Studies of a polymerizable crystal : I. - structure of monomer pts (bis-p-toluenesulphonate of 2,4-hexadiyne 1,6-diol) by neutron diffraction at 120 and 221 k

HAL Id: jpa-00209398

https://hal.archives-ouvertes.fr/jpa-00209398

Submitted on 1 Jan 1982

HAL is a multi-disciplinary open access archive for the deposit and dissemination of sci- entific research documents, whether they are pub- lished or not. The documents may come from teaching and research institutions in France or abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est destinée au dépôt et à la diffusion de documents scientifiques de niveau recherche, publiés ou non, émanant des établissements d’enseignement et de recherche français ou étrangers, des laboratoires publics ou privés.

Studies of a polymerizable crystal : I. - structure of monomer pts (bis-p-toluenesulphonate of 2,4-hexadiyne

1,6-diol) by neutron diffraction at 120 and 221 k

J.P. Aimé, J. Lefebvre, M. Bertault, M. Schott, J.O. Williams

To cite this version:

J.P. Aimé, J. Lefebvre, M. Bertault, M. Schott, J.O. Williams. Studies of a polymerizable crystal : I.

- structure of monomer pts (bis-p-toluenesulphonate of 2,4-hexadiyne 1,6-diol) by neutron diffraction at 120 and 221 k. Journal de Physique, 1982, 43 (2), pp.307-322. �10.1051/jphys:01982004302030700�.

�jpa-00209398�

Studies of a polymerizable crystal :

I.

Structure of monomer pTS (bis-p-toluenesulphonate ^of 2,4-hexadiyne 1,6-diol) by ^neutron diffraction at 120 and 221 K (*)

J. P. Aimé (1) (2), ^{J. Lefebvre} (2) (4), ^{M. Bertault} (1), ^{M. Schott} (1) ^{and J. O. Williams} (3) (1) Groupe ^de Physique des Solides de l’ENS (**),

Université Paris VII, ^Tour 23, ² place Jussieu, 75251 Paris Cedex 05, France

(2) ^Institut Laue-Langevin, 156X, ^{Centre de} Tri, ^{38042 Grenoble} Cedex, ^France

(3) ^Edwards Davies Chemical Laboratories, University College ^of Wales, Aberystwyth, Wales, ^U.K.

(4) Dynamique des Cristaux Moléculaires (***), Université de Lille I, ⁵⁹⁶⁵⁵ Villeneuve d’Ascq, ^France (Rep ^{le 25} juin 1981, accepté le 15 octobre 1981)

Résumé.

Les structures cristalline et moléculaire du monomère pTS (bis-toluène-sulfonate ^de hexadiyne- 2,4 diol-1,6) ^{ont été} déterminées par diffraction de ^neutrons à 120 K et 221 K. La structure basse température

est monoclinique P21/c

^Z

^{4 et a}

14,745(7) Å, b

5,086(2) Å,

25,738(12) Å, 03B2

91,71(5) degrés

et V

1 929 Å3 à 120 K. La structure haute température ^est également monoclinique P21/c

^Z

^{2 et}

a ⁼

14,630(20) Å, b

5,133(2) Å,

14,845(15) Å , 03B2

^118,55(7) degrés ^{et V}

^{979 Å3 à 221 K.}

Ceci correspond ^{à 295 K à b}

5,178 Å. ^Les quatre molécules de la maille basse température occupent des centres de symétrie ^et appartiennent à deux familles (sites)

^des géométries ^et des environnements diffé- rents. En particulier, ^les groupements diacétylène ^ont

les deux sites des orientations et des contacts intermolé- culaires légèrement différents,

^aucune contrainte intramoléculaire notable. Les groupements latéraux toluène- sulfonate ont peu de contacts atome-atome intermoléculaires et leurs librations sont encore à 120 K de grande amplitude; ceci facilite les mouvements induits par la contraction selon b qui accompagne la polymérisation.

La structure à 221 K, analysée de manière usuelle, ^sans désordre, ^{montre de très} grandes librations des groupes latéraux. Elle

pu être également analysée,

^la supposant désordonnée, chaque groupe latéral occupant ^l’une

ou

l’autre de deux configurations très semblables à celles des sites à 120 K. Cependant, la barrière de potentiel qu’on peut

déduire, ^à partir ^de l’analyse ^de l’agitation thermique, ^est très peu élevée. Pour le reste, les géométries moléculaires et les contacts intermoléculaires sont très semblables à 120 K et 221 K. Le monomère pTS ^{et le} polymère poly-pTS ^ont également ^des structures très semblables, dans les deux phases. On discute aussi briève- ment la signification ^des structures ici déterminées pour la réactivité, ^{et diverses} propriétés électroniques.

Abstract.

The crystal ^{and molecular} structures of

pTS (bis-p-toluenesulphonate ^of 2,4-hexadiyne 1,6-diol) have been determined by ^neutron diffraction at 120 K and 221 K. The low-temperature ^{structure is}

monoclinic P21/e ^{with Z}

^{4, and a}

^14.745(7) Å, b

5.086(2) Å,

25.738(12) Å, 03B2

91.71(5) deg.,

V = 1929 Å3 at 120 K. The high-temperature ^structure is also monoclinic P21/c ^{but with Z}

^{2 and}

a ⁼

14.630(20) Å, b

5.133(2) Å,

14.845(15) Å, 03B2

118.55(7) deg., ^V

⁹⁷⁹ Å3 at 221 K. This corresponds

to

temperature b parameter ^{of 5.178} Å. The four molecules in the low-temperature ^{unit cell}

^unstrained

and all lie at centres of symmetry. They belong ^{to two families} (sites) with different geometries and different envi- ronments. Particular diacetylene ^groups

^{the two} sites have slightly different orientation and intermolecular

contacts. Toluenesulphonate side groups have few ^atom-atom intermolecular contacts and exhibit libration of

large amplitude ^{at 120} K, leaving

for the contraction along ^b brought ^about by polymerization. ^{A «}

tional

analysis of the 221 K structure (i.e. ^without positional disorder) shows very large libration of the side groups. It could be analysed by assuming disorder, ^each side group occupying ^{either of two} configurations ^which

Classification

Physics ^Abstracts

61.12

(*) ^The isotropic ^and anisotropic ^{thermal factors}

^well

as

calculated and observed structure factors for all (hkl)

are

available from

Editions de Physique, Zone Industrielle de Courtaboeuf, ^B.P. 112, 91944 Les Ulis Cedex (France) ».

(**) Laboratoire associe

C.N.R.S. No 17.

(***) Equipe de Recherche associee

C.N.R.S. No 465.

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphys:01982004302030700

are

very similar to the two low-temperature ^site configurations. However, the barrier height between the two

configurations, deduced from TLS analysis of thermal motions, is very low. Except ^for this, the overall molecular

geometries ^and intermolecular contacts

very similar to those fo~nd ^{at 120 K. pTS}

^{and poly-pTS-}

polymer have similar structure both at low- and high-temperatures. The relevance of the structure to reactivity

and various electronic properties ^is briefly ^discussed.

,1. Introduction.

Recent interest in the diacety-

’lenes is due, among other reasons, to the fact that several of them polymerize in the solid state, ^to yield

pure, macroscopic crystals ^of conjugated polymers [1].

The polymerization process conforms with the topo- chemical principle enunciated by ^Schmidt [2] ⁱⁿ

which the crystal ^{structure of the reactant controls} completely ^{the nature of the} product ^{formed. In such}

systems, ^accurate knowledge of the detailed structure of the reacting ^monomer crystal ^is essential, together

with information about structural changes brought

about by progressive polymerization. For the final

product ^{to be a} polymer single crystal ^both polymer

and monomer must belong ^{to the same} space group, and _possess closely ^related structures. However reac-

tive monomers polymerize fairly rapidly ^under X-ray irradiation, ^{and a detailed} X-ray study is, ^{in these} cases,

extremely ^{difficult or} impossible. ^Neutron diffraction,

therefore offers a solution to the determination of the

crystal ^{structure of these monomers. The} only way for a thermal neutron to deposit enough energy in a monomer crystal ^{to initiate} polymerization ^{would be}

a nuclear scattering ^event

^a very ^{rare event} in

crystals containing only H, C, N, 0, ^{S atoms. Some}

·X-ray studies of reactive monomers are, however,

available (see below). Reactivity ^{is not a} problem ^for polymer crystals ^{which can be} routinely ^studied by X-rays.

In this _paper we report ^the study ^{of a} diacetylene

which is known in the literature as pTS, ^{or alternati-} vely ^{as TSHD or TS. The} gefleral formula of the dia-

cetylene molecules is R--C=---C--C=---C-R’ where R and R’ _may be various ^« side-groups ^{». In} pTS, ^a symmetrical diacetylene, ^{R and R’ are}

a para-toluene sulphonate moiety.

pTS ^was chosen for study ^{since it} is, by far, ^the

most thoroughly investigated diacetylene. ^The polymer

structure at 300 K is known [3]. ^It belongs ^to space group P21 /c ^{with two} repeat units in the cell, ^Z

2,

and the one-dimensional polymer ^{backbone chains} elongated along ^{the b} crystal axis. The low-tempera-

ture polymer ^{structure has been} explored ^{at 120 K} [4].

The space group remains P21/c but the unit cell doubles with Z

4 and two inequivalent sites. The

phase transition ^{occurs near} 190 K [5].

It was known that the monomer exhibits a similar

phase change [6] ^and recently ^an incommensurable

phase, ^which is absent in the polymer, has been dis- covered between about 160 and 200 K [7]. ^{A low}

accuracy structure at 120 K was available [6], together

with several unit-cell measurements at various tempe-

ratures. The polymerization ^of pTS ^is homogeneous,

and polymer ^{and monomer are} considered to form

a continuous series of solid solutions extending ^from

a perfect ^{monomer to a} perfect polymer crystal.

However, this does not necessarily ^{mean that mono-} mer-polymer ^mixed crystals ^are untrained and, indeed, the kinetics of single crystal polymerization [8]

take account of the lattice strain. Several methods for

determining, ^{at least} approximately, ^the polymer ^con-

tent in reacting crystals ^{have been} proposed [9-10].

This paper is part ^{of a} series of investigations ^on pTS which include structural studies (reported here),

inelastic neutron scattering [11], ^Raman scattering [12]

and calorimetry [13] ^{to be} reported elsewhere. The present paper is organized ^{as follows.} Experimental

details are given in section 2. In section 3, ^{we discuss} the low-temperature structure, ^{which serves as a}

starting point since it is the only perfectly ^ordered phase. ^{In section 4, we} discuss the high-temperature phase. Finally, in section 5, ^a comparison ^{is made}

between monomer and polymer structures. We shall

keep in mind the relation between structure and reac-

tivity throughout temperature ^and pressure depen-

dences of lattice parameters, ^and preliminary ^results

on the incommensurable phase ^{and the} correspond- ing transitions, ^{will be} given ⁱⁿ following papers.

2. Experimental (general).

pTS monomer was

prepared by ^{reaction of} tosylchloride (Fluka) ^with 2,4-hexadiyne 1,6-diol, ^or HDD (K ^and K) ^{at 4 °C} [14].

These chemicals, especially ^{HDD, were first} recrystal-

lized several times in toluene to remove all traces of the polymer. ^{Care was taken to} minimize side reac-

tions. pTS thus obtained ^was recrystallized ^several

times from CH2Cl2--CH30H ^{and the} crystals were

grown ^at 4 ~C from acetone solution under a slow flow of nitrogen [15]. Except during mounting ^{on the} goniometer head, ^{and of course} during heat tr,eat- ments, the crystals ^were kept ^{at 255 K or below in}

the dark, ^{in order to avoid} polymerization. ^{In all cases,}

the colour of a crystal ^{at the} beginning ^{of an} experi-

ment was pink, indicating ^{an initial} polymer ^content of less than 0.5 %, judging ^{from the} spectroscopic

studies on other crystals. ^{No further} polymerization

was detected after crystals ^had remained in the neutron beam for _up to a week. Indeed, ^the y-contamination ^at

the sample ^{in the neutron beam was} always ^{less than} 10-1 rad., ^{whereas 4 x 105 rad. are needed to achieve}

a 0.01 polymer content at room temperature [9].

’

The structure determinations at 120 K and 221 ^K

were made using ^{data collected at ILL} high-flux

reactor (Grenoble) ^{on D8 4-circle} diffractometer,

using ^neutron wavelengths ^{0.891 A and 1.266 ± 0.001} A,

selected respectively by ^{a Cu} (220) ^{and Cu} (200) ^mono-

chromator. The wavelengths ^{were measured} by ^refin- ing the lattice parameter ^{of a} standard KCI crystal.

A/2 contamination was measured to be "" 2 x 10- 3 Á

at 0.891 A. An Air-Products Displex ^He compressor

was used, ^{with a} temperature stability - 0. I ^{K and an}

absolute accuracy - 1 K.

Data were treated using program COLL5N written

by ^M. S. Lehmann and F. K. Larsen [16] ^{with correc-}

tions for cryostat absorption. ^For crystal absorption corrections, ^real absorption ^was unimportant, ^and only isotropic incoherent scattering ^was considered,

with _~H

30 barn, using ^{ABSCOR in XRAY} pro- gram. This correction plays ^a r5le for the crystal ^used

at 120 K only, ^{which was} plate-shaped

Program ^XRAY [17] ^{was used for structure refine-}

ment, with Fermi lengths ^{0.665 for} C, - ^{0.374 for} H, 0.580 for 0 and 0.28 for S [18]. ^The quality ^{of the}

structure was estimated using R (y ^{Fo - Fc I)IFO}

and Rw

(Y(Fo - F~)2)/Fo.

3. Structure of the low temperature phase.

^3.1

EXPERIMENTAL.

The crystal used for this structure determination was a plate ^of perfect morphology [19], light pink ⁱⁿ colour, ^{with a volume 8 mm3. The}

measurement temperature ^{was chosen to be the same}

as the one chosen for polymer ^{structure determina-}

tion [4]. ¹⁸⁸¹ independent reflections were used. They

were collected at 1.266 A, ^{with 0 50~. No} 1/Q(l~

condition was applied. ^{To avoid} applying ^extinction corrections, ^{the 12 most intense} reflections were

rejected, all the others ^were given equal weight.

’

Refinement ^was started from the known 120 K

polymer ^{structure [4]. A first series of runs in which} only isotropic thermal factors on H atoms were used

yielded ^{a structure with R}

^7.3 %. Introduction of

anisotropic ^{factors on these atoms} decreased R to 4.9 % ^{in two} cycles. The final values are R

3.7 %

and Rw

^3.8 %.

3.2 R.ESULTS.

The structure is P2i/c ^{with Z}

⁴ (using ^{the same} setting ^as previous ^workers [3, 4, 6]).

The monomer molecules are centrosymmetric ^{and lie}

at centres of symmetry. ^{There are therefore two sets} of molecules with different geometries, occupying ^two

sites I and II, ^{as in the} polymer ^{at 120 K} [4], ^{and as}

in trans-stilbene for instance [20].

A cell parameters refinement on 16 intense lines with 0 _up to 39 deg. ^and distributed throughout reciprocal space yielded ^{the data} given ^{on table I.}

The two sets of lattice parameters ^{at 120} K, ^avai- lable from X-ray measurements [6, 21] ^{are also} given

in table I. As mentioned above, they certainly ^suffer

from the fact that the samples change during ^data acquisition, ^since polymerization occurs, albeit more

slowly ^{than at room} temperature, ^and therefore lattice parameters change [21, 22].

The discrepancy ^with present data is outside the stated accuracies. Note in particular ^{the much} larger

Table I.

Low-temperature ^{unit cells} of pTS ^mono-

mer.

(*) ^{The standard errors stated do not} include the uncer-

tainty ^{on the neutron} wavelength, which may add

syste- matic error ³

10-4.

(**) Calculated by

^{from the lattice} parameters given.

value of b which cannot be explained by X-ray ^induced polymerization. The value of b found here is smoothly

connected to the room temperature value of about 5.178 A [42] which has been confirmed independently by X-rays [23].

The lattice contraction along ^b upon complete polymerization is therefore only ^{0.17 A at 120} K, compared ^{to 0.27 A at 300 K,} using ^the quasi tempera- ture-independent polymer ^{value of b}

4.917 A [3, 24]. Despite this smaller contraction, polymer ^chain propagation ^is blocked below 105 K [25]. ^Lattice

mismatch along ^b is therefore not the only ^structural

feature important ^{in the} polymerization ^of pTS.

, -, ’-I~’

Fig. ^1.

Projection

plane (101) ^of the site I molecule in the 120 K structure and labelling ^{of the atoms. The labels}

of the corresponding ^{site II atoms are in} parenthesis.

Final atomic positions ^are given ^{in table II. Thermal} agitation ^is expressed ^as U-equivalent. ^{Atoms are}

labelled as in figure 1, which shows a projection ^of

site I geometry ^{on the} (101) plane. ^Bond lengths ^are.

given ^{in table} III, ^{columns 1 and} 2, and bond angles

in table IV, ^{columns 1 and 2.}

Table II.

Atomic positions ⁱⁿ monomer pTS ^{at 120 K.}

Atoms S(I) ^to H(9) belong ^to site I molecules and atoms

S(2) ^to H(19) ^to site II. Note that there is

atom labelled

H(10). Coordinates in reduced units. U-equivalent, express- ed in 10-2 A2.

Figure ^{2 shows a} projection ^{of a} whole unit cell

on (101) plane.

3 , 3 DlscussloN.

3 . 3 .1 Bond lengths ^and angies.

-

The pTS ^{monomer molecule} comprises ^several

~

1.

Fig. ^2.

Projection of the low-T unit cell on plane ^(101).

fairly rigid ^units (diacetylene, phenyl) ^connected by non-rigid series of bonds. It can then take different overall shapes ^without strongly distorting any indi- vidual bond. Indeed, ^on neither site is _any bond _very different from the _average length corresponding ^{to its} type [26, 27]. ^For instance, ^the phenyl rings ^are only slightly ^distorted regular hexagons ^{and bonds} C(6)C(7j

and C( 16)C( 17) only differ from the ^« average » ^aro- matic C-C bond length ^{of 1.395 A} [26] by ^{more than}

the standard deviation of 0.003 A - they ^measure

1.405 A. The rings ^have approximate ^threefold sym- metry ^{and differ} only slightly ^{on the two} sites. Three CCC angles ^{are 118.9} (resp. 119.1) degrees; ^{the three}

others 121.2 (resp. 120.8), ^{with a} standard deviation of about 0.2 degree.

The phenyl ^{C and H atoms are almost} exactly coplanar ^{in site I, but site II shows a} slight ^deviation

from planarity (Table V). ^Atoms H(6) ^and H(16) are somewhat farther out of plane. ^As they ^{seem to have}

some specific interaction with the diacetylene moiety

of a neighbouring ^molecule (see § 3.3.3), they ^were

not used in the calculation of _average plane ^coordi-

nates.

Differences in the bonds connecting ^{the more or}

less « rigid )) ^{units are absent or} barely significant :

the only ^ones larger than twice the standard deviation

C(1)C(3)-C(11)C(13) ^{= 8 x} 10-3 A and

C(3)0(1)-C(13)0(4) ^{= 7 x 10-3 A.}

No angular difference is larger ^{than 0.6} degree.

3.3.2 Relative position of parts of the molecule.

In a non-rigid molecule, ^molecular geometries ^can

differ by the relative displacement ^of parts ^{of the}

molecule, ^{such as} that caused by rotation around

Table III.

Bond lengths ^{obtained in the} different refinements.

u(X- Y) ^{is the standard}

^{for all bonds not} involving ^H atom, between different

identical atoms. The

is about the same in all these

Bond lengths corresponding ^to

rigid group

^not given.

single ^bonds. This indeed occurs in pTS ^monomer.

First of all, ^{the two} sites differ by ^the angle ^between

the plane ^defined by the axis of the diacetylene group and the b axis (equivalent ^to the backbone plane ^{in the} polymer) ^{and the average} plane ^{of the} group S---C6H4-C. ^This angle ^{is 60.0} degrees ^{on site I and}

74.8 degrees ^on site II. The small uncertainty ^{in the}

definition of the _average phenyl plane, implies ^that

it is not useful to specify ^these angles ^{to less than}

0.4 degree. Similarly, ^{in the} polymer, ^the correspond- ing angles ^are 64.2 and 79.3 degrees [4, 6].

The atoms S( 1)C(4)C(7)C( 10) define the « axis » of the rigid phenyl group, and ^are almost exactly ^collinear.

The maximum distance from the least-square straight

line is 3.5 ^x 10- 3 A on site I and 2 x 10- 3 on site II

(atoms S(2)C( 14)C( 17)C(20)). ^{The angle} between this axis and the corresponding diacetylene ^axis C(1)C(2)

is 82.86 degrees ^{(site 1) and 88.52} degrees ^{on site II.}

One difference between the molecular geometries ^on

the two sites is therefore a difference in position ^of

the unit SC6H4CH3 ^{as a} whole, ^{which can} be described

(although ^{it is not an actual} movement) ^{as a} rocking

of its (approximate) ^« twofold axis » to and from the

diacetylene axis, by ^{about 6} degrees, ^{and a rotation}

of the unit around its o twofold axis » leading ^{to a}

15 degrees difference of the angle between the planes

of the phenyl ring and the backbone.

The deformation does not extend _very far toward

C(1)C(2) : ^the angle ^between planes C(2)C(1)C(3)0(1)

and C(3)0(1)S(1) ^{is 9.9} degrees, and between the cor-

responding planes C(12)C(11)C(13)0(14) ^and C(13)0(4)S(2), ^11.9 degrees. ^{All other} pairs ^of planes

have the same relative orientation on both sites within 0.5 degree.

As mentioned above (§ 3.1), ^a significant improve-

ment of the structure is produced by introduction of

anisotropic ^thermal agitation factors for the H atoms.

This is especially ^{true of the} methyl ^H atoms, whose temperature ^{factors are} very large (see ^table I) ⁱⁿ comparison with others which ^are normal. In addi-

tion, ^the largest principal ^axes of the 3 thermal ellip-

soids are in the planes ^{of the 3} hydrogens. ^This suggests

Table IV.

Bond angles ^{obtained in the} different refinements.

that fast rotation of methyl groups around the

C(7)C(10) ^and C(17)C(20) ^{axes still occurs at 120 K.}

3.3.3 Intermolecular packing.

^{Extensive dis-}

cussion of the intermolecular packing will be deferred until comparison with calculations using ^atom-atom potentials ^is possible. The overall impression ^{is one}

of fairly efficient space filling by ^the non-rigid pTS

molecules. Most atoms are in close contact with one

or several atoms of neighbouring molecules. Only ^a

few salient points will be mentioned here, including ^the packing around the diacetylene ^{itself, relevant to the} polymerization reaction, and differences between the two sites.

Around the diacetylene itself, packing ^is fairly ^dense.

Each of the C(l), C(2), C(3) carbons is associated with

two kinds of non-bonded interactions : with carbon

atoms of translationally equivalent molecules dis-

Table V.

Distance of the benzene ring ^atoms (in A)

from ^their least-square plane.

Site I qitt- 11

(*) ^{Atoms not included in the} definition of the planes.

placed by ^± b and with carbon and hydrogen ^atoms

of the benzene group of neighbouring ^{molecules on}

the other site. The first type ^{of contacts is} obviously

of prime importance ^{in the} polymerization ^reaction

itself. The second type ^{of contacts would be} of impor-

tance, ^{if it} could hinder the large amplitude displace-

ment of atom C(l) ^{in the reaction. In this case it would}

communicate the reaction of molecules in one stack

parallel ^{to b to molecules in} neighbouring ^{stacks, so}

that reactivity ^{of monomers vicinal to a} polymer ^chain

would be affected

Fig. ^3.

Contacts between neighbouring diacetylenes ^relat-

ed by

^b translation, ^with

der Waals radii indicated.

The

shown is site I in the low-T phase. First values of

C(l)-C’(1) ^and C(1)-C’(2) ^distances correspond ^{to site I of}

the low-T phase, ^{values in} parenthesis ^to site II and values in brackets to the high-T phase (independent ^{atoms refine-} ment).

Figure ^{3 shows a} projection ^{on the} plane ^defined by ^{b and site I} diacetylene axis. There is close contact between the reacting ^atoms C(I) and C’(1). ^{Table VI}

shows there is a noticeable difference between sites I and II, ^{the HT} phase resembling the latter.

Table VI.

Interatomic distances corresponding ^to

intermolecular contacts near the diacetylenes (in A).

(*) ^In Polymer C(1)-C’(1) ; ^1.36 A (Bond).

Figure ^{4 shows a} projection ^{on the} (a, c) plane ^of

molecules at site I and site II. The benzene rings ^of

site II molecules of the ^same unit cell define a cage, and the only ^{hindrance to} diacetylene motion in the

plane ^defined by ^its axis and b is the _very close

C’(2)H(16) ^contact. Table VI shows the significant

intermolecular distances. To our knowledge only

pyrene [28] ^{has such a} short C... H distance. Since

C(19), ^{the C atom to which} H(16) ^is bonded, ^{is in}

contact with C’(2), the situation is reminiscent of that

occurring ^{in weak} hydrogen bond-like A-H... B

bonds, although ^no such C-H... C bond is known to us. Some of the _necessary ingredients ^are present :

a somewhat polar ^{C-H bond - on a benzene} ring nearby S03 - ^{as H-donor, and the} triple ^{bond 1t}

electrons as acceptor. ^{The excess} energy correspond- ing ^to this short C... H distance, calculated using ^the

parameters given by Kitaigorodskii [27], ^is only

0.5 kcal./mole ^{or 2 kT at 120} K, ^{and can} be compen- sated locally by ^{even a} very weak bond. Such interac- tion does not occur on site II since the distance

C’(12)H(6)

^{2.84 A is} almost normal. There is ^no hindrance to polymerization ^{on site II due to} neigh- bouring ^atoms, but the situation is not so clearcut

on site I. This difference _may be reflected in different

polymerizabilities between the two low-T sites.

Here again, ^the high-T situation is similar to that

of site II.

Fig. ^4.

Projection ^on plane (101) ^{of the} vicinity ^of

diacetylene ^with

der Waals radii. Case of site I in the low-T phase.

A region ^{of close} intermolecular ^contact is also found near the diacetylene itself, ^{around atom} 0(3)

on site I, 0(6) ^on site II. The salient distances are

given ^{in table} VII. Note that, ^{if the} oxygen ^van der Waals radius is taken as 1.40 A [29], rather than 1.52 A

as preferred by Kitaigorodskii [27], ^no distance is

anomalously ^{short. In addition to} these intermolecular contacts, there its also close intramolecular contact between 0(3)H(2)

0(6)H(12)

^2.62 A. Therefore,

the molecules related by successive b translations are

connected by ^a continuous chain of non-bonded contacts between atoms C(3)H(1)0(3)H(2)C(3), ...

which _may help ^{in the} arrangement ^{of the} diacetylenes

in positions favourable to reaction. This configuration

Table VIIA.

Intermolecular contacts around 0(3) (in A).

is also present ^{in the} high-T phase, ^and probably ⁱⁿ

the polymer, although ^{of course} C(I) ^{has now moved}

away, and H positions ^{are unknown.}

The packing along b of the side _groups is loose : table VIIB shows the corresponding shortest intera- tomic distances.

There is only ^one C-H contact, of H(8) with either

C(8), ^{on site} I, ^or C(9), ^{on site} II, displaced by ^{b :}

distance 2.90 A. The real significance ^{of such contacts}

is dubious, ^since H(8) belongs ^{to the,} presumably rotating, methyl group. Contacts around this _group

are such that they allow almost free rotation, ^{on both} sites. There is no C-C contact, the shortest distance

being ^{3.76 A between} C(9) ^and C(10) displaced by ^b

on site I. The only ^C-0 near-contact is C(5)-0(2).

Therefore, ^more than half of all contacts along ^{b are}

between diacetylenic ^{carbons. This,} plus ^the flexibility

of the pTS molecule around C(3), helps ^{to understand}

how the structure can accommodate a large change

of parameter ^{b with} slight side-group reorientations.

Indeed, ^as shown in table VIIB, the short distances

are almost the same in monomer and polymer, ^the

maximum difference being ^{less than 0.1 A.}

3.3.4 Structural consequences for reactivity ^and

electronic properties.

The discussion of § 3. 3. 3 has Table VIIB.

Shorter distance between atoms of ^one side-group ^{and those} of ^{the same} one, displaced by ^b (in A).

Distances within 0.05 A of the

of

der Waals radii are underlined. Displayed

distances shorter than

C-C

3.7 A, ^C-0

^3.3 A, ^C-H

^3.1 A, ^C-S

^3.85 A, ^0-H

^{2.8 A and H-H}

^{2.5 A.}

revealed packing differences between the sites which,

albeit small, may affect the reactivity. Study ^{of such} reactivity differences would be interesting.

The packing also shows close proximity ^{of the sul-} fonyl part ^{or one} molecule and of the diacetylene ^unit

of another molecule. This _may be important ^{in the} polymerization ^{processes in which an} excited elec- tronic state is a kinetic intermediate. The short distance

implies ^efficient energy transfer from the _upper lying tosyl singlet ^{and even} triplet ^{excited states to the}

lower lying diacetylene ^{excited states of the same multi-} plicity. ^Hence photopolymerization ^{even for} light predominantly ^absorbed by ^the tosyl group may be facilitated. Even if the polymerization actually ^occurs

from a vibrationally ^excited ground state, excited by

internal conversion, ^{the close contact} observed _sug- gests ^the possibility of efficient vibrational (multi- quantum C-H) energy transfer from the benzene _group to the diacetylene. ^{In such a situation «} photopolyme-

rization » will occur even if the side-group ^excited

states are below those of the diacetylene ^unit.

Another consequence of the existence of two sites may be a difference in electronic excitation energies.

In the polymer, the existence of two sites in the low-T

phase manifests itself spectroscopically by ^a

~

250 cm-1 splitting (at ⁴ K) ^of the vibronic bands

corresponding ^to the first excitonic transition, ^near

620 nm [1, 30]. ^{This can be} interpreted ^{as site} split- ting [31], ^as observed in the _very similar crystal ^struc-

ture of trans-stilbene [32]. Broadly speaking, ^{such a} splitting may be of intramolecular and/or ^intermole-

cular origin. ^{The same} phenomenon certainly ^occurs

in pTS ^{monomer as well. The monomer UV} absorption

bands have not been studied at high enough ^resolu-

tion. However, ^the absorption ^{due to} polymer ^chains

near 600 nm in slightly polymerized crystals ^{show a} larger splitting : ^{500 cm-’}

^{at 4 K} [33].

Since the molecules on both sites seem largely unstrained, and since the geometrical differences are

mainly ^{confined to the outer} parts ^{of the} molecules,

it is unlikely ^{that a} splitting ^{of a monomer electronic}

transition would correspond ^to changes in intramo- lecular through-bond interaction between benzene and

diacetylene. ^{The same} probably applies ^{to the} pure

polymer, ^since X-ray ^data [4] ^{seem to allow to rule}

out difference in such interactions. The situation of isolated polymer chains in the almost _pure monomer

matrix is not clear, since these chains are known to be extended [34], ^and might ^be differently ^{strained on}

the two sites. Another, ^{and more} likely, ^{source of site} splitting ^{is a} site-dependent contribution to exciton

energies ^{of the} change ^{in van der Waals and} multipolar

interactions [35], ^{as in} 1.4-dibromonaphthalene ^for

instance [36]. ^In pTS ^monomer, diacetylene ^and tosyl

moieties can be approximated ^as independent ^chro- mophores. Differences in relative positions imply ^diffe-

rence in angles ^made by dipole and transition dipole

moments of neighbouring chromophores (of ^{the same}

or different molecules) with the transition dipole

moment of a given diacetylene, yielding differences in the corresponding ^{energy terms. The same will} apply

to an isolated polymer ^chain.

Considering ^{that the amount of} splitting ^{of the}

electronic transition of an isolated polymer ^{chain in}

the monomer crystal reflects the difference between

sites, the maximum difference _may not yet ^{be reached}

at 120 K : the splitting ^{of the} principal peak ^near

600 nm is, ^{at 120} K, only 2/3 ^{of its 4 K value} [33],

and the low _energy optical line shows a red shift of 200 cm-1 from 120 to 4 K. Therefore, ^{a 4 K structure}

would _very likely ^{show a} larger difference between sites than that found at 120 K.

4. Structure of the high-temperature phase.

^4.1

EXPERIMENTAL.

Data were collected at 221 K, ^i.e.

about 20 K above the onset of incommensurable modu- lation [7]. Data collection took about a week and

a relatively low-temperature ^{was chosen to minimize}

thermal polymerization.

A different crystal ^{from the one used at 120 K was} used, ^since polymerization might have occurred during

the several months which elapsed between the two

experiments. ^The crystal ^{used at 221 K was not far}

from cubic in shape ^{and had a} volume ~17 mm3.

Absorption corrections were minimal. 1895 indepen-

dent reflections with 0 550 were collected using ^a

neutron wavelength A

^{0.891 A. 1696} reflections with 1/ 6(~ > 1.5 were used in the subsequent ^calcu- lations, ^all being given equal weighting. ^{The 3 most}

intense lines were rejected ^{and no} extinction correc-

tion was applied.

Refinement was started from the published polymer high-temperature ^structure [3]. ^{For reasons discussed} below, three calculations were performed : using

XRAY [17], ^an independent ^atoms calculation, ^and using program ORION [37], ^two calculations using rigid groups. The ten C and H benzene atoms were

taken as one rigid group and thermal group. The

methyl ^{was taken as another} rigid group. In ^one

approach, ^{ORION was used, as usual, with one} posi-

tion _per atom. The corresponding geometry ^chosen

was that of site I, the less intramolecularly ^distorted.

In the other approach, ^{we tried to} analyse ^the high

T-structure as a disordered one, and atoms were given

two positions, ^{each with} probability 1/2, ^{as if each}

molecule could be either in site I or in site II.

These approaches ^were tried since the exact nature of the phase transition, and whether it is displacive

or order-disorder is not clear. The refinements cor-

respond ^{to either of these} assumptions. This is further discussed in paragraph ^4.3.

4. 2 REsULTS.

The structure (the average ^struc- ture if the crystal is assumed disordered) ^is P21/c ^with

Z

2. The two monomer molecules lie at centres of

symmetry ^{and are now related} by ^the interchange

operations usual in that structure [38]. ^{The situation}

is, again, ^{the same as in} the pure polymer [3]. ^{At 221 K,}

since it has been claimed that p 1 o polymer ^is pyro- electric [39], ^{a more detailed} investigation ^{of some}

lines absent in P21~~ ^{but which could be present in the}

related non-centrosymmetric groups P21 ^{or Pc was} performed. The intensities at (010) ^and (030) ^were

found to be (2 ± 1) .10- 3 ^{those of} (020) ^and (060) ^and

could be entirely ^{accounted for} by h/2 contamination transmitted through the monochromator. Some (hOl)

reflections with I odd were tested and none was found.

Atoms being ^{labelled as} those of site I in figure 1, the final atomic positions and thermal agitations expressed ^as U-equivalent ^are listed in table VIII, ^bond lengths ^{in table III, and bond} angles in table IV. The results of all three refinements are listed in tables III and IV, ^since they ^are used in the following discussion.

The atomic positions ^obtained by ^{ORION are avai-}

lable with the (hkl) ^data.

Table VIII.

Atomic positions ^{in monomer} pTS ^at

221 K obtained by independent ^atoms refinement.

U-equivalent

expressed ^{in 10-2 A’.}

4. 3 DISCUSSION.

4.3. .1 Independent ^atoms refi-

nement.

This XRAY refinement yields final values R

8.9 ~/~, R~

^9.2 ;’%. Figure ^{5 shows a} projection

of a whole ^unit cell on (101) plane.

Thermal agitation ^{factors are} large. ^{This is not sur-} prising ^{for the} methyl hydrogens, already rotating ^at

120 K. But all the atoms of the benzene _group, as well

as the methyl ^carbon, also show large anisotropic

motion. Consider for instance the atoms C(7), C(8),

Fig. ^5.

Projection ^{of the} high-T ^{unit cell}

plane (101).

C(9) ^and H(5), H(6). Their motion can be analysed

as due to a rotation around the C(4)-C(7) ^{axis and}

rotation of this axis around a point ^near C(4), ^which

is the type ^of displacement relating, in the low-tem- perature phase, ^the geometry ^{of site I to that} of site II.

In addition, ^{one finds a} fairly large distortion of the

phenyl group : bonds C(4)-C(5) ^and C(7)-C(8) ^for

instance are shorter by ^{more than 0.03 A} than in the low temperature structure. This is more than 3 ^stan- dard deviations (see ^table III).

One is then led to suspect that the refinement _pro- cedure misses a significant feature of the structure, such as disorder. The room temperature ^{structure of}

poly-pTS has been described as disordered [5] ^and pTS

and poly-pTS structural properties ^are usually ^consi-

Fig. ^6.

Comparison ^of

high-temperature ^confi- guration ^{at 221 K} (a) (independent ^atoms refinement) ^and

of polymer high-temperature configuration ^{295 K from refe-}

rence

[3] (b).

dered _very similar, ^not only ^the geometries

except for the polymer ^backbone

^{but even the} anisotropic

thermal agitation ^factors (Fig. 6).

4.3.2 Refinements ^using rigid groups.

a) ^Non- disordered structure.

To analyse ^{the structure as}

’disordered, ^{we must allow at least some atoms to}

occupy several positions ^with probabilities ^{1. Since}

this is not possible ^{with XRAY as we use} it, program ORION was used instead [37]. ^{As a first} step, ^{a refine-}

ment similar to the previous one, i.e. without disorder,

must be performed, ^{to allow} comparison. Using C6H4

and CH3 ^as rigid groups reduces the number of inde-

pendent coordinate parameters ^{from 60 to} 39, ^and using in addition C6H4 ^{as a thermal} group (but ^not CH3 ^{since the H atoms are} rotating) reduces the num-

ber of thermal parameters ^{from 138 to 98. Since the} benzene ring ^is nearly perfectly planar ^{on site I} (table V) ^{but not on site} II, ^{site I} geometry ^{was chosen.}

Final values are R

10.2 %, R,

^10.4 %. ^{The non-}

constrained bonds and angles ^are normal, except C(7)-C(10) ^{which is} slightly ^shortened (table III).

Thermal motion.

Since rigid and thermal _groups

are used, ^the analysis of thermal motion could not be done in terms of independent ^atomic ~~~ ^{as in para-} graph ^3. Instead, ^we shall consider here the motion of the benzene _group C6H4, ^{which is} important ^{in the} understanding ^{of the nature of the} phase ^transition

and high-temperature structure. This benzene group motion ^was studied through ^{a TLS} analysis [40] ^{of its}

translation T, ^libration L, ^and coupling ^{S tensors.}

There is of course some arbitrariness in analysing ^the

normal modes of that _group alone, since it is covalently

linked to the diacetylene carbons, ^but this link is only through ^a flexible series of bonds. The phenyl group

is at a general position in the unit cell and no symme-

try consideration can be invoked to simplify ^{or elimi-}

nate the S tensor [40]. ^{T and L were referred to the} phenyl ^{inertial axes :} e1

perpendicular ^{to the} phenyl plane, ^the C(4)-C(7) ^direction e2 and _e3 perpendicular

to el and _e2.

The data thus obtained are not directly comparable

to those of the 120 K structure, ^since they ^{have been} processed differently. ^{To assess the} feasibility ^and degree ^of confidence of such a comparison, ^{the 120 K}

data were analysed using ^ORION using ^{the same} rigid and thermal _groups as those used ^at 221 K, starting from the atomic positions already ^determined (§ 3), ^and refining only thermal motions. The final R value is 5.6 %. The increase over the value found in

paragraph ^{3 is} comparable ^to the difference found between the two refinements of the 221 K structure, treated as non-disordered.

The eigenvalues ^{of the T and L tensors} of the low-T

phase ^obtained, either from the atomic ~i~~ independent

atoms refinement using ^XRAY (§ 3), ^or directly by ORION, ^are compared ⁱⁿ table IX. Results are similar,

but differences are obvious. Using ^ORION L22 ^is

smaller and L eigenvectors ^have significant compo- nents along ^{at least two} ~/s. ^{Still, the} eigenvectors

are not much rotated, ^{and the} larger ^libration ampli-

tude is in both cases found to have its larger compo- nent along e2. The TLS analysis may therefore be used,

but for qualitative discussion only : the benzene group is not really rigid.

Table X shows a comparison ^{of T and L data ob-}

tained in different refinements of the high-T phase. ^In

the one discussed here, L33 ^is anomalously ^small (smaller ^{than at 120} K) ^and gives another indication of the imperfection of the TLS approach ^{since the}

benzene ring is almost planar. ^Some non-diagonal

Table IX.

Benzene group T and L tensors at 120 K. Eigenvalues ^and components of ^the eigenvectors ^{on the} e j ^vectors. (Inertial ^axes of the benzene _group, see text.)

Tij ⁱⁿ Angstroms squared, Lii ⁱⁿ degrees squared.

Table X.

Benzene group TL ^{tensors at} 221 K.

(*) Standard deviations about 6 degrees squared, except L33, double-well, position ^I, where it is large : ²⁷ degrees squared.

components of L, ^{which are not zero} by symmetry, ^are ill-defined.

The eigenvectors obtained in the TLS analysis, although predominantly along ^one ej, often have

significant components along ^others. However, ^{in all}

cases, the eigenvalue L22 ^is large ^and corresponds ^to

an eigenvector predominantly along e2. This is the

motion by which the molecule can go from site I to site II (around ^{the same inversion} centre) ^and gives

another indication of a disordered structure. The libration centre is displaced by ^0.76 A from the ben-

zene

symmetry)) ^centre along C(4)-C(7), ^towards C(4).

b) Disordered structure.

The same type ^{of refi-}

nement was attempted assuming that the 221 K struc- ture is disordered, and started with the ^two low-T

geometries being equally probable for each molecule.

The two positions ^of many ^{atoms are} then so close

as to be indistinguishable, and this introduces _pro- blems in the refinement. Thus only ^{the atoms of the} C6H4-CH3 group could be given ^{two different} posi- tions, forcing ^the S( 1)-C(4) ^{bond to be} slightly (a ^few degrees) ^{out of the} average plane of the benzene ring.

The other atomic starting positions ^were those obtain- ed in the previous refinement. The final values

R=8.8%, ^R, =9.1%.

Bond lengths ^are given ⁱⁿ table III and bond angles

in table IV.

Due to the constraints of the rigid group, the

C(7)-C( 10) ^bond lengths ^differ significantly (by ^0.07 A)

in the two configurations.

It is therefore possible ^to refine the high-T pTS

structure as a disordered one, with even an improve-

ment in R over that of the similar ORION non-

disordered one (but ^this may be due at least in part

to the larger ^{number of} parameters introduced in the

refinement). ^{The two} positions introduced initially ^do

not tend to converge towards a single ^{one. We know}

of no example ^{where a} non-disordered structure with

large amplitude motions could be forced ^to refine into a disordered one.

The relative orientations of the benzene rings ^{on the}

two positions ^can be defined by ^the angles ^made by ^the principal ^{inertia axes as} given ^{in table XI. If the two} positions ^{were related} by ^a rotation around a common

C(4)-C(7) ^axis (plus ^a translation), ^{one would have}

e , e"

^{0 and} e;, e"

e3, e". ^{Table XI shows that}

the actual relation between the two positions ^{is not}

far from this. Comparison with the low temperature data also shows that the disordered positions ^are slightly ^less different than are the two low T sites, and the displacement connecting ^{them nearer to a}

rotation around _e2 plus ^a translation (plus ^{the sui-}

table operation ^{of the} space group).

Table XI.

Angles between the principal ^{inertia axes} of the ^benzene groups ^on the two sites (in degrees).

Column 1 : high-temperature structure, treated

disor- dered.

Column 2 : low-temperature structure, . both site confi-

gurations put ^{at the}

position by the suitable operation

of the high-T ^structure interchange group.

e 1 : perpendicular ^to the benzene plane.

e2 : along C(4)-C(’~ (or C(14)-C(17)).

e3 : along el

e2.

Thermal motion.

Results of the TLS analysis ^of

the benzene _group motion on both sites are given ⁱⁿ

table X. The T tensors are similar in both ORION

refinements, and comparison with table IX shows that

they scale with T approximately ^as expected ^on going
