Fibers with Deformation-induced Damage
Ming Cheng, Weinong Chen
To cite this version:
Kevlar
Õ
KM2 Single Fibers with
Deformation-induced Damage
MINGCHENG
Med-Eng Systems Inc., 2400 St-Laurent Boulevard Ontario, Canada K1G 6C4
WEINONGCHEN*
AAE & MSE Schools, Purdue University, 315 N. Grant St. West Lafayette, IN 47907, USA
ABSTRACT: A phenomenological continuum model is adapted to describe the transverse mechanical behavior of KevlarÕ KM2 single fibers in compression.
This model could be used for numerical simulations of the mechanical behaviors of fabrics made of KevlarÕKM2 fibers. An equivalent fiber model is used to form the
phenomenological model in terms of nominal stress and nominal stretch ratio. This model includes the features of stress-softening and residual strain to account for the damage caused by transverse compression, making it more accurate to represent the fiber when the effects of physical crossover of warp and fill yarns are considered and multiple loadings are applied. It is demonstrated that this model provides a good agreement with experimental results on the transverse behavior of KevlarÕ KM2
single fibers in compression.
KEY WORDS: KevlarÕ KM2, stress-softening, residual strain, constitutive
behavior, phenomenological model.
INTRODUCTION
T
HE PROTECTION OFmilitary and law enforcement personnel from injury by high-velocity-object impact has created new challenges for funda-mental scientific research in the mechanical response of textile materials.International Journal ofDAMAGEMECHANICS, Vol. 15—April 2006 121
1056-7895/06/02 0121–12 $10.00/0 DOI: 10.1177/1056789506060733 ß 2006 SAGE Publications
Fabrics and flexible fibrous composites have been widely used in bulletproof vests and other body armor systems. Recent use of these materials in personnel protection applications creates an urgent need to develop a better scientific understanding of the mechanical response of these materials and the components made of these materials.
The earliest efforts in the attempt to predict ballistic impact effects on fabrics were those of Roylance (1973) on biaxial fabrics. Since then, many research efforts have focused on computational models to predict the resistance of fabrics to a high-velocity impact. For example, Taylor and Vinson (1990) proposed a ballistic fabric model that simulates the transverse impact by treating the fabric as a homogeneous, isotropic, and elastic plate, which deforms into the shape of a straight-sided conical shell. However, such simple isotropic material models preclude the possibility of accurate simulation.
Fabrics are composite materials that offer significant computational challenges. The stress–strain behavior of these materials is generally nonlinear as well as anisotropic. Since there are few experimental investigations on these materials, many models assume a simple linear stress–strain relationship (Parga-Landa and Hernandez-Olivares, 1995; Roylance et al., 1995). In order to improve model accuracy, Lim et al. (2003) employed a three-element spring-dashpot model to describe a rate-dependent nonlinear stress–strain behavior of Twaron fabric in their finite-element modeling study. They also accepted a failure criterion (Shim et al., 2001) that specifies the rate-dependent failure strain.
During impact, yarns and also fibers, are subjected to transverse compressive loading while they are being extended (tensile loading). Therefore, it is essential to obtain the tensile behaviors of the yarns with transverse compressive loading superimposed on them. However, few numerical models include the transverse behaviors of the fabric materials into account because of the lack of experimental investigations on this issue. Cunniff and Ting (1999) recognized this problem. They developed a numerical model to characterize the ballistic behavior of fabrics with warp and fill yarn elements modeled independently as elastic rod elements. Coupling between these elements was modeled with transverse spring elements corresponding to physical crossover. A nonlinear model with three empirical constants was used to describe the transverse behavior of the yarns.
transverse spring elements, experimental studies must be performed on the yarns, which are bundles of fibers. Contact between individual fibers inside the yarns can be quite complicated and the behaviors of single fibers must be investigated first. Cheng et al. (2004) performed a systematic experimental study of single KevlarÕ KM2 fibers. Their experimental results revealed that the transverse mechanical behavior of a single KevlarÕ KM2 fiber is nonlinear and exhibits strong stress-softening phenomenon, which indicates deformation-induced damage in the fiber. We repeated the experiment over ten times on specimens with nominally identical properties and initial states, prepared from fibers in the same general location of the same tow from the same lot. The results overlap, which indicates the repeatability of the observed phenomenon. In this article, a phenomenological model that accounts for the damage effects is introduced based on the experimental results of Cheng et al. (2004). Since rate dependence of the mechanical behavior of KevlarÕ KM2 single fiber has been reported insignificant (Cheng et al., 2004), this model takes no rate effects into consideration within the same strain-rate range as in the experiments.
PHENOMENOLOGICAL MODELING
To investigate the transverse mechanical properties of KevlarÕ KM2 fibers, Cheng et al. (2004) developed a new experimental device. Several series of periodic loading–unloading transverse compressive tests were carried out at room temperature to investigate the damage effects.
Experimental Results
The compressive load is sensed by a load cell, which is positioned under the supporting rod. The displacement is measured using a linear variable displacement transducer (LVDT). A vertical translational stage is used to facilitate the proper positioning and alignment of these components. The driving signal for the piezoelectric translator and data acquisition of load and displacement signals are controlled by a computer. This computer and the associated signal conditioners are not shown in Figure 1.
The specimens are 850 denier KevlarÕ KM2 fibers made by DuPont. The density of these fibers is 1440 kg/m3. The diameter (D) of the KevlarÕ KM2 fiber is determined using a scanning electronic microscope (SEM) and is 12 mm.
Figure 2 shows a typical load–deformation curve obtained from an experiment on a KevlarÕ KM2 fiber with cycling of displacement. The displacement profile is repeated linear ramps with identical peaks. The insert in Figure 2 is the time history of the displacement. In Figure 2, the ordinate is nominal compressive stress, which is defined as push load per unit of length in longitudinal direction divided by the diameter of the fiber. Abscissa is the displacement of the bottom surface of the push-rod normalized by the diameter of the fiber specimen. In this study, the normalized displacement is called nominal strain when its value at the initial point of the push-rod touching the fiber is subtracted from data, so that this value is zero at the beginning of loading. The term, nominal stretch ratio, is the nominal strain plus one.
Load cell
Translational stage
PZT LVDT
A A
A–A sectional view Push-rod
Support
Fiber specimen
1.6 mm
Φ3.40
A KevlarÕ KM2 fiber may be approximately considered linear elastic in its transverse direction at an infinitesimal deformation range. However, the overall behavior in a large deformation range is obviously nonlinear and nonelastic. As shown in Figure 2, the first loading path from its virgin state to a nominal stretch ratio of about 0.52 is nonlinear. An unloading from this nominal stretch ratio hardly recovers its full deformation, leaving a large residual strain of about 0.70 in terms of nominal stretch ratio. Observation with an optical microscope shows that the fiber retains its deformed shape even two months after it is transversely pressed. Once this fiber is loaded again, the second and later loading and unloading paths follow the first unloading path with some small deviation from it.
From the experimental results described above, it is clear that the first nominal compressive stress versus nominal stretch ratio curve in transverse direction is much different from those curves obtained from reloading the same specimen. The first loading and unloading cycle is the most energy-absorbing cycle, and causes larger residual strain upon unloading. The differences observed in the following loading and unloading paths are not significant compared to differences observed between the first cycle and
1.0 0.9 0.8 0.7 0.6 0.5 0 −200 −400 −600 −800 01 0 20 30 40 0 2 4 6
Nominal stress (MPa)
Nominal stretch ratio
Time (s) Displacement ( µ ) 1st loading 1st unloading & 2nd loading 2nd unloading & 3rd loading 3rd unloading
the following loading cycles if their maximum nominal stretch does not exceed the first one. In the case of compression, the maximum stretch means the minimum value of stretch ratio because compressive stress and strain are both negative. In order to reveal the mechanical behavior of later loading cycles when their maximum nominal stretches exceed the previous maxima, a series of experiments were conducted with sets of four cycles where the nominal stretch amplitude of each set of cycles gradually increases. The results of these successive loading cycles are shown in Figure 3 with an insert to describe the time history of loading cycles. In these experiments, each loading–unloading cycle with same amplitude consists of four subcycles of loading and unloading.
The results in Figure 3 show that large residual strain exists even at a small strain level after the first subcycle in the first cycle. The amplitude of the first four loading and unloading subcycles is 0.925 in terms of nominal stretch ratio. The observed transverse mechanical behavior for the cycles is very similar to those shown in Figure 2. After these initial four successive sub-cycles, the next loading cycle can be divided into two stages. The first stage, with nominal stretch less than previous maximum, which is 0.925 in terms of nominal stretch ratio, follows the fourth loading subcycle.
1.0 0.9 0.8 0.7 0.6 0.5 0.4 0.3 0 −500 −1000 −1500 −2000 0 100 200 300 400 500 600 0 2 4 6 8 10 12
Nominal stress (MPa)
Nominal stretch ratio
Displacement (
µ
)
Time (s)
However, once the first loading subcycle of the second loading cycle exceeds the previous maximum nominal stretch, it turns to a loading path that a virgin specimen is expected to follow. The fifth unloading path (unloading of first subcycle in the second cycle) leaves an even larger residual strain, causing large energy absorption. The later loading and unloading cycles follow the fifth unloading path until the ninth loading (first subcycle of the third loading cycle), which is another new loading with its maximum nominal stretch exceeding the previous maximum nominal stretch. This phenomenon is similar to the Mullins effect, which was found in many rubber materials (Mullins, 1969; Cheng and Chen, 2003). In the experimental results presented in this article, the degree of damage in specimen is exclusively determined by the maximum stretch the specimen experienced.
Pseudo-elastic Modeling
Some finite elemental analysis (FEA) software, such as ANSYSÕ6, have interface elements, which are based on the relative deformation of the top and bottom surfaces, offering a direct means to quantify through-thickness deformation of joints. It is therefore practical to use such solid continuum elements to effectively model the coupling between warp and fill yarn elements. A material model with stress-softening feature can readily be applied to this element.
Our purpose is to provide material properties for an interface element to represent the transverse coupling between warp and fill yarn elements. These material properties must be directly obtained from experimental results. Because of the circular cross-section of the fiber, it is impossible to obtain true material properties by performing transverse compressive tests. Stresses in the fiber are not uniformly distributed. However, in FEA simulations where the focus is on the fabric structural response instead of fiber behavior, we may represent a fiber’s cross-section with a diameter-by-diameter square. With this equivalent fiber specimen, the transverse loading can be considered uniaxial, provided the engineering stress and strain are replaced with the nominal stress and nominal strain defined earlier.
rubber materials. Another modeling theory incorporating the permanent strain set was published by Holzapfel et al. (1999). This model provides a sharp unloading path and large residual strain, which is the case for most biological soft tissues rather than particle-reinforced rubber materials. The unloading paths of most rubber materials are like softened versions of their loading paths, leaving a relatively small residual strain in comparison to biological soft tissues. Although Holzapfel’s modeling theory is not proper for the description of rubber behavior, it is good for the transverse behavior of the KevlarÕ KM2 fiber. In this study, we use this modeling theory to develop a phenomenological model for the experimental results. Since, the mechanical properties of a single KevlarÕ KM2 fiber has insignificant loading-rate effects (Cheng et al., 2004), loading-rate is not embedded into this model.
The stress–stretch behavior on the original loading path can be described using a strain-energy function in the conventional way for an incompressible hyperelastic material as follows,
13¼1@W
@1, 23¼2 @W
@2 ð1Þ
where i(i ¼ 1, 2, and 3) are the principal Cauchy stresses, i(i ¼ 1, 2, and 3)
are principal stretch ratios, and W is a strain-energy function. Since incompressibility requires J ¼ 123¼1, the strain-energy function, W, is a
function of 1and 2only. According to Holzapfel et al. (1999), the
strain-energy function, W, for hyperelastic materials can be modified by incor-porating into it three additional discontinuous variables i(i ¼ 1, 2, and 3)
that describe the internal damage state in the three principal directions and take the value of unity on the original loading path, with the form as
W ð 1, 2, 3, 1, 2, 3Þ ¼ ~W ð 1, 2, 3Þ þ ð 1, 2, 3, 1, 2, 3Þ p J ð 1Þ ð2Þ where ~W 1, 2, 3ð Þ is a strain-energy function characterizing the original loading path, which takes any standard form of the strain-energy function, such as the Neo-Hookean, Mooney-Rivlin, or Ogden forms and is a supplemental function describing the damage state in the material. A Lagrange multiplier p represents an arbitrary hydrostatic pressure. To represent the damage variables in terms of the principal stretch ratios, it is convenient to assume that
@
which results in the following Cauchy stress expressions for the problem of homogeneous biaxial strain.
¼t¼
@ ~W þ
@ ð4Þ
where tare nominal (or Biot) stresses with ¼ 1 and 2. In the derivation of
Equation (4), the stress 3 is set to be zero without loss of generality
(Dorfmann and Ogden, 2004).
Holzapfel et al. (1999) proposed a function for ,
¼X 3 i¼1 iii, maxþ ið Þ ð5Þ
where is a damage function and i, max are the three maximum principal
stretches the material experienced. From Equation (3), we obtain
0 i
ð Þ ¼ ii, max
ð6Þ
Assuming a linear function for the derivative of the damage function, 0
i
ð Þ ¼ ci ð7Þ
where c is a positive material constant to regulate the slope of the unloading path relative to the loading path. Therefore, we finally get the expressions for the damage variables:
i¼1
c ii, max
ð8Þ
Ogden’s form of strain-energy function is then employed.
~ W 1, 2, 3ð Þ ¼X 3 m¼1 m m m 1 þ m 2 þ m 3 3 ð9Þ
In the case of uniaxial loading, we use the following notation,
Therefore, we obtain the following stress-strain relationship for the uniaxial loading condition.
¼ t ¼X 3 i¼1 iii=2þ11=22 ð11Þ where 1¼ 1 cð maxÞ, 2¼ 1 c 1=2 1=2max ð12Þ
max represents the maximum stretch the specimen experienced.
In compression, it is the minimum value of the stretch ratio. RESULTS
With Equation (11), a loading and unloading cycle of a virgin specimen is used to identify material constants. The loading path is used to determine the six material constants associated with Ogden’s model of strain-energy function, while the unloading path is used for the determination of the material constant, c, associated with the damage function. Table 1 lists the material constant set, curve-fitted from this loading and unloading cycle from one experiment on a virgin specimen.
The material constants in Table 1 are based on nonlinear least-squares curve-fitting of only one loading and unloading cycle. With these constants in hand, it is possible to predict the transverse stress-stretch behavior (including the stress-softening effect) of the KevlarÕ KM2 fiber. Figure 4 presents predictions of successive loading cycles with step-increasing nominal stretch ratios as shown in Figure 3. The solid gray curves are experimental results, exactly the same as shown in Figure 2. The solid black curves are predictions of the model (Equation (11)) based on the material constants listed in Table 1. The differences between successive loading and unloading in a certain loading section are not considered. There are six steps with maximum stretch ratios of 0.925, 0.78, 0.66, 0.544, 0.424, and 0.29875. The predictions provide a good description of the experimental results.
CONCLUSIONS
from Cheng et al. (2004). The degree of damage is a function of previous maximum stretch the specimen experienced.
The model development employs a pseudo-elasticity theory (Holzapfel et al., 1999) as modeling frame to describe the stress-softening effects and residual strains. The Ogden’s form of strain-energy function is used to describe the original stress–stretch behavior of the KevlarÕ KM2 single fiber in transverse direction. This model exhibits good agreement with the experimental results over a wide range of nominal stretch ratios.
REFERENCES
Cheng, M. and Chen, W. (2003). Experimental Investigation of the Stress–Stretch Behavior of EPDM Rubber with Loading Rate Effects, International Journal of Solids and Structures, 40(18): 4749–4768. 1.0 0.9 0.8 0.7 0.6 0.5 0.4 0.3 0.2 0 −500 −1000 −1500 −2000 −2500
Nominal stress (MPa)
Nominal stretch ratio
Experimental Model predicted
Figure 4. Comparison between experimental results and model description.
Table 1. Material parameters
Index i 1 2 3
i 155.3 1352 1363
i 2.177 10.14 10.13
Cheng, M., Chen, W. and Weerasooriya, T. (2004). Experimental Investigation of the Transverse Mechanical Properties of a Single KevlarÕKM2 fiber, International Journal of
Solids and Structures, 41(22–23): 6215–6232.
Cunniff, P.M. and Ting, J. (1999). Development of a Numerical Model to Characterize the Ballistic Behavior of Fabrics, In: Proceedings of the 18th International Symposium on Ballistics, San Antonio, Texas, pp. 814–821.
Dorfmann, A. and Ogden, R.W. (2004). A Constitutive Model for the Mullins Effect with Permanent Set in Particle-reinforced Rubber, International Journal of Solids and Structures, 41(7): 1855–1878.
Holzapfel, G.A., Stadler, M. and Ogden, R.W. (1999). Aspects of Stress Softening in Filled Rubbers Incorporating Residual Strains, In: Dorfmann, A. and Muhr, A. (eds), Constitutive Models for Rubber, pp. 189–193.
Johnson, G.R., Beissel, S.R. and Cunniff, P.M. (1999). A Computational Model for Fabrics Subjected to Ballistic Impact, In: 18th International Symposium on Ballistics, San Antonio, TX, pp. 962–969.
Johnson, G.R., Beissel, S.R. and Cunniff, P.M. (2002). A Computational Approach for Composite Materials Subjected to Ballistic Impact, In: 2nd International Conference on Structural Stability and Dynamics, Singapore
Lim, C.T., Shim, V.P.W. and Ng, Y.H. (2003). Finite-element Modeling of the Ballistic Impact of Fabric Armor, International Journal of Impact Engineering, 28(1): 13–31.
Mullins, L. (1969). Softening of Rubber by Deformation, Rubber Chemistry and Technology, 42(3): 339–362.
Ogden, R.W. and Roxburgh, D.G. (1999). A Pseudo-elastic Model for the Mullins Effect in Filled Rubber, In: Proc. R. Soc. Lond, A 455: pp. 2861–2877.
Parga-Landa, B. and Hernandez-Olivares, F. (1995). An Analytical Model to Predict Impact Behavior of Soft Armour, International Journal of Impact Engineering, 16(3): 455–466. Roylance, D. (1973). Wave Propagation in a Viscoelastic Fiber Subjected to Transverse Impact,
ASME J. Appl. Mech., 40: 143–148.
Roylance, D., Hammas, P., Ting, J., Chi, H. and Scott, B. (1995). Numerical Modeling of Fabric Impact, In: High Strain Rate Effects on Polymer, Metal and Ceramic Matrix Composites and Other Advanced Materials, AD-Vol. 48, ASME, pp. 155–160.
Shim, V.P.W., Lim, C.T. and Foo, K.J. (2001). Dynamic Mechanical Properties of Fabric Armour, International Journal of Impact Engineering, 25(1): 1–15.
