JOURNAL DE PHYSIQUE

Colloque C2, suppliment au n02, Tome 45, fivrier 1984 page C2-37

AN EXPERIMENTAL TEST OF A ZAF CORRECTION PROGRAM FOR T I L T E D SPECIMENS AND ENERGY D I S P E R S I V E SPECTROMETRY

B. Lodding and L. Reimer

PhysikaZisches I n s t i t u t , Universitet Mtlnster, Domagkstrasze

75, 0-4400

Mnster,

F.R.G.

Rksum6 - On propose et teste une m6thode ZAF modifige dans la- quelle on &value le facteur R et la correction d'absorption pour le cas d'un objet incling.

Abstract - ^A ^modified ZAF correction program is proposed and tested which considers the R-factor and the absorption correction for tilted specimens.

In many scanning electron microscopes with a plane lower pole-piece of the probe-forming lens, the Si(Li) energy-dispersive x-ray detector works with a take-off direction normal to the electron beam and the specimen has to be tilted by an angle @ between electron beam and sur- face normal. The backscattering coefficient and the mean energy of backscattered electrons increase with increasing @ resulting in a de- creased production of characteristic x-ray quanta as compared to normal incidence. Otherwise, the absorption decreases with increasing @ due to the decrease of the absorption path length and the production of x-rays nearer to the specimen surface. This results in a maximum of recorded x-ray quanta at a tilt angle fl (Fig.1). This maximum will also be the optimum tilt for a quantita?I.ve x-ray microanalysis which, however, needs modifications in the backscatter and absorption correc- tion factors / I / .

The backscatter factor kR is defined as k R = l / ~ where R=(n-An)/n and n denotes the total intensity without backscatter correction and An the fraction not excited due to backscattering. The backscatter factor R can be measured with a special specimen /2/. A thin 1-2 pm foil with a hole of 50 pm is mounted on top of a bulk specimen (Fig.2). We measure either n =n- An or n2=n because the backscattered electrons are absor- bed in the foil and generate x-ray quanta. The recorded signal n2 has 1 to be corrected for the absorption of x-rays in the foil. Fig.3 shows experimental R(@) values for Cu Ka and different overvoltage ratios U.

The loss An of x-ray excitation can also be calculated from the energy distribution dq /dW of the backscattered electrons where W=EBSE/Eo :

Eo QK(E)

R = l - dE dW / / 7 ^dE .

I

c c

E denotes the ionisation energy of the corresponding shell. When cal- c81ating dn/dW by the Monte Carlo method / 3 / , R can be calculated by numerical integration. Experiments and calculations are plotted in Fi 4 and are compared with the correspondigg formula proposed by Love

147: Good agreement can be found for @ 5 45 .

The absorpti2n correction can be modified by substituting x ^cos @ or

x (1-0.5 sin @ ) for x /5/. If using the complete Philibert / 6 / formula,

the surface ionisation

@

can be considered which is normally neglected

Our experiments showed tRat @ ( @ )

a

sec fl. This results in a more rea-

sonable depth distribution function

@ ( p z )

of x-ray emission ( ~ i ~ . 5 ) .

However, the influence on the absorption correction factor f(x) will

Article published online by EDP Sciences and available at http://dx.doi.org/10.1051/jphyscol:1984209

(3)

C2-38 JOURNAL DE _PHYSIQUE

normally be small, so that the simple formula can be used for ~ 1 1 cm /g.

2

For testing the modifications, we measured the x-ray counts from alloys of known concentration and from the pure element standards over a large range of tilt and'azimuth angles of the surface normal. The concentra- tions were calculated from the k-ratios using a FRAME program with the modifications discussed above. Figure 6 shows typical examples for Cu-A1 and Cu-Au alloys. The measurements were done with different take- off directions of the Si(Li) detector (see insets in Fig.6). The con- centrations calculated with the modified A- and R-corrections agree with the real concentration over a large range of tilt angles when using the detector with a take-off angle of 45' relative to the elec- tron beam in a SEM with a conically-shaped pole-piece. However, agree- ment only exists in a range @=30°-60' when working with a take-off angle of $0' in a SEM with a glane lower pole-piece. The smallest error can be observed at @=45 which is identical with @ma for this geometry. The exact position of flm depends, however, on %he compo- sition of the specimen and on the gatio of backscatter and absorption corrections.

Fig.1 - X-ray intensity versus tilt Fig.2. Experiment for measuring R angle @.

Fig.3 - Experimental R-values of the backscatter correction of Al, Cu and Au as a function of specimen tilt @ for different overvoltage ratios U.

A l

10. ^10- Cu Au

U = ^U=

u

=

5 1 7

10 a

2 8

% .

¹⁴

3 8

21

05- 2 9

3 7

, m , 8 , . 0

(Y

0' 20' LO* 60' '

8'0'

'0 20° LOD 60° ' 80'

70'

^'^@^; ^' ^L^O^' ^60. ^80.

4- 6- @-

L

.

95.

LL

.

aS-

- r . . . . . . 0

(4)

i_ ^,

^,

^::: j

^, ^,

^,

, o M c . , exp.

0

1 2 3 4 5 6 1 2 3 L

u- u-

⁵ ⁶

0 M.C.

exp.

Fig.4 - Comparison of the depen- dence of R on overvoltage ratio U at tilt angles @=0, 45' and 60°,

(0)

Monte Carlo calculations

10) Experiments

Dashed curves: formula of Love et al. /4/.

a b

Fig.5 - Comparison of depth distribution of Cu Kaexcited by 20 keV electrons. a) Monte Carlo calculation, b) modified Phili ert formula:

@(pz)

=

c RW{exp(-apz sec @ ) - (I-Rosec @/Rm) exp(-a(l+

K ) p z

P sec @ ) I .

(5)

JOURNAL

DE PHYSIQUE

Au-La -line wt. %

c d

Fig.6 - Influence of tilt angle 0 on the x-ray analysis of Cu-41 (a,c) and Cu-Au (b,d) alloys for take-off angles of 90' (a,b) and 45 (c,d) of the Si(Li) detector. Dash-dotted curves: uncorrected ratio k=N/Ns

R N

=

counts from pure element standard). Dashed curve: concentrations cafculated with an unmodified FRAME program for normal incidence (@=O).

Full curves: concentrations by the program containing the tilt correc- tion.

Cu-G.lwt% A1

---
