gibbs-Duhem equation and the values of t h e titanium p a r t i a l thermadynamic properties a t 1100 K. The r e s u l t s have been compiled i n a polynom form d i s c l o s i n g t h e l o g a r i t h m of t h e a c t i v i t y c o e f f i c i e n t s a s a function of t h e composition.

A t 1100 K t h e homogeneity range extends from C / T i = 0.59 t o C/Ti = 0.98 (3-6). For C/ti between 0.59 and 0.98 t h e following re1 ations were used :

were

Yi

is the a c t i v i t y coefficient and Xi the molar fractions.

In t h e Tico 98

+

C two phases domain ( C / T i > , 0.98) t h e C a c t i v i t y i s equal t o 1 and t h e T i a c t i v i t y is'constant and equal t o i t s value in Ticoag8 t h a t i s :

a ~ i = 6.9427 10" ;

YTi

= 6.9427 10"/xTi

In t h e TiC0.59 + T i two phases domain ( C/Ti

<

0.59 ) t h e a c t i v i t y of T i i s supposed t o be equal t o 1 as t h e s o l u b i l i t y of C i n Ti i s low (3) and t h e a c t i v i t y of carbon i s constant and equal t o i t s a c t i v i t y i n t h a t i s :

Calculation r e s u l t s :

From thermodynamic calculations of the interaction of TiC14 with pure Ti a t 1300 K, t h e Cl/Ti r a t i o was fixed a t 3.0071. Then t h e equilibrium i n t h e Ti

-

^C

-

^H

-

C1 system was calculated f o r d i f f e r e n t i n i t i a l compositions in one mole of t h e Tic1

-

^C^H

-

^H gaseous i x t u r e and c o n s t a n t v a l u e s of t h e t e m p e r a t u r e and t h e pressure3('0f7=1 110% J0and

?

⁼^{5.33 10}

^"3

^Pa ^).

In t h e following of t h i s paper t h i s TiC13.0071 mixture of titanium chloride w i l l be written TiC13.0.

Thermodynamic calculations a r e often used t o specify t h e equi 1 i brium domain of t h e d i f f e r e n t phases ( Ticx, T i and C ) versus t h e i n i t i a l gaseous mixture composition. When compared with t h e deposition domains calculated with TiC14 (1 1, i t i s c l e a r t h a t t h e + Ti deposition range i s considerably enlarged especially a t high XO TiC13.0. On t h e other hand, the two phases TiC0.98 + C domain remains almost unchanged.

The v a r i a t i o n s i n t h e production of t h e d i f f e r e n t gaseous s p e c i e s and s o l i d phases a r e presented on fig.1 a s a f u n c t i o n of t h e i n i t i a l gaseous composition. The t h e o r e t i c a l e f f i - ciencies of T i - c o n t a i n i n g s p e c i e s ( f u l l l i n e s and C-containing$pecies ( d o t t e d l i n e s ) are p l o t t e d a g a i n s t 4 X 0 C H f o r a c o n s t a n t X O Tic1

-

2.8 10'

.

The y i e l d s a r e defined with respect t o X0 TiC13 joo? Pi-containing species and.!

i0

^C4H2P f o r C-containing species.

As previously shown i n d e stoichiometric case ( I ) , TiC13 and 1 2 have a high y i e l d i n the Ti-rich region despite the low temperature employed because TiC13.0 chlorides were used as Ti-containing c a r r i e r s in t h e i n i t i a l mixture.

TiC14,TiC1

,

Tic1 e f f i c i e n c i e s remains constant i n t h e + Ti domain as t h e Ti a c t i v i - t y i s equa? t o 1. t h e n TiC13 and TiC12 d e c r e a s e q u i c k l y

-

e s p e c i a l l y TiC12

-

i n t h e s i n g l e phase region while the TiC14 y i e l d increases ( before i t decreases also near t h e l i m i t of t h e single-phase domain ). Thus a s d i s c u s s e d p r e v i o u s l y from e q u i l i b r i u m c a l c u l a t i o n s which involve stoichiometric Tic ( 1 ) t h i s important amount of TiC14 i s produced by t h e disproportionation of t h e s u b c h l o r i d e s . Accordingly, t h e s u b c h l o r i d e s formed a t 1300 K allow t o l i b e r a t e and incorporate Ti i n a titanum carbide deposit a t 1100 K.

The CH4 y i e l d which i s lower t h a n 1 0 ' ~ i n t h e two phases T i c O 59 + Ti domain and i n t h e Ti- rich part of t h e single phase region increases quickly u n t i l 1

lt

reaches a maximum value when the f r e e carbon production begins. Then C H 4 e f f i c i e n c y d e c r e a s e s a s t h e f r e e carbon y i e l d r i s e s .

The C/Ti v a r i a t i o n s a r e shown on fig.2 which p r e s e n t s t h e C.V.D. phase diagram f o r Ti-C s o l i d s deposited from TiC13.0

-

^C4H10

-

Hz mixtures. While titanium carbide can be deposited

(5)

a t e q u i l i b r i u m i n a wide range o f concentrations o f t h e i n p u t reactants, t h i s diagram shows t h e s e n s i t i v i t y o f t h e composition o f t h e n o n - s t o i c h i o m e t r i c t i t a n i u m c a r b i d e phase t o t h e i n i t i a l m i x t u r e composition.

F i g u r e 1 : V a r i a t i o n s o f t h e e- q u i l i b r i u m y i e l d s o f t h e p r i n c i p a l species as a f u n c t i o n o f t h e i n i - t i a l h y d r o c a r b o n c o n t e n t a t X 0 T i c 1 - = 2 8 T = 1100 K and P =

2% l o 3

Pa.

F i g u r e 2 : Phase f i e l d s f o r s o l i d spec? es and i s o - c o n c e n t r a t i o n curves o f t i t a n i u m c a r b i d e i n i t s s i n g l e ehase d o m a i n a t e a u i 1 i b r i u m f o r i i c 1 3

-

^C ^H

-

H ' m 0 x t u r e s a t T = 1100 R and

8

lO5.33210~ Pa.

I V Comparison w i t h t h e e x p e r i a e n t a l r e s u l t s and d i s c u s s i o n on t h e d e p o s i t i o n mecanism : The use o f b o t h a l e s s s t a b l e h y d r o c a r b o n t h a n methane and a p r e r e d u c i n g s t e p o f t i t a n i u m t e t r a c h l o r i d e by t i t a n i u m metal a t a low pressure improves t h e chemical k i n e t i c s enough t o a l l o w t h e d e p o s i t i o n o f t i t a n i u m c a r b i d e a t a non-negligeable r a t e a t moderate temperature.

However some k i n e t i c s contr.01 o f t h e p r o c e s s can o c c u r a g a i n a t t h e s e l o w e r t e m p e r a t u r e s , producing some departure f r o m t h e e q u i l i b r i u m . We remember t h a t such k i n e t i c s c o n t r o l i s i n f a c t necessary t o o b t a i n n e a r l y constant d e p o s i t i o n c o n d i t i o n s i n l a r g e s c a l e reactors.Two k i n d s o f k i n e t i c s l i m i t a t i o n s can be considered, caused e i t h e r by t h e r e d u c t i o n o r (and) t h e d i s p r o p o r t i o n a t i o n o f t h e t i t a n i u m subchlorides o r by t h e p y r o l y s i s o f butane.

A comparison b e t w e y t h e t h e o r e t i c a l and t h e experimental C/Ti r a t i o s versus 4 XO C4H10, a t X0TiC13 = 2.8 10'

,

i s presented i n f i g u r e 3. The corresponding v a r i a t i o n s o f t h e t h e o r e t i - c a l y i e l d and e x p e r i m e n t a l g r o w t h r a t e a r e r e p o r t e d i n f i g u r e 4 and a l l t h e e x p e r i m e n t a l r e s u l t s a r e p u t t o g e t h e r i n f i g u r e 5, t h a t i s t h e v a r i a t i o n s o f C/Ti, t h e g r o w t h r a t e , t h e c h l o r i n e i n c o r p o r a t i o n and t h e microhardness o f t h e deposits.

(6)

.-

^{C I T i}

.-.-Deposition rate

1.5

i

-

10-2 10.'

4X~C4H10

F i g u r e 3 : Comparison o f t h e va- 0.9

r i a t i o n s o f t h e C/Ti r a t i o b e t - ween t h e e q u i l i b r i u m a t T = 1100 k and t h e experimental r e s u l t s a t

T = 1123 K as a f u n c t i o n o f t h e o 0.02 0.04 0.06 4 x0 C ~ H , ~

i n i t i a l h y d r o c a r b o n c t e n t f o r X O T i C b 3 0 = 2.8 10-'and P = 5.33 10 Pa.

F i g u r e 5 : V a r i a t i o n s o f t h e C/T7 r a t i o , t h e d e p o s i t i o n r a t e ,

.E 9 6

N

B Y m

t h e c h l o r i n e c o n t e n t a n d t h e Vickers microhardness o f t h e coa- t i n g s d 5 p o s i t e d a t X 0 TiC13 = 2.g 10-

,

T = 1123 K and P = 5.33 10 Pa v e r s u s t h e i n i t i a l b u t a n e concentration.

3 ^e--o. "

8

>

1500

-

2 1

.-

Microhardness .

. - _ . A t . % Chlorine

___-

-

. .

F i g u r e 4 : Comparison b e t w e e n t h e y i e l d o f t h e s o l i d species a t

e q u i l i b r i u m f o r one m o l e o f i n i - F i g u r e 6 : V a r i a t i o n s o f t h e C/Ti r a t i o t i a l m i x t u r e a t T = I 1 0 0 K and versus e i n i t i a hydrocarb n conten f o r X 0 t h e d e p o s i t i o n r a t e o f t h e coa- TiC13

Otl

^2.8

^lo-',

^1.3

^lo-',

^6.^10-

5

^{a t T}⁼

t i n g s d e p o s i t e d a t T = 1123 K 1123R and P = 5.33 10 Pa.

versus t h e i n i t i a l h y d r o c a r b o c o n t e n t f o r X 0 -$iC13.~ = 2.8 1 0 -

!!

and P = 5.33 10 Pa.

(7)

For 4 X O C H1

o,(

^2.8 t h e experimental C/Ti r a t i o i s f a r g r e a t e r than t h e t h e o r e t i c a l one ( f i g .

4)

and f r e e carbon has been d e t e c t e d by X-ray d i f f r a c t i o n . In t h e s e c o n d i t i o n s of high titanium subchlorides concentrations ( XO Tic1 ),4 X O C4HI0 ) titanium is not proper- l y incorporated i n t o the titanium carbide. ~ c c o r d i n ? j f ~ t h e chlorine content i s very high i n t h e corresponding region of f i g u r e 5. The whole r e s u l t s show some l i m i t a t i o n of t h e process by t h e r e d u c t i o n and ( o r ) d i s p r o p o r t i o n a t i o n of t h e t i t a n i u m s u b c h l o r i d e s . This d e p a r t u r e from e q u i l i b r i u m i s apparently reduced f o r X O TiC13.0.= 4 X" C4Hb0 ( f i g . 3). How v e r t h e similar theoretical and experimental values of C/Ti o b t a ~ n e d fo r 4 X C4H10 = 2.8 10" do not permit t o conclude t h a t near e q u i l i b r i u m c o n d i t i o n s a r e reached because t h e experimental values afterwards vary only s l i g h t l y up t o about 1 when 4X0 C4H10), XO TiC13.0.

Moreover microprobe analysis showed a C/Ti r a t i o near t h e stoichiometry and no f r e e carbon has been detected by X-ray diffraction. The whole r e s u l t s obtained in t h i s l a s t range of t h e i n l e t composition d e p a r t a l o t from t h e equi 1 ibrium r e s u l t s which p r e d i c t an i m p o r t a n t deposition of f r e e carbon ( f i g . 3-4). I t i s c l e a r t h a t , i n t h i s d e p o s i t i o n range, t h e process i s principally control led by t h e decomposition of butane. Accordingly, the chlorine incorporation in the solid i s lower as shown in f i g u r e 5.

A comparison, a t X0 TiC13-0 .= 2.8 between the solid phases e f f i c i e n c i e s a t equilibrium and t h e e x p e r i m e n t a l deposition r a t e s ( f i g . 4) c o n f i r m s t h e e x i s t e n c e of t h e two k i n e t i c controls. The coating r a t e variation exhibits two levels which can be linked respectively t o t h e kinetics l i m i t a t i o n of the titanium deposition and then t h e carbon incorporation when t h e r a t i o 4 X O C4H10/ XO TiC13.0 increases.

I t can be supposed t h a t the kinetics l i m i t a t i o n by t h e titanium incorporation r a t e i s overcome because a t r a n s i t i o n occurs from a reduction reaction t o a disproportionation one when 4 XO C4H10 increases, as t h i s second reaction type becomes thermodynamically enhanced in the single-phase deposition domain (fig. 1 ). Accordingly, t h e deposition r a t e increases f o r 4 X"

C4HIO i n t h e range 0.04

-

0.05 u n t i l i t i s l i m i t e d by t h e carbon i n c o r p o r a t i o n ( f i g . 4). I t i s i n t e r e s t i n g t o note t h a t i n t h a t case t h e C/Ti r a t i o remains near t h e s t o i c h i o m e t r i c composition ; when t h i s l i m i t a t i o n of t h e deposition r a t e i s compared t o t h e titanium carbide and f r e e carbon y i e l d s p r e d i c t e d a t e q u i l i b r i u m , i t appears t h a t high s u p e r s a t u r a t i o n i n butane can be employed w i t h o u t d e p o s i t i o n of f r e e carbon. Such a r e s u l t was p r e v i o u s l y reported also f o r t h e deposition of titanium carbide and boron carbide a t higher temperature, respectively a t about 1300 K and 1400 K when C H 4 i s employed a s carbon c o n t a i n i n g s p e c i e

(7,8). The i n h i b i t i n g e f f e c t of C H 4 r e p o r t e d p r e v i o u s l y ( 8 ) seems t o be found again f o r C4H10, as the deposition r a t e s l i g h t l y decreases f o r high values of 4 X O C4H10.

The f i g u r e 6 shows t h e varlation of t h e experimental C/Ti r a t i o in the solid as a function of 4 XO C H f o r three values of t h e i n l e t concentration of TiC13

.

When t h e concentration of TiC13

:

ieO;reases, t h e C/Ti r a t i o increases s l i g h t l y f o r a conitant concentration of C4H10, especially f o r 4 X°C4H 0 between 0.02 and 0.03. This r e s u l t can be.explained e a s i l y because t h e boundary between t k e single and two-phases domains occurs f o r decreasing values of t h e C4HI0 c o n c e n t r a t i o n when t h e Tic1 c o n c e n t r a t i o n d e c r e a s e s ( v a l u e s of t h i s l i m i t a r e indicated by arrows i n f i g . 6 ). h O a n y c a s e , t h e i m p o r t a n t d e p o s i t i o n of f r e e carbon, predicted a t equilibrium f o r C4H10 concentrations higher than t h i s l i m i t , does not occur and an important departure from the equilibrium remains.

The f i g u r e 7 p u t s t o g e t h e r t h e v a r i a t i o n s of t h e d e p o s i t i o n r a t e , t h e composition of t h e solid ( C/Ti and C1 content ) and the microhardness as function of t h e Tic1 concentration, f o r a c o n s t a n t value of 4 X O C 4 H equal t o 3. According t o f i g . 6, 2f?e C / T i r a t i o i n t h e s o l i d i n c r e a s e s s l i g h t l y a s ? i ~ 1 decreases. For X O TiC13 v a l u e s lower t h a n 0.01 i t appears t h a t t h e deposition r a t e i s ?imited by t h e concentratiofi of t h e titanium chlorides, and t h e c h l o r i n e c o n t e n t i n t h e s o l i d i s low. As X 0 Tic13 0 i n c r e a s e s , t h e d e p o s i t i o n r a t e reaches a maximum and t h e n s l o w l y d e c r e a s e s : t h i s r e j u l t confirms t h e f i r s t l e v e l of f i g u r e s 4 and 5 f o r t h e d e p o s i t i o n r a t e , and corresponds t o t h e k i n e t i c 1 im i t a t i o n by t h e deposition r a t e of t h e titanium attributed t o the reduction reaction. A t t h e moderate tempe- r a t u r e employed i t i s obvious t h a t t h i s l e a d s t o a higher i n c o r p o r a t i o n of c h l o r i n e i n t h e solid a s shown on f i g u r e 7.

The influence of t h e i n i t i a l conditions on the deposition mechanism will be more developped e l sewhere ( 9 ) .

(8)

.

^-^ClTi

.-.-

Deposition rate

Figure 7 : V a r i a t i o n s of t h e C/Ti r a t i o , t h e d e p o s i t i o n r a t e , t h e c h l o - r i n e content and t h e Vickers microhardness of the co t i n g s deposited a t

h

4 X0 C H = 3. 10'

,

T = 1123 K and P = 5 ? 3 J 0 ~ ~ 3 Pa versus t h e i n i t i a l subchlo- r i d e s mixture concentration.

V Optimization of the deposition process :

In o r d e r t o improve t h e c o a t i n g q u a l i t y , t h e v a r i a t i o n s of t h e C/Ti r a t i o v e r s u s t h e i n l e t gaseous composition and t h e c h l o r i n e conte'nt i n t h e s o l i d , t h e d e p o s i t i o n r a t e and t h e microhardness have t o be compared t o each other.

The existence of a certain chlorine amounts i n the titanium carbide leads t o a poor chemical s t a b i l i t y and t o poor coating properties. From f i g u r e 5, i t i s c l e a r t h a t t h e microhardness decreases when t h e C1 c o n t e n t i n c r e a s e s f o r a n e a r l y con t a n t value of C/Ti, i n t h e range 0.98

-

^{1 when 4}^{X O}^C ^H10 v a r i e s between 3. and 8. 10-I. The i n f l u e n c e of t h e C1 c o n t e n t i s confirmed by t h e $ i g u r e 7, a t l e a s t f o r X 0 T i C 1 3 - 0 5 0.06

.

When i t s value i s lower t h a n 0.5 at.%, t h e microhardness does n o t depend a l o t on t h e c h l o r i n e i n c o r p o r a t e d a s shown on fig. 7 f o r X O Tic1 G 0 . 0 6 . Hard t i t a n i u m c a r b i d e d e p o s i t s can t h e r e f o r e be d e p o s i t e d , a s expected, i f t h e &'content i s low and the composition near the stoichiometry. Such a r e s u l t i s o b t a i n e d f o r X 0 Tic1 O / X O C 4 H k Q < 1, t h a t i s a r a t i o Ti/C <1/4 i n t h e i n l e t gaseous mixture. Moreover the in?et Cl/H r a l o must be s u f f i c i e n t l y low t o l i m i t t h e chlorine incorporation b u t the deposition r a t e decreases a t low reactant concentrations as shown on f i g u r e

-

A compromise s o l u t i o n f o r t h e d e p o s i t i o n a t higher r a t e of a good d e p o s i t was found by increasing the titanium chloride and butane concentrations, the i n l e t r a t i o Ti/C being main- tained equal or lower than 1/4. As the C1 content increases w i t h X O Tic1 t h e threshold of 0.5 at.% C1 incorporated in t h e solid determines t h e upper l i m i t of the3.Pic1 concentration. Table I gives t h e r e s u l t s of some experiments carried out i n t h i s way, w%?ch leads t o very high microhardnesses.

(9)

Figure 8 : S.E.M. micrograph of a fractured c r o s s - s e c t i o n of a titanium carbide coating deposited on steel at moderate temperature a/ 1D23, b/ ID39

Figure 9 : S.E.M. micrograph of a fractured c r o s s - s e c t i o n of a titanium carbide coating aeposited on cemented carbide by a/ the moderate temperature process, b/ the classical C.V.D process.

(10)

TABLE I :

Values i n t h e range 4700

-

⁵⁰⁰⁰^kg.mm-2 were measured i n samples coated a t t h e s e s p e c i a l conditions (a1 so f o r one experiment r e p o r t e d on f i g u r e 8 ) ; t ey a r e s i g n i f i c a n t l y higher than t h e c l a s s i c a l r e orted microhardness of about 3200 k g . m i p f o r Tic. Values i n the range of 2600

-

3200 kg...-' were verified, with t h e same measurement conditions under 509 load, f o r l a y e r s d e p o s i t e d by t h e c l a s s i c a l C.V.0 process, from TiC14

-

^{C H 4}

-

^H2a t T >100O0C on cemented carbi de.

Sample number 1039 ? 20109 201 10

)r

TABLE I 1 :

These high values of the microhardness can be attribuated t o the grain refinement obtained with t h i s process a t moderate temperature, especially f o r the best conditions l i s t e d in t h e t a b l e I. The fractured cross-sections of two coatings deposited on s t e e l in t h e conditions of t a b l e I I a r e given on f i g u r e 8.

*

r = X0 TiC13.0 / X o C4H10

C1 a t .

0.3

+

^0.02

0.25

+

^0.03

0.16

+

^0.10

Sample N o 23 e x h i b i t s a q u i t e f i n e g r a i n b u t t h e C1 c o n t e n t i s very high. Sample ID39 was obtained w i t h i n the range of conditions which optimize t h e composition of t h e solid and t h e grain refinement. I t i s interesting t o note that the f i n e s t grain s i z e which can be obtained depends on t h e s u b s t r a t e . As t h e r e i s no d i f f e r e n c e i n t h e growth r a t e of t h e T i c l a y e r between s t e e l and cemented c a r b i d e coated i n t h e same c o n d i t i o n s and a s a d e c a r b u r i z a t i o n i n t e r l a y e r has never been observed neither on s t e e l nor on cemented carbide, t h e grain s i z e variations could not be l i n k e d t o t h e carbon d i f f u s i o n from t h e s u b s t r a t e . On cemented carbides t h e g r a i n s i z e does not change a l o t from t h e s u b s t r a t e t o t h e s u r f a c e ( f i g 9 a ) , but i t i s g e a t e r than on s t e e l , and the best microhardnesses are lower, in t h e range 4000

-

4300 kg.mm-', however t h e e f f e c t of c o n s t r a i n t s lower t h a n on s t e e l cannot be neglected.

Figure 9 b p r e s e n t s f o r comparison a f r a c t u r e of a Tic c o a t i n g d e p o s i t e d on a cemented carbide by t h e c l a s s i c a l C.V.D process.

X" TiC13.0

1.029 1.045 loa2 1.646

Microh rdness kg.,-

h

1160

+

⁶⁰

Sample number ID23

Finer grain s t r u c t u r e s obtained i n a single layer from t h i s process a t moderate temperature can be connected t o t h e f i n e - g r a i n e d s t r u c t u r e achieved by t h e d e p o s i t i o n of a m u l t i l a y e r coating and ( o r ) t h e use of extraneous dopants in the deposition process a t high temperature (10).

C/Ti

0.96

+

^0.02

0.98

-

+ 0.02 0.99

+

^0.02

V I Conclusion :

4 X O C4H10

5.791 5.795 lom2

8.522

X O TiC13.0

2.787

Titanium c a r b i d e c o a t i n g s can be d e p o s i t e d a t high r a t e , i n t h e range 5

-

10 microns p e r hour, a t a moderate temperature of about 850°C from butane instead of methane and a mixture of titanium chlorides prepared in-situ by the prereduction of the TiCT4 by Ti metal.

r*

0.711 0.721 0.773

Grow: r a e g.cm

'.,-I

0 . 8 1.01 1.33

From a comparison with a thermodynamic study, i t can be shown t h a t t h e deposition conditions and r e s u l t s d e v i a t e from e q u i l i b r i u m . The s u p e r s a t u r a t i o n a t the deposit surface together with the moderate temperature lead t o grain refinement. However, t h e f i n a l grain s i z e depends t o a c e r t a i n extent on the s u b s t r a t e and i t s preparation. When associated w i t h a low chlorine incorporation and a composition c ose t o stoichiometry, t h e f i n e s t s t r u c t u r e leads t o a very

h

high microhardness of 5000 kg.mm-

.

Microh rdness kg.,-

9

4950

+

²⁷⁰

4800

+

³⁵⁰

4800

+

²⁵⁰

4 X0 C4HI0

7.431

r*

1.5

C1 a t .

2.4

+

^0.27

C/Ti

0.99

+

^0.01

Grow! r a e g c

.

1.51

(11)

REFERENCES :

1 1 J. P. P i t o n , B. Ladouce, L. Vandenbulcke, Proceedings of t h e 6th European Conference on C.V.D., R. P o r a t , E d i t o r . I s c a r Ltd, Nahariya, I s r a e l (1987) p. 120.

2/ G. Eriksson, Chemica Scripta, 8 (1975) p.100

3/ E. K. Storms, " The r e f r a c t o r y c a r b i d e s

",

J. L. Margrave, E d i t o r . Academic P r e s s , New York and London (1967)

4/ K. Koyama and Y. Hashimoto, Nippon Kinzoku Gakkaishi, 37-4 (1973) p. 406.

5/ V. I. Malkin and V. V. Pokidyshev, Russian J. Phys. Chem., 45-8 (1971) p.1159.

6/ M. Hansen " C o n s t i t u t i o n of b i n a r y a l l o y s

",

Mc. Graw-Hill book Company Inc., New York, Toronto and London (1958).

7/ L. Vandenbulcke, Proceedings of t h e 8th International Conference on C.V.D., J. M. Blocher, Jr., G. E. V u i l l a r d and G. E. Wahl, E d i t o r s , The E l e c t r o c h e m i c a l S o c i e t y . Softbound S e r i e s , Pennington N. J. ( 1 981 ) p.32

8/ L. Vandenbulcke and G. V u i l l a r d , Proceedings of t h e 8th I n t e r n a t i o n a l Conference on C.V.D., J. M. Blocher, Jr., G. E. V u i l l a r d and G. E. Wahl, E d i t o r s , The E l e c t r o c h e m i c a l Society. Softbound S e r i e s , Pennington N. 3. ( 1 981 3 p.95

9/ B. Drouin-Ladouce, J. P. Piton and L. Vandenbulcke, t o be published.

10/ H. Van Den Berg, U. K6nig and N. R e i t e r , Proceedings of t h e 6th European Conference on C.V.D., R. P o r a t , E d i t o r . I s c a r Ltd, Nahariya I s r a e l (19871 p.114.
