Enabling Testing of Large Scale Highly Configurable Systems with Search-based Software Engineering: the Case of Model-based Software Product Lines

(1)

PhD-FSTC-2015-17

The Faculty of Science, Technology and Communication

Dissertation

Defense held on the 27

th

_{May 2015 in Luxembourg}

to obtain the degree of

Docteur de l’Université du Luxembourg

en Informatique

by

Christopher Henard

Born on 8th_{June 1986 in Nancy (Lorraine, France)}

Enabling Testing of Large Scale

Highly Configurable Systems with

Search-based Software Engineering:

The Case of Model-based Software Product Lines

Dissertation Defense Committee

Dr-Ing. Yves Le Traon, Dissertation Supervisor

Professor, University of Luxembourg, Luxembourg

Dr. Lionel C. Briand, Chairman

Professor, University of Luxembourg, Luxembourg

Dr. Michail Papadakis, Vice Chairman

Research Associate, University of Luxembourg, Luxembourg

Dr. Myra B. Cohen

Associate Professor, University of Nebraska, Lincoln, NE, USA

Dr-Ing. Jean-Marc Jézéquel

(2)

(3)

Enabling testing of large scale highly configurable systems with search-based software engineering: the case of model-based software product lines Abstract

Complex situations formed by mixes of versatile environments, various user needs and time-to-market constraints led to the development of highly configurable systems. In line with the emergence of such systems, software development is increasingly moving from the production of a single, yet configurable software to the development of families of software products. Such families of related software are called Software Product Lines (SPLs), and they allow the automation of the configuration, deployment and management of tailored software products through the combination of software features. These features and the constraints defining their legal combinations are usually encoded in a feature model (FM), which is used to represent a SPL.

One main challenge with SPLs is testing them, a task which is even more difficult as the number of features proposed is important. Ideally, all the possible products that can be configured from a SPL should be tested. This, however, is unfeasible in practice since only 270 optional features allows configuring more products than the number of atoms in the universe. Considering that realistic SPLs involve thousands of features and that testing capabilities are limited by time and budget constraints, only a subset of all the configurable products can actually be tested, introducing the needs for strategies to test such SPLs.

To reduce the testing effort, techniques using combinatorial interaction testing (CIT) have been proposed and proven to be successful. However, they fail at scaling to large and heavily constrained SPLs. In addition, CIT is costly to apply due to the combinatorial explosion induced by calculating the feature combinations. Besides, existing approaches do not consider multiple and potentially conflicting testing objectives such as minimizing the number of configurations and their cost. In this respect, this dissertation introduces scalable techniques for both generating and prioritizing relevant SPL product configurations for CIT by using a similarity heuristic which avoids the combinatorial explosion. In a second step, methods for handling multiple testing objectives are presented.

The following part of this thesis focuses on the quality assessment of given product configurations prior to testing. The objective here is to evaluate how good is a given set of configurations according to different testing criteria, whatever the way these configurations have been selected. This situation arises when configurations that have to be tested are already available. Since testing these software products individually is a costly and time consuming task, methodologies to evaluate them prior testing are introduced, thus allowing to discard unnecessary ones and save testing sessions. In particular, an approach based on mutation of the SPL FM which can form viable and cheaper alternative to CIT is presented.

The next part of this dissertation investigates the reverse-engineering of a SPL and its FM from existing source code of software product variants. Since SPLs allows us to reduce development costs and quickly derive tailored products for specific market share, automated techniques to migrate similar product variants into a whole SPL are necessary. In particular, the challenge of reverse-engineering a SPL which is concordant with the underlying software products is tackled by a fully automated approach. In addition, since reverse-engineering approaches (whether manually or automatically performed) are inherently error-prone, a methodology for evaluating and fixing reverse-engineered SPL FM is presented.

(4)

(5)

Acknowledgements

This PhD is the result of a long process that began mid-October 2011 and whose outcome owes much to the support and help of a few people. It is a pleasure for me to express my gratitude to them. First of all, I am grateful to my supervisor, Yves Le Traon, for allowing me to perform this thesis after my graduation internship. He always trusted and supported me throughout these three and a half years. I would like particularly to thank him for having reassured and encouraged me to continue in the moments of doubts that I had, and for always emphasizing the bright side of things.

I am equally thankful to my daily supervisor, Mike Papadakis, for his patience, advice and flawless guidance. He pointed me in the right direction, showed me how to perform research, taught me how to write papers and how to conduct rigorous experiments. I am very happy about the friendship we have build up during the years.

Of all the people involved in my thesis, I am particularly grateful to Gilles Perrouin and Jacques Klein. They somehow initiated my work on the software product line subject and introduced me to all the related concepts. I had the chance to work with them and I really appreciate that they were always here to support me when I was down. I also would like to thank all the jury members for their interest in my research and for the time they invested in my dissertation.

I am thankful to Renaud Dechambre and Alain Barthelemy from CETREL for the time they found to collaborate with us. It was really useful and rewarding to me to be able to apply my research to a concrete industrial case.

I would like to express my warm thanks to the all group members of SERVAL for the plenty good coffee breaks and discussions we have had. I would like to extend my thanks to all my co-authors and to the people I have been in touch during my PhD and that I’m not explicitly citing.

Finally, and more personally, I would like to express my deepest heartfelt thanks to my family and my friends for their support, especially to my girlfriend Birsena for her love and support and to my mother who led a life of sacrifice to allow me to study in the best possible conditions.

Christopher Hénard

Luxembourg, Luxembourg, April 2015
