Static and dynamic properties of two-dimensional polymer melts

HAL Id: jpa-00212422

https://hal.archives-ouvertes.fr/jpa-00212422

Submitted on 1 Jan 1990

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

Static and dynamic properties of two-dimensional

polymer melts

I. Carmesin, Kurt Kremer

To cite this version:

Static and

_{dynamic properties}

of two-dimensional

_polymer

melts

I. Carmesin

₍₁₎

and Kurt Kremer

₍₂₎

(1)Max

Planck-Institut für

_{Polymerforschung,}

D-6500

_Mainz,

F.R.G.

(2)Institut

für

_{FestkOperforschung,}

KFA

Jülich,

D-5170

_Jülich,

F.R.G.

(Reçu

le 8 novembre

_1989,

_accepté

le

_{7 février}

₁₉₉₀₎

Abstract. 2014 We

present a detailed

_{analysis of}

the

_properties

of dense linear two-dimensional

_polymer

chains. The

_systems

are simulated

_by

the

_{recently developed}

bond fluctuation method. We

_investigate

systems

of _up to 80 %

_density.

The chain

_length

and densities considered cover the crossover from the

_expanded

_single

chain limit to a dense

_polymer

melt. The chains

_completely

_segregate and follow

a _power law of the chain extension

R2

>~

N203BD,

N

_being

the number of bonds of the chains and 03BD =

1/2.

While for

single

_two dimensional chains the Rouse modes _{are not}

_{eigenmodes they}

are

_eignemodes

for the chains in a 2-d melt. Relaxation functions and mean _square

_{displacements}

display

typical

Rouse-like

_behavior,

with the

_distinction,

that the

_prefactors

for the various relaxation processes differ.

Classification

Physics

Abstracts 61.40-66.10c

1. Introduction.

Most

_{experimental investigations}

of

_polymers

consider chains in three dimensions. This is the

most natural

situation,

however,

there are _many exact theoretical results for d = 2

[1-3].

Thus,

a two-dimensional

_polymer

_system

would be an ideal

_testing

case _{for many} modern theoretical

concepts,

such as renormalization

_group

and conformal invariance methods. Besides this there is not much known about the

_dynamics

of such

_systems

_[4].

_Again

a two-dimensional

_system

should be ideal to

_investigate

the Rouse model

_{experimentally.}

For d = 3

hydrodynamic

interactions

always

dominate the behavior of thé chains in solution. For d =

2,

_e.g. chains near a

_surface,

this

probably

is not the case since

_long

_range

_hydrodynamic

_{interactions may} be

_completely

screened

out. For two dimensional melts the situation is

_especially

_interesting.

The

_topological

interaction is

_completely

different

_compared

to the d = 3 case.

_Following

recent theoretical

_{investigations}

the chains should

_collapse

and

_segregate

_[1].

However,

how does the

_shape

of the chains look like? Do

_they

_appear

as ideal random

_walks,

_although

the

_topological

_aspect

of the excluded volume interaction is a dominant

_aspect

for d = 2? Recent numerical simulations were not able to discuss this

_question

in detail

_[6-8].

Since

_they

use bond

_breaking

simulation methods their

samples

are,polydisperse.

As a

_consequence

there is a

_mixing

of

_long

and short chains

_leading

to

an effective

_expansion

of the

_longer

chains. The classical

_papers

of Wall et al.

_[9]

were not able

to address the above

_questions.

_Baumgârtner

_[10]

used the

_{reptation algorithm}

to

_analyse

the

916

differences between the ideal random walk structure and the 2-d melt chains. There the

_analysis

was confined to the ratio of the radius of

_gÿration

and the end to end distance.

_Bishop

et aL

_[11]

use a Brownian

_Dynamics

method in order to

analyse

2-d melts at rather low densities and for

short chains

_{( N}

_50,

p =

0.50).

In addition not much is known about the

dynamics

of dense 2-d

systems.

A recent

_{investigation}

of the

Rouse/Zimm

model of 2-d chains

_[12],

of course, could not

take into account the

_topological

_aspects

of the

_{problem. Experimentally}

these

_systems

are also

not

_completely

out of reach. Modern technics in

_producing

various

_polymers

could _e.g. construct

chains with small side branches

_preferring

two different solvents. If these solvents are

_immiscable,

such

_polymers

would be located at the interface between the two solvents. One can also think of chains between

_lipid

_monolayers.

Also recent

_developments

in the surface

_coating

of mica sheets

[13]

may

lead to

_stricly

2-d

_systems.

_Finally,

of _{course, the} classical

_approach

of

_spreading

chains out of a volatile

_good

solvent onto a

_liquid

air interface

_may

be used. After some

_{equilibration}

time one then can

_compress

the film towards a semidilute or dense

_layer.

Of _{course, there} one

ltas to take care not to

_get

double or multi

_layers.

Considering

these

_{developments,}

we think that it is

_very

desirable to have a better

under-standing

of such

_systems.

Thus we

_performed

an extensive numerical

_study

of a 2-d

_many-chain

system.

To do this we made use of a

_{recently developed}

Monte Carlo

_algorithm

_{[8, 15].}

This bond fluctuation method was used to

_analyse

the

_properties

of an isolated 2-d chain. The way the

moves are constructed also allows to

_study

the

_dynamics

of 2-d

_polymers

_[15].

We use this method

to

_study

_systems

with

_up

to 80 %

_density

and chain

_length

of

_up

to N = 100 monomers. A short

preliminary

account of this work is

_given

in reference

_[16].

Chapter

two

_gives

a short

_description

of the

_algorithm

and the

_systems

considered. Then we

describe in some detail the

_{équilibration}

_process.

_Chapter

three

_gives

our results for the

_statics,

while

_chapter

four

_gives

the

_{dynamics. Finally}

_chapter

five contains the conclusions and a short outlook.

2. Model and methods.

In order to

_investigate

the

_{dynamical properties}

of a 2-d

_polymer

_system

_by

mean of Monte

Carlo,

we have to assure that the

_{algorithm displays}

Rouse

_dynamics

for the non reversal random walk

_[8].

This random walk assures that consecutive monomers are not allowed to sit on

_top

of

each other. Besides this short _range

_{repulsion along}

the chains no additional interaction is taken into account. For such a

_system

one can use the

_complete

set of moves as for chains with full

ex-cluded volume. This then

_gives

a

_good

and

_dependable

check on the static and

_dynamic

_properties

of an

_algorithm.

For

_dynamic

Monte Carlo

_algorithms

the

_typical

_requirements

for the moves _are,

that

_they

create new bond vectors within the chain. Standard lattice methods for d = 2

only

cre-ate new bond vectors at the

ends,

which then diffuse into the chain. This enhances the relaxation times

_{artificially.}

To overcome this

_problem

the bond fluctuation method was introduced

_recently

[15].

It combines the

_advantage

of a lattice

simulation,

which means

_e.g.

fast

_algorithms

on both

scalar and vector

machines,

with continuum

_approaches,

so that new bond vectors are created in

successful moves.

_Figure

1 illustrates the method. Each monomer

_occupies

four lattice sites. The bond

_{length 1}

is restricted to be

₁

_13.

In

addition,

a lattice site can never be

_occupied

_by

more

than

one monomer. For a move, a monomer is selected at

_random,

then it

_jumps

at random

_by

one

lattice distance into one of the four lattice directions. If the new

_position

_complies

with

_both,

the bond

_length

restriction and the excluded volume

restriction,

the move is

_accepted

and otherwise

Fig.

1. - Illustration of the bond fluctuation method. Ibe

typical

moves are indicated.

Note that the initial state must not contain crossed bonds. Since the bond

_length

constraint is

set to

_prevent

_crossing

of bonds such a

_{configuration}

would be

_preserved

forever. For dense

sys-tems the first blocked

_{configuration,}

which is a situation the

_system

cannot reach or

_leave,

occurs

at

_{density exceeding}

80% for infinite chains. Since this

_{configuration}

is

_ordered,

its

_probability

is

_{vanishing compared}

to the other random coil states.

in

the

_{subsequent investigation}

we

_only

use densities of

_up

to 80%. Since our chains are finite

_(N

₁₀₀₎

there will be no

_problem

of unresolvable blocked

_{configurations. (There}

is a _very small

_probability

that a random initial

configuration

of a chain is blocked

_by

itself. These

_{configurations}

have a local

_density

of one.

The initial conditions

_employed

in the

_present

work excluded such

_{configurations automatically).}

The simulations were

_performed

on a 100 x 100

_square

lattice with

_periodic

_boundary

condi-tions and densities with

_{20%, 40%, 60%,}

80% of the lattice sites

_,occupied.

We

_analysed

chains with

₂₀

N 100. The N = 100 and 80%

density

_system

then constains 20 chains. The

calculations were

_performed

on a

_Fujitsu

VP

100wector

_processor.

_typically

100

_{statistically}

in-dependent

systems

of

thé

same kind were simulated in

_parallel

The vectorization was set

in

a

way that one monomer in each

_system

was moved

_{simultaneously. By}

this

_approach,

even

_during

the standard simulations

_part,

we were able to vectorize the

_program

_efficiently

_[18].

lb start our

systems,

we filled the lattices with ordered

_arrays

of chains of

_length

N = 100 _monomers and

80%

_density.

The chains all had a U-like form and were

_pairwise

nested into each other.

Fig-ure 2a

_gives

a

_snapshot

_picture

of such a

_system

_shortly

after the simulation started. One

_easily

identifies from this the initial

_type

of

_{configuration. Figure}

2b

_gives

a

_{typical snapshot picture}

of an almost

_equilibrated

structure of the same

_sample.

The three different marked chains

_give

the

_typical

cases. 1Bvo chains have a

_fairly

smooth round

surface

while the third is still

_strongly

stretched. The stretched one

_(which

is the extreme of that

_sample)

_displays

a rather unfavourable

configuration indicating

that the

_system

is not

_yet

in

_complete

_{equilibrium. During}

the actual

918

Fig.

2. -

_(a)

_{Snapshot configuration}

of a p = 0.8,

N = 100 _system a short time after the initial state. The internested structure is

_{clearly displayed.}

_(b)

_Snapshot

_{configuration}

of the structure of

_figure

_2a,

where the

system

was almost

_{equilibrated.}

Fig.

3. -

Typical equilibrated

structures for

_a)

p =

0.2,

N

_{= 100;}

_b)

p =

_0.4,

_N = 20.

has the same

_amplitudes

while in the very

beginning they

were _very

_asymmetric

due to the initial condition. This

_provided

a sensitive test of

_{equilibration.}

The short

chain/low

_density

_systems

then were made from the N =

100,

_p = 0.80

sample

simply

_by

_cutting

bonds and

_eliminating

-

had started the

_systems

from scratch

_again.

The

_special

initial condition was used to make sure

that no

_memory

was

_{kept during}

our simulation and to check the

_proposed

_segregation

_[1].

The initial internested structure is

_specific

_enough

to follow its

_decay

in détail. After

_{equilibrating}

the

_systems

we followed the motion of the chains at least

_up

to a distance of their own diameter.

Considering

that we

_always

ran 100

_systems

in

_parallel

this

_gives

even for

_{the p}

=

0.80,

N = 100

system

20 x 100

_independent

diffusion

_paths,

which is

_enough

to

_provide

data of

_good

_accuracy.

Figure

3

_gives

two other

_typical

_{configurations}

at

_density

_p = 0.20 and _p = 0.40.

3. Static

_properties.

In

_polymeric

melts the excluded volume

effect,

which causes the

_expansion

of chains in

_good

solvent

_{[2, 19, 20],}

is

_expected

to be

_effectively

screened out

_by

the interaction

_among

the

differ-ent

_polymers.

This is known

_{theoretically}

to hold also for d = 2

[1, 2].

The

major

différence

between d = 2 and d _>

2,

however,

is

_that,

due to the

_topological

constraints in d =

2,

the chains cannot

_entangle.

If

_they

want to

_{interpenetrate,}

this

_only

is

_{possible by partial alignment}

of the chains. This

_certainly

causes a reduction of

_entropy.

The

_consequence

_is,

that the chains are

_going

to

_segregate.

One of the

_{interesting questions}

now

_is,

how

_strong

is the

_{segregation depending}

on

_chainlength

and concentration. The

_equilibrium

structure of chain is

_supposed

to be like a

Hamiltonian walk.

In order to

_investigate

the structure of such a

_polymer

_melt,

we first check the mean

_squared

end to end distance

_R2(N)

> and the radius of

_gyration

_{R 2 (N)}

> . With rcm

being

the center of mass of a

_polymer

and ri the

position

vector of the i-th monomer

_they

are

_{given by}

Table 1

_gives

the results for the various densities and chain

_lengths

_considered,

while

_figure

4 shows the data for _p = 0.40 and

p = 0.80 for several chain

_lengths.

For ideal chains _one

_expects

làble I. -

values for

RG

> and

R2

>

_for

the various cases considered. The error bars

_{given for}

R2

> are estimated

_from

the

_fluctuation

between the 100

_{statistically independent}

_systems,

which

920

Fig.

4. -

Log-plot

of

R2

> and

_RG

> vs. N for p = 0.80

_(a)

and _p = 0.40

_(b).

The indicated

_slopes

of 2v =1 show that the

_expected

behavior is reached

_{quite clearly.}

R2

>

_/

4

> = 6 and

R2

_>

o:N211, V

=

1/2

[2, 20].

As can be seen from the

data,

for N = 100

_compared

to the

_expected

ratio

R 2>

is about 10% too small.

Sjrnilar

but

_stronger

effects were also found in

_[10].

This

_certainly

is a

_consequence

of the fact that the chains rather

_homogenously

fill a little

_fluctuating

disk,

while the random walk is a fractal

object displaying

self

_similarity

_[2].

The

_expected

_power

law with v =

1/2,

_however,

is fulfilled

very

well. From

scaling

for d = 2 _one would

_expect

R2(N)

>1/2=

Nvf

(N/p-2)

_(here

v =

3/4

the

_single

isolated chain value

_[2]

has to be

_{used). làldng}

the data from table 1 we find that the data for

_{f (x)}

_reasonably

well

_collapse

on a

_single

curve

_(besides

N =

20, 25),

however,

the

_slope

is not the

_expected

one. Ideal

_{scaling gives}

a

_slope

_{of -1/2}

for

_{f (x)}

in a

_{log log}

_plot,

while here the

_slope

is too

_large.

This can be

_explained

_by

the

_following:

_Scaling

is

_only

valid for the limits

x =

N / p-2 ’"

_const but N --+ _{oo, p -} 0. Hère we

_certainly

are out of this

_regime.

Similar effects

were also seen for d = 3

[21].

There is another

_interesting

_aspect

about how dense the

_systems

really

are. For

_regions

where the chains

_already

interact it makes sense to write

where all the excluded volume effects are taken into the variable

_{density dependent}

_persistence

length

_{p2 p (p)}

> 1/2 . Using (2)

we

_{get land}

_Ip

as function of

_density

as

_given

in table II. This decrease of

_lp

and

also £,

as also shown

_by

_figure

5,

_certainly

is an effect of

_{high density. Up}

to

7àble II. - Persistence

length

and mean bond

_{Iength for}

various

_{densities following}

the

_{definition of}

equation

(2).

For _p = 0

equation

(2)

requires

_Ip

= 00 since there the

_exponent

is v

_{= 3 /4}

instead

_of

1/2,

as is described

_by

the above-mentioned

_{scaling function.}

"

Fig.

5. -

(a)

Plot of the

_{persistence length}

_lp

vs.

_density

_p due to

_{equation (2). (b)}

Plot of the mean bond

length Î

vs.

_density

v.

This leads us back to the above discussion of the

_scaling

of

_{R2 ( N )}

> and

_{lîâ (N)}

> .

_Scaling

assumes that the internal structure of the chains do not

_change.

From the

data, however,

we see

that not

_only

the

_{persistence length}

varies with

_density,

but also the

_average

bond

_length

itself. The

_compression

of the chains is so

_strong,

that there is no

_space

for a

_selfavoiding

walk like

_blob,

which is

_required

for the

_validity

of

_{density scaling.}

Indeed,

if we normalize

R2

> not

_only

_by

N2"

but also

_by

£2

> at least for N = 100 between

p =

40%

and

p =

80%

the

expected slope

922

chains and the Rouse modes.

First,

we turn to the static

_scattering

function of the individual chain

where the

_{index 1 k}

_denotes

the

_spherical

_average over the orientation of k.

_Following

the standard

scaling

theories

_S(k)

should,

for d = 2 and v

= 4

for the isolated chain

[2], display

the fractal

scattering

law

here e

is the

_{typical screening length}

on which the chain still is

_expanded.

From

_{scaling e}

-vl(l-vd) _ -3/2 ,

however as one could see from the data of

R2

>,

R 2

> this

_screening

length

does not follow that

_power

law for the

_high

densities

_investigated

hère. Thus we

_hardly

can

_expect

the occurrence of a

k -4/3

_regime

for the

_highest

densities considered.

_Figure

6a shows

S(k)

for N = 100 and _p = 0.20

leading

to 03BE ~

30.

Going

back to

_figure

5 this is a reasonable

number,

giving

n =

(l212p/E2) ~- 110

monomers

_per

_{screening·distance.}

It means

_{for p}

= 0.20

even the

_largest

chains considered

_just

interact with each other. This also

_explains,

_why

there is no distinct

k-2

_regime

for _p = 0.20 rather than the

typical overshooting

effect of the

single

chain. The

_{overshooting, coming}

from the

_fluctuating

ends was discussed

_earlier[15]

and can also be found for d = 3. For d =

3,

since the chain can

_penetrate

_through

itself this effect is much weaker. With

_{increasing density}

this effect is more and more reduced.

_{Simultaneously,}

even the onset of the

k-4/3

_region

_disappears,

_indicating

that e

is

_{significantly}

reduced to about one or two

bond

_lengths

for _p = 0.80. The

sequence

of

figures

6a-c

nicely displays

this. For p = 0.80 we

_give

a

_scaling

_plot

of

_S(k)

vs. k for various N with the normalization that

_S(k

=

0, N

=

100)

= 1.

The data

_{reasonably collapse}

onto a

_single

curve.

_However,

_following

the

_snapshot

_pictures

of the introduction this is somewhat

_surprising.

There the cliains seem to

_{homogeneously}

fill

disk-shaped regions.

Such

disks, however,

would

_display

the

_(d

=

2)

Porod

_scattering

of

S(k) -

k-3.

Obviously

the

_shape

fluctuations are still

_strong

_enough

to

_prevent

such a

_scattering

behavior. In order to see this we have to consider the overall structure of the

_system.

With R2

>~

R 2

>N N the

_average

_{density throughout}

the chains

_approaches

a constant

for distances

Ar »

_e.

Thus for d = 2 a

_given

chain

_only

_directly

can interact with a constant number of

_neighbors.

For a dense solution of disks

_typically

one

_would

_expect

6

_{neighbors giving}

a

triangular

lattice like short

_range

order. If we assume the chains to form

_{s herical objects}

of radius r with

homogeneous

density they

would cover a disk of radius r =

2 12 RG.

Using

this,

we can

estimate the

_space

which would be

_occupied

_by

such chains.

_’Paking

the data of table 1 the

_chains

typically

would need about 220% for

_(N

_{= 100,}

_p =

0.80)

_to 150% for

(N

=

20,

_p =

0.20)

of the

space

available.

However,

this is

simply

impossible.

Therefore,

there must be

_strong

fluctuations of the chain

_shape.

_typically

we find the chains to have between 5 and 7

_{neighbors averaging}

to

6. This leads to a characteristic

_packing

_pictured

in

_figure

_7,

as

_expected

_by

_figure

2.

_Although

their overall

_density

is

_relatively

constant there must be

_strong

_shape

fluctuations. For ideal

ran-dom walks one has

_(d

=

2)

For the radius of

_gyration

one

_typically

_gets

a fluctuation reduced

_by

a factor of two

_[22].

Here we

Fig.

6. -

(a,b,c) Scattering

function

_S(k)

of the individual chains for various densities and N = 100 _as

indicated in the

_figures.

The data are

_averaged

over

_randomly

taken orientations of the

_scattering

vector k.

(d)’Scaling

plot

S(k,

N)/

_(1002/N2)

vs. k for N =

_{25, 50,}

100 _and

924

Fig.

7. -

Illustration of the _average local

_packing

structure.

which is close to the ideal random walk value.

_Although

the chains are

_{densely packed,}

this

_suggest

that these fluctuations allow for a

_{relatively high mobility}

of the chains. As we shall

_explain

in the

next

_chapter

this is the case. These fluctuations which indicate that the chains almost look like ideal

_chains,

also

_propose

that it

_might

be useful to

_analyse

the Rouse normal modes of a random walk. For a discrete

_system

_they

are

_{given by}

_[23]

’Iÿpically,

this one dimensional Fourier transform

_along

the

_sequence

of the chain is done with

periodic

boundary

conditions,

_{corresponding}

to a

_cyclic

chain.

_{By subtracting}

the second term we

cut the

_ring.

Note that we

_only

can

_expect

the Rouse modes to be

_eigenmodes

for ideal chains. In

principle

this would mean that the monomers

_arbitrarily

can

_pass

_trhough

each other.

_However,

we find the Rouse modes are

_eigehmodes

of the chains. Within the error bars the cross correla-tions

_Xp(t)Xq(t)

_>p#q

are zero. Even the

_amplitudes

of the modes follow the

_prediction

of the Rouse model

As

_figure

8 shows

_they

follow a common curve for _p = 80 and

p = 0.40 for the various chain

lengths.

The

_{expected slope}

is

_reproduced

_very

well and

_only

for small

_n/p2

_{values and p} = 0.40

significant

deviations can be found which is consistent with the results of

_S(k).

_{Forp large}

the

length

scale is reduced to the

_region

where the

_{self-avoiding}

walk behavior starts to dominate. There deviations are

_expected

and were also

seen

for d = 3

[24].

This also shows that for

p = 0.80

already

N = 25 reaches the

_asymptotic

regime.

In addition the ratio of the

_amplitudes

for the

two densities

_pictured

is the same as for the

_squared

radii of

_gyration.

Similar to the fluctuation of the radius of

_gyration

we can calculate

6z: =

_z

_X4

> -

X2

> 2)1/2

_/

X2

> . Since

_Xp

p p p p

as

_large

as the one for

_RG.

This is

_essentially

similar to the end to end distance

R2

>. For all densities and chain

_lengths

and

_p-modes

which follow the

_N/p2

_power

of the

_amplitudes

we find

0.8 b.,

1.0 in _very

_good

_agreement

to the above line of

_arguments,

_{demonstrating}

the overall

consistency

of the

_picture.

Fig.

8. -

Scaling

of the mode

amplitudes

Xp (N,

p)

> vs.

N/p2

for _p =0.80

_{and p}

=0.40. The ratio of

the two sets of data _agree with the ratios of

R2

> and

R2

> as shown in table 1 for

N/p2 >

5. The

date

give

the average over the Cartesian coordinates. The absolute value is somewhat smaller than

_expected

from ideal chains.

4.

_Dynamics.

After

_finding

that the static

_properties

of dense

_polymers

_very well

_compare

to ideal

_chains,

it is

_{especially interesting}

to check the chain

_dynamics.

Since the chain cannot

_entangle,

the

rep-tation model

_certainly

is not an

_{appropriate description.}

On the other hand in order to move

around the chains as well as the monomers have to

_get

_along

each other. This

_puts

_strong

con-straints onto the motions of the individual monomers.

_However,

how does this affect the overall

dynamical

behavior?

To

_investigate

these

_questions,

we first

_analyse

the mean

_square

_displacement

of the individual

monomers and the diffusion constants of the individual chains.

Figure

9 shows the data of the diffusion constant D for _p = 0.40 and

p =

_0.80,

as

_given

in

ta-ble III.

_Following

the Rouse model we

_expect

D =

KBTIN(,

where

kBT

is the

_{temperature and (}

the bead friction. Since there 1 - o

_temperature

in our

_system

but

_only

the

_acceptance

rate, we can

926

Fig.

9. - Diffusion constant 4D = lim

g3(t)

vs. number of monomers N. t->oo

this later in the context of the modes. What is

_surprising

is that the diffusion constant seems to

display

a weaker

_N-dependence

than the Rouse model

_suggests.

_Any

crossover to

_{reptation-like}

behavior would cause the inverse

effect,

namely

an

_{increasingN-dependence. Certainly}

we would

need a more extensive

_analysis

of a

_larger

_system.

As is showm

later,

such an acceleration does

not show

_up

in the

_meansquare

_{displacements}

of the monomers. Thus since for this estimate of D

_large

time intervals were

_used,

_figure

9

_probably

shows a residue of the

_{equilibration.}

Thus

Table III. -

Diffusion

constants 4D

_for

various N and

_{density p}

= 0.4 and

we think that the data are consistent with D -

N-1.

_Figure

10

_gives

_examples

for the motion of individual monomers N = 50 and _p =

0.40,

0.80.For N = 100 the data show the same behavior.

Fig.

10. - Mean

square

displacement

gl(t)

and

_g2(t)

and the diffusion of the

center

of mass of the chain

g3(t)

for p

= 0.80

_(a)

and _p = 0.40

_(b)

and N = 50. The two sets of data for

_{Yl/ Y2}

_{give the}

results for middle

(lower data)

and end monomers

_(upper

_data).

The difference in the motion between inner and the outer

monomers decreases with

_increasing

_density.

What is

_especially

_striking

is that the difference between the mean

_square

_{displacements}

_{gl , 92} of

the total

_chain,

_{given by}

and

_{corresponding}

data of gl, 92 for individual inner monomers is much smaller than for d = 3. For d = 3 this effect is

quite

dramatic since this shifts this

visibility

of

reptation

in these

quatities

far

_beyond

the

_{entanglement length}

_[23-25].

_However,

similar to the chain confined to a

_straight

tube,

g2-for-inner

monomers saturates much earlier than the mean

_square

_displacement

_gl. Such

an effect was first observed for the chain in the

_straight

tube

_[26]

and seems to be

_typical

for such constrained

_geometries.

This

_certainly

must be an effect of the

_segregation

of the chains and the

confinement due to the

_{surrounding compared}

to the 3-d case. For both cases we find a nice

t112

behavior for _{gl, 92 up} to the

_longest

relaxation time of the chain. After that time the diffusion of the whole chain takes over. Table IV

_gives

a collection of relaxation times. So far all data seem to

reasonably

agree to the Rouse model. The most crucial test for the

_{dynamic properties}

is the

928

Thble IV. -

Relaxation times Tp

for the first

three

_{modes p for}

chains at densities

_of

_p = 0.4 and 0.8.

The error bar

of

the data is around 15% .

rates of the Rouse modes

_Xp

as well as the autocorrelation function of the radius of

_gyration

squared. Figure

11 shows the relaxation function

for N =

50,

_p = 0.40 as an

_example

for the first three modes.

_{They display}

a

_good

_single

exponen-tial behavior for

_longer

times,

which enables us to calculate the relaxation times which enables us

to calculate the relaxation times _{Tp .} For the Rouse model one

_expects

Figure

12

_gives

a

_{scaling plot}

of the relaxation times _7p from table IV.

_They

all follow the

_single

curves and

_roughly

follow a

_slope

of

_(N/p)2.

From these data as well as from the diffusion

con-stants D we

_directly

estimate the normalized bead friction

_{(IKBT. Using}

the data of table II for l and

_lp

and table III for D the two friction constants do not _{agree very} well. We find that the relaxation of the individual modes is

_considerably

slower than one would

_expect

from the diffu-sion. For d = 3 melts it was found

_[25]

that

_they

_agree

_very well.

_Taking

_e.g.

N =

_50,

p = 0.8

(here

the statistic is better than for N =

100)

the modes

_give

(IKBT

6.4 _x

102

while D

_gives

1.5 x

102,

_giving

a ratio of ~ 4.3. For _p

= 40%

this ratio is reduced to a value of less than 3. Thus with

_{increasing density}

this deviation increases as well.

However,

this reflects that the monomers

cannot

_{interpenetrate}

_freely,

as

_required

_by

the Rouse model.

_Thus,

_although

the Rouse modes

are

_eigenmodes

and ₉₁ does not show

_significant

deviations from

_Rouse,

the diffusion seems to be

governed by

shape

fluctuations,

which are faster

_by

a constant factor than the internal

reorgani-zation which would allow the Rouse modes to relax. Similar distinctions in time scale have been

proposed

for star

_polymers

_[29].

Finally,

let us check the overall relaxation of the radius of

_gyration.

The

autocorrélation

function shows a

_single

_exponential

_decay

similar to the modes. A more detailed

_inspection

shows that

rouphlv

In order to obtain the

_precise

N and p

_dependence

much more estensive simulations are needed.

The relaxation times are

_given

in table V. Since the fluctuation of

_RG

are the

_shape

fluctuations

Fig.

11. -

Examples

of a

_typical

mode relaxation

_plot

for N =

_{50, p}

= 0.4. The time is

_given

_{in Monte}

Carlo

_steps

_(mcs).

Fig.

12. - Relaxation

times of the first three Rouse modes vs.

N/p

for _p = 0.40 and _p = 0.80 and different

930

Thble V. - Longest

relaxation times

_of

the auto-correlalion

_function

R$(t)Rl(0)-(flÕ(0»)2

»

_/(

RG

>2 -

(Rô)2

_>)

_for

various

chain

_lengths

and densifies _p = 0.4 and

0.8. The

N2

_dependence

is

_{rougihlyfulfiued.}

The error bar

_of

the data is

_expected

to be between 10% and 15%.

Fig.

13. -

Acceptance

rate

_A(S)

of

_attempted

moves vs.

_density

_p. The insert

_gives

the normalized devia-tion of the

_acceptance

rate

_A(S)

with

_respect

to the

_acceptance

rate  =

A( p

=

0)

of an inner monomer of

a

_single

isolated chain.

mode.

_Using

_again

_{equation (11)}

with p = 1 shows that we arrive at a bead friction which is in

very

good

agreement

to the diffusion

data,

while the modes

_give

a different result. This rather

regular

behavior indicates that there are no

_precursors

of the

_glass

transition

_yet

in

_agreement

to the mode

_analysis.

The

_density

_dependence

is

_directly

seen also from the

_acceptance

rate of the moves. For lattice

_gases

it is known that due to

_back/hopping

corrélations the

_acceptance

rate

_decays

slower than the increase of relaxation times

_suggest

_[27].

_Figure

13 shows the relative

power

law with

density

as for

_THe;

_indicating

that back

_hopping

_only

enters in the

_prefactor

and is dominated

_by

the intrachain correlation of monomers

_{nearby along}

the chemical

_sequence

of the

polymers.

5. Conclusion.

We

_presented

a detailed

_study

of the

_properties

of a melt of two-dimensional

_polymer

chains.

By

the use of the bond fluctuation method we were able to

_study

both static and

_{dynamic properties}

of the chains.

For statics we found that the

_chains,

_{although they}

cannot cross each

_other,

_display

_typical

random walk behavior for

_{many uantities}

like

R2

>,

RG

>,

_{S( k)}

and the Rouse modes. As function of

_density

the

_decay

of

_{R ,}

_Rb

shows that we are

_explonng

the hmit of

_high

_density

melts. The chains

_segregate

_comptetety

and the ends seem

_only

to ftuctuate on small scales. Nevertheless the overall

_shape

fluctuations turn out to be sufficient to result in a

_scattering

law

_{S(k) -V k2}

instead of the Porod

_scattering.

The

_amplitude

of these

_shape

fluctuations is of the same order as for

ordinary

random walks. For the lowest

_density

considered we

_nicely

find the inner

k-4/3

_regime

for short internai distances. This is

_important

with

_respect

to recent ideas of the

_e-collapse

transition of

_{polymers [28].}

_Considering

the

_present

result for these

_concepts

the disorder of the defects in the

lattice,

althougt they

are

_annealed,

is crucial. Otherwise the

_scattering

function of

our

_systems

would show a

_very

different behavior.

_Although

the overall

_properties

of the chains

are the same as for ideal Gaussian chains there are some distinct differences with

_respect

to the inner structure, such as the uniform

_density

in the chains or

_probability

of monomers

_approaching

each other. The latter

_quantities

have been calculated

_[1]

and a future

_{investigation}

should be able

to check this.

The most

_unexpected

results were found for the

_dynamical

_properties.

The Rouse model does not consider

_any

other interaction betweeen the monomers than the chain

_{connectivity.}

Consid-ering

that this

_requires

monomers

_crossing

each other

_freely,

we found it rather

_surprising

that the

2-melt almost

_perfectly

_reproduces

the Rouse model. There is no

_sign

of decrease of

_mobility

due

to

_topological

constraints. Ibe

_only,,

but

_significant

deviation is

_given

in the time scales.

_Although

the mode relaxation as well as the diffusion

_give

the same N

_dependence

of the relaxation

time,

there is a difference in the

_prefactor

of about 4

_{for p}

= 0.8. It shows that diffusion via

_shape

fluc-tuations is faster than internal structure relaxation. This

_suggests

that the

_similarity

to the Rouse model is rather accidental since the 2-d

_exponents

for the dense

_system

and the related

_quantities

exhibit the same

_power

law as the

_ordinary

random walks. We therefore think that it is

_especially

interesting

to

_investigate

the chain

_dynamics

of a

_collapsed

3-d chain. _{There many}

_interesting

de-viations

_might

_occur, while for the

_single

_collapsed

2-d chain we do not

_expect

different behavior

compared

to our

_present

_findings.

Acknowledgements.

932

References

[1]

DUPLANTIER

B.,

SALEUR

_H.,

NucL

_Phys.

B290

₍₁₉₈₇₎

291 and references

therein ;

DUPLANTIER

B.,

J.

Phys

A19

₍₁₉₈₆₎

11009.

[2]

de GENNES

_P.G.,Scaling

_Concepts

in

_Polymer

_{Physics, (Cornell}

Univ.

_{Press, Ithaca,}

_N.Y.)

1979.

[3]

NIENHUIS

B.,

Phys.

Rev Lett. 49

₍₁₉₈₂₎

1062.

[4]

DOI

_M.,

EDWARDS

S.F.,

The

_Theory

of

_{polymer Dynamics (Clarendon}

_Press,

_Oxford)

1986.

[5]

MANSFIELD

_M.,

J. Chem.

_Phys.

77

₍₁₉₈₂₎

1554.

[6]

TUTHILL

_G.F.,

J. Chem.

_Phys.

90

₍₁₉₈₉₎

5869.

[7]

REITER

J.,

ZIFFERE

_G.,

OLAJ

_O.F.,

_{preprint (1989).}

[8]

For a

_general

overview about lattice simulations methods for _poymers see KREMER

_K.,

BINDER

_K.,

Comp.

Phys. Rept.

7

₍₁₉₈₈₎

259.

[9]

WALL

_F.T.,

CHIN

_J.C.,

J. Chem.

_Phys.

66

₍₁₉₇₇₎

_3143;

WALL

F.T.,

SEITZ

W.A.,

J. Chem.

_Phys.

67

₍₁₉₇₇₎

3722.

[10]

BAUMGARTNER _A.,

_Polymer

23

₍₁₉₈₂₎

334.

[11]

BISHOP

M.,

CEPERLEY

_D.,

FRISCH

H.L.,

KALOS

_{M.H., J.}

Chem

_Phys.

75

₍₁₉₈₃₎

5583.

[12]

MUTHUKUMAR M. J Chem.

_Phys.

82

₍₁₉₈₅₎

5696.

[13]

GRANICK

S.,

private

communication.

[14]

Such a method is the standard method to measure the 2-d

_exponents.

see _e.g. VILANOVE

_R.,

POUPINET

D.,

RONDELEZ

_F.,

Macromolecules 21

₍₁₉₈₈₎

2880.

[15]

CARMESIN

I.,

KREMER

_K.,

Macromolecules 21

₍₁₉₈₈₎

2819.

[16]

CARMESIN

I.,

KREMER

_K.,

in

_proceedings

of ILL

_Workshop

on

_{Polymer Dynamics,}

Proc. in

_Physics,

Eds. D.

_Richter,

T.

_Springer

_{(Springer Heidelberg)}

1988.

[17]

for a detailed discussion of such

_{ergodicity problems}

see also: MADRAS

N.,

SOKAL

A.D., J.

Stat.

_Phys.

47

₍₁₉₈₇₎

573.

[18]

More than 90% of the code ran on the vector unit of the VP100. Besides this the VP100 does not

_give

further information

_regarding

the

_effectivity

of the vector unit

_being

used.

[19]

There is an extensive

_experimental

and numerical literature devoted to 3-d melts. For simulations see

references

_[8,25]

and K. Binder

_preprint

_(1989).

[20]

FLORY

P.J.,

Principle

of

_{Polymer Chemistry (Cornell}

Univ.

_{Press, Ithaca,}

_N.Y.)

1953.

[21]

See _e.g. KREMER

K.,

Macromolecules 16

₍₁₉₈₃₎

1632.

[22]

LYKLEMA J.W.,

KREMER

K., J.

Phys.

A19

₍₁₉₈₈₎

279.

[23]

KREMER

K.,

GREST

G.S.,

CARMESIN

I.,

Phys.

Rev. Lett. 61

₍₁₉₈₈₎

566.

[24]

DIAL

_M.,

CRABB

S.,

CRABB

_C.C.,

KOVAC

_J.,

Macromolecules 18

₍₁₉₈₅₎

2215.

[25]

KREMER

K.,

GREST

_G.S.,

_{preprint J.}

Chem.

_Phys.,

in _press

_(1990).

[26]

KREMER

_K.,

BINDER

_{K., J.}

Chem.

_Phys.

81

₍₁₉₈₄₎

6381.

[27]

KEHR

_K.W,

BINDER

_K.,

_Application

of the Monte Carlo Methods in Stat.

_{Physics, Topics}

Current

_Phys.

36 and references

_therein,

Ed. K. Binder

_{(Springer Verlag, Heidelberg)}

1987.

[28]

DUPLANTlER

B.,

Phys.

Rev. A 38

₍₁₉₈₈₎

3647;

DUPLANTIER

B.,

SALEUR

H.,

Phys.

Rev. Lett. 59

₍₁₉₈₇₎

539.
