Optical and radiometric models of the NOMAD instrument part I: the UVIS channel

Ann C. Vandaele,

1,*

Yannick Willame,

1

Cédric Depiesse,

1

Ian R. Thomas,

1

Séverine Robert,

1

David Bolsée,

1

Manish R. Patel,

2,3

Jon P. Mason,

2

Mark Leese,

2

Stefan Lesschaeve,

4

Philippe Antoine,

5

Frank Daerden,

1

Sofie Delanoye,

1

Rachel Drummond,

1,6

Eddy Neefs,

1

Bojan Ristic,

1

José-Juan Lopez-Moreno,

7

Giancarlo Bellucci,

8

and the NOMAD Team

1Belgian Institute for Space Aeronomy (IASB-BIRA), 3 av Circulaire, 1180 Brussels, Belgium

2The Open University, Walton Hall, Milton Keynes, MK7 6AA, UK

3Space Science and Technology Department, STFC Rutherford Appleton Laboratory, Oxfordshire OX11 0QX, UK

4OIP, Westerring 21, 9700 Oudenaarde, Belgium

5LambdaX, Avenue Schuman 102, 1400 Nivelles, Belgium

6IndoSpace Ltd., 6 Nuneham Square, Abingdon,Oxon, OX14 1EH., UK

7Instituto de Astrofisica de Andalucia (IAA/CSIC), 18080 Granada, Spain

8Istituto di Astrofisica e Planetologia Spaziali (IAPS/INAF), 00133, Rome Italy

* a-c.vandaele@aeronomie.be

Abstract: The NOMAD instrument has been designed to best fulfil the science objectives of the ExoMars Trace Gas Orbiter mission that will be launched in 2016. The instrument is a combination of three channels that cover the UV, visible and IR spectral ranges and can perform solar occultation, nadir and limb observations. In this series of two papers, we present the optical models representing the three channels of the instrument and use them to determine signal to noise levels for different observation modes and Martian conditions. In this first part, we focus on the UVIS channel, which will sound the Martian atmosphere using nadir and solar occultation viewing modes, covering the 200-650nm spectral range. High SNR levels (>1000) can easily be reached for wavelengths higher than 300nm both in solar occultation and nadir modes when considering binning.

Below 300nm SNR are lower primarily because of the lower signal and the impact of atmospheric absorption.

©2015 Optical Society of America

OCIS codes: (010.0280) Remote sensing and sensors; (120.6085) Space instrumentation;

(120.6200) Spectrometers and spectroscopic instrumentation; (010.1280) Atmospheric composition; (010.5620) Radiative transfer.

References and links

1. A. C. Vandaele, E. Neefs, R. Drummond, I. Thomas, F. Daerden, J.-J. Lopez-Moreno, M. Patel, G. Bellucci, M.

Allen, F. Altieri, D. Bolsee, T. Clancy, E. Cloutis, S. Delanoye, C. Depiesse, E. Cloutis, A. Fedorova, V.

Formisano, B. Funke, D. Fussen, A. Geminale, J.-C. Gérard, M. Giuranna, N. Ignatiev, J. Kaminski, O.

Karatekin, F. Lefèvre, M. López-Puertas, M. López-Valverde, A. Mahieux, J. M. Connell, M. Mumma, L.

Neary, E. Renotte, B. Ristic, S. Robert, M. Smith, S. Trokhimovsky, G. Villanueva, J. Whiteway, V. Wilquet, and M. Wolff, and the NOMAD Team, “Science objectives and performances of NOMAD, a spectrometer suite for the ExoMars TGO mission,” Planet. Space Sci. in press.

2. E. Neefs, A. C. Vandaele, R. Drummond, I. R. Thomas, S. Berkenbosch, R. Clairquin, S. Delanoye, B. Ristic, J.

Maes, S. Bonnewijn, G. Pieck, E. Equeter, C. Depiesse, F. Daerden, E. V. Ransbeeck, D. Nevejans, J.

Rodriguez-Gómez, J.-J. López-Moreno, R. Sanz, R. Morales, G. P. Candini, M. C. Pastor-Morales, B. Aparicio Del Moral, J. M. Jeronimo-Zafra, J. M. Gómez-López, G. Alonso-Rodrigo, I. Pérez-Grande, J. Cubas, A. M.

Gomez-Sanjuan, F. Navarro-Medina, T. Thibert, M. R. Patel, G. Bellucci, L. De Vos, S. Lesschaeve, N. V.

Vooren, W. Moelans, L. Aballea, S. Glorieux, A. Baeke, D. Kendall, J. De Neef, A. Soenen, P. Y. Puech, J.

Ward, J. F. Jamoye, D. Diez, A. Vicario-Arroyo, and M. Jankowski, “NOMAD spectrometer on the ExoMars trace gas orbiter mission: part 1-design, manufacturing and testing of the infrared channels,” Appl. Opt. 54(28), 8494–8520 (2015).

3. M. R. Patel, A. C. Vandaele, E. Neefs, and the NOMAD Team are preparing a manuscript to be called “NOMAD spectrometer on the ExoMars trace gas orbiter mission: part 2—design, manufacturing and testing of the UVIS channel,”, Appl. Opt. (in preparation).

#249556 Received 9 Sep 2015; revised 29 Oct 2015; accepted 1 Nov 2015; published 9 Nov 2015

© 2015 OSA 16 Nov 2015 | Vol. 23, No. 23 | DOI:10.1364/OE.23.030028 | OPTICS EXPRESS 30028

(2)

4. V. Wilquet, R. Drummond, A. Mahieux, S. Robert, A. C. Vandaele, and J. L. Bertaux, “Optical extinction due to aerosols in the upper haze of Venus: Four years of SOIR/VEX observations from 2006 to 2010,” Icarus 217(2), 875–881 (2012).

5. V. Wilquet, A. Fedorova, D. Belyaev, M. Luginin, R. Drummond, A. Mahieux, S. Robert, A. C. Vandaele, F.

Montmessin, and J.-L. Bertaux, “SPICAV/SOIR mesospheric aerosols observations and characterization,”

Geophys. Res. Abstr. 16, 11491 (2014).

6. I.R. Thomas, A. C. Vandaele, S. Robert, E. Neefs, R. Drummond, F. Daerden, S. Delanoye, C. Depiesse, B.

Ristic, A. Mahieux, L. Neary, Y. Willame, V. Wilquet, L. Aballea, W. Moelans, L. De Vos, S. Lesschaeve, N.

Van Vooren, J. J. Lopez-Moreno, M. R. Patel, G. Bellucci, and the NOMAD Team, “Optical and radiometric models of the NOMAD instrument - Part II: The IR channels - SO and LNO,” Optics Express (submitted for publication).

7. D. Nevejans, E. Neefs, E. Van Ransbeeck, S. Berkenbosch, R. Clairquin, L. De Vos, W. Moelans, S. Glorieux, A. Baeke, O. Korablev, I. Vinogradov, Y. Kalinnikov, B. Bach, J. P. Dubois, and E. Villard, “Compact high- resolution space-borne echelle grating spectrometer with AOTF based on order sorting for the infrared domain from 2.2 to 4.3 micrometer,” Appl. Opt. 45, 5191–5206 (2006).

8. A. C. Vandaele, M. De Mazière, R. Drummond, A. Mahieux, E. Neefs, V. Wilquet, O. Korablev, A. Fedorova, D. Belyaev, F. Montmessin, and J. L. Bertaux, “Composition of the Venus mesosphere measured by SOIR on board Venus Express,” J. Geophys. Res. 113, E00B23 (2008).

9. A. C. Vandaele, M. Kruglanski, and M. De Mazière, “Modeling and retrieval of Atmospheric spectra using ASIMUT ” in Proc. of the First ‘Atmospheric Science Conference, 2006)

10. R. Drummond, A. C. Vandaele, F. Daerden, D. Fussen, A. Mahieux, L. Neary, E. Neefs, S. Robert, Y. Willame, and V. Wilquet, “Studying methane and other trace species in the Mars atmosphere using a SOIR instrument,”

Planet. Space Sci. 59(2-3), 292–298 (2011).

11. W. O. Gallery, F. X. Kneizys, and S. A. Clough, “Air mass computer program for atmospheric transmittance/radiance calculation: FSCATM,” ERP-828/AFGL-TR-83–0065 (Air Force, 1983).

12. M. I. Mishchenko and L. D. Travis, “Capabilities and limitations of a current Fortran implementation of the T- matrix method for randomly oriented, rotationally symmetric scatterers,” J. Quant. Spectrosc. Radiat. Transf.

60(3), 309–324 (1998).

13. R. J. D. Spurr, “VLIDORT: A linearized pseudo-spherical vector discrete ordinate radiative transfer code for forward model and retrieval studies in multilayer multiple scattering media,” J. Quant. Spectrosc. Radiat. Transf.

102(2), 316–342 (2006).

14. S. Kochenova, M. De Mazière, A. C. Vandaele, T. Kerzenmacher, V. Letocart, N. Kumps, and Y. Willame,

“ALVL 1.0: an advanced line-by-line radiative transfer model for the retrieval of atmospheric constituents from satellite and ground-based measurements,” in International Symposium “Atmospheric Radiation and Dynamics”, 2011)

15. D. Bolsée, “Métrologie de la Spectrophotométrie Solaire Absolue: Principes, Mise en œuvre et Résultats.

Instrument SOLSPEC à bord de la Station Spatiale Internationale,” (Univ. Brussels, 2012).

16. D. Bolsée, N. Pereira, G. Cessateur, D. Gillotay, W. Peetermans, A. Michel, A. Sela, C. Jacobs, T. Foujols, S.

Bekki, M. Marchand, A. Hauchecorne, M. Meftah, A. Irbah, and M. Hersé, “SOLAR/SOLSPEC mission on ISS:

in-flight performances for SSI measurements in the UV,” Astron. Astrophys. (in prep.).

17. F. Daerden, J. A. Whiteway, L. Neary, L. Komguem, M. T. Lemmon, N. G. Heavens, B. Cantor, E. Hébrard, and M. D. Smith, “A Solar Escalator on Mars: Self-Lifting of Dust Layers by Radiative Heating,” Geophys. Res.

Lett. 42(18), 7319–7326 (2015).

18. B. Hapke, “Bidirectional reflectance spectroscopy 7: The single particle phase function hockey stick relation,”

Icarus 221(2), 1079–1083 (2012).

19. M. J. Wolff, R. T. Clancy, J. D. Goguen, M. C. Malin, and B. A. Cantor, “Ultraviolet dust aerosol properties as observed by MARCI,” Icarus 208(1), 143–155 (2010).

20. M. G. Tomasko, L. Doose, M. Lemmon, P. H. Smith, and E. Wegryn, “Properties of dust in the Martian atmosphere from the Imager on Mars Pathfinder,” J. Geophys. Res. 104(E4), 8987–9008 (1999).

21. Y. Willame, A. C. Vandaele, C. Depiesse, D. Gillotay, S. Kochenova, and F. Montmessin, “Preliminary results of aerosols’ properties studied with EPF measurements from the SPICAM/UV instrument,” in 39th COSPAR Scientific Assembly, 2012)

22. Y. Willame, A. C. Vandaele, D. Gillotay, C. Depiesse, R. Drummond, and F. Montmessin, “Studying the Martian aerosols UV properties with SPICAM,” in EGU General Assembly 2010, 2010)

23. Y. Willame, “Aerosol and ozone retrieval in the Martian atmosphere using the SPICAM/UV instrument and preparation for future missions,” (Univ. Libre de Bruxelles, Brussels, Belgium, 2015).

24. M. E. Ockert-Bell, J. B. Bell JF 3rd, C. P. Pollack, McKay, and F. Forget, “Absorption and scattering properties of the Martian dust in the solar wavelengths,” J. Geophys. Res. 102(E4), 9039–9050 (1997).

1. Introduction

NOMAD (Nadir and Occultation for MArs Discovery) is one of four instruments on board the ExoMars Trace Gas Orbiter [1], scheduled for launch in January 2016 and to begin nominal science mission around Mars in late 2017. It consists of a suite of three high-resolution spectrometers [2, 3] – UVIS (Ultraviolet-Visible), SO (Solar Occultation) and LNO (Limb
