Relaxation of entangled polymers at the classical gel point

HAL Id: jpa-00212407

https://hal.archives-ouvertes.fr/jpa-00212407

Submitted on 1 Jan 1990

HAL is a multi-disciplinary open access

archive for the deposit and dissemination of

sci-entific research documents, whether they are

pub-lished or not. The documents may come from

teaching and research institutions in France or

abroad, or from public or private research centers.

L’archive ouverte pluridisciplinaire HAL, est

destinée au dépôt et à la diffusion de documents

scientifiques de niveau recherche, publiés ou non,

émanant des établissements d’enseignement et de

recherche français ou étrangers, des laboratoires

publics ou privés.

Relaxation of entangled polymers at the classical gel

point

M. Rubinstein, S. Zurek, T.C.B. Mcleish, R.C. Ball

To cite this version:

Relaxation of

_{entangled polymers}

at the

classical

_{gel point}

M. Rubinstein

_(1),

S. Zurek

_(*),

T. C. B. McLeish

_{(2, *)}

and R. C. Ball

₍₂₎

(1)

Corporate

Research Laboratories, Eastman Kodak

Company,

Rochester, NY 14650-2115,

U.S.A.

(2)

Cavendish

_{Laboratory, Madingley}

Road,

Cambridge,

CB3 _0HE, G.B.

(Reçu

le 6 novembre 1989,

accepté

le 18 décembre

₁₉₈₉₎

Résumé. 2014

Nous considérons la relaxation d’un

système

de chaînes enchevêtrées et

_pontées

au

voisinage

de la transition

_sol-gel,

dans le cadre de la théorie de

champ-moyen

(Flory

et

Stockmayer).

Le calcul utilise le modèle de « tube » des enchevêtrements

_{topologiques :}

la

contrainte diminue à cause de la fluctuation

_{hiérarchique}

des chaînes entre les ponts. Le _temps de relaxation est _{calculé par} une relation _ayant une solution

_analytique

au

_voisinage

de la transition. Une conclusion surprenante

s’impose :

tous les

_polymères

relaxent avant le _temps fini

T~

et donnent une courbe de relaxation

_G(t)

=

G0

03B3-2[a-1 ln (T~/t)]4,

où 03B1 dénombre les

enchevêtrements entre les _ponts, et 03B3 est une constante de l’ordre de l’unité. Pour des _temps

beaucoup plus

courts _que

_T~,

on retrouve une loi d’échelle faible. La relaxation

_rapide

des

polymères

les

_{plus grands}

_(qui

_{n’a pas de} sens

_physique)

est

_gênée

_par une transition vers la

statistique

de la

_percolation.

Les deux domaines sont

_séparés

_par un _temps de l’ordre de

T~.

Abstract. 2014

We examine the relaxation behaviour of an

_entangled

cross-linked

_{polymer gel}

as it

approaches

the

_{gel point}

in mean field

_{(Flory-Stockmayer)}

_percolation.

The calculation is based

on a tube model for the

_topological

interactions in which stress is lost via hierarchical fluctuation of the

_{primitive paths}

between cross-links. The

_decay

time of a _segment is calculated via a

recursion relation which has an

_analytic

solution near the

_{gel point.}

The

startling

conclusion is that all clusters relax in a finite time

_{T~ giving}

a relaxation modulus

_{G (t )}

=

Go

03B3-2[03B1-1 ln

(T~/t)]4,

where 03B1 counts the number of

_{entanglements}

between cross-links and 03B3 is a constant of order

unity.

For timescales much shorter than

_T~

_{this may resemble} a weak power law. The

unphysically rapid

relaxation of the

_largest

clusters is

_{prevented by}

a transition to

_percolation

statistics at

_long

_length

scales. The timescale

_separating

the two

_regimes

is close to

T~.

Classification

Physics

Abstracts 47.50 - 61.25 - 46.30

Introduction.

The

_{dynamical properties}

of

_{polymer gelation}

have

_enjoyed

considerable recent interest both

experimentally

and

_{theoretically}

_[1-7].

Near the

_gel

_point,

at which an infinite cluster first appears, static

properties

of the

_system

take on a

_scaling

form. The molecular

weight

(*)

Permanent address :

Dept.

of

_{Physics, University}

of Sheffield, Sheffield, S3 7RH, G.B.

distribution as

_specified

_by

the number

_density

of clusters of mass

_M,

n

(M),

is a

_power-law

[8-10] :

where

_f

is a cut-off

function,

constant for molecular

_weights

between

_M.,,

which is a low-mass

cut-off,

and

_Mchar’

The latter is the molecular

_weight

of the

_largest

cluster

_present

and

_diverges

at the

_{gel point :}

Here p

is the number

_density

of bonds in the

_system,

or an extent of

reaction,

and Pc is the critical

density

at

percolation.

The zero shear rate

_viscosity

_{qo and recoverable}

compliance

J2

diverge

at _{pc and the} zero shear rate modulus

_Go

_appears

_beyond

it :

The

_{frequency-dependent}

modulus also exhibits

_scaling

behaviour at the

_{gel point}

_{[3-7] :}

There is no direct way of

_determining

the

_dynamic

_{exponents s, t}

and u from the static ones

without further

_assumptions

about the nature of the

_dynamic

interaction

_[2,

_6,

_7].

One of the most

_important

_quantities

_affecting

the

_dynamics

of

_gelation

clusters is their

degree

of

_overlap.

Even without the

_complication

of

_topological

interactions between clusters the

_overlap

determines whether the

_hydrodynamic

interaction between monomers is screened or _{not ;} i.e. whether the

_dynamical

behaviour is Rouse-like or Zimm-like

_[10].

This is seen in solutions of linear

_polymers.

The motion of monomers on

_really

dilute chains is

_strongly

coupled

via the backflow of solvent to distant monomers on the same chain. When chains

begin

to

_overlap,

_however,

_hydrodynamic

contributions from other chains in the

neighbour-hood interfere and

_conspire

to screen the self interaction on

_length

scales

_longer

than the

correlation

_length

for

_density

fluctuations. This «

_{screening length}

» is therefore

dependent

on

concentration. It divides the

_dynamical

modes of a

_polymer

chain into those of

_{large length}

scales which see local friction

_(Rouse-like)

and those of

_{small length}

scales which are

non-local

_(Zimm-like).

Strong

overlap

will

_additionally

mean that

_{entanglements}

_may

_dominate,

_though

these

become

_important

at rather

_higher

concentrations than the onset of

_hydrodynamic

_screening.

This is seen in melts of linear chains where there is a critical molecular

_weight

(which

is

_usually

several

_thousand)

above which

_dynamical

behaviour

_diverges

from the

_{phantom-chain}

predictions. Entanglements

are also affected

_by

_{polydispersity}

so that in a melt of

_polymer

bimodally

distributed

_(say

that a few

_long

chains are

_present

in a bath of much shorter

_ones)

for

_example,

it is

_possible

for the

_long

chains to be

_effectively

_{unentangled (at}

timescales characteristic of their orientational relaxation

_{they only entangle}

with other

_long

_chains)

even

though

the short chains are well

_entangled.

The richness of this

_problem

has been

_investigated

by

Doi et al.

_[11].

For

_gelation

clusters we therefore

_expect

_{entanglements}

to be

_{important only}

when a

of the

_degree

of

_overlap

for a cluster of molecular

_weight

M was introduced

_by

Cates

_[12].

We count the number of

_pieces

of mass M from all

larger

clusters that sit within the volume

spanned by

a

_single

cluster of mass M. The radius of

_gyration

of a cluster scales as

R(M) ’" M1/df

where df

is the fractal dimension of the clusters. The

_degree

of

_overlap

4S (M)

[12]

is then

_{given by}

an

_integral

over the mass distribution

_larger

than M :

Here d the dimension of space. We notice that an entire distribution of clusters may exist at

marginal overlap

(e (M) - const. )

if the

_{exponents df and T obey}

the «

hyperscaling »

[8]

relation :

« Blobs » of mass M

just

_manage to _{fill space}

_{independently}

of the

_scale,

_M,

that we choose

-the

_system

is self-similar. This is satisfied

_by

3-dimensional

_percolation

clusters which have

d f ---

2.5 and T = 2.2

[1],

so are not

_{strongly overlapped.}

A more

_general

result due to Cates

[12]

is that branched

_polymers

with excluded volume which is screened at

_{large overlap}

will

obey

(1.6)

for a _{range of values of} T and

df.

This was used

_by

Rubinstein et al.

_[6]

to calculate the

_{dynamical scaling}

of

_{polymeric percolation}

clusters on the

_assumption

that

_marginal

overlap

was effective in

_{hydrodynamic screening}

but did not cause the clusters to

_entangle

strongly,

results which are confirmed

_{by experiment}

_[3,

_6,

_7].

Near the

_gel

_point

we find that the

_dynamic

modulus satisfies

_(1.4)

with u = 0.69

compared

with the theoretical value of 0.67.

A

_contrasting

case is found in the

_{cross-linking,}

or

_{vulcanisation,}

of dense

_polymer

chains when excluded volume is screened

_throughout

the distribution

_except

_{for the very}

_largest

clusters

_[13].

Now the classical

_theory

is valid and

_gives

the

_{exponents df}

= 4 and

T = 5/2. From

(1.5)

_{we see} that the the clusters _are

strongly overlapped

and that over some

range of timescales at

_least,

_{entangled dynamics}

must dominate. It becomes

_compelling

to ask what viscoelastic behaviour this new

_{assumption implies.}

The

_{viscoelasticity}

of

_entangled

linear

_polymers

is now understood

_using

the tube model of

topological

interactions

_[14]

and its extension to branched

_polymers

has been an active area of interest

_{recently. Applications}

have

_progressed

from treatments of star molecules

_[15]

without

accounting

for « constraint release » to models for more

_complex

molecules

_{[16, 17]}

which treat the

_topological

constraints

_{self-consistently}

_[18].

The main results for

_entangled

tree-like branched

_polymers

_(containing

no closed

_loops)

_{may be} summarised as follows :

1)

as for linear

_polymers,

stress

_(after

a

_step

strain)

comes from the

_anisotropy

of the

polymer

segments.

In fixed networks this is is

_proportional

to the fraction of

_originally

occupied

tube that has not been

_{passed by}

a free chain

end ;

2)

stress relaxes

_by

arm retraction. Most

segments

have an end whose chemical distance to the outside of the tree is shorter

_(by

the molecular

_weight

of the

_segment)

than the distance from the other end. The former fluctuates on a characteristic timescale _Tri in the

entropic

potential

for

_{path length}

that is

_{approximately quadratic}

about the mean

_length,

as for star

Fig.

1. - A

region

of the Bethe lattice on which we _{grow the clusters. Bond i has} a

_seniority

of 3, which

is the

_longest

chemical

_path

to the outside of the cluster of the tree shown in

_(b).

The other tree

_(c)

has a

longer

LCP of 4.

Here

_Mx

is the molecular

_weight

between the cross-links and

_Mei

is the

_entanglement

molecular

_{weight appropriate}

to the timescale at which the i-th

_segment

relaxes.

v is a constant of order one which may be calculated from the tube model’s

_prediction

for the

plateau

modulus of linear

_polymers

to be 15/8

_[11].

Those

_segments

whose ends share the

same chemical distance to the ouside of the tree are the last in their cluster to

relax,

and do so

by reptation

(see

later) ;

3)

relaxation is hierarchical. _{Ti +}

_{1 becomes}

the

_timestep

for the

_{path length}

fluctuations of the

_neigbouring

_segment

nearer in chemical distance to the centre of the tree ;

4)

the

_{large separation}

of timescales on which different

_parts

of a molecule relax means

that all relaxed

_segments

act as effective solvent for unrelaxed

_parts.

If

_Ci

is the concentration of unrelaxed

_segments

at the timescale on which

_segment

i relaxes then the effective dilution

means that the stress is

_proportional

to

C 2 rather

than

_{Ci [19].}

_{This may be} recast in terms of a

dynamic

value of the

_entanglement

molecular

_weight

when it becomes clear that the dilution has a

_dynamical

effect as

_well,

_accelerating

the relaxation of

_neighbouring

_segments

via

_(1.7

and

_1.8).

This acceleration can _{have very}

dramatic effects indeed even in the case of

_simple

star

_polymers

_[18].

_{In this paper} we

_apply

these ideas to

_{Flory-Stockmayer}

_gelation.

Statistics of

entangled paths

at

_gelation.

Consider a Bethe lattice with co-ordination number z

_(such

as shown in

_Fig.

la for

z =

3).

Each bond is

occupied

with

_probability

p and

empty

with

_{probability 1 - p}

independent

of any other bonds of the lattice. This defines the mean field

(Flory-Stockmayer)

percolation

model. It

_produces

an ensemble of branched

polymers

which may be embedded in

concentration is to be

_unity

as it must if we wish to model a

_melt).

We note that a certain

amount of linear

_polymer

is

_present

at _any

_stage

of reaction

_(or

_probability

_p).

In an accurate treatment this fraction must be handled

_separately

from the remainder because

_they

will relax their stress

_{by reptation}

rather than fluctuation.

However,

we

suspend

this consideration for

the moment

_(but

see the discussion

_below),

_{observing only}

that the fraction of linear chains becomes

_{exponentially}

small at

_high

molecular

_weight,

and consider the result of

_fluctuating

dynamics

alone on the model

_system.

We now define the

_concept

of

_seniority

of a bond. If the bond is

_empty,

we _{say that it has}

seniority

0. If it is

_occupied,

then it

_belongs

to a cluster - either finite

or infinite. Consider

bond i

_belonging

to a cluster as shown in

_figure

la. This bond divides the cluster into two trees with bond i as the trunk of each of them

(as

shown in

_Figs.lb

and

1c).

Let

m/l)

and

_mi(2)be

the

_longest

consecutive _sequence of

_occupied

bonds which we call the

_longest

chemical

_path

_(LCP)

in each of these trees

_(in

_Fig.

1

_mi(1)

= 3 and

mi(2)

=

4).

We say that bond

i is of

_seniority

This careful

_prescription

_{above is unnecessary when the}

_polymer

itself is a

_{regular Cayley}

tree

_[17]

_{in which every} branch

_{point i}

is connected to z - 1

_equivalent

branch

_points

with characteristic relaxation timescales _{Ti _} 1, and one with a timescale of Ti + 1. In a tree formed

by

random

_gelation,

_however,

the relaxation times of

_neighbouring

branch

_points

are

_typically

very different. To allow the branch

point

to _move, z - 1 arms must retrace

_completely

within their tubes

_{(Fig. 2),}

_{e.g. in the}

_Cayley

tree

_polymer

we

_require

consecutive

_complete

Fig.

2. - Branch

point

i is mobilised

_by

the

_sequential

retraction of z - 1 arms. In this case

fluctuation of z - 1 arms. In the case where the fluctuation rates of these arms are _very

different,

the

_waiting

time for the

_entanglement

loss of

_figure

2 is dominated

_by

the slowest of the arms

_(excepting

the arm that remains

unrelaxed).

This is

because,

_given

an event of

waiting

time T

the probability

of an

_{(uncorrelated)}

event of

_waiting

time _T2

_occurring

before another of the first kind is

p

(event

2 before event

_{1 ) =}

this tends to

_unity

when

_{Ti >}

r2 which must

_typically

be the case when the

_waiting

times are

exponentially

separated

as in

_(1.7).

Henceforth we assume that the relaxation of a bond is

dominated

_by

the

_neighbouring

tree with the fastest relaxation time. This will be the

_longest

of the relaxation times of the first

_hierarchy

of

_segments

in the tree. This

_segment

in turn will be dominated

_by

the relaxation of the faster of its two

_neighbouring

trees

_(the

slower

_begins

with the the first bond we

_considered)

and so on

_following

the LCP for bond i out to the

_edge

of the cluster. So the

_seniority

of a bond determines its

_dynamics.

The

_seniority

of a bond can

be infinite if it is

_part

of the backbone of the infinite cluster. Bonds of infinite

_seniority

do not relax

by

retraction. Bonds that are not in the backbone of the infinite cluster may relax

by

retraction when their turn comes. Perimeter bonds have

_seniority

one.

_They

are the first to relax in an

_entangled

melt of clusters. Their

_neighbours

which are not

_perimeter

bonds themselves have

_seniority

two and are next to relax after the

_perimeter

bonds,

and so on until either the backbone of the infinite cluster is reached or the

_topological

constraints become ineffective

_{(see below).}

We now need to _{calculate the concentration cm of bonds of}

_seniority

m. Let us first define

two

_{auxiliary quantities :}

_{qm is the}

_probability

that a

_randomly

chosen bond is the base of a

tree with the LCP

_equal

to m and

_Qm

is the

_probability

that a

_randomly

chosen bond is the

base of a tree with the LCP not

_larger

than m so

We can _{calculate qm}

_recursively

in terms of the

_Qm

_noting

that the chosen bond must be

occupied

(with

probability

p)

and that at least one of the z - 1 branches must have a LCP

equal

to m - 1

_(we

exclude the case where

_they

all have branches of LCP of m - 2 or

smaller) :

using

the fact _{that qm} =

Q m - Q m - 1.

These _recurrence relation

together

with the initial values

This

_probability

is nonzero

_only

above the

_percolation

threshold,

i.e.

_{for p}

_{> Pc where}

For

_large

m the finite difference

_{equation (2.4)}

can be

_{approximated by}

a nonlinear second order differential

_equation

in terms of a continuous function

_{Q (m ) :}

(From

henceforth we will use

_subscripted

variables to denote the

_quantities

with discrete

arguments

and standard functional notation to denote their continuous

_{approximants).}

As

m becomes

_large,

we can find the

_asymptotic

behaviour of

_Q(m)

_{by writing}

with

when to second order in

_Q(m),

Away

from the

_{gel point}

the first term dominates

_{giving exponential decay}

of

q(m) =

dQ /dm.

At the

_{gel point,}

however

_{(p = pc = 1 / (z - 1 »}

this

_leading

order term is

identically

zero and the next term becomes dominant. This has a

_power-law

solution and we

have to first order in

_{1 /m}

and for the

_leading

behaviour of

_q(m)

This can be checked

_against

exact evaluation of

_(2.4)

and

_(2.5).

We find that the error

becomes very small for values of m

larger

than

_10,

and that

_asymptotic

forms are reached sooner for

_large

values of

_{functionality}

z.

We are now in a

_position

to calculate the lattice concentration

_{cL (m )}

of bonds with

_seniority

m in the continuous

_{approximation.}

It is

_proportional

to the

_probability

that one of its two trees has the LCP

_equal

to m, while the other has a LCP

_equal

to or

_larger

than m. So the exact discrete result is

with the continuous

_{approximation :}

(once

in each

_tree).

The result

_gives

the lattice concentration of clusters. In the melt the total concentration

_{(volume fraction)}

of all clusters is

_{unity independent}

of the

_degree

of

percolation

so for the

_real-space

concentration we divide

_by

another factor

_{ofp(= l/(z -1)}

at

_{percolation).}

The

_leading

behaviour of

_{c (m )}

for

large m

is determined from

_{(2.11), (2.12)}

and

_(2.13)

to be

We now

_apply

this to the hierarchical relaxation of the ensemble of branched

_polymers

at the

gel point.

Relaxation

_dynamics.

The characteristic times for the relaxation of stress from bonds of

_seniority

m is

_given

now

quite directly by

(1.7)

and

_(1.8)

with the effective concentration C

_(m)

_{given by}

the fraction of bonds of

_seniority

_greater

than m :

and in the continuous

_{approximation,}

where this is a definition of the

_{0 (1)}

_prefactor

_{y (z).}

Between the two characteristic timescales

_{delimiting complete}

relaxation of one

_bond,

stress relaxation

_proceeds

in

_exactly

the same _way as for a

_single

star arm, and follows the function

_{g (t)}

calculated

_by

Pearson and Helfand

_[15].

The final

_expression

for the

_dynamic

_modulus,

where

_Go

is the

_{high-frequency}

plateau

modulus is

(Note

that this is the correct

_expression,

not the one

_{given by}

McLeish in

_[17],

which overcounts contributions from

_higher

_{generations).}

We need

_{only apply}

the

_dynamical

rules summarised in the first section to calculate the series of timescales Tm. We can extract the essential behaviour at the

_gel

_{point by taking}

the continuum limit of the discrete series

Tm

just

as we did for the statistics of bond

_seniority.

This was done for a melt of stars

_by

Ball and McLeish

_[16]

who showed that

_Me

needs to be allowed to _vary over the relaxation of the arms as the effective concentration

_changes.

In our case, we have

where

The

_{dynamical equation}

for T

(m )

can be

_thought

of as a series of _{activated processes in which} the rate

T - 1 (m + dm)

is

_{given by}

an

_attempt

_frequency

T - 1 (m)

and an

_entropic

barrier

energy dU =

kTvMx/Me(m)

dm

(this

is exact for dm =

1).

The

pre-exponential

factor

gives

only

small corrections to the

result,

as _{may be checked}

_by

_comparing

the

_analytic

solution of

(3.3b)

with evaluation of

_(3.3a).

We have to use the current effective value for

M,

at each level in the

_hierarchy

so that all relaxed bonds act as solvent for unrelaxed

_bonds,

while all unrelaxed bonds are effective in

_creating

the

_entanglement

network. This

_requires

the continuous differential

_equation

for

_{r (m)}

to be of the form of

_(3.3b)

rather than

d(log T) = d(U(m)/kT)

in which the function

_Me(m)

is differentiated. For

Flory-Stockmayer gelation

(3.3)

becomes

so that

Here a =

v M xl M eO

and we have

_arranged

the units of time so that

_{T (1 )}

= 1. The

«

accelerating »

effect of the

dynamic

dilution is very

_{strong :}

we recover a finite time T

(1 ) exp {a

_y

(z)}

in the limit m - oo which we call

_{T 00.}

This is

_{exponentially longer}

than the

time to relax the

_perimeter

_{bonds. We may} now calculate the relaxation modulus under the

assumption

that bonds of a

given seniority

relax

_{independently,}

but that the

_density

is

_high

enough

to

_permet

a well-defined

_pre-averaged

effective concentration :

This is a universal function of

_{a -1 log}

_{(T oo/t)}

_up to the

_{functionality-dependent prefactor,}

as

may be seen from

_(3.6).

Just as in the case of

_simple

stars, however for times shorter than

T 00

the

_exponential

term in

_(3.7)

becomes

_effectively

a

_step

function in m and the relaxation

modulus becomes from

_(3.1)

and

_{(3.6) :}

A

_graph

of

_{[G (t) ]1/4}

_{against log t will give straight}

line for timescales dominated

_by

entanglements.

For times t «

_{T 00}

the bracket in

_(3.8)

can be

_expanded

to

_give

a

_regime

over

which

_{G (t )}

has an

_{approximate power-law}

form t-" :

In const with

though

the full function

_{drops steeply}

_{away from any}

_{power-law approximation}

at times

AN EXACT RESULT. - We noted that the

asymptotic

forms for the concentrations

q (m )

and

_{c (m )}

become better

_{approximations}

at _{any finite} m as we increase the

functionality

z. It is therefore no small

_surprise

that

_the

final form for the relaxation modulus

(3.8)

becomes

exact for all

_integer

values of m in the case of z =

3,

the lowest

possible functionality,

provided

we choose a renormalised value for

_Too.

This is

_fairly

_{straightforward}

to

demonstrate,

and is a _{consequence of the}

_simple

form of the recursion relation

_(2.4)

in this

case. The derivation is

_given

in

_appendix

A. The distinction is that

_TOC)

is renormalised to

t (1) exp {3 a}

rather than

_{t (1) exp {16 a }.}

Such a

_change

is to be

_expected

from the observation that the

_asymptotic

calculation overestimates

_C(m)

for small values of

m

_{(Eq. (3.1)).}

An exact solution must

_produce

the faster relaxation that results from

_greater

dilution. The result for z = 3 is useful because it

gives

a bound on the renormalisation of

TOC)

(the

asymptotic

results become more accurate for

_large

_z)

and because it indicates that the form of the relaxation

_spectrum

at low

_seniority

is not

_{strongly dependent}

on

_{functionality}

at

experimentally

relevant values. The

_prediction

of a linear

_dependence

of

_{[G (t) ]1/4}

on

log

(t )

is not

_changed.

Discussion.

The model described above is

_idealised,

and

_requires

careful

_{qualification}

if it is to be

_applied

to

_experiment.

We saw earlier that there are still

_{approximations}

in our treatment _{which may} be

_important,

but even as it stands we know that at

_long

times our

_picture

of a

_highly

entangled

network must fail. We consider this

_regime

first.

TRANSITION AT LONG TIMES. - The existence of

a finite time for the relaxation of

indefinitely

large

finite clusters is

_unphysical,

and we

_expect

the model to break down at times

_(and

corresponding length

scales)

shorter than

_Too

There are a

_priori

two routes

_by

which the model may fail : on the one hand the

_assumption

of classical statistics for the static distribution of the clusters is wrong at

_{large length}

scales because clusters

_{with df}

= 4

eventually pack

in d = 3

[13] ;

on the other we know that

_dynamic

dilution

_eventually

renders the

_largest

clusters

_effectively

_dilute,

after which

_{unentangled dynamics}

are

_appropriate.

In

practice,

whichever

_transition,

_dynamic

or

_static,

occurs first will define the crossover to the

new

_regime.

First we consider

_possible

_dynamic

transitions. At the level of the small modifications

introduced

_by

the term in

_log

_(Mx/Me)

we must

_expect

a

_change

in behaviour when the

effective

_entanglement

molecular

_weight

reaches

_M,,

_[17].

This will occur at a

_high

_seniority

m,,

given by

giving

This cannot affect the main features of the

_entangled

relaxation,

however,

because

segments

there is no

_topological

constraint from the tube

_[22].

We arrive at a

_seniority

for the

_dynamic

transition

_Mdy.

_{given by}

This

_seniority

varies as the square of mx, so in the limit of

_increasing

distance between branch

points, entangled dynamics

may

persist

well

_beyond

_mx.

This

_{potential dynamic}

_{transition may} not be active if our model fails to

_obey

classical statistics at molecular

_{weights corresponding}

to smaller seniorities than

_mdyn.

We must check whether the static

_{configuration}

affects our

_assumptions

at an earlier level in the

_hierarchy.

At

large length

scales and cluster masses fluctuations in the number densities

destroy

the

applicability

of the mean-field

_results,

as

_pointed

out

_by

de Gennes

_[13].

_Beyond

this

_point

percolation

statistics

_hold,

which as we have seen leads to

_{only marginal overlap}

and

unentangled dynamics.

De Gennes casts the result in the form of an interval

_Op

around the

percolation

threshold inside which classical statistics break down and finds

where

_Mk

is the molecular

_weight

of a Kuhn

_length.

We _may use the

_relationship

between the

largest

mass of the distribution and crosslink

_{density Mchar -}

Mx(J1p /Pc)-l/u to

convert this into a critical cluster mass

_{Mstat -}

MX5/3 Mk 213

using

the classical value of u = 1/2.

Finally

_we

use the fact that bonds of

_{seniority m typically belong}

to a cluster of LCP - m and of mass

M - Mx m 2

(the

mass

_scaling

of clusters with

_{path length}

must be half the

_spatial

fractal dimension because the

_segments

are

Gaussian).

This

_produces

When

_Mx

becomes

_large,

this transition dominates because it

_gives

the smallest value for a

transition

_seniority.

In this case, the

dynamics

become « slaved » to the static distribution and must be

_unentangled

at times

_longer

than

_{T (mstat) (which}

can be calculated from

(3.6)).

Which

_type

of crossover wins in

_practice

_{may be affected}

_by

the rather different

_prefactors

to

Mx

in

_(4.3)

and

_(4.5).

The static transition dominates

_only

for

which may be

large

since

_polymer

chains are flexible well below the

entanglement

molecular

weight

in the melt.

However,

the differences of

_seniority

between these two

_possible

transitions

_(and

even the

seniority

mx)

are masked in an

_experiment

which measures relaxation as a function of time because all m » 1

_correspond

to times close to

_{T 00}

from

_(3.6).

The form of

_{G (t )}

observed is

expected

to follow

_(3.8)

for 0 t

_{T 00}

and then cross over to the

_{percolation power-law}

relaxation

_predicted

and observed

_by

Rubinstein et al.

_[6],

_{G(t) -- t-0.67.}

We

_present

a

calculation of

_{G (t )}

for a

_{well-entangled}

ensemble near the

_gel

_point

in

_{figure 3.}

This

illustrates three

_{regimes :}

the

entangled

for 0 t

_{T 00’}

the

_unentangled

for

_{T 00}

t

_{T max}

and the terminal

_regime

for t >

T max

where

T max

is the Rouse relaxation time of the

largest

Fig.

3. - The

_dynamic

modulus

_{G (t )}

of the

_entangled

ensemble

_just

below

_{gel point.}

The molecular

weight

between cross-links is such that

_{T 00}

_exp =

{60}.

The _{crossover to}

unentangled

dynamics

occurs

just

before

_{T 00 , Tmax, corresponding}

to the Rouse relaxation of the

_largest

cluster is

_{exp {70} .}

Also

shown

_superimposed

is the

_{resulting compliance}

_{J (t) (the}

_rising

_curve)

with a vertical shift factor to

allow use of the same axes.

FORM OF THE COMPLIANCE. - Because _{of the very}

_long

terminal times associated with

entangled

branched

_polymers,

_creep

_experiments

on the

_compliance

J(t)

will be more

accurate in

_assessing

the linear

_rheology

than constant-strain

_experiments

such as

_oscillatory

or

_{step-strain rheometry.}

The characteristic behaviour of the different relaxation

_regimes

discussed above is reflected in the

_compliance

_just

as

_strongly

as in the modulus. In the two

regimes

where

_{G (t )}

is

_{approximately}

a

_power-law

_{(0 - t T 00}

when

_{G(t) = t-4/ay,}

and t >

_{T 00}

when

_{G (t) = t - 0.67)}

_{J (t)}

also has a

_power-law

form. This may be seen from the

integral relationship

between

_{G (t )}

and

_{J (t) [20] :}

Taking Laplace

transforms and

_putting

_{G (t )}

=

Go t-U

gives

for 0 u 1 :

So we

_expect

to see

_{J(t )}

_following

the inverse power to

_{G (t ).}

Numerical evaluation of

J(t)

is

_superimposed

in

_{figure 3.}

Below the

_{gel point}

the

_viscosity

is finite

_(the

_largest

characteristic cluster has a terminal time of

_{T max}

of

_Fig.

₃₎

so that the eventual

_slope

of a

4/a y.

Between

_Too

and

_Tmax

the

_slope

is 0.67. The existence of these two

_regimes

of

entangled

and

_unentangled

relaxation divided

_by

a transition near

_{T 00}

is the main

experimental signature

that we

_predict.

EFFECT OF LINEAR AND LINEAR-LIKE SECTIONS. - The

_gelation

_process introduced in section 2 above does not _{exclude the presence of} a fraction of

purely

linear

polymer

at the

_gel

_point.

By

randomly occupying

bonds on the

_Cayley

tree we _may achieve linear sections

_by

_occupying

just

two of the z bonds at each node

_along

a

_simply

connected

_path

between nodes at which

only

one bond is

_occupied

(terminating

the

_chain).

Now when we

_embed

the ensemble into

real space, the fraction of

_segments

which

_belong

to linear chains will not relax their stress

_by

fluctuation,

but

_by

_reptation.

As the molecular

_weight

between cross-links

increases,

so does the ratio of the characteristic times for fluctuation and for

_reptation,

so for

_{well-entangled}

ensembles,

the main effect of these linear

_components

is to a

_provide

a _way to relax a fraction of the

_original

stress

_quickly,

and to renormalise the concentration for the branched

_polymers

whose relaxation follows the

_pattern

described

above,

but

_initially

diluted

_by

the fraction of linear material.

The fraction of linear material of molecular

_weight

_{kM. (consisting}

of k consecutive

_bonds)

we denote

_by

_{L (k, 0 ) (we}

_explain

the notation

_below)

The term _{in p} comes from the necessary

_occupied

_bonds,

in

_{1 - p}

from the

_unoccupied

ones

both

_along

the

_length

and at the ends of the

_chain,

and the term in

_{(z - 1 )}

is a combinatorial

factor

_arising

from the choice of

_paths

on the lattice. The total fraction of bonds in linear

material is

_given

_by

the sum of

_{L (k, 0)}

over k. This is

_dependent

of the

_{functionality}

z and is

_greatest

for small z. At the

gel

point

p = 1 / (z - 1 )

giving,

The total concentration of linear material is the ratio of this sum to the total fraction of

occupied

bonds

_(which

_{fill space in the}

_melt).

This is 1/2 for z = 3 _so at this

functionality

1/4 of

the total mass is in the form of linear chains and 1 -

_{[1 -}

_{(1/4 ) ]2}

= 7/16 of the total initial

stress is relaxed

_by

these linear

_segments.

The relaxation

_spectrum

of these

_reptating

chains will be

_{given by}

a sum over their

_exponential

molecular

_weight

distribution :

The

_reptation

time of k-chains is

_dependent

on their

_length

_cubed,

the well-known result from

linear melts

_[14],

but is also modified

_by

the effective concentration

C,

which is

_defined,

as for

It is clear that this dilution effect reduces the

_reptation

times

_by

9/16 over the

_reptation

régime.

The full relaxation modulus of

_{(4.11 )}

is

_complicated,

but its

_approximate

_{form may be} extracted

_by

_representing

the sum over molecular

_weights

as an

_integral

which is then evaluated

_by

_steepest

_descents,

_giving

a « stretched

_exponential

» :

After this extra short-time _{response, the} branched

_polymers

relax

_by

fluctuation.

_However,

polymers

which are not

_linear,

and

_begin

to relax their stress

_by

fluctuation,

may become

effectively

linear at

_long

times when

_only

_high

seniorities remain unrelaxed. An

_example

is shown in

_figure

_4,

which behaves as a diluted linear

_polymer

after bonds of

_seniority

1 have relaxed. The backbone bonds which have seniorities of two and three

_actually

relax via the

reptation

of the diluted backbone after

_{t (1 ),}

so

_giving

an error to the relaxation

_spectrum

calculated in section

_3,

which assumes that all relaxations

_proceed

via fluctuation. In

_general

we must calculate the number of

_objects

which become linear-like at some

_stage

of the

relaxation. We denote

_by

_{L (n, m )}

the lattice-concentration of

_objects

which

_beyond

a

seniority

m consist of

_just

a linear chain of n

_segments

_{(L (n, 0 )}

counts the

_simple

linear chains

as

above).

We

_find,

after a little

_thought,

that

The first term,

_{q;" + l’}

is the

_probability

that the two end bonds of the linear subsection are of

seniority

m + 1. Then we have the

_probability

that the

_{remaining n -}

2 bonds are

_occupied,

pn- 2multiplied

by

the number of _ways this can occur

_{(z -}

1 )n -1.

We

_multiply

this

_by

the

probability

that all

_{(z - 2) (n - 1)}

side branches have

_seniority

less than or

_equal

to

m,

QJ: - 2)(n -1).

We

should, however,

subtract the

_probability

that the linear subsection is

_part

of a

_longer

linear subsection that was able to

_reptate

at an earlier

_stage.

In this case

_just

one of

the z - 1 bonds at each end of the section must have

_seniority

m -

_giving

the factor

(z -

1)2 q 2,

and the

_remaining

z - 2 must all have seniorities less than m

_giving

the factor

Fig.

4. - The occurrence of linear-like sections at

_long

times. After bonds of

_seniority

one have _relaxed,

this cluster follows

_{reptative dynamics}

within the effective

_entanglement

network because no tree

Q2(,- 2

All n bonds of the subsection must be

_occupied

as

_before,

but now all the side branches must have seniorities

_strictly

less than m. This

_explains

the second term of

(4.14).

Beyond

seniority

m, these

_objects

relax

_{by reptation.}

We need an estimate of the error that

they

introduce into our calculation of the relaxation

_spectrum.

A

_good

measure of this is the

concentration

_{F (m )}

of

_segments

of nominal

_seniority

m that have their actual relaxation

speeded

up

by

belonging

to a backbone that becomes

_effectively

linear,

i. e. that relax

_by

reptation

at an earlier

_timestep.

We observe that

_{objects belonging}

to the fraction

L (n, m’ )

affect bonds with

_seniority

m such that m’ m m’ +

n /2.

The total fraction of

bonds of

_{seniority m}

affected is the sum over relevant linear-like

objects :

The case of z = 3 is

especially

instructive here because _we

_expect

it to

give

the

largest

effect of

linear-like sections

_(only

one _{side branch per node} need relax

_along

a

subsection),

and also

because it is

_possible

to calculate

_{F (m )}

_exactly

in terms of

_{C (m ) (see}

_appendix

_B).

We find that

which means that 1/4 of all relevant bonds are affected. This

_implies

an

_interesting

form of

dynamic

scale-invariance at the

_{gel point :}

the linear-like chains are

_significant

at all scales.

However,

the form of the relaxation modulus is still

_unchanged,

because the

_system

behaves

as if it were at the renormalised concentration

_{Ceff (m) = C (m) - F (m) = 3 C (m)14.}

Repeating

the calculation of

_appendix

A

_using

the effective concentrations

_yields

The

_only

difference

_is,

as before in the case of

_accounting

for

_{non-asymptotic}

_behaviour,

a

renormalisation of

_TOC)

which now has a value of

_t1

_exp

{9 a /4}.

A smaller size of error is

_expected

to arise from effective

_dangling

ends of

_{lengths longer}

than one

_segment.

_Imagine

the linear-like

object

of

_figure

4 connected to a

_large

cluster

_by

one of its ends. Its stress is still relaxed

_by

_fluctuation,

but now the

entropic potential

is that

for a

_dangling

arm four

_segments

_long

rather than one, and allows the intermediate bonds to relax faster than

_they

would in a

_strictly

consecutive

_hierarchy.

Such structures can blur the

time-orderedness of

_seniority,

but occur with a

_frequency

_given

_by

an

_expression

similar to

(4.14).

Moreover,

the

_{re-ordering only}

occurs within the hierarchies of the

_effectively

linear

dangling

end.

_{Large experimental}

deviations from the model

spectrum

are not

_expected

from this source.

AN ALTERNATIVE ENSEMBLE. - Instead of the mechanism of

_creating

clusters on a

_Cayley

tree and then

_embedding

_{in real space,} consider the

_following

_{procédure :}

We

_begin

with a

bath of

_monodisperse

linear flexible

_polymers

with reactive end _{groups of}

_{functionality}

z

_(that

_is,

with z - 1 spare

bonds).

We allow each end group to attach to z - 1 other chains

_(so

that its

_valancy

is

_saturated)

with

_probability

_{p, and} to be

_completely

unreacted with

probability

1 - p.

The reactions are

_independent

or

_mean-field,

and so lead to

Flory-Stockmayer

statistics,

when the chains start

_highly

_overlapped

_(loop

formation is

_suppressed).

If we consider the calculation of

_{probabilities}

of LCPs in trees

_starting

on a chosen

bond,

we

too,

except

that

_{q (0)}

now describes the fraction of linear sections in the final

_bath,

not the

empty

bonds on a

_Cayley

tree. Such a

_system

_{may arise}

_chemically,

and is a little « cleaner »

than the

_Cayley

tree model in that all

_long

linear chains are

_{suppressed, though}

we note that

long-time

linear-like material is still

_present.

BEHAVIOUR AWAY FROM GEL POINT.

_{- Finally}

we _may comment

_briefly

on the behaviour

away from the

gel point.

Below

_{gel point}

the terminal time

_Tmax

of the

_largest

_{cluster may be} less than

_{T 00}

_(rigorously

it must be less than T

(mstat)

_{in which} case there will be no

unentangled

regime

where the

_percolation

_{relaxation appears. The relaxation}

_spectrum

is cut off at

_Tmax.

Above the

_{gel point}

the situation is more

_complicated.

There is a finite fraction of

bonds which contribute to the backbone of infinite clusters. These never

_relax,

and

_give

rise to

a finite modulus. Their existence affects the relaxation of other bonds because now the

effective

_entanglement

molecular

_weight

does not

_diverge

but is bounded above

_by

the

entanglement

of the

_permanent

network. As we move above

_{gel point}

the

_permanent

network becomes denser. There will be a new contribution to the

_dynamic

modulus

_coming

from clusters

_dangling

from the infinite

backbone,

which have an

_exponential

distribution of

dangling

LCPs. The relaxation of such an ensemble was examined

_by

Curro and Pincus

_[21]

in the case of

_strictly

linear

_segments

and led to a

_power-law

stress

_decay.

We defer a detailed

calculation of this

_{complex regime}

to a further paper, but await

_experiments

on

_entangled

gelling

systems

with interest.

Appendix

A.

Here we derive the exact discrete form of the

_seniority

statistics and relaxation

_spectrum

for the case of z = 3. We _start with the recursion relation for the

Q., equation (2.4).

For

z = 3 this becomes

which we can use to _prove a result

_special

to this case for the summed

_quantities

Q,,,:

The result may be

proved by

induction as follows. First we observe that it is true for

m =

0,

for

Qo

= _qo = 1/2 and ql = 1/8. Now suppose it to be true for _a

general

m -

_1,

then

which

_completes

the

_proof.

We also have a relation between the lattice concentration of

seniorities cLm and the one-sided LCP

probabilities :

This is true for m > 0

_only.

For m = 0 _we have CU = 1/2.

The modulus

_depends

on the effective lattice concentration of unrelaxed

_segments

which,

as we saw

_above,

is the

_complement

of the sum of these cm. However

(A6)

makes the sum

very easy to

_do,

so

This can be

_directly

related to the time at which bonds of

_{seniority m relax tm}

via their recursion relation

_(we

are still not at the level of the

_{prefactor) :}

The factor of z - 1 accounts as before for the renormalisation of concentration when we

embed the

_Cayley

tree _{lattice into real space.}

_Finally

we _may sum this relation with

t1 = 1

to show that

_log

_{tm}

=

8 a [Qm - q0 - q1]

and _use

(A5)

_to relate the effective

concentration to the relaxation time :

So the form of the relaxation modulus derived from the

_asymptotic

results becomes exact in the case of z = 3

(for

the discrete _{sequence of}

times tm

with

integer

m),

but with a

renormalised value for

_Too

_{of tl}

_exp

_{(3 a ).}

Appendix

B.

In this

_appendix

we calculate the fraction of linear-like chains at each

_seniority

m,

which we must use in the double sum for

_{F (m ) :}

We may

perform

the sum over n

_using

the two standard results

The first term

_contributing

to

_F(m)

from

_(Bl)

_gives

on

_summing

over n :

using

(A5)

A similar summation can be

_performed

on the second term to

_give,

on

_combination,

The second sum starts from 1 rather than zero because the

_expression

for

_{L (n, 0 )}

does not contain the subtracted

_part

of

_{(B1) .}

Terms cancel between the two sums in

_pairs

_except

for the

largest

element in the first sum, so

which _{proves the result.}

Acknowledgments.

We thank M. E.

_Cates,

R.

_Colby

and L. Leibler for useful discussions. SZ and TCBM were

supported by

ICI

_plc.

References

[1]

STAUFFER D., CONIGLIO A. and ADAM M., Adv.

_Polym.

Sci. 44

₍₁₉₈₂₎

103.

[2]

CATES M. E., J.

_Phys.

France 46

₍₁₉₈₅₎

1059.

[3]

DURAND D. , DELSANTI M. , ADAM M. and LUCK J. M. ,

Europhys.

Lett. 3

(1987)

297.

[4]

DAOUD M., J.

_{Phys. A}

21

₍₁₉₈₈₎

L237.

[6]

RUBINSTEIN M., COLBY R. H. and GILLMOR J. R.,

Space-Time Organisation

in Macromolecular

Fluids, Eds. F.

_Tanaka,

T. Ohta and M. Doi

_{(Springer-Verlag, Berlin)}

_{1989 ;}

_Polymer

Preprints

30

₍₁₉₈₉₎

81.

[7]

MARTIN J. E., ADOLF D. and WILCOXON J. P.,

Phys.

Rev. Lett. 61

₍₁₉₈₈₎

2620.

[8]

STAUFFER D., Introduction to Percolation

_{Theory (Taylor}

and Francis,

London)

1985.

[9]

STOCKMAYER W. H., J. Chem.

_Phys.

11

₍₁₉₄₃₎

45.

[10]

FLORY P. J., J. Am. Chem. Soc. 63

₍₁₉₄₁₎

_3083,

3091, 3096.

[11]

DOI M., GRAESSLEY W. _W., HELFAND E. and PEARSON D. S., Macromolecules 20

₍₁₉₈₇₎

1900.

[12]

CATES M. E., J.

_Phys.

Lett. France 46

₍₁₉₈₅₎

L837.

[13]

DE GENNES P.

G.,

J.

_Phys.

Lett. France 38

₍₁₉₇₇₎

L355.

[14]

DOI M. and EDWARDS S. F. E., The

_Theory

of

_{Polymer Dynamics}

(Oxford

University

Press,

Oxford)

1986.

[15]

DE GENNES P.

G.,

J.

_Phys.

France 36

₍₁₉₇₅₎

_{1199 ;}

DOI M. and Kuzuu N., J.

_Polym.

Sci.

_Polym.

Lett. Edn.18

₍₁₉₈₀₎

775 ;

PEARSON D. S. and HELFAND E., Macromolecules 17

₍₁₉₈₄₎

888.

[16]

McLEISH T. C. B., Macromolecules 21

₍₁₉₈₈₎

1062.

[17]

McLEISH T. C. B.,

Europhys.

Lett. 6

₍₁₉₈₈₎

511.

[18]

BALL R. C. and MCLEISH T. C. B., Macromolecules 22

₍₁₉₈₉₎

1911.

[19]

MARRUCCI G., J.

_Polym.

Sci.

_{Polym. Phys.}

Edn. 23

₍₁₉₈₅₎

159.

[20]

FERRY J. D., Viscoelastic

_Properties

of

_Polymers

3rd edn.

_(Wiley,

New

_York)

1980.
